ONEQ 202201702 User manual

ONEQ WOK BURNER
ARTICLE NUMBER 202201702 (30MBAR) / 202201703 (50MBAR)
ONEQ SMART OUTDOOR COOKING
oneQ B.V.
Wateringweg 83-C
2031 EK HAARLEM
The Netherlands
[email protected]
Island not included
Leg not included

-2-
oneQ B.V. 2022
one-q.com
INTRODUCTION
Congratulations with the purchase of your oneQ WOK BURNER!
The oneQ is made to provide you with outdoor cooking fun for years.
The highest demands are made on the convenience and safety.
The oneQ gas burner has an extremely clean combustion and an optimal airflow. The burnercomponents are made from
heath resistent stainess steal and are optimal resistent against corrosion.
In case the burner is used and maintained correctly it will work safety and reliable for years. Read the manual carefully
before using or installing the burner, so you are aware of all the important issues.
If you are interested in new products or enlargement of your oneQ set, please visite the website www.one-q.com or find
us on our socials.
INTRODUCTIE
Gefeliciteerd met de aankoop van uw oneQ WOK BURNER!
De oneQ is gemaakt om u jarenlang veel buitenkookplezier te verschaffen. Aan het gebruiksgemak
en de veiligheidsaspecten zijn de hoogste eisen gesteld.
Indien de oneQ op juiste wijze wordt gebruikt en onderhouden doet deze jarenlang veilig en betrouwbaar dienst. Neem
deze handleiding vóór ingebruikname en installatie grondig door, zodat u op de hoogte bent van alle belangrijke
aandachtspunten.
Bent u geïnteresseerd in nieuwe producten of uitbreiding van uw oneQ set, bezoek dan de website www.one-q.nl.
EINFÜHRUNG
Herzlichen Glückwunsch zum Kauf Ihrer oneQ WOK BURNER!
Die oneQ ist hergestellt Ihnen seit Jahren Freude am grillen zu bieten.
Die höchste Anforderungen sind gemacht an die Bequemlichkeit und Sicherheit.
OneQ der Gasbrenner hat eine sehr saubere Verbrennung und eine optimale Luftströmung. Der Brenner Komponenten
sind aus hitzebeständigem Edelstahl gefertigt und sind komplett korrosionsbeständig.
Wenn der Grill richtig eingesetzt und gepflegt wird, gibt es viele Jahren von sicheren und zuverlässigen Arbeit. Bitte lesen Sie
diese Bedienungsanleitung sorgfältig vorher Inbetriebnahme, so dass Sie alle wichtigen Fragen wissen.
Haben Sie Interesse an neuen Produkten oder erweitern Sie Ihre oneQ, besuchen Sie die Website www.one-q.com.
READ CAREFULLY

-3-
oneQ B.V. 2022
one-q.com
INTRODUZIONE
Congratulazioni per l'acquisto della vostra oneQ WOK BURNER!
Il oneQ è fatta per fornire burnerfun per anni. I più elevati sono fatte sulla convenienza e la sicurezza.
l bruciatore a gas oneQ ha una combustione estremamente pulita e un flusso d'aria ottimale. Il burnercomponents sono
fatti da Heath stainess resistente rubare e sono ottimali resistente alla corrosione.
Nel caso in cui il burner viene utilizzato correttamente e mantiene il corretto funzionamento della sicurezza e relaible per
anni. Leggere attentamente le istruzioni prima di utilizzare o installare il burner, per cui siete a conoscenza di tutte le
questioni importanti.
Se sei interessato a prodotti nuovi o l'ampliamento del vostro oneQ, per favore visita il sito www.one-q.com.
INTRODUCTION
Félicitations à l'achat de votre oneQ WOK BURNER!
Le oneQ est concu pour fournir des années de plaisir de burner. Les plus hautes exigences sont faites sur la facilité et la
sécurité.
Le brûleur à gaz oneQ a une combustion très propre et une circulation d'air optimale. Le burner composants sont
fabriqués en acier inoxydables refractaires ou sont protégés contre la corrosion optimale.
Lorsque le burner est utilisé et maintient correctement, il travaillera de sécurité et relaible beaucoup des années. Lire
attentivement le manuel avant d'utiliser ou d'installer le burner, si vous êtes au courant de toutes les questions importantes.
Si vous êtes intéressé par de nouveaux produits ou l'élargissement de votre oneQ cuisine d'ete, s'il vous plaît visiter le site
Internet www.one-q.com.
INTRODUCTION
Onnittelumme oneQ WOK BURNER -grillin hankinnan johdosta!
oneQ on valmistettu tuottamaan sinulle grillausiloa vuosiksi eteenpäin. Olemme täyttäneet korkeimmat vaatimukset laadun
ja turvallisuuden kannalta.
oneQ polttimessa on erittäin puhdas palaminen ja optimaalinen ilmavirta. Polttimen komponentit on valmistettu korkeaa
kuumuutta kestävästä ruostumattomasta korroosiota kestävästä teräksestä.
Kun grilliä käytetään ja huolletaan asianmukaisesti toimii se turvallisesti ja luotettavasti vuosia. Lue kaikki ohjeet huolellisesti
ennen grillin asennusta ja käyttöä, jotta olet tietoinen kaikista grilliä koskevista tärkeistä seikoista.
Lisätietoa löytyy www.one-q.com.
INLEDNING
Grattis till att köpa din OneQ WOK BURNER!
OneQ är gjord för att ge dig grillfunktioner i flera år.
Högsta krav ställs på komfort och säkerhet.
OneQ gasbrännaren har extremt ren förbränning och optimal luftflöde. Brännarkomponenterna är gjorda av
värmebeständigt rostfritt stål och är optimalt resistenta mot korrosion.
Om grillen används och underhålls korrekt fungerar den på ett säkert och tillförlitligt sätt i flera år. Läs igenom
bruksanvisningen noga innan du använder eller installerar grillen så att du är medveten om alla viktiga funktioner.
Om du är intresserad av att utöka nya produkter eller utöka din OneQ-uppsättning, besök www.one-q.com eller sök oss
på Facebook.

