Omron Sentech CoaXPress STC-MBS212CXP6 Installation instructions

No.20S024-ES00
1/16
STC-MBS212CXP6 / STC-MCS212CXP6
Product Specifications and User’s Guide
CoaXPress
Monochrome / Color CMOS Camera
STC-MBS212CXP6 (2M / Monochrome / High speed / CXP-6 x1)
STC-MCS212CXP6 (2M / Color / High speed / CXP-6 x1)
Product Specifications and User’s Guide
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

No.20S024-ES00
2/16
STC-MBS212CXP6 / STC-MCS212CXP6
Product Specifications and User’s Guide
Table of Contents
1 Product Precautions ........................................................................................................................................................ 5
2 Warranty ........................................................................................................................................................................... 5
3 Overview ........................................................................................................................................................................... 6
3.1 Features ..................................................................................................................................................................... 6
3.2 Product Number Naming Method ............................................................................................................................... 6
4 Specifications .................................................................................................................................................................. 7
4.1 Electronic Specifications............................................................................................................................................. 7
4.2 Spectral Sensitivity Characteristics ............................................................................................................................ 9
4.2.1 STC-MBS212CXP6 (Monochrome) .................................................................................................................... 9
4.2.2 STC-MCS212CXP6 (Color) ................................................................................................................................ 9
4.3 Mechanical Specifications ........................................................................................................................................ 10
4.4 Environmental Specifications ................................................................................................................................... 10
4.5 External Connector Specifications ............................................................................................................................11
4.5.1 Micro BNC connector .........................................................................................................................................11
4.5.2 IO Connector (TBD) .......................................................................................................................................... 12
4.5.3 Connector indicator lamp .................................................................................................................................. 13
5 Dimensions .................................................................................................................................................................... 14
6 Revision History ............................................................................................................................................................ 15
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

No.20S024-ES00
3/16
STC-MBS212CXP6 / STC-MCS212CXP6
Product Specifications and User’s Guide
Precautions for safe use
Please read carefully this “Precautions for safe use” before use the camera. Then the camera uses correctly with
agreeing with below notes.
In this “Precautions for safe use”, notes divides into “Warning” and “Caution” to use the camera safety and prevent to
harm and damage.
Warning This shows, assumption for possibility of serious accident leading death or
serious injury if ignore this note and camera uses incorrectly.
Caution This shows, assumption for possibility of bear the damage or physical
damage if ignore this note and camera uses incorrectly.
About Graphic
symbols This symbol shows general prohibition.
This symbol shows completion or instruction.
[Environment / condition]
Warning
Do not use flammable or explosiveness
atmospheres.
This will cause of personal injury or fire.
Do not use for “safety for human body” related
usage.
This camera is designed for use “do not harm
human body immediately” if by any chance the
camera has malfunction.
Caution
Use and store under specified environmental
conditions (Vibration, shock, temperature,
humidity) in the specifications for this camera.
This will cause of fire or damage the camera.
[Installation and cable wiring]
Warning
Do not use with out of power voltage range
that is specified in the specifications for this
camera.
This will cause of fire, electrification or
malfunction.
Do not wrong wiring.
This will cause of fire or malfunction.
Caution
Do not grounding DC power (+) of all devices
that are connect to the camera.
The camera housing is connecting to 0 V line of
camera inside circuit.
There is a risk of short circuit between camera
inside ciurcuit and frame ground.
This will cause of malfunction.
It is necessary to wiring and mounting that is
specified in the specifications for this camera.
This will cause of fire or malfunction.
It is necessary to wiring with turn off the camera.
This will cause of electrification or malfunction.
It is necessary to mounting the camera without
stress for the cable.
This will case of electrification or fire.
Do not use CoaXPress un-supported cable
and board.
There is a risk of malfunction if the camera
connects with wrong environment and turn on
the camera.
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

