Onkyo DV-SP503E User manual

En
Super Audio CD &
DVD Audio/Video player
DV-SP503E
Instruction Manual
Thank you for purchasing the Onkyo DV-
SP503E Super Audio CD & DVD Audio/Video
player. Read this manual carefully before using
your new DVD Player. A good understanding of
its features and operation will allow you to
achieve optimum performance and enjoyment.
Keep this manual for future reference.
Contents
Overview ..............................................2
Connections ......................................18
Getting Started and Setting up ........25
Basic Playback ..................................26
Playback Techniques ........................30
Detailed Settings ...............................43
Miscellaneous information...............54
Downloaded From Disc-Player.com Onkyo Manuals

2
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radia-
tors, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are pro-
vided for your safety. If the provided plug does not
fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience recepta-
cles, and the point where they exit from the appara-
tus.
11. Only use attachments/accessories specified by the
manufacturer.
12.
Use only with the cart, stand,
tripod, bracket, or table spec-
ified by the manufacturer, or
sold with the apparatus.
When a cart is used, use cau-
tion when moving the cart/
apparatus combination to
avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
15. Damage Requiring Service
Unplug the apparatus from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
A. When the power-supply cord or plug is damaged,
B. If liquid has been spilled, or objects have fallen
into the apparatus,
C. If the apparatus has been exposed to rain or
water,
D. If the apparatus does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as an improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the apparatus to its normal operation,
E. If the apparatus has been dropped or damaged in
any way, and
F. When the apparatus exhibits a distinct change in
performance this indicates a need for service.
16. Object and Liquid Entry
Never push objects of any kind into the apparatus
through openings as they may touch dangerous volt-
age points or short-out parts that could result in a
fire or electric shock.
The apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as
vases shall be placed on the apparatus.
Don’t put candles or other burning objects on top of
this unit.
17. Batteries
Always consider the environmental issues and fol-
low local regulations when disposing of batteries.
18. If you install the apparatus in a built-in installation,
such as a bookcase or rack, ensure that there is ade-
quate ventilation.
Leave 20 cm (8") of free space at the top and sides
and 10 cm (4") at the rear. The rear edge of the shelf
or board above the apparatus shall be set 10 cm (4")
away from the rear panel or wall, creating a flue-like
gap for warm air to escape.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage”within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN RISQUE DE CHOC ELECTRIQUE
NE PAS
OUVRIR
AVIS
PORTABLE CART WARNING
S3125A
Downloaded From Disc-Player.com Onkyo Manuals

3
Precautions
This unit contains a semiconductor laser system and is
classified as a “CLASS 1 LASER PRODUCT”. So, to
use this model properly, read this Instruction Manual
carefully. In case of any trouble, please contact the store
where you purchased the unit.
To prevent being exposed to the laser beam, do not try
to open the enclosure.
DANGER:
VISIBLE AND INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCK FAILED OR
DEFEATED. DO NOT STARE INTO BEAM.
CAUTION:
THIS PRODUCT UTILIZES A LASER. USE OF
CONTROLS OR ADJUSTMENTS OR PERFOR-
MANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARD-
OUS RADIATION EXPOSURE.
The label on the right is
applied on the rear panel
except for USA and Canadian
models.
1. This unit is a CLASS 1 LASER PRODUCT and employs a
laser inside the cabinet.
2. To prevent the laser from being exposed, do not remove the
cover. Refer servicing to qualified personnel.
For U.S. model
The laser is covered by a housing which prevents expo-
sure during operation or maintenance. However, this
product is classified as a Laser Product by CDRH (Cen-
ter for Devices and Radiological Health) which is a
department of the Food and Drug Administration.
According to their regulations 21 CFR section 1002.30,
all manufactures who sell Laser Products must maintain
records of written communications between the manu-
facturer, dealers and customers concerning radiation
safety. If you have any complaints about instructions or
explanations affecting the use of this product, please
feel free to write to the address on the back page of this
manual. When you write us, please include the model
number and serial number of your unit.
In compliance with Federal Regulations, the certifica-
tion, identification and the period of manufacture are
indicated on the rear panel.
FCC INFORMATION FOR USER
CAUTION:
The user changes or modifications not expressly
approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules.
These limits are designed to provide reasonable protec-
tion against harmful interference in a residential instal-
lation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a partic-
ular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and
receiver.
•Connect the equipment into an outlet on a circuit dif-
ferent from
•that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV tech-
nician for help.
Downloaded From Disc-Player.com Onkyo Manuals

