Omega OCD7C User manual

Tumble Dryer
Read all instructions and explanations before use.
Follow the instructions carefully.
Keep the operation instructions handy for later use.
if the appliance is sold or passed on then ensure
that the new owner always receives these operation
instructions.
OWNER’S MANUAL
CAUTION: HOT SURFACE !
CAUTION: RISK OF FIRE !

1 2
CONTENTS SAFETY INSTRUCTIONS
Safety Instructons
SAFETY INSTRUCTIONS
Safety Instruc�ons ..................................................
INSTALLATION
Product Descrip�on ................................................
Installa�on ...........................................................
OPERATIONS
Quick Start .............................................................
Before Each Drying ..................................................
Control Panel ........................................................ .
Other Func�ons......................................................
Drying Programmes Table ........................................
MAINTENANCE
Cleaning And Care.................................................
Trouble Shoo�ng ....................................................
Technical Specifica�ons .........................................
2
7
7
9
10
12
14
17
19
20
22
!To prevent damage to your appliance and preven personal injury,
please read and follow the following safety information.
1.This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience or knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a person responsible
for their safety. Children should be supervised to ensure that they do not
play with the appliance.
2. In certain circumstances electrical appliances may be a danger hazard.
Check the conformity of voltage and power settings, which are specified on
the information plate attached to the appliance and/or packaging, with the
usage conditions available.
3. Do not place heavy objects in or on these appliances, or use for storage,
or let children play or swing from the door. Do not use the appliances until
fully installed.
4. The electrical connection must be accessible after installation. The
appliance must be electrically isolated before any maintenance can be
performed. The appliance is not intended to be operated by means of an
external timer or separate remote control system.

3 4
SAFETY INSTRUCTIONSSAFETY INSTRUCTIONS
5. The appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervised or instruction concerning
the use of the appliance by a responsible person for their safety.Young
children should be supervised to ensure that they do not play with the appliance.
6. If the supply cord is damaged, it must be replaced by the manufacturer or its
service agent or a similarly qualified person in order to avoid a hazard.
7. The tumble dryer is not to be used if industrial chemicals have been used
for cleaning.
8. WARNING: Clean the lint trap regularly.
9. Lint must not be allowed to accumulate around the dryer. Not applicable for
appliances intended to be vented.
10. Adequate ventilation has to be provided to avoid the back flow of gases
into the room from appliances burning other fuels, including open fires.
11. CAUTION - If this appliance is supplied from a cord extension set or an
electrical portable device, the cord extension set or electrical portable device
must be positioned so that it is not subjected to splashing or ingress of moisture.
12. Items that have been spotted or soaked with vegetable or cooking oil
constitute a fire hazard and should not be placed in a tumble dryer. Oil-affected
items can ignite spontaneously, especially when exposed to heat sources such
as a tumble dryer. The items become warm, causing an oxidation reaction in
the oil. Oxidation creates heat. If the heat cannot escape, the items can become
hot enough to catch fire. Piling, stacking or storing oil-affected items can
prevent heat from escaping and so create a fire hazard.
13. If it is unavoidable that fabrics that contain vegetable or cooking oil or have
been contaminated by hair care products be placed in a tumble dryer they
should first be washed in hot water with extra detergent – this will reduce, but
not eliminate, the hazard. The “cool down” cycle of tumble dryers should not be
used to reduce the temperature of the items. They should not be removed from
the tumble dryer or piled or stacked while hot.
14. Items that have been previously cleaned in, washed in, soaked in or
spotted with petrol/gasoline, Dry-cleaning solvents or other flammable or
explosive substances should not be placed in a tumble dryer. Highly flammable
substances commonly used in domestic environments include acetone,
denatured alcohol, petrol/gasoline, kerosene, spot remover (some brands),
turpentine, waxes and wax removers.
15. Item containing foam rubber (also known as latex foam) or similarly texture
rubber-like materials should not be dried in a tumble dryer on a heat setting.
Foam rubber materials can, when heated, produce fire by spontaneous
combustion.
16. Fabric softeners or similar products should not be used in a tumble dryer
to eliminate the effects of static electricity unless this practice is specifically
recommended by the manufacturer of the fabric softener or product.
17. Undergarments that contain metal reinforcements should not be placed in
a tumble dryer. Damage to the tumble dryer can result if metal reinforcements
come loose during drying. When available a drying rack could be used for such
items.
18. Plastic articles such as shower caps or babies’ waterproof napkin covers
should not be placed in a tumble dryer.
19. Rubber-backed articles, clothes fitted with foam rubber pads, pillows,
galoshes and rubber-coated tennis shoes should not be placed in a tumble
dryer.
20. Do not cover the air inlet or exhaust openings.
21. If appliances has ventilation openings in base, ensure carpet does not
obstruct the openings.
22. The appliance must not be installed behind a lockable door, a sliding door
or a door with a hinge on the opposite side to that of the tumble dryer in such a
way that a full opening of the tumble dryer door is restricted.
23. The maximum mass of dry load is 7kg.
24. The final part of a tumble dryer cycle (cool down cycle) occurs without heat
to ensure articles are left at temperatures that won’t damage them.
25. WARNING: Never stop a dryer before the end of the drying cycle unless
all items are quickly removed and spread out to allow heat dissapation.
26. Do not overturn the appliance either during operation or during
maintenance.

