Oneinmil IF-1330TCL User manual

1
Electric Fireplace
Model No.:
□IF-1330TCL □IF-1340TCL □IF-1350TCL
CONSUMER SAFETY INFORMATION
Read this manual before installing and operating this appliance
Failure to follow these instructions may result in electric shock, fire property,
or personal injury
Do not store or use gasoline or other flammable liquids in vicinity of this
appliance.

2
IMPORTANT SAFETY INFORMATION!
WARNING
Read all instructions before using this heater!
This heater is hot when in use. To avoid burns, DO NOT let bare skin touch hot surfaces. If
provided, use handles when moving this heater. Keep combustible materials, such as
furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from the front
of the heater, and keep them away from the sides and rear.
Extreme caution is necessary when any heater is used by or near children or invalids and
whenever the heater is left operating and unattended.
DO NOT operate any heater with a damaged cord or plug or after the heater malfunctions,
has been dropped or damaged in any manner. Discard heater, or return to an authorized
service facility for examination and /or repair.
DO NOT run power cord under carpeting. DO NOT cover power cord with throw rugs,
runners, or similar coverings. DO NOT route power cord under furniture or appliances.
Arrange power cord away from traffic area, and where it will not be tripped over.
WARNING
Connect to properly grounded outlets ONLY.
DO NOT insert or allow foreign objects to enter any ventilation or exhaust openings, as
this may cause electric shock or fire, or damage the heater.
To prevent a possible fire, DO NOT block air intakes or exhaust in any manner. Doing so
could cause a fire. DO NOT use on soft surfaces, like a bed, where openings may become
blocked.
A heater has hot and arcing or sparking parts inside. DO NOT use it in areas where
gasoline, paint, or flammable liquids are used or stored.
Use this heater only as described in this manual. Any other use not recommended by
the manufacturer may cause fire, electric shock, or injury to persons.
ALWAYS plug heaters directly into a wall outlet/receptacle. Never use an extension
cord or relocatable power tap (outlet/power strip).
DO NOT place the heater near a bed because objects such as pillows or blankets can fall off
the bed and be ignited by the heater.
NEVER use this heater in bathrooms, laundry rooms, or any other location where the
heater could fall into a bathtub or pool,become damp, or come in contact with water.
AVOID FIRE! Regularly inspect all air vents to make sure they are free from dust, lint, or other
Blockage. Unplug the unit and clean with a vacuum ONLY.DO NOT rinse or get wet.
ALWAYS mount to wall bracket before use. DO NOT set on the floor, or other surface, to use.

3
NEVER use a wall mount bracket from another manufacturer.
This product is not intended to be a primary heat source. It is for supplemental heat only.
INDOOR use only! NEVER use this heater outdoors! Doing so may result in electric shock!
Risk of electric shock!DO NOT OPEN! No user-serviceable parts inside!
ALWAYS turn this heater off before unplugging it from the outlet.
ALWAYS disconnect this unit from the power supply before performing any assembly or
cleaning, or before relocating the electric fireplace.
NEVER leave this heater unattended. ALWAYS unplug this heater when not in use.
ALWAYS store this heater in a dry location.NEVER use the fireplace if it has become wet.
NEVER plug this heater into an outlet that is old,cracked, or has any loose wires or
connections. Plugging this heater into a faulty outlet could result in electric arcing within
the outlet that could cause the outlet to overheat or catch fire.
ALWAYS check your heater cord and plug connections with each use!
i) MAKE SURE the plug fits tightly in the outlet! Faulty wall outlet connections or loose
plugs can cause the outlet to overheat.
ii) Heaters draw more current than small appliances. Overheating may occur even if it
has not occurred with the use of other appliances.
iii) During use check frequently to see if the plug outlet or faceplate is HOT!
iv) If the outlet or faceplate is HOT,discontinue use immediately and have a qualified
electrician inspect and/or replace the faulty outlets.
The power cord supplied with the heater
has a plug with two flat blades (live and
neutral) and one round pin (ground). If a 3-
slot receptacle is not available, an adapter
MUST be used. The adapter MUST be
properly grounded to the outlet box (see
figure at right).
(Note: Adapter NOT INCLUDED.)
SAVE THESE INSTRUCTIONS!
PREPARATION
This product includes a GLASS panel! Always use extreme caution when handling
glass. Failure to do so could result in personal injury or property damage.
Remove all parts and hardware from the carton and place them on a clean, soft, dry surface. Parts
and assembly steps are grounded for wall-hanging or recessing use. Check the parts list to make
sure nothing is missing. Dispose of packaging materials properly. Please recycle whenever
possible. You will need the following tools (not included): Phillips screwdriver; stud finder; level;
tape measure; electric drill; 1/4” wood drill bit, hammer.