4
Precautions —Continued
For Canadian model
NOTE:
This class B digital apparatus complies with
Canadian ICES-003.
For models having a power cord with a polarized plug:
CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
Modèle pour les Canadien
REMARQUE:
Cet appareil numérique de la classe B
est conforme àla norme NMB-003 du Canada.
Sur les modèles dont la fiche est polarisee:
ATTENTION:
POUR ÉVITER LES CHOCS ÉLEC-
TRIQUES, INTRODUIRE LA LAME LA PLUS
LARGE DE LA FICHE DANS LA BORNE CORRE-
SPONDANTE DE LA PRISE ET POUSSER
JUSQU’AU FOND.
For British models
Replacement and mounting of an AC plug on the power
supply cord of this unit should be performed only by
qualified service personnel.
IMPORTANT
The wires in the mains lead are coloured in accordance
with the following code:
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead of this
apparatus may not correspond with the coloured mark-
ings identifying the terminals in your plug, proceed as
follows:
The wire which is coloured blue must be connected to
the terminal which is marked with the letter N or
coloured black.
The wire which is coloured brown must be connected to
the terminal which is marked with the letter L or
coloured red.
IMPORTANT
A 3, 5 or 13 ampere fuse is fitted in this plug. Should the
fuse need to be replaced, please ensure that the replace-
ment fuse has a rating of 3, 5 or 13 amperes and that it is
approved by ASTA or BSI to BS1362. Check for the
ASTA mark or the BSI mark on the body of the fuse.
IF THE FITTED MOULDED PLUG IS UNSUITABLE
FOR THE SOCKET OUTLET IN YOUR HOME
THEN THE FUSE SHOULD BE REMOVED AND
THE PLUG CUT OFF AND DISPOSED OF SAFELY.
THERE IS A DANGER OF SEVERE ELECTRICAL
SHOCK IF THE CUT OFF PLUG IS INSERTED
INTO ANY 13 AMPERE SOCKET.
If in any doubt, consult a qualified electrician.
For European Models
1. Region Numbers
The DVD standard uses region numbers to control how
discs can be played around the world, the world being
divided into six regions. This unit will only play DVD
discs that match its region number, which can be found
on its rear panel (e.g., ).
2. About this Manual
This manual explains how to use all of this unit’s func-
tions. Although the DVD standard offers many special
features, not all discs use them all, so depending on the
disc being played, this unit may not respond to certain
functions. See the disc’s sleeve notes for supported fea-
tures.
When you attempt to use a DVD feature that is
not available, this logo may appear onscreen,
indicating that the feature is not supported by
the current disc or this unit.
3. Recording Copyright
Unless it’s for personal use only, recording copyrighted
material is illegal without the permission of the copy-
right holder.
4. Power
WARNING
BEFORE PLUGGING IN THE UNIT FOR THE
FIRST TIME, READ THE FOLLOWING SECTION
CAREFULLY.
AC outlet voltages vary from country to country. Make
sure that the voltage in your area meets the voltage
requirements printed on this unit’s rear panel (e.g., AC
120 V, 60 Hz).
Declaration of Conformity
We, ONKYO EUROPE
ELECTRONICS GmbH
LIEGNITZERSTRASSE 6,
82194 GROEBENZELL,
GERMANY
GROEBENZELL, GERMANY
ONKYO EUROPE ELECTRONICS GmbH
I. MORI
declare in own responsibility, that the ONKYO product
described in this instruction manual is in compliance with the
corresponding technical standards such as EN60065,
EN55013, EN55020 and EN61000-3-2, -3-3.
1
Downloaded From Disc-Player.com Onkyo Manuals

5
Precautions —Continued
5. Never Touch this Unit with Wet Hands
Never handle this unit or its power cord while your
hands are wet or damp. If water or any other liquid gets
inside this unit, have it checked by your Onkyo dealer.
6. Installing this Unit
•Install this unit in a well-ventilated location.
Ensure that there’s adequate ventilation all around
this unit, especially if it’s installed in an audio rack. If
the ventilation is inadequate, the unit may overheat,
leading to malfunction.
•Do not expose this unit to direct sunlight or heat
sources, because its internal temperature may rise,
shortening the life of the optical pickup.
•Avoid damp and dusty places, and places subject to
vibrations from loudspeakers. Never put the unit on
top of, or directly above a loudspeaker.
•Install this unit horizontally. Never use it on its side or
on a sloping surface, because it may cause a malfunc-
tion.
•If you install this unit near a TV, radio, or VCR, the
picture and sound quality may be affected. If this
occurs, move this unit away from the TV, radio, or
VCR.
7. Care
Occasionally, you should dust this unit all over with a
soft cloth. For stubborn stains, use a soft cloth damp-
ened with a weak solution of mild detergent and water.
Dry the unit immediately afterwards with a clean cloth.
Do not use abrasive cloths, thinners, alcohol, or other
chemical solvents, because they may damage the finish
or remove the panel lettering.
8. Handling Notes
•If you need to transport this unit, use the original pack-
aging to pack it how it was when you originally bought
it.
•Do not use volatile liquids, such as insect sprays, near
this unit. Do not leave rubber or plastic items on this
unit for a long time, because they may leave marks on
the case.
•This unit’s top and rear panels may get warm after pro-
longed use. This is normal.
•When you’ve finished using this unit, remove all discs
and turn off the power.
•If you do not use this unit for a long time, it may not
work properly the next time you turn it on, so be sure
to use it occasionally.
9.To Obtain a Clear Picture
This unit is a high-tech, precision device. If the lens on
the optical pickup, or the disc drive mechanism
becomes dirty or worn, the picture quality may be
affected. To maintain the best picture quality, we recom-
mend regular inspection and maintenance (cleaning or
worn part replacement) every 1,000 hours of use
depending on the operating environment. Contact your
Onkyo dealer for details.
10. Moisture Condensation
Moisture condensation may damage this unit.
Read the following carefully:
When you take a glass containing a cold drink outside
on a summer’s day, drops of water, called condensation,
form on the outside of the glass. Similarly, moisture
may condense on the lens of the optical pickup, one of
the most important parts inside this unit.
•Moisture condensation can occur in the following sit-
uations:
—The unit is moved from a cold place to a warm
place.
—A heater is turned on, or cold air from an air con-
ditioner is hitting the unit.
—In the summer, when this unit is moved from an
air conditioned room to a hot and humid place.
—The unit is used in a humid place.
•Do not use this unit when there’s the possibility of
moisture condensation occurring. Doing so may dam-
age your discs and certain parts inside this unit.
If condensation does occur, remove all discs and
leave this unit turned on for two to three hours. By
this time, the unit will have warmed up and any con-
densation will have evaporated. To reduce the risk of
condensation, keep this unit connected to a wall out-
let.
Downloaded From Disc-Player.com Onkyo Manuals