3 4
SAFETY INSTRUCTIONSSAFETY INSTRUCTIONS
5 6
SAFETY INSTRUCTIONSSAFETY INSTRUCTIONS
Correct Disposal of this product:
This marking indicates that this product hould not be
disposed with other household wastes throughout the
EU. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, recycle
it responsibly to promote the sustainable reuse of
material resources. To return your used device, please
use the return and collection systems or contact the
retailer where the product was purchased. They can take
this product for environmental safe recycling.
Injury danger
Electric shock hazard
1.Do not draw the power cord forcefully to pull out the mains
plug.
2.Please do not plug/draw the mains plug with wet hands.
3.Do not damage the power cord and the power plug.
1.Do not disassemble and install the dryer under no instruction
or supervision.
2.Do not stack this dryer on washing machine without stacking
kits.(if want stacking on washing machine, please purchase
the Independent parts and it must be installed by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.)
3.Do not lean on the opened door of the dryer.
Damage danger
1.Do not dry over the rated capacity.
2.Do not operate the dryer without the filter door and filter base.
3.Do not dry the clothes before being spun.
4.Do not expose the dryer directly under the sun, and indoor
use only.
5.Do not install the dryer in the humid and drenching
environment.
6.At the cleaning and maintenance, please do remember to pull
out the power plug and do not directly wash the dryer with
water.
Explosion danger
Please do not dry the clothes with some flammable substances
such as the coal oil, alcohol or there will be the explosion.
27. Always remove items from pockets (especially flamables like matches).
28. This appliance is for indoor use only.
4. Do not place hot or burning items (for example candles) on this
appliance.

7 8
INSTALLATION
Accessories
The following parts are optional for specific models.
If your dryer has following parts, please wear gloves and them
following the instruction below .
install
Hose holder(optional)
Condensing drain
hose(optional)
Use pliers to remove
the drain hose from
the hose connector.
Insert the
external
drainage
hose.
Container
Control Panel
Door
Drum
Power Cord
Handle
Maintenance cover
Air inlet
Top board
Product Description
Max.120cm
200cm
Put the hose holder on the washing
basin or any other sink.
Installation
Lint filter
Transport
Move cautiously. Do not grasp any salient parts of machine. The machine
door can not be used as the handle for delivery.
Installation Position
Level Adjusting
Once in its permanent operating position,
check that the dryer is absolutely level with the aid
of a spirit level. If it is not, adjust the feet with a tool.
Power Supply Connection
1.It is recommended that, for your convenience, the machine is positioned close
your washing machine.
2.The tumble dryer must be installed in a clean place, where dirt does not build up.
Air must be able to circulate freely all round the appliance. Do not obstruct the
front air inlet or the air intake grilles at the back of the machine.
3.To keep vibration and noise to a minimum when the dryer is in use, it should be
placed on a firm and level surface.
4.The feet must never be removed. Do not restrict the floor clearance through
deep pile carpets, strips of wood or similar. This might cause heat built-up which
would interfere with the operation of the appliance.
to
1.Make sure that the voltage of the power supply is the same as the electric specification
2.Do not connect the dryer with the power connection board, the universal plug or socket.
of the dryer.
INSTALLATION