No.20S024-ES00
4/16
STC-MBS212CXP6 / STC-MCS212CXP6
Product Specifications and User’s Guide
[Usage instruction]
Warning
Do not touch the terminal and PCB board
While turn on the camera.
This will cause of electrification or accident
caused by malfunction.
Do not put combustibles near the camera.
This will cause of fire.
Do not use without usage that is specified in
the specifications for this camera.
This will cause of personal injury or malfunction.
Do not push metals including screw driver into
radiation holes.
This will cause of electrification or malfunction.
Do not touch the camera housing while or
afterusing the camera.
There is a risk of get burned.
Caution
Do not push contamination into opening of
the camera.
This will cause of electrification or malfunction.
Do not block the radiation holes.
This will cause of fire due to increase the
camera inside temperature.
[Maintenance]
Caution
Do not disassemble or repair the camera.
This will cause of fire, electrification or
malfunction.
It is turn off the camera when maintaining or
inspecting the camera.
This will cause of electrification.
[Disposal]
Caution
It is necessary to dispose as industrial waste.
]
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

No.20S024-ES00
5/16
STC-MBS212CXP6 / STC-MCS212CXP6
Product Specifications and User’s Guide
1 Product Precautions
Do not give shock to the camera.
Do not haul or damage the camera cable.
Do not wrap the camera with any material while using the camera. This will cause the internal camera
temperature to increase.
When the camera moving or using the place that temperature difference is extreme, countermeasure for
dew condensation (heat removal / cold removal) is necessary.
While the camera is not using, keep the lens cap on the camera to prevent dust or contamination from getting
in the sensor or filter and scratching or damaging it.
Do not keep the camera under the following conditions.
・In wet, moist, high humidity or dusty place
・Under direct sunlight
・In extreme high or low temperature place
・Near an object that releases a strong magnetic or electric filed
・Place with strong vibrations
Apply the power that satisfies the specified in specifications for the camera.
The defective pixels may appear due to the sensor characteristics.
Use below recommend materials (or equivalent materials) to clean the surface of glass.
・Air dust: Non Freon air duster (NAKABAYASHI Co., LTD.)
・Alcohol: Propan-2-ol (SAN’EI KAKO Co., LTD.)
・Non-woven: nikowipe clean room (NKB)
Use a soft cloth to clean the camera.
2 Warranty
■Warranty period
One year after delivery (However, the camera had malfunction with camera uses correctly)
In below case for a fee even within warranty period.
・The malfunction caused by incorrect usage, incorrect modify or repair.
・The malfunction caused by external shock including the camera dropping after delivery the camera.
・The malfunction caused by fire, earthquake, flood disaster, thunderbolt struck, other natural disaster or
wrong voltage.
■Warranty coverage
Exchange or repair the malfunction camera if the malfunction is occurred by our responsibility.
“Warranty” mean is warranty for the delivered camera itself. Please accept the induction damage by the
camera malfunction is not included.
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

No.20S024-ES00
6/16
STC-MBS212CXP6 / STC-MCS212CXP6
Product Specifications and User’s Guide
3 Overview
This document describes the specifications of the following cameras
STC-MBS212CXP6 / STC-MCS212CXP6
3.1 Features
・CoaXPress (CXP) Interface: CXP-6, 1 lane
・PoCXP (Power Over CoaXPress) support
・Maximum frame rate (Full resolution): 239 fps @ 2M 8bits
・CMOS (Global Shutter)
・Up to TBD Pixel Defect Correction (Default: ON)
・8bits, 10bits, 12bits output
3.2 Product Number Naming Method
STC-MxS212CXP6
212: 2M, 1/1.7” high speed sensor
B: Monochrome
C: Color
CXP6: CoaXPress 6.25Gbps (CXP-6)
Sensor Manufacture
S: SONY
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