6
Table of Contents
Basic Operation
Overview
Important Safety Instructions.............................. 2
Precautions ........................................................ 3
Introduction......................................................... 7
DV-SP503E Features ..................................... 7
Supplied Accessories ..................................... 8
Disc Notes ...................................................... 9
Before Using the DV-SP503E .......................... 11
Installing the Batteries .................................. 11
Using the Remote Controller ........................ 11
Front & Rear Panels......................................... 12
Front Panel ................................................... 12
Display.......................................................... 13
Rear Panel.................................................... 14
Rear Panel.................................................... 15
Remote Controller ........................................ 16
Connections
Connecting the DV-SP503E............................. 18
Before Making Any Connections .................. 18
AV Cables & Connectors.............................. 18
Basic Setup .................................................. 19
Connecting Your TV ..................................... 20
Connecting to an AV Receiver ..................... 22
Connecting -compatible Components.... 23
Connecting the Power/Turning on the
DV-SP503E .................................................. 24
Getting Started and Setting up
Getting Started ................................................. 25
Using the on-screen displays ....................... 25
Setting up the player for your TV.................. 25
Setting the language of this player’s
on-screen displays ..................................... 26
Basic Playback
Playing discs................................................. 26
Basic playback controls ................................ 27
Resume and Last Memory ........................... 28
DVD disc menus........................................... 28
Video CD PBC menus .................................. 29
Advanced Operation
Playback Techniques
Playing discs..................................................... 30
Scanning discs..............................................30
Playing in slow motion...................................30
Frame advance/frame reverse......................31
Viewing a JPEG slideshow ........................... 31
Browsing video content with the Disc
Navigator ....................................................32
Browsing WMA, MP3 and JPEG files
with the Disc Navigator...............................33
Looping a section of a disc............................34
Using repeat play ..........................................34
Using random play ........................................35
Creating a program list..................................36
Other functions available from the program
menu........................................................... 37
Searching a disc............................................37
Switching subtitles.........................................38
Switching audio language/channel................38
Zooming the screen ...................................... 39
Switching camera angles ..............................39
Displaying disc information ...........................39
DivX® video playback on the DV-SP503E
(not North American model).......................... 40
About DivX .................................................... 40
Playing DivX video ........................................40
About DivX® VOD content............................ 42
Playing DivX® VOD content .........................42
Detailed Settings
Audio Settings and Video Adjust menus...........43
Audio Settings menu.....................................43
Audio DRC ....................................................43
Video Adjust menu........................................44
Initial Settings menu..........................................45
Using the Initial Settings menu......................45
Digital Audio Out settings.............................. 46
Video Output settings.................................... 46
Language settings......................................... 47
Display settings.............................................47
Options settings ............................................48
Speakers settings..........................................48
About the audio output settings.....................49
Parental Lock ................................................ 50
Registering a new password.........................50
Changing your password .............................. 50
Setting/changing the Parental Lock .............. 50
Setting/changing the Country code...............51
Country code list ........................................... 51
DTS Downmix ...............................................52
Audio Output Mode .......................................52
Speaker Installation.......................................52
Speaker Distance.......................................... 53
Downloaded From Disc-Player.com Onkyo Manuals

