Onida Induction cooker User manual

Instr uction manual
for induction cooker
Thank you for purchasing this ONIDA induction cooker. Please thoroughly read
through this instruction manual before use and store it carefully for future use.
The pictures are only for reference, please keep the real product as a standard.
If there is technical amendment for the product, it will be edited into the updated
version of the instruction manual. Please be aware that we will not inform
customers of this separately. If the appearance or color of the product is modified,
please refer to the real appliance as a standard..

Safety instructions
Product introduction
Preparation
Instructions for use
Cleaning and maintenance
Self-diagnosis for abnormalities
Guarantee for repairs and service
……………………………………………………（1）
…………………………………………………（5）
……………………………………………………………（5）
……………………………………………………（6）
……………………………………… （11）
………………………………… （11）
……………………………… （12）
Table of contents
Applicable model list
OIC19K52B
Model Rated power
230V~2100W
Rated
voltage Rated frequency
50Hz
Dimension
(mm)
280x355x62
Pulsated

1
Symbols: AttentionWarningMandatoryForbidden
Safety instructions
For safety reasons and to avoid damage to the appliance or
injuries to people, please abide by all the safety instructions
below.
Ignoring safety warnings may result in injuries.
This appliance does not take into consideration
the following situations:
--- use by children or disabled people without
supervision;
--- children treating it as a toy.
Do not directly rinse this induction
cooker under water. Do not spill water or
soup into the internal parts of the
induction cooker.
Never heat foods in sealed containers,
such as compressed products, cans, or
coffee pots, to avoid explosion caused
by heat expansion.
To avoid affecting product performance
and to prevent injury, do not heat empty
pots. When in use, do not leave the
appliance without supervision for a long
time. When leavi ng the appli ance
without supervision, make sure there is
enough water in the pot.
To avoid accidents, do not place the
induction cooker, when in use, on a gas
stove (the magnetic lines can heat the
metal parts of the gas stove).
The utensils provided for the induction
cooker can only be used for cooking with
it. These cooking utensils cannot be
used on both induction cooker and gas
stove.
Do not heat iron items on the induction
cooker heating plate to avoid danger
caused by high temperatures.

2
>10cm >10cm
Safety instructions
To avoid injuries such as scalding, do
not let children operate the appliance
alone.
Unplug the power cord from the outlet
after use to avoid fire and/or damaging
the electronic components, caused by
prolonged electrical connection.
To avoid danger, do not insert any
foreign object, such as iron wire, nor
block the air ventilation opening or air
entry port.
People with heart pacemakers should
consult a doctor. Only use the appliance
after confirming that it does not affect
the pacemaker.
To avoid danger, do not place paper,
aluminium foil, cloth or other unsuitable
articles on to t he induction c oo ke r
heating plate for indirect heating.
To avoid damage, avoid causing impacts
on the heating plate. If damaged, please
stop using it and take it to a maintenance
and repair site to have it replaced.
When using the induction cooker, do not
put it on any metal platform (such as
iron, stainless steel, aluminium), or
place a non-metal pad less than 10cm
thick on the heating plate.
When using the induction cooker, place
it horizontally and allow at least 10cm of
free space between the sides and back
of the induction cooker and the wall. Do
not use the induction cooker in narrow
spaces. To avoid hindering release of
heat, d o not cover the ve ntilation
opening.