-4-
oneQ B.V. 2022
one-q.com
oneQ LEGS:
¼” LH connection

-5-
oneQ B.V. 2022
one-q.com




-6-
oneQ B.V. 2022
one-q.com
WOK AND SIDE BURNER ASSEMBLY TO oneQ LEGS
The burner hangs loose in the slot of the stand. Choose an accessible place for you to install the controls in the preparation
of the burner.
Üfigure A Carefuly release the wok and side burner in the slot of the stand.
Üfigure B Place the wok burner lid, knob and battery into the appliance.
CONNECTION GAS BOTTLE
The oneQ gasburner is suitable for both propane and propane / butane (gas). We advise you to use standard 5 or 10 kg
cylinders. Use a regulator that matches the pressure indicated on the date plate (EN16129).
Üfigure C Place the cylinder on ground, then attach the hose to the gas tap by turning/ tighten the nut.
The valve has a standard 1/4” LH connection.
OPERATION AND FIRST USE
The appliance is fully assembled and properly adjusted at the delivery by the manufacturer. In the first use of the wok and
side burner it is
important that you completely remove all packaging materials.
Üfigure D Press the control knob and turn it to the left to the ignition position until the burners are
burning completely.
Depending on the type of gas and gas pressure the oneQ burner has a load of 6,5kW. The burnerpower can be adjusted
with the knob.
TROUBLESHOOTING
Failures Possible Cause Solution
Burner will not ignite - ignitionpin dirty clean pin
or does not burn - cylinder (almost) empty replace cylinder
completely. - hose kinked remove kink
- restriction air intake manifold release air intake
- burner tubes are wet (after cleaning) leave to dry
- Defective pressure regulator replace
Üfigure E The air intake at the bottom of the manifold should have an unobstructed air input. If there is
dirt in it you should remove it.
If the problem remains unresolved then contact your oneQ supplier.
CLEANING & MAINTENANCE
We recommend cleaning the burner after each use. Check all areas where oil, grease or food residue may accumulate, then
you keep all parts in optimal condition.
SERVICE, WARRANTY AND CERTIFICATIONS
If you have problems with your oneQ wok and side burner or if you want to order (reserve) parts, contact your dealer or
see
www.one-q.com, where you find an extensive customer service section.
The oneQ wok and side burner measures up to the NEN-EN 484 standard for wok burner and is certified by the world-
renowned KIWA GASTEC testing station for gas appliances.
ONEQ B.V.

-7-
oneQ B.V. 2022
one-q.com
oneQ BUILT-IN:
With built-in Adaptor and Socket With built-in Socket only:
Full built-in instructions are included with the oneQ Built-in Socket and Built-in Adaptor.
Go to one-q.com for more information.