7
Table of Contents —Continued
Miscellaneous information
Additional information .......................................54
Screen sizes and disc formats ......................54
Setting the TV system
(Not North American model).......................54
Resetting the player ......................................55
Titles, chapters and tracks ............................55
DVD-Video regions .......................................55
Selecting languages using the language
code list ......................................................56
Language code list........................................57
Using the Remote controller with Other
Brand’s TVs (North American model only)....58
DivX Titles.........................................................60
Glossary............................................................62
FAQ...................................................................63
Troubleshooting ................................................64
DV-SP503E...................................................64
Remote Controller .........................................66
Specifications....................................................67
Introduction
Highlights
•Dolby
1
Digital and DTS
2
•DVD-Video / Video CD / Audio CD playback
•CD-R, CD-RW (Video CD, audio CD, MP3/WMA
3
/
JPEG)
•DVD-Audio and SACD compatible
•Super VCD compatible
•DVD-R (DVD-Video)
•DVD-RW (DVD-Video, VR format)
•5.1-channel analog audio output
Video
•Advanced 108 MHz/12-bit video D/A converter
•Component video output
•S Video and composite video outputs
•Frame-by-frame playback
•Slow motion playback
•Fast forward and reverse
•Repeat playback
•Random playback
•Supports 4:3 and 16:9 aspect ratio TVs
•Multiple camera angle support
•Parental Lock function
•Screen Saver function
Audio
•192 kHz/24-bit D/A converter
•Optical / Coaxial digital output
Others
•Dynamic Range Control setting
•Adjustable display brightness
•Full-function remote controller
The letter displayed at the end of the product name found in
catalogs and on package represents the color of the
DV-SP503E. Though the color varies, the specifications and
operations are the same.
DV-SP503E Features
1. Manufactured under license from Dolby Laboratories.
“Dolby”and the double-D symbol are trademarks of Dolby
Laboratories.
2. “DTS”and “DTS Digital Out”are trademarks of Digital The-
ater Systems, Inc.
3.
Windows Media, and the Win-
dows logo are trademarks, or reg-
istered trademarks of Microsoft
Corporation in the United States
and/or other countries.
Downloaded From Disc-Player.com Onkyo Manuals

8
Introduction —Continued
Make sure you have the following accessories:
Supplied Accessories
Remote controller & 2 batteries (AA)
AV cable (RCA) (1.5 m)
S Video cable (1.5 m)
cable (0.8 m)
This cable is used to connect the DV-SP503E to other
-compatible Onkyo components for (Remote
Interactive) control.
To use , in addition to an
connection, you must
make an analog audio connection (RCA) between the
DV-SP503E and your Onkyo AV receiver.
SCART cable (1.5 m) (European models only)
Power cord (2 m)
RC-582DV
(North American model)
RC-574DV
(Other model)
Power-plug adapter
Only supplied in certain countries. Use this adapter if
your AC outlet does not match with the plug on the DV-
SP503E’s power cord. (Adapter varies from country to
country.)
Downloaded From Disc-Player.com Onkyo Manuals

9
Introduction —Continued
Supported Discs
The DV-SP503E supports the following discs.
•Some audio CDs feature copy protection that doesn’t
conform to the official CD standard. Since these are
nonstandard discs, they may not play properly in the
DV-SP503E.
•The DV-SP503E supports CD-R and CD-RW discs
recorded in Video CD format, audio CD format, or
ISO 9660 Level 1 or 2 format with MP3, WMA, and
JPEG files. It also supports DVD-R and DVD-RW
discs recorded in DVD-Video format. However, some
CD-R, CD-RW, DVD-R, and DVD-RW discs may not
work properly for any of the following reasons:
incomplete disc finalization, disc burner characteris-
tics, disc characteristics, the disc is damaged or dirty.
See the manual supplied with your disc burner for
more information. Condensation or dirt on the optical
pickup lens can also affect playback.
•The DV-SP503E supports 8 cm and 12 cm discs.
•The DV-SP503E does not support disc types not
listed.
•Don’t use discs with an unusual shape, such as those
shown below, because you may damage the DV-
SP503E.
•Don’t use discs that have residue from adhesive tape,
rental discs with peeling labels, or discs with custom-
made labels or stickers. Doing so may damage the DV-
SP503E and you may not be able to remove the disc
properly.
Discs Made on Personal Computers
Discs made on personal computers, including those of a
compatible format, may not work properly in the DV-
SP503E because of incorrect settings in the disc burning
software. Check the manuals supplied with your disc
burning software for additional compatibility informa-
tion.
CD-R/RW compatibility
•Compatible formats: CD-Audio, Video CD, ISO 9660
CD-ROM* containing MP3, WMA or JPEG files
* ISO 9660 Level 1 or 2 compliant. CD physical format:
Mode1, Mode2 XA Form1. Romeo and Joliet file systems
are both compatible with this player.
•Multi-session playback: No
•Unfinalized disc playback: No
DVD-R/RW compatibility
•Compatible formats: DVD-Video, Video Recording
(VR)*
* Edit points may not play exactly as edited; screen may go
momentarily blank at edited points.
•Unfinalized playback: No
•WMA/MP3/JPEG file playback on DVD-R/RW: No
Compressed audio compatibility
•Compatible formats: MPEG-1 Audio Layer 3 (MP3),
Windows Media Audio (WMA)
•Sampling rates: 32, 44.1 or 48kHz
•Bit-rates: Any (128Kbps or higher recommended)
•VBR (variable bit rate) MP3 playback: No
•VBR WMA playback: No
•WMA lossless encoding compatible: No
•DRM (Digital Rights Management) compatible: Yes
(DRM-protected audio files will not play in this
player—see also DRM in the “Glossary”on page 62)
•File extensions: .mp3, .wma (these must be used for
the player to recognize MP3 and WMA files –do not
use for other file types)
•File structure: Up to 299 folders; up to 648 folders and
files combined
Disc Notes
Disc Logo Format or file type
DVD-Video
See page 55 for
region information.
DVD-Audio
DVD-Audio
SACD
Super Audio CD (sin-
gle layer, dual layer,
hybrid)
DVD-R
DVD-Video
DVD-RW
DVD-Video,
VR format
Video CD
Including PBC
Audio CD
PCM and DTS
CD-R
Video CD, audio CD,
MP3, WMA, JPEG
CD-RW
Video CD, audio CD,
MP3, WMA, JPEG
JPEG CD JPEG
Downloaded From Disc-Player.com Onkyo Manuals