9 10
OPERATIONS
After Drying
Drying
Buzzer beep or " :00"on display.0
1 2 3 4 5
open the door and
take out laundry
pull out the
container
pour out
condensate water
clean the filter power off
Quick Start
Before using, please make sure it's installed properly.
Note!
1
plug in
2
load
3
close door
start
on select program select function
or default
• If use the socket with a switch, please press the switch to turn off the power
directly.
Note!
Never overload.
• Not for textile with dropping water. The dryer could be damaged, even fire.
• Not suitable for silk or woolen textiles.
•
1.Before drying, thoroughly spin the laundry in washing machine. High spin speed can
the drying time and save energy consumption.
2.For uniform drying result, sort the laundry according to fabric type and drying programme.
3.Before drying, please close zips, hooks and eyelets, button up, tie fabric belts, etc.
4.Do not over dry the clothes, because over dried clothes can easily get creases.
5.Do not dry the articles containing rubber or similar elastic materials.
6.The door can be opened only after the programme of the drying machine finishes to
from being scalded by hot steam or over heated drying machine.
7.Clean the lint filter and empty container after each use to avoid extension of drying time
and energy consumption.
8.Do not dry these clothes after dry-clean process.
reduce
prevent human skin
The reference weight of dry clothes (each)
Mixed-fabric clothes
(about 800g)
Jacket
(about 800g cotton)
Jeans
(about 800g)
Towel quilt
(about 900g cotton)
Single bedsheet
(about 600g cotton)
Short sleeve shirt
(about 180g cotton)
Work clothes
(about 1120g)
Short pants
(about 70g cotton)
Sleepwear
(about 200g)
Socks
(about 50g
mixed-weave)
Long sleeve shirt
(about 300g cotton)
Note!
Before Each Drying
Attention!
Before the first cycle, the dust and grease may remain in this dryer during the
period of manufacture and transportation, to avoid contaminating your clothes,
please follow these steps:
• Put some clean rags into the drum.
• Plug the power.
• Select the “Quick” Programme, press “Start/Pause” button.
• After finishing this programme, please follow the “cleaning and routine
maintenance” to clean the lint filter and air condenser on page 14.
OPERATIONS





 

 







OPERATIONSOPERATIONS
11 12
Control Panel
2
1
3
54

OPERATIONS OPERATIONS
13 14
Speed dry indicator
Programme selector
Other Functions
1.The drum will stop running after the programme ends,
the display will show " ", last cycle phase status light will flash. The
dryer will start Anti-crease if user doesn’t remove the load in
1 minute (refer to page 13). Please press key to cut off power and
pull the plug out.
2.Deal with the problem accroding to “Malfunction display and solutions , if
there is a unexpected stop during the drying procedure and the dryer show
information(refer to page 16 ).
the buzzer will beep,
the
【 】function
【On/Off】
”
The drum will keep rotating after the programme starts, the state light in the
display area will flash in sequence, the remaining time displayed will change
automatically.
1.Press the【On/Off 】 button ,when the LED display screen brightens up, rotate
the programme knob to select the desired programme.
2.Select the【Delay】,【Time】,【Intensity】,【Speed Dry】,【Signal】or
【Anti-Crease】 functions for additional option.
3.Press the【Start/Pause】button.
Programme start
Programme end
• Instructions of the 【Delay】 function
This function is used for delaying clothes drying time within 24 hours.
means the programme
time starts to decrease on the
Steps in details
1. Load your laundry and make sure the machine door is closed.
2. Press the 【On/Off】button,then to turn the programme selector knob and select a
desired programme.
3. You can select the 【Anti-Crease】 or 【Signal】functions according to your need.
4. To press the 【Delay】 key.
5. Continue to press the 【Delay】to select the delay time.
6. After the 【Start/Pause】 button is pushed, the dryer is at the run condition. The
drying procedure will be automatically performed when the delay time is over.
7. If you push the【Start/Pause】button again, the delay function will be paused.
8. If you want to cancel the “Delay” function, please press the 【On/Off】button.
The delay time
will start after x hours. When the delay programme starts, the
display and the delay icon blinks.
Fliter
Please clean the filter when the“ ” is lighting, after the dryer stops.
Tank
Please empty the container when the“ ” is lighting, after the dryer stops.
On/Off
Product is switched on or off.
1
1
Start/Pause
the button to start or pause the
drying cycle.
Press
1
2
Specialty function
These buttons are used for setting
additional functions.
3
Display
This display shows the setting, estimated
remaining time and status messages of
your dryer.
4
Programmes
Different Dryer cycle can be selected
according to the user's needs to make the
clothes have more effective drying results.
5
Delay start
Child lock
Remaining Time indicator/Error message
Cycle phase status
Clean filters (warning)
Empty water container (warning)
Dryness level (four grades)
Signal indicator
Anti-crease mode
Time
My cycle