No.20S024-ES00
7/16
STC-MBS212CXP6 / STC-MCS212CXP6
Product Specifications and User’s Guide
4 Specifications
4.1 Electronic Specifications
Bold: Default
Model Number
STC
-
M
B
S
212CXP6
STC
-
M
C
S
212CXP6
Image Sensor 1/1.7” 2M Progressive Monochrome CMOS
(SONY: IMX422)
1/1.7” 2M Progressive Color CMOS
(SONY: IMX22)
Shutter Type Global Shutter
Active Picture Elements 1,624 (H) x 1,240 (V)
Cell Size 4.5 (H) x 4.5 (V) µm
Scanning System Full scanning / ROI
Frame Rate
(Full resolution)
8bits:
239
fps
10bits Packed: 194 fps
12bits Packed: 165 fps
ADC bit width 12bits
Image Output Format
Mono
8
Mono10Packed
Mono12Packed
BayerRG8
BayerRG10Packed
BayerRG12Packed
CoaXPress Data Output CXP-6 (6.25 Gbps) 1 Lane
Noise Level 8bits output Less than TBD digits (Gain 0 dB)
10bitsPacked output Less than TBD digits (Gain 0 dB)
12bitsPacked output Less than TBD digits (Gain 0 dB)
Sensitivity (*1) TBD Lux TBD Lux
Exposure Time 1 µseconds to 16.777 seconds (Default: TBD µseconds)
Gain Analog 0 to 18 dB (Default: 0 dB)
Digital x1 to x3 (Default: x1)
Black Level 0 to 63 digits @ 8bits
White Balance Gain N/A 0 (Black Level) to x4 (Default: x1)
ROI Horizontal: TBD to 1,624 pixels / Vertical: 4 to 1,240 lines (Default: 1,624 x 1,240)
Adjustable Steps for size: 8 pixels in horizontal direction / 4 lines in vertical direction
Adjustable Steps for offset: 8 pixels in horizontal direction / 4 lines in vertical direction
Multi ROIs TBD
Gamma TBD
Binning Horizontal and Vertical summing /
Off
N/A
Decimation N/A
Image Flip Horizontal / Vertical / Horizontal and Vertical / Off
Defective Pixel Correction Up to TBD points
Auto Image
Control
Auto Exposure N/A
Auto Gain N/A
Auto White Balance N/A TBD
Operational Mode Edge Preset Trigger / Pulse Width Trigger / CXP Tigger Packet / Free Run
Interface GenICam
Protocol CoaXPress Standard Version 1.1
I/O 4 GPIOs
Power Input Voltaga PoCXP (+18.5 to +26 Vdc) / External power (+24 Vdc)
Consumption Maximum: Less than TBD W, Typical: TBD W
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

No.20S024-ES00
8/16
STC-MBS212CXP6 / STC-MCS212CXP6
Product Specifications and User’s Guide
Precautions
(*1) The sensitivity is measuring the luminance when white level achieved 100 % in below conditions. (TBD)
Camera Setting Environment
Parameter Setting Parameter Setting
Gain Up 0 dB Light Source Light Box (White)
AGC Off Color temperature 5,100K
White Balance Optimum Lens
Electrical Shutter 1/30 seconds F on Lens F5.6
Black Level Optimum Target Luminance IM-600 (Topcon)
Gamma Factory Setting
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

No.20S024-ES00
9/16
STC-MBS212CXP6 / STC-MCS212CXP6
Product Specifications and User’s Guide
4.2 Spectral Sensitivity Characteristics
4.2.1 STC-MBS212CXP6 (Monochrome)
4.2.2 STC-MCS212CXP6 (Color)
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