10
Introduction —Continued
About WMA
WMA is an acronym for Windows Media Audio and
refers to an audio compression technology developed by
Microsoft Corporation. WMA content can be encoded
by using Windows Media
®
Player version 7, 7.1, Win-
dows Media
®
Player for Windows
®
XP, or Windows
Media
®
Player 9 Series.
JPEG file compatibility
•Compatible formats: Baseline JPEG and EXIF 2.2*
still image files up to a resolution of 3072 x 2048.
* File format used by digital still cameras
•Progressive JPEG compatible: No
•File extensions: .jpg (must be used for the player to
recognize JPEG files –do not use for other file types)
•File structure: Up to 299 folders; up to 648 folders and
files combined
PC-created disc compatibility
Discs recorded using a personal computer may not be
playable in this unit due to the setting of the application
software used to create the disc. In these particular
instances, check with the software publisher for more
detailed information.
Discs recorded in packet write mode (UDF format) are
not compatible with this player.
Check the DVD-R/RW or CD-R/RW software disc
boxes for additional compatibility information.
Copyright
It is forbidden by law to copy, broadcast, show, broadcast
on cable, play in public, or rent copyrighted material
without permission.
DVD-Video discs are copy-protected, and any record-
ings made from these discs will be distorted.
This product incorporates copyright protection technol-
ogy that is protected by method claims of certain U.S.
patents and other intellectual property rights owned by
Macrovision Corporation and other rights owners. Use
of this copyright-protection technology must be autho-
rized by Macrovision Corporation, and is intended for
home and other limited viewing uses only, unless other-
wise authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited.
Handling Discs
•Never touch the underside of a disc.Always hold discs
by the edge, as shown.
•Never attach adhesive tape or sticky labels to discs.
Cleaning Discs
•For best results, keep your discs clean. Fingerprints
and dust can affect the sound and picture quality and
should be removed as follows. Using a clean soft
cloth, wipe from the center outwards, as shown. Never
wipe in a circular direction.
•To remove stubborn dust or dirt, wipe the disc with a
damp soft cloth, and then dry it with a dry cloth.
•Never use solvent-based cleaning fluids, such as thin-
ner or benzine, commercially available cleaners, or
antistatic sprays intended for vinyl records, because
they may damage the disc.
Storing Discs
•Don’t store discs in places subject to direct sunlight, or
near heat sources.
•Don’t store discs in places subject to moisture or dust,
such as in a bathroom or near a humidifier.
•Always store discs in their cases and vertically. Stack-
ing, or putting objects on unprotected discs may cause
warping, scratches, or other damage.
Underside
✔
Downloaded From Disc-Player.com Onkyo Manuals

11
Before Using the DV-SP503E
Notes:
•The supplied batteries should last for about six
months, although this will vary with usage.
•If the remote controller doesn’t work reliably, try
replacing both batteries.
•Don’t mix new and old batteries, or different types of
batteries.
•If you intend not to use the remote controller for a long
time, remove the batteries to prevent possible leakage
and corrosion.
•Flat batteries should be removed as soon as possible to
prevent possible leakage and corrosion.
To use the remote controller, point it at the DV-SP503E’s
remote control sensor, as shown below.
Notes:
•The remote controller may not work reliably if the
DV-SP503E is subjected to bright light, such as direct
sunlight or inverter-type fluorescent lights. Keep this
in mind when installing the DV-SP503E.
•If another remote controller of the same type is used in
the same room, or the DV-SP503E is installed close to
equipment that uses infrared rays, the remote control-
ler may not work reliably.
•Don’t put anything, such as a book, on the remote con-
troller, because the buttons may be pressed inadvert-
ently, thereby draining the batteries.
•The remote controller may not work reliably if the
DV-SP503E is installed in a rack behind colored glass
doors. Keep this in mind when installing the DV-
SP503E.
•The remote controller will not work if there’s an obsta-
cle between it and the DV-SP503E’s remote control
sensor.
Installing the Batteries
1Open the battery compartment, as shown.
2Insert the two supplied batteries (AA) in
accordance with the polarity diagram
inside the battery compartment.
3Close the battery compartment.
Using the Remote Controller
RETURNSETUP
TOPMENUMENU
C
U
R
S
O
R
P
U
S
H
T
O
E
N
T
E
R
DV-SP503E
SUPER
AUDIO
CD&DVD
AUDIO
/
VIDEO
PLAYER
PROGRESSIVE
SCAN
PROGRESSIVE
30˚
30˚
Approx. 16 ft. (5 m)
Remote control sensor
DV-SP503E
Downloaded From Disc-Player.com Onkyo Manuals