4
PARTS & HARDWARE
A. Fireplace
B. Wood Screws
C. Drywall anchors
D. Remote control
E. Wall Bracket
Fixed on back of firebox
F. Log set
G. Decorative
Crystals
Specification and Dimension
PRODUCT DIMENSIONS
Model Number
A
B
C
D
E
F
G
IF-1330TCL
30”
76.2cm
17.0”
43.2cm
4.13”
10.5cm
26.2”
66.5cm
16.2”
41.2cm
9.1”
23.2cm
23.7”
60.2cm
IF-1340TCL
40”
101.6cm
17.0”
43.2cm
4.13”
10.5cm
36.2”
91.9cm
16.2”
41.2cm
9.1”
23.2cm
33.7”
85.6cm
IF-1350TCL
50”
127.0cm
17.0”
43.2cm
4.13”
10.5cm
46.2”
117.3cm
16.2”
41.2cm
9.1”
23.2cm
43.7”
111.0cm

5
Installation and Assembly
Your appliance is a wall-mounted, recessed, and /or mantel-installed appliance. Select a suitable
location that is not susceptible to moisture and is away from drapes, furniture, and high-traffic areas.
NOTE: Follow all National and local electrical codes.
MINIMUM CLEARANCE TO COMBUSTIBLES
Measurements are taken from the glass front.
Bottom 0” Top 11.8”(300mm) to mantel
Sides 0” Top 11.8”(300mm) to ceiling
Back 0”
MINUMUM MANTEL CLEARANCES
WARNING
WHEN USING PAINT OR LACQUER TO FINISH THE MANTEL, THE PAINT OR LACQUER MUST
BE HEAT RESISTANT TO PREVENT DISCOLOURATION

6
RECESSED TO WALL INSTALLATION
STEP 1. Selection of a dry wall to open a hole for the fireplace box. Size of the hole as below chat. Figure (A)
Figure (A) Hole cut size of IF-1330TCL
Figure (A) Hole cut size of IF-1340TCL
Figure (A) Hole cut size of IF-1350TCL

7
STEP 2. Fix the four wall anchors on each side of the fireplace box according to the dimensions.
Shown on the drawing. Figure (B)
Figure (B) Hole cut size of IF-1330TCL
Framing Hole Size
Model Number
W
H
IF-1330TCL
26.77”(68.1cm)
16.54”(42.0cm)
IF-1340TCL
36.77”(93.5cm)
16.54”(42.0cm)
IF-1350TCL
46.77”(118.9cm)
16.54”(42.0cm)

8
Figure (B) Hole cut size of IF-1340TCL
Figure (B) Hole cut size of IF-1350TCL

9
STEP 3. Take off the two screws in both sides of fireplace. Figure (C)
STEP 4. Have two-person take the glass panel out of the fireplace box. Place it in a soft and clean place. Figure
(D), take two pieces of foam out of the fireplace. Figure (E)
(C) (D) (E)
STEP 5. Have two-person move the fireplace box to the wall hole or fireplace mantel. Figure (F)
If the appliance is fully recessed into the wall:
Use the 4 screws (provided) to lock the appliance into the wall with the existing two side flanges, see
Figure(G)
Install the media and re-install the glass front.
STEP 6. Place the front panel lock the appliance. See Figure (H)
STEP 7. The fireplace will be like this after installation. Figure (I)
(F) (G) (H)
(I)

10
Wall Mounted Installation
Due to the many different materials used on different walls, it is highly recommended that you consult your
local builder before you install this appliance on the wall.
A. Select a location that is not prone to moisture and is located at least 36”(914mm) away from combustible
materials such as curtain drapes, furniture, bedding, paper, etc.
B. Have two people hold the appliance against the wall to determine the final location.
C. Place unit faces down on a soft, non-abrasive surface. Remove the bracket from the back of the unit by
removing the screws, refer to Figure 1. Remove four pcs of silver screws at both sides, refer to Figure 2.
Fig.1 Fig.2
D. Take glass off carefully, then take two pcs of foam out of the fireplace.
Fig.3 Fig.4
E. Mark out location, then mount the bracket(s) onto the wall using the supplied screws. This bracket MUST
have the hooks facing upward and be level.