3
≥10A
To avoid danger, if the power cord is
damaged, have it replaced by agents of
the m an ufactur er, its m ai ntena nc e
department or specialized personnel
from a similar department.
Please use a dedicated and high quality
power outlet, with high power rating,
equal to or above 10A. Do not use poor
quality outlets. Do not share the power
outlet with electrical appliances with
h i g h p o w e r r a t i n g s , s u c h a s a i r
conditioners, electrical stoves etc to
avoid fires caused by overburdening the
outlet.
When using the induction cooker or after
use, please keep it clean. Protect the
induction cooker from bugs, dust and
humidity. Avoid letting cockroaches etc
fall in to the i nternal p arts of the
induction cooker and causing a short
circuit of the electrical board. When not
in use for a long period, please clean it
and put it into a plastic bag to store it.
Do not touch the cooker plate with sharp
tools to avoid cracking or damaging the
plate. If cracking is found on the cooker
plate, turn off the appliance to avoid any
electrical shock that might occur.
Do not use the induction cooker by
putting it onto a carpet, tablecloth or thin
paper to avoid blocking the air inlet
opening or air outlet opening, which
results in influencing heat emission.
Do not use the induction cooker near a
gas stove, kerosene stove, gas cooker
or in any space with an open fire or an
environment with high temperature.
Metal objects, such as knives, forks,
spoons and lids, should not be put on the
surface of the cooking area, since they
can become heated.
The cooker cannot be overloaded.
Overloading the plate may damage the
plastic cover and cooker plate.
Safety instructions

4
Safety instructions
Always clean the induction cooker to
prevent mess from getting into the fan,
whi c h c o uld i nfl u enc e the n orma l
operation of the appliance.
When operating the appliance or after
moving the pot, the cooking area will
remain hot for a period of time. Do not
touch it, be careful of scalding caused by
the high temperature.
Danger of
scalding
Note:
1. The adult should supervise the children in order to make sure the
children can not play with the appliance.
2. This appliance is not intended for use by persons (including
children ) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction. concerning use of the appliance by a
person responsible for their safety.
3. This appliance is intended to be used in household and similar
applications such as: -staff kitchen areas in shops, offices and other
working environments; -farm houses;-by clients in hotels, motels
and other residential type environments ; -bed and breakfast type
environments.
4. Never have the induction hotplate to work without food inside,
otherwise its operational performance may be affected and danger
may happen.
5. We suggest that you should periodically check that there are no
object (glass, paper, etc) that could obstruct the inlet under your
induction hotplate.
6. Keep electrical appliance out of reach from children or inform
person. Do not let them use the appliances without supervision.

5
Instructions for product use
Product summary
This induction cooker is designed for household use. Please refer to
the instructions for detailed cooking methods.
Part list Air outlet Power cord
Air intake
Control panel
Cooker plate
Preparation
Before using, please first check if the power plug connects well with
the power outlet.
Before placing the pot on the cooker plate, please clean up water
stains, oil spots or any other adherent dirt from the outside surface of
the pot and cooker plate.
Please put the pot to be heated on the central part of the induction
cooker. Do not put an empty pot on the cooker plate to be heated.
Cooking zone

6
Instructions for use
Connecting the power and switching on
ON/OFF
Function selection
Power adjustment
After pressing the “On/Off” key, the induction cooker
enters the working status.
After pressing the “On/Off” key, if there is no proper pot
on the cooker plate, the induction cooker will not heat up
and the alarm will sound to indicate that a pot is required.
One minute later, it will switch off automatically.
After switching on the appliance, press the corresponding function
key to enter the desired cooking mode.
Please refer to “Functional cooking mode instructions” for the
details of the corresponding heating process for each cooking
mode.
After selecting a mode, if needed, you can press power
keys “+” or “-” to adjust the power.
For some modes, during the heating procedure, the
induction cooker can automatically adjust the power
according to the cooking effect.
For certain modes, the power is restricted complying
with the cooking effect.
Note: LAVA COOK is the maximum temperature range
cooking.
ON/OFF
Switch off
When the operating time is over, the induction cooker
switches off automatically.
If switch-off is needed in advance, press the “ON/OFF”
key to turn the appliance off.