12
Front & Rear Panels
For detailed information, refer to the pages in brackets.
ASTANDBY/ON button [24, 26]
This button is used to set the DV-SP503E to On or
Standby.
BSTANDBY indicator [24]
This indicator lights up when the DV-SP503E is in
Standby.
CDISPLAY button [39]
This button is used to display information about the
current disc, title, chapter, or track, including the
elapsed time, remaining time, total time, and so on.
Press it repeatedly to display more information.
DPLAY MODE button [34–37]
This button is used to open and close the Play Mode
menu.
EPROGRESSIVE indicator [20, 46]
This indicator lights up when the DV-SP503E is set
to output progressive scan video.
FDisc tray [26]
Discs are loaded here.
GTOP MENU button [28]
This button is used to display the top menu of a
DVD-Video disc.
HCursor /// &ENTER buttons [25]
The four cursor buttons located around the central
[ENTER] button are used to navigate DVD-Video
menus and the onscreen setup menus.
The central [ENTER] button is used to start play-
back of the selected title, chapter, or track and to
confirm settings.
IMENU button [28]
This button is used to display a menu on a
DVD-Video disc or to open the Disc Navigator
when using a Video CD, audio CD, WMA/MP3/
JPEG disc, or VR format DVD-RW disc.
J(open/close) button [26]
This button is used to open and close the disc tray.
K(pause) button [27]
This button is used to pause playback.
L(stop) button [27]
This button is used to stop playback.
M(play) button [26, 27]
This button is used to start playback.
NPrevious/Next / buttons [27]
The Previous button is used to select the previous
chapter or track. During playback it selects the
beginning of the current chapter or track.
The Next button is used to select the next chapter or
track.
OSETUP button [25]
This button is used to open and close the onscreen
setup menus.
PRETURN button [25, 28]
This button is used to return to the main menu with-
out saving your changes.
QRemote control sensor [11]
This sensor receives control signals from the remote
controller.
RCLEAR button [36]
This button is used to cancel various functions.
SDIMMER button
This button is used to adjust the display brightness.
Front Panel
RETURN SETUP
TOP MENU MENU
C
U
R
S
O
R
P
U
S
H
T
O
E
N
T
E
R
DV-SP503E
SUPER AUDIO CD & DVD AUDIO / VIDEO PLAYER
PROGRESSIVE SCAN
PROGRESSIVE
1 2 3 4 5 6 7 8 9 J
PON
K L M
SRQ
normal dim dimmer
Downloaded From Disc-Player.com Onkyo Manuals

13
Front & Rear Panels—Continued
1D indicator
This indicator appears when playing Dolby Digital
material.
2Disc type indicators
These indicators show the type of disc loaded.
3TITLE indicator
While stopped, the total number of titles on the cur-
rent DVD-Video disc is displayed here. During
playback, the number of the current title is dis-
played.
4GROUP indicator
While stopped, the total number of groups on the
current DVD-Audio disc is displayed here. During
playback, the number of the current group is dis-
played.
5TRACK indicator
This indicator appears while track numbers are
being displayed. While stopped, the total number of
tracks on the current SACD, Video CD, audio CD,
or MP3/WMA disc are displayed. During playback,
the number of the current track is displayed.
65.1 CH indicator
This indicator lights up when 5.1-channel analog
audio output is selected.
7CHP indicator
This indicator appears while the number of the cur-
rent chapter is being displayed.
8D.MIX indicator
During multichannel audio playback, indicates that
the output signal has been “downmixed”from the
original audio source. This is an automatic function
performed by the player in order to present the most
appropriate audio mix to the speakers present in
your system.
9RANDOM indicator
This indicator appears when using the Random
function.
0REMAIN indicator
This indicator appears while the remaining time is
being displayed.
ARepeat indicator
This indicator appears when A–B playback or
repeat playback is used.
BA–B indicator
These indicators appear when using the A-B Repeat
function.
CCamera angle indicator
This indicator appears if the DVD-Video disc being
played features multiple camera angles.
DDTS indicator
This indicator appears when playing DTS material.
EPlay indicator
This indicator is shown during playback.
FPause indicator
This indicator appears when playback is paused.
GPROGRESSIVE indicator
This indicator appears when the Progressive Scan-
ning function is on.
HMessage & time area
Time information, such as total time, remaining
time, and so on, is displayed here in hours, minutes,
and seconds. Other messages are also displayed.
IGUI (Graphical User Interface) indicator
This indicator appears when the onscreen setup
menu is open.
Display
75 6 8 9A
B
HE
D
0
G
1 2 C
34
IF
Downloaded From Disc-Player.com Onkyo Manuals