11
NOTE: It is Strongly Recommended that the mounting bracket(d) be screwed into the wall studs where
possible. If the wall studs cannot be used, ensure that the supplied plastic anchors are used to affix the bracket to
the wall and the bracket are adequately secured.
F. With the wall mounting bracket installed have two people lift the appliance up and insert the two hooks
on the bracket into the two slots on the back of the appliance. Use original 4x8mm screws to fasten the wall
bracket.
G. Check the appliance for stability ensuring that the bracket will not pull free from the wall.
H. Place the front panel lock the appliance, refer to Figure 7.
Fig.5 Fig.6
Fig.7

12
Log set /Crystal Ember Installation
(Note: Please make the installation according to the embers which you bought or selected.)
A. The glass front must be removed and the appliance must be mounted in its final location before the log
set/crystal embers are installed.
B. If your fireplace comes with a log set, remove the log set from the package, put it in the fireplace-designed
place. Figure 1
C. If your fireplace comes with CLEAN CRYSTAL MEDIA: crystal may have a fine oil residue that needs to
be cleaned prior to installation. Clean them with mild dish soap, drain, rinse thoroughly, and dry them before
placing them into the tray.
D. Then carefully place crystal embers into the bottom tray on the front of the appliance as illustrated. Apply an
even layer from side to side. Figure 2.
Figure 2.(Crystal medias)

13
Power
Plug the power cord into a 110-120V Volt 12 Amp grounded outlet (see IMPORTANT SAFETY
INFORMATION on Pages 2 and 3). Make sure the outlet is in good condition and that the plug is not loose.
NEVER exceed the maximum amperage for the circuit. DO NOT plug other appliances into the same circuit.
Methods of Operation
This electric fireplace can be operated by the TOUCH PANEL, located on the BOTTOM right side glass panel
of the fireplace, or by the battery-powered REMOTE CONTROL.
The operation and functions of the two methods are the same.
Before operating, please review the IMPORTANT SAFETY INFORMATION on Pages 2 and 3, and heed all
warnings.
WARNING
Read and understand this entire owner’s manual, including all safety information, before
plugging in or using this product. Failure do to so could result in electric shock, fire,
serious injury, or death.

14
Touch panel/Remote control Operation
BUTTON
FUNCTION
ACTION&INDICATION
POWER
ON: Enables control panel functions and remote control.
Turn on flame effect.
OFF: Disabled control panel functions and remote control.
Turn off flame effect.
1. Press once. The indicator light turns on. Power
turns on. All functions enabled.
2. Press again. The indicator light turns off. Power
turns on. All functions will off.
COLOR
COLOR button: Makes the color flame effect changing.
1. Press once. The Flame color effect gets
changing.
2. Press again. Until the desired setting is reached.
FLAME
FLAME button: Makes flame effect dimmer and brighter.
NOTE: The flame effect stays on until the power button is
turned off. The flame effect must be on for the heater to
turn on.
1. Press once. The Flame brightness effect gets
changing.
2. Press again. Until the desired setting is reached.
HEATER
HEATER button: Turn the heater on and off.
NOTE: To prevent overheating, the heater fan will blow
out cool air for 30 seconds after the heater turns off.
1. Press once. Indicator lights up. 750W heater
turns on and blows warm air.
2. Press again. Indicator lights up. 1500W heaters
turn on and blow hot air.
3. Press again. Heaters turn off. The display shows
“00”. The fan blows cool air for 30 seconds to
allow the heater to cool down, then turns off.
TEMP.
TEMPERATURE button: Control temperature settings to
choose temperature as desired.
Setting range from 62F to 82F.
1. Press once. Indicator light turn on. Temperature
is set to 62F.
2. Press again. Until the desired setting is reached.
LED display show setting.
TIMER
TIMER button: Control timer settings to turn off the
fireplace at the selected time.
Settings range from 0 hours,1 hour, to 8 hours.
1. Press once. Indicator light turn on. Temperature
is set to hours.
2. Press again. Until the desired setting is reached.
LED display show setting.
Temperature Limiting Control
This heater is equipped with a Temperature Limiting Control. Should the heater reach an unsafe temperature,
the heater will automatically turn OFF. To reset:
1. Unplug the power cord from the outlet.
2. Turn the ON/OFF switch on the CONTROL PANEL to OFF. Wait 5 minutes.
3. Inspect the fireplace to make sure no vents are blocked, or clogged with dust or lint. If they are,
use a vacuum to clean the vent areas.
4. With the POWER switch in the OFF position, plug the power cord back into the outlet.
5. If the problem continues, have your outlet and wiring inspected by a professional.
Remote Control Battery Information
With 2x AAA batteries.
NOTE: Remote control battery used depends on the remote control type selected above
NOTICE
When the heater is first turned on, a slight odor may be present. This is normal and
should not occur again unless the heater is not used for a long period of time.
NOTICE
To improve operation, aim the remote control at the front of the fireplace. DO NOT press
the buttons too quickly. Give the unit time to respond to each command.