7
Instructions for use
Pause
Pause/
Start
The pause function is designed for temporarily stopping
heating during the normal operation process. You can
switch to pause status in any cooking mode.
During operation, when pause is needed, please press
the function key “Pause”. Now, the pause indicator lights
up, the display and other function indicators stay in the previous
status. The power indicator turns off and the induction cooker stops
heating.
When the induction cooker is in pause, press the “Pause” key again
or select any cooking mode to quit the pause status and return to the
normal heating process.
After setting pause, the induction cooker stops heating. The default
pause time interval is 10 minutes. After 10 minutes, if the pause
mode is not cancelled, the induction cooker will sound an alarm. The
alarm will last for several seconds, then the induction cooker will
switch off automatically.
Timer adjustment
If timer operation is not needed or this function is not
provided, the induction cooker will heat the ingredients
for the default time duration (for the detailed time
duration, refer to “Cooking mode instruction”).
If timer is needed, first press the “Timer” key. When the
timer indicator lights up and the
numbers blink on the display, press the key “+” or “-” to adjust the
time duration.
When the adjustment is finished, the number on the display will be
shown after blinking for several seconds. The induction cooker starts
counting down.
When the counting down is over, the induction cooker automatically
stops heating and switches off(in Veg Curry mode, the automatic
keeping warm function starts) .
For particular modes, the timer function does not work. For
Milk\Tea\Coffe function, the timer uses a counting up method.
Timer

8
Instructions for use
Functional cooking mode instruction
User can select among the different cooking modes according to
cooking purpose. For your convenience, we provide the following
instruction:
The “Pressure cooker” individually fit to heating
requirements, such as rice cooking and boiling
water. In the heating procedure, the time and power
can be adjusted at any time. If the water in the pot
dries up or the temperature is abnormally high, the
induction cooker automatically switches off or
starts protection function.
Pressure
cooker
Veg curry
The cooking modes of Deep-fry and Roti/Dosa fit to
high temperature cooking. When the temperature of
the ingredients reaches the temperature level
provided by the selected mode (the highest
temperature of various modes are different), the
induction cooker will switch to interval heating or
stops heating. After the temperature cools down,
the induction cooker restarts heating.
For the cooking modes of Veg curry and Idli/Dhokla,
the induction cooker can automatically control the
power according to the time duration that has been
set and the temperature of the ingredients. Under
these modes, the power can be adjusted within the
adjustable power range at any time. After this
manual adjustment, the induction cooker will return
to auto power control according to the cooking
purpose two minutes later. Among these modes,
when veg curry mode is selected, the induction
cooker will start the auto two-hour keeping warm
function after the operation is finished.
Roti/Dosa
Deep fry
Idli/
Dhokla

9
Instructions for use
Functional cooking mode instruction
Milk\Tea\Coffee mode fits for boiling water.
Milk
Tea
Coffee
Note:
1. It is recommended to put water that occupies 30% to 80% of the
pot capacity when boiling water.
2. When boiling water, factors such as uneven pot bottom, scale or
weather conditions could influence the boiling effect.
3. Please use the specific stock pot or water kettle when boiling
water.
4. Under this mode, the power cannot be adjusted.
Keeping warm cooking mode fits for cooking that
needs gentle heat to maintain warmth. Under this
mode, the induction cooker heats the ingredients
with gentle power to maintain a certain temperature
inside the pot.
Keep warm
Note:
Under this mode, the power cannot be adjusted.
When residual heat LED is lighting, It shows the glass plate is hot so
don’t touch it by your hands to avoid scalding.
Residual heat

11
120 60 60
Instructions for use
Functional cooking mode instruction
The default time duration of heating for each mode is shown in the
following table:
Mode R o t i
Dosa Deep fry
Default time duration
of heating (Minute)
Note: The table above provides the time duration of heating for general modes. The time duration for
certain modes of some products is not included. Please refer to the real time duration as a standard.
a
c
ef
b
d
Please use the attached pots sold by ONIDA. Do not use other pots
as replacements to avoid influencing the performance.
The maximum load for the frying pan is 4kg. When using it, do not let
the weight of the ingredients exceed this weight to avoid danger.
If other pots are used, please comply with the following conditions:
1. Requirements for pot material: containing iron material.
2. Requirement of pot shape: with even bottom, the diameter is not
less than 12cm and not more than 20cm.
Proper pots
Iron stock pot Iron milk pot
Iron wok Iron water kettle
Iron frying pan Iron steamer pan
Note: For optimum performance, please use the standard pots
provided.
pressure
cooker
V e g
curry
Idli
Dhokla
Keep
warm
120120120