15 16
OPERATIONS OPERATIONS
• Instructions of the 【Time】function
When the warm or cool or refresh programme is selected, the 【Time】button can be
used to adjust the drying time in 10 min. steps.
• Instructions of the 【Intensity】function
Used to adjust the dryness level of the laundry. The level has four grades .
The drying time increases 3 minutes in every grade.
1. The intensity function can be activated only before the programme start.
2. Press the 【Intensity】button repeatedly to select the drying time.
3. Except the 【Cotton Iron】【Qucik】【Synthetic Iron】【Baby Care】【Warm】
【Cool】【Refresh】,all the other programmes can be the【Intensity】function.
• Instructions of the 【Speed dry】
Use to curtail shorten the drying time, the 【Cotton Extra】【Cotton Standard】【Mix】
【Jean】programme can be set the function.
• Instructions of the【Signal】function
Set up the buzzer on or off. In the general condition, the buzzer is on. Please press it if
needed. When the buzzer on:
1. The dryer will give the leading sound if press the extra function buttons.
2. If the dryer is running, rotate the function choosing knob, the dryer will remind the
operator it is an invalid choose.
3. When the drying programme is end, the buzzer will also remind the user
• Instructions of the【Anti-Crease】function
At the end of the drying cycle,the anti-crease operation time is 30 minutes (default ) or 120
minutes (selected).
The 【Anti-Crease】 light shall illuminate when the anti-crease function is selected. This
function prevents the laundry from creases. The laundry can be removed during the
anti-crease phase. Except【Cool】,【Refresh】and 【Baby Care】, all the other programmes
have this function.
• Instructions of the【My Cycle】function
Used to define and save your favorite proragmmes that are used frequently.
1. Use the programme selector to select the required programme and other drying functions.
2. Press and hold the 【Intensity】button for 3 seconds until the beep and the required
programme has been saved.
3. Turn the programme selector to the 【My Cycle】position, you can start your favorite
proragmmes. If you want to change the 【My Cycle】settings, repeat the steps 1 and 2.
• Instructions of the 【Child Lock】 feature
1.This machine incorporates a special child safety lock, which can prevent children from
carelessly pressing keys or making the faulty operation.
2.When the dryer is at the operation state, press the【Anti-Crease】and 【Signal】buttons
at the same time for over 3 seconds to start child lock function. When child lock function
is set, the display will show child lock icon and no key can effect to the dryer except
【On/Off】button.
Under the start state of the child lock, the【Anti-Crease】and 【Signal】buttons shall
be pressed at the same time for over 3 seconds to release the child lock function.

Drying Programmes Table
17 18
OPERATIONSOPERATIONS
Y N
YN
Y N Y N
Y N Y Y
Iron
For non-iron ws
F
Standard Standard

Shirts
Jean Mix
Extra Sports



Extra
(max)
Weight

Programme
e and save yor favorite programme
Warm
Time
To w
To dry thin s h are not ironed, sh as easy are shirts,
e , y s, ss
Ts: extra dry
To dry n s of Drying : ae to iron
To dry n s of Drying : d dry
To dry n s of Drying : extra dry


For washing h is to e dried y,eg,made of as or for itemso for st drying
 To dry the s of the y at r te
 Refresh
T
To dry jeans or e s that are sn at high speeds in the washing e
If yon not determine what the s materiais, e e Mix
To dry sportswear, thin fs, prh are not ironed
For easy are s h shirts and s with ae m for m ironing ee s y in the dryerOe dried,
hang it on a s hange

T
 Time
YN

 Y


   
 

  To dry ed n amd r e s
• This means the energy ey test programme “standard n programme”, whh is
ae with the ae EN 61 standard and most sae to dry normaoon ad at rated
ad y
• Tor md fs,enen, jeans, ets , are not easy to dry
Yod r oose Cn Extra programme
• As the neven , tand d hes are not easy to dry, it is r to hoose the
appropriate e drying programme to dry them if some parts of the othes damp ar programme
nished
Note!