-8-
oneQ B.V. 2022
one-q.com
SAFETY MEASURES AND WARNINGS
• This wok and side burner uses inflammable gas and creates excessive heat. Therefore, it is very important that you
follow all the safety instuctions consistently, to prevent risk, damage or accidents.
• The top bench of the wok and side burner are extremely hot during use. Contact while in use may cause burns to
body, clothes or other sensitive materials. Also, after using these parts stay hot for a long time. Use heat resistent gloves
like oven mitts.
• Make sure you wear fire resistent clothes while using the barbecue. Some synthetic materials are very fire sensitive and
should not be worn. Do not wear loose clothes or clothes that blow away easily if they can catch fire unexpectedly.
• Only use this appliance outdoors. Never use the wok and side burner in confined spaces like a garage, barn nor other
kind of building. Never use the appliance in or on recreational vehicles or boats.
• Use a firm flat surface where the appliance stands stable and at state level as much as possible. Do not move the
appliance while using.
• Make sure there are no childeren playing, sitting or standing around the wok and s ide burner.
• Do never cover up the (gas)burner with something like a plate or foil during use. Also never cover up the air holes in
the burner. This will cause not enough air flow and a foul burning of gas which can cause the release of toxic gases like
Carbon monoxide (CO). In case you want to cover the food while using the barbecue you must only use the suitable
(optinal) cover, this ensures proper airflow.
• Do not heat up any unopend cans because the accumulated pressure can lead to bursting of the cans.
• Keep the burner away from flammable materials. Grease is flammable. Let hot grease cool down before you remove it.
USAGE
• Execute each time you start using the wok and side burner or at any replacement of the gas cylinder the “no leakage
test”. If there is any suspicion of gas leaks, turn the gas knob Off and close the tap on the gas cylinder. Make sure you
have your equipment checked at your authorized dealer or certified gas fitter.
• Inspect the gas hose each time before using the barbecue. Make sure that it is not kinked. If there is extensive wear or
damage to the hose you should replace it. Do not use a hose that is longer than 1.50 meters. Refer to the local national
standards that apply, these may differ.
• The output pressure of the pressure regulator should match the pressure that is listed on the date plate of the wok and
side burner.
• Never use a dented or rusted gas cylinder or a cylinder with a damaged valve. Store cylinders always upright (even
empty ones). Buy or lease a new cylinder always at an authorized company as a camping store.
• Ensure that during the changing of the cylinder no ignition sources are near the cylinder. Place the gas cylinder always at
the appropriate cross between the appropriate cams.
• Only clean the parts when they are cooled down appropriately. Some cleaners produce unhealthy fumes or ignite even
if they are used on a hot surface. Make sure the wok and side burner is not opperating during cleaning.
• If you notice a gas leak or lack of operation of the barbecue, turn the gas off and do not use the appliance anymore.
Conact your oneQ dealer and let him/her check the wok and side burner for defects.
• Authorized companies in your country must carry out repair- or replacement work on the (gas) burner and gas
components. In this work, the local standards and regulations concerning liquid gas appliances are to be complied to.
You may never do this unless otherwise noted in this guide. Yourself. In case you deviate from this, you will create
major risks and any kind of warrenty wil be revoked.

-9-
oneQ B.V. 2022
one-q.com
• Always close the tap on the gas cylinder when you no longer use the barbecue.
• Applying modifications to the equipment is dangerous and prohibited.
• The manufacturer can not be held responsible for accidents, injury or damage caused by unappropriate use of oneQ
wok and side burner.
• Always use a certified flexible tube that is suitable for Propane/Butane and not longer that 150cm. Your dealer can
supply it to you.
• Vent openings in the container compartment and on the appliance should not be obstructed in any way.
• Check all vent openings and access to the venturi of the appliance before every use and remove any dirt or any
blockages.
STORAGE
When storing the appliance for extended periods, be certain all controls and cylinder valves are turned off.
Gas cylinders must be stored outdoors, out of reach of children and must not be stored in a building, garage or any other
enclosed area. The gas cylinder supply valve must be turned off when the appliance is not in use.
VENTILATION
When building the appliance in a confined space, make sure 2 opposite openings (top/bottom, top-back/top-front, top-
left/top-right) of at least 20x3cm are applied for proper ventilation for the appliance to function.
For installations having enclosed cabinetry, low level venting must be installed. This is to allow the gas which is heavier than
air to escape from the enclosure in the situation where there may be a leak. A minimum opening of 200cm2 is required.
POSITION OF THE GAS CYLINDER
Do not place a gas tank directly below the appliance when using hot liquids that may leak onto the gas tank.

-10-
oneQ B.V. 2022
one-q.com
ONEQ WOK BURNER (PROD. NO. 202201702/202201703)
For more options go to www.one-q.com or contact oneQ at [e-mail]