14
Front & Rear Panels—Continued
■Not European model
See page 15 for the European model.
AAUDIO OUTPUT [22–23]
These jacks output analog audio. The FRONT/
D.MIX jacks can be connected to the stereo input on
a TV, hi-fiamp, or other component. The 1 and 2
jacks output the same signals so you can use either.
DVDs with 5.1-channel audio are downmixed into
two channels before being output by the FRONT/
D.MIX jacks.
If you’re using an AV receiver or surround decoder
with a 5.1-channel analog audio input, use the
FRONT/D.MIX 1 or 2 jacks and the SURR L/R,
CENTER, and SUBWOOFER jacks. In this case,
you must set the Audio Output Mode on the Initial
Setup menu to 5.1 Channel. With this setting, the
FRONT/D.MIX jacks will output the front signals,
and the SURR L/R, CENTER, and SUBWOOFER
jacks will output the surround, center, and sub-
woofer signals respectively.
BCOAXIAL DIGITAL AUDIO OUTPUT [22]
This coaxial digital audio output can be connected
to a coaxial digital audio input on a hi-fiamp, AV
receiver, or surround sound decoder (Dolby Digital,
DTS).
COPTICAL DIGITAL AUDIO OUTPUT [22]
This optical digital audio output can be connected to
an optical digital audio input on a hi-fiamp, AV
receiver, or surround sound decoder (Dolby Digital,
DTS).
DVIDEO OUTPUT [19]
This RCA connector can be used to connect a TV or
projector with a composite video input.
ECOMPONENT VIDEO OUTPUT [20]
These jacks output component video and can be
connected to an component video input on a TV or
projector.
FS VIDEO OUTPUT [20]
This connector can be used to connect a TV or pro-
jector with an S Video input.
Gjack [23]
These (Remote Interactive) connectors can be
connected to the connectors on your other
Onkyo AV components for interactive control.
Connecting an cable only does not make the
system operational.You must also connect the audio
cables as well.
HAC INLET [24]
The supplied power cord is connected here. The
other of the power cord should be connected to a
suitable wall outlet.
Rear Panel
AC INLET
REMOTE
CONTROL
SUPER AUDIO CD & DVD AUDIO/
VIDEO PLAYER
MODEL NO. DV-SP 503E
RATING:
AC 120V 60 Hz 11 W
VIDEO
S VIDEO
R
L
SURR CENTER
12
FRONT/D. MIX
AUDIO OUTPUT
DIGITAL
SUB
WOOFER OPTICAL
COAXIAL
PB
Y
PR
COMPONENT
VIDEO OUTPUT
654 7 8321
Downloaded From Disc-Player.com Onkyo Manuals

15
Front & Rear Panels—Continued
■European Model
AAUDIO OUTPUT [22–23]
These jacks output analog audio. The FRONT/
D.MIX jacks can be connected to the stereo input on
a TV, hi-fiamp, or other component. The 1 and 2
jacks output the same signals so you can use either.
DVDs with 5.1-channel audio are downmixed into
two channels before being output by the FRONT/
D.MIX jacks.
If you’re using an AV receiver or surround decoder
with a 5.1-channel analog audio input, use the
FRONT/D.MIX 1 or 2 jacks and the SURR L/R,
CENTER, and SUBWOOFER jacks. In this case,
you must set the Audio Output Mode on the Initial
Setup menu to 5.1 Channel. With this setting, the
FRONT/D.MIX jacks will output the front signals,
and the SURR L/R, CENTER, and SUBWOOFER
jacks will output the surround, center, and sub-
woofer signals respectively.
BCOAXIAL DIGITAL AUDIO OUTPUT [22]
This coaxial digital audio output can be connected
to a coaxial digital audio input on a hi-fiamp, AV
receiver, or surround sound decoder (Dolby Digital,
DTS).
COPTICAL DIGITAL AUDIO OUTPUT [22]
This optical digital audio output can be connected to
an optical digital audio input on a hi-fiamp, AV
receiver, or surround sound decoder (Dolby Digital,
DTS).
DVIDEO OUTPUT [19]
This RCA connector can be used to connect a TV or
projector with a composite video input.
ECOMPONENT VIDEO OUTPUT [20]
These jacks output component video and can be
connected to an component video input on a TV or
projector.
FS VIDEO OUTPUT [20]
This connector can be used to connect a TV or pro-
jector with an S Video input.
GAV CONNECTOR [20]
This SCART output can be connected to a TV or
projector with a SCART input by using the supplied
SCART cable. This SCART connector outputs 2-
channel stereo audio, composite video, S Video, and
RGB video.
Hjack [23]
These (Remote Interactive) connectors can be
connected to the connectors on your other
Onkyo AV components for interactive control.
Connecting an cable only does not make the
system operational.You must also connect the audio
cables as well.
IAC INLET [24]
The supplied power cord is connected here. The
other of the power cord should be connected to a
suitable wall outlet.
Rear Panel
AC INLET
VIDEO
S VIDEO
R
L
SURR CENTER
12
FRONT/D. MIX
AUDIO OUTPUT
DIGITAL
SUB
WOOFER OPTICAL
COAXIAL
PB
Y
PR
COMPONENT
VIDEO OUTPUT
SUPER AUDIO CD & DVD AUDIO/
VIDEO PLAYER
MODEL NO. DV-SP 503E
RATING:AC 100-240 V
50/60Hz 12 W
REMOTE
CONTROL
AV CONNECTOR
1 6 87 95324
Downloaded From Disc-Player.com Onkyo Manuals