19 20
MAINTENANCE
MAINTENANCE
Trouble Shooting
Empty the water container
1.Hold and pull out the water container with two hands.
2.Tilt the water container, pour out the condensate water.
3.Insert the water container.
• Empty the water container after each use, the programme will be paused and
the “ ” icon will light if the water container is full during the drying process.
After the container is emptied, the dryer can be restarted by pressing
【Start/Pause】 button.
• Do not drink the condensate water.
• Do not use the dryer without the water container.
Warning!
！
Clean the lint filter
Wash air condenser
Leave the dryer to cool down.
1.Open the machine door.
2.Take out the lint filter, pull
upward to take it out.
3.Clean the lint filter; wipe off
the scrap threads accumulated
on the lint filter, with your hand or
rinse with water and dry thoroughly.
4.Reinstall the lint filter.
• The lint filter accumulated on the filter will block the air circulation, which will
cause the extension of drying time and energy use; therefore, the scrap thread
filter shall be cleaned after each use.
• Do disconnect the power cord before cleaning!
• Do not operate the dryer without the lint filter!
• Clean the lint filter after each use to prevent lint accumulation inside the dryer.
Leave the dryer to cool down.
Residual water may escape, place an absorbent
cloth under the maintenance cover.
1. Unlock the maintenance cover.
2. Completely open maintenace cover.
3. Screw both locking levers towards each other.
4. Pool out the air condenser.
5. Clean the air condenser completely, drain thoroughly.
6. Clean the seals.
7. Re-insert the air condenser, handle at the button!
8. Unscrew both locking levers.
9. Cloth the maintenance cover until it locks into position.
Please clean the air condenser approx, once every 3
months if frequently used.
Do not damage the air condenser!
• Clean with water only; do not use hard/sharp-edged objects!
Do not operate the dryer without the air condenser!
• During drying, water may collect between the window and the
seal, but this does not affect the function of your dryer!
Cleaning And Care
Warning!
！
Note!
“ ”E30
“ ”E32
“ ”E33
Alarm Problem Alarm Reason Release
Heating problem
Humidity sensor error
Temprature sensor error
P lease contact your local service
center if the problem persists.

21 22
MAINTENANCE
MAINTENANCE
• The rated capacity is the maximum capacity, make sure that the dry clothes which are
loaded to the appliance do not exceed the rated capacity each time.
• Do not install the tumble dryer in a room when there is a risk of frost occurring. At
temperatures around freezing point the tumble dryer may not be able to operate
properly.
• There is a risk of damage if the condensate water is allowed to freeze in the pump,
hoses and / or condensate water container.
+5°c ~ +35°c
Technical Specifications
220-240V~
Rated capacity
Rated frequency
Dimension(L*W*H)
Rated input power
Rated voltage
615*595*845(mm)
2000W
Weight of product 41kg
7.0kg
50Hz
Model
Parameter
1%&%

Ambient temperature
Note!
• Only authorised technicans can carry out repairs.
• Before you call service,
fault yourself or if you have followed the user instructions.
• A technician will charge you for advice, even during the warranty period.
please check if you have dealt with the
If you cannot deal with the fault by yourself and need help:
• Press the 【On/Off】button.
• Pull out the mains plug and call the service.
Warning!
！
Warning!
！
• Clean lint filter and .
• Empty container.
• Check drain hose.
• Dryer installation place is too restricted.
• Clean the moisture sensors.
• Keep the Air inlet clean.
• Use higher drying intensity level programme or
time programme.
heat exchanger
• “ ”is lighting
•“ ”is inglight
Problem Solution
•Display does not on
• Check if the power supply works.
• Check if the mains plug is inserted.
• Check the selected programme .
• Press the 【On/Off】button.
• Empty water container.
• If the light is still on, please call the service.
• Clean heat exchanger.
• Clear lint filter.
•Dryer does not start
• the door has closed.
• Check the programme has set.
• Check the start button has selected.
Check the
•Degree of dryness was
reached or drying time too
long
not

23