15
NEVER dispose of batteries in the fire. Failure to observe this precaution may result in an
explosion. Dispose of batteries at your local hazardous material processing center.
CARE AND MAINTENANCE
Cleaning
NEVER immerse in water or spray with water. Doing so could result in electric
shock, fire, or personal injury.
Metal:
Buff using a soft cloth, slightly dampened with a citrus oil-based product.
DO NOT use brass polish or household cleaners as these products will damage the metal trim.
Glass:
Use a good quality glass cleaner and dry thoroughly with a paper towel or lint-free cloth.
NEVER use abrasive cleansers, liquid sprays, or any cleaner that could scratch the surface.
Vents:
Use a vacuum or duster to remove dust and dirt from the heater and vent areas.
Clean the exterior of the fireplace with a slightly damp cloth or duster.
Maintenance
Risk of electric shock!DO NOT OPEN! No user-serviceable parts inside!
ALWAYS turn the heater OFF and unplug the power cord from the outlet before
cleaning, performing maintenance, or moving this fireplace. Failure to do so could result in
electric shock, fire, or personal injury.
Electrical and Moving Parts:
The fan motors are lubricated at the factory and will not require lubrication.
Electrical components are integrated in the fireplace and are not serviceable by the consumer.
Storage:
Store heater in a clean dry place when not in use.
WARNING! No other servicing should be performed by the consumer. Do not attempt to
service the unit yourself.
ALWAYS turn the heater OFF and unplug the power cord from the outlet before
cleaning, performing maintenance, or moving this fireplace. Failure to do so could result in
electric shock, fire, or personal injury.

16
Troubleshooting
WARNING
DISCONNECTED THE APPLIANCE COMPLETELY AND LET IT COOL PRIOR TO ANY SERVICE.
ONLY A QUALIFIED SERVICE PERSONNEL SHOULD SERVICE AND REPAIR THIS ELECTRIC APPLIANCE.
Problem
Possible Cause
Solution
1. Fireplace turns off
and will not turn on.
1. Fireplace has overheated
and safety device has caused
thermal switch to disconnect
or home circuit breaker has opened.
1. Reset switch by turning main
power off and waiting to turn it
back on or breaker circuit breaker.
2. Flame is not moving.
1. Loose wiring.
2. Flame motor defective.
3. Flame rod out of place
1. Inspect wiring for loose
connections.
2. Call a qualified service
technician to replace the flame
motor.
3. “Flame Rod” out of place due
to rough transit/handling of the
product. This issue can be corrected
as simple as removing the glass,
flipping the fireplace upside and
down, removing a set of screws
that are holding the bottom frame
plate, and placing the flame rod
back into place.
3. Flame is not visible.
1. Wiring is loose.
1. Disconnect from the power
source and inspect the wiring for
loose connections and repair or
replace if necessary.
2. Push the flame button to high.
4. Log set is not glowing.
1. Wiring is loose.
2. Ember is off mode.
1. Disconnect from the power
source and inspect the wiring for
loose connections and repair or
replace if necessary.
5. Remote control does not work.
1. Low batteries.
2. Not aiming control correctly.
3. Defective remote control and /or
sensor.
1. Replace the batteries of the
remote control.
2. Aim control at the sensor located
directly behind the glass screen in
the center of the unit just above
logs.
3. Replace remote control and/or
sensor.