No.20S024-ES00
10/16
STC-MBS212CXP6 / STC-MCS212CXP6
Product Specifications and User’s Guide
4.3 Mechanical Specifications
(*1) Excluding connectors
4.4 Environmental Specifications
(*1) Please insure the camera is installed with the appropriate heat dissipation. If camera has a mounted lens and a
tripod with an aluminum plate, this could decrease the camera housing temperature for heat dissipation. When the
internal temperature sensor on the camera shows less than TBD deg. C, the camera housing temperature
(top plate) will be less than TBD deg. C.
Taking these steps will maintain the heat rating of the electronic components of the camera.
Upper side of camera
Model Number
STC
-
M
B
S
212CXP6
STC
-
M
C
S
212CXP6
Dimensions 28 (W) x 28 (H) x 40 (D) mm (*1)
Optical Filter No Optical Filter
Optical Center Accuracy Positional accuracy in Horizontal and Vertical directions: +/- 0.3 mm
Rotational accuracy of Horizontal and Vertical: +/- 1.5 deg.
Material Aluminum alloy (AC)
Lens Mount C Mount
Interface Connector CXP connector: BNC, 75 Ohm x 1
IO: HR10A-7R-6PB (Hirose) or equivalent x 1
Camera Mounting TBD
Weight Approximately TBD g
Model Number
STC
-
M
B
S
212CXP6
STC
-
M
C
S
212CXP6
Operational Temperature /
Humidity
Environmental Temperature: 0 to TBD deg. C,
Environmental Humidity: 0 to 85 %RH (No Condensation)
Storage Temperature /
Humidity
Environmental Temperature: -20 to TBD deg. C,
Environmental Humidity: 0 to 85%RH (No Condensation)
Vibration 20 Hz to 200 Hz to 20 Hz (5 min. / cycle), acceleration 10G, XYZ 3 directions 30 min. each
Shock Acceleration 38 G, half amplitude 6 mseconds, XYZ 3 directions 3 times each
Standard Compliancy EMS: EN61000-6-2, EMI: EN55011
RoHS RoHS Compliance
Measuring point
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

No.20S024-ES00
11/16
STC-MBS212CXP6 / STC-MCS212CXP6
Product Specifications and User’s Guide
4.5 External Connector Specifications
4.5.1 Micro BNC connector
Micro BNC, 75 Ohm x 1
This camera is PoCXP supported CoaXPress camera.
The CoaXPress frame grabber board is supplied power to camera through Micro BNC connector.
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

No.20S024-ES00
12/16
STC-MBS212CXP6 / STC-MCS212CXP6
Product Specifications and User’s Guide
4.5.2 IO Connector (TBD)
HR10A-7R-6PB (Hirose) or equivalent.
This connector is for input and output signals.
As for the cable part (Female connector), HR10A-7P-6S (Hirose) or equivalent can be used.
Pin assignment
Output signal selection for Line 0 to 3
The output signal can be selectable from below: (TBD)
GenICam
UserOutput
TriggerOut
TriggerThroughOut
FrameEndOut
TBD
Pin No. Signal Name IN/OUT Signal Voltage
1 GND - 0 V
2 Line3 IN/OUT +3.3 V
3 Line2 IN/OUT +3.3 V
4 Line1 IN/OUT +3.3 V
5 Line0 - +3.3 V
6 - - -
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

No.20S024-ES00
13/16
STC-MBS212CXP6 / STC-MCS212CXP6
Product Specifications and User’s Guide
4.5.3 Connector indicator lamp
Connector indicator LED exists beside of Micro BNC connector.
LED informs status of communication. The detail of status is as following table.
Status LED Blinking Pattern
No connection Off
System booting Solid orange
External powered, but no CXP connection RED slow blinking
PoCXP connection Fast flash alternating green / orange shown for a minimum
CXP connection with external power Fast flash orange
Device / Host connected, but no data being transferred Solid green
Device / Host incompatible, PoCXP Slow flash alternating red / green
Device / Host incompatible, CXP with external power Slow flash alternating red / orange
Device / Host connected, waiting for trigger Slow flash orange
Device / Host connected, data being transferred Fast flash green
Data Transfer Error Solid red (500 mseconds)
System Error Red fast blinking
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

No.20S024-ES00
14/16
STC-MBS212CXP6 / STC-MCS212CXP6
Product Specifications and User’s Guide
5 Dimensions
Tentative.
Unit: mm
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com

No.20S024-ES00
15/16
STC-MBS212CXP6 / STC-MCS212CXP6
Product Specifications and User’s Guide
6 Revision History
Rev
Date Changes Note
ES00 2020/02/25 New Document
Note: Product specifications would be changed without notification.
CoaXPress is registered trademarks of JIIA (Japan Industrial Imaging Association)
GenICam is trademark of EMVA.
Other company names and product names in this document are trademarks of their respective owners.
Aegis Electronic Group
www.aegiselect.com
For More Information Please Call Aegis Electronic Group, Inc. * [phone] Phone * [email protected] * http://www.aegis-elec.com