11
Cleaning and maintenance
Before cleaning, please switch off the appliance first and then
disconnect the power plug from the power outlet. Wait till the cooker
plate of the induction cooker is not hot and start cleaning.
After using the induction cooker for a long time, the opening of air
inlet/air outlet will pile up with dust or other dirt, please wipe it with a
soft dry cloth. Dust in the air inlet and outlet can be cleaned by using
a soft brush or a mini vacuum cleaner.
Note: Please do not rinse it with water
For oil spots on the cooker plate, wipe the cooker plate by using a
soft moist cloth with a little tooth paste or mild detergent. And then
use a soft moist cloth to wipe it until no stain remains.
When not using it for a long time, please disconnect the power plug
from the power outlet and protect the induction cooker from any dust
or bugs.
Self-diagnosis for abnormalities
Abnormalities Key checking points and trouble shooting
After plugging in the power cord
and pressing the “ON/OFF” key,
the indicator and display do not
light up.
The “ON/OFF” indicator lights up
and the display works normally, but
heating does not start.
Heating suddenly stops during the
process.
Is the power plug properly connected?
Is the switch, power outlet, fuse or power cord
damaged?
Is the pot material proper?
Is the appliance in a “Preset” working status?
For other causes, please take the appliance to a
repairing and maintenance site to be fixed.
Is the temperature of the oil too high when frying
dishes?
Is the temperature of the surroundings very
high?
Is the air inlet or air outlet of the induction
cooker blocked?
Is the default heating time of the induction
cooker over?
The self-safety protection of the induction
cooker starts, wait for several minutes and
connect power to use it.

13
Self-diagnosis for abnormalities
The protection codes appear
Protection for over-
high temperature
Protection for over-
high temperature of
the cooker plate
Protection for over-
h i g h / o v e r - l o w
voltage
The temperature inside the induction cooker is too high.
When the temperature lowers, press the “ON/OFF” key,
the heating can start normally.
The temperature of the cooker plate is too high. When
the temperature lowers, press the “On/Off” key, the
heating can start normally.
When the voltage restores normally, the appliance can
restart heating automatically.
Pr ot ec t io n f or t he
inner sensor of the
induction cooker
When using the induction cooker, if the temperature of
the surroundings is too low, the auto protection function
will start. With switching on the appliance again or
switching after simple warm-up, the appliance can
return to normal working status automatically.
Call the service number or the professional repair and
maintenance site to make an inquiry.
The description above is for diagnosing and checking common issues. If the problems cannot be
solved, please send the product to a repair and maintenance site or make an inquiry by calling service
number.
Do not disassemble or repair the product by yourself to avoid product damage or personal injury.
If problems occur with the product, please contact our specific repair
and maintenance site or service center.
One year warranty for the whole chassis of ONIDA induction cookers.
The starting warranty date refers to the invoice opening date of the product.
Any problem caused by the following items is not included in the warranty:
1. Damage caused by incorrect use, storing or maintenance by the customer.
2. Disassembling or repairing the appliance by a repair agent that is not
appointed by our company, resulting in damage to the appliance.
3. The model number on the invoice is different from the one of the product to
be repaired, or the model number on the invoice is modified.
4. No valid invoice.
5. Damage due to force majeure.
6. Putting the induction cooker to commercial use.
7. ONIDA is not responsible for accidents arising due to the use of ONIDA
accessories not designed for utlilisation with this product.
8. Using the product in a non-household environment is not covered by the
warranty scope.
9. Man-made issue or problems caused by incorrect use are not covered by
the warranty scope.
For those products beyond the warranty, the customer service center of
the company will still serve you warmly.
Guarantee for repairs and service
Protection when using
not applicable pot of
cooker
Protection when effective heating area of pot is too
small or pot deformation, only press “ON/OFF” key and
change cooking cooker to resume heating.

13

14