16
Front & Rear Panels—Continued
■North American models ■Other models
Remote Controller
STANDBY
ON
OPEN /
CLOSE
PLAY MODE
DISPLAY
DIMMER
TOP MENU MENU
RETURN SETUP
AUDIO ANGLE ZOOMSUBTITLE
TV CONTROL
TV/ VIDEO CHANNEL
VOLUME
ON
/
STANDBY
RC-582DV
123
4
5
6
789
0
CLEAR
ENTER
3
4
6
7
9
J
K
8
5
2
1L
M
N
O
Q
P
R
S
T
U
X
V
W
Y
ON STANDBY
DISPLAY
DIMMER
MENU
SETUP
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
RC-574DV
CLEAR
OPEN/
CLOSE
ENTER
123
6
789
0
45
PLAY
MODE
3
4
6
7
9
J
K
8
5
2
1L
M
N
O
Q
P
R
S
T
U
X
V
W
Downloaded From Disc-Player.com Onkyo Manuals

17
Front & Rear Panels—Continued
ASTANDBY button [24]
This button is used to set the DV-SP503E to
Standby.
BON button [24]
This button is used to turn on the DV-SP503E.
Don’t turn on the DV-SP503E until you’ve com-
pleted, and double checked all connections
(pages 18–23).
CNumber buttons [27–29, 37, 50]
These buttons are used to enter title, chapter, and
track numbers and to enter times for locating spe-
cific points in time.
DTOP MENU button [28]
This button is used to display the top menu on a
DVD-Video disc.
ECursor /// buttons [25]
These buttons are used to navigate onscreen menus.
FRETURN button [25, 28]
This button is used to return to the main menu with-
out saving your changes.
GAUDIO button [38]
This button is used to select foreign language
soundtracks and audio formats (e.g., Dolby Digital
or DTS) on DVD-Video discs.
For Video CDs you can select left-channel, right-
channel, or stereo.
HANGLE button [39]
This button is used to select camera angles on
DVD-Video discs.
IStop button [27]
This button is used to stop playback.
JFast Reverse / ( ) button [27, 30,
31]
This button is used for fast reverse, reverse slow
motion, and reverse frame-by-frame playback.
KFast Forward / ( ) button [27, 30,
31]
This button is used for fast forward, slow motion,
and frame-by-frame playback.
LOPEN/CLOSE button [26]
This button is used to open and close the disc tray.
MPLAY MODE button [34–37]
This button is used to open and close the Play Mode
menu.
NDISPLAY button [39]
This button is used to display information about the
current disc, title, chapter, or track, including the
elapsed time, remaining time, total time, and so on.
Press it repeatedly to display more information.
ODIMMER button
This button is used to adjust the display brightness.
PCLEAR [36]
This button is used to cancel various functions.
QMENU button [28]
This button is used to display the menu on a
DVD-Video disc or to open the Disc Navigator
when using a Video CD, audio CD, WMA/MP3/
JPEG disc, or VR format DVD-RW disc.
RENTER button [25]
This button is used to start playback of the selected
title, chapter, or track, and to confirm settings.
SSETUP button [26, 43–45]
This button is used to open and close the onscreen
setup menus.
TZOOM button [39]
This button is used with the Zoom function.
USUBTITLE button [38]
This button is used to select subtitles on
DVD-Video discs.
VPause button [27, 30, 31]
This button is used to pause playback.
WPrevious/Next / buttons [27]
The Previous button is used to select the previous
chapter or track. During playback it selects the
beginning of the current chapter or track.
The Next button is used to select the next chapter or
track.
XPlay button [27]
This button is used to start playback.
YTV Control buttons [58]
TV/Video button
Used to select TV or VCR on your TV.
Channel –/+ buttons
Used to select channels on your TV.
On/Standby button
Used to set your TV to On or Standby.
Volume / buttons
Used to adjust your TV’s volume.
normal dim dimmer
Downloaded From Disc-Player.com Onkyo Manuals

18
Connecting the DV-SP503E
•Read the manuals supplied with your AV components.
•Don’t connect the power cord until you’ve completed
all audio and video connections.
Optical Digital Outputs
The DV-SP503E’s optical digital connectors have a shut-
ter-type cover that opens when an optical plug is
inserted, and closes when it’s removed. Push the plug in
all the way.
Caution: To prevent shutter damage, hold the optical
plug straight when inserting and removing.
RCA AV Connection Color Coding
RCA AV connections are usually color coded: red,
white, and yellow. Use red plugs to connect right-chan-
nel audio inputs and outputs (typically labeled “R”). Use
white plugs to connect left-channel audio inputs and out-
puts (typically labeled “L”). And use yellow plugs to
connect composite video inputs and outputs.
The supplied AV cable is made up of an analog audio
cable and a composite video cable.
•Push each plug in all the way to
make a good connection (loose
connections can cause noise or
malfunctions).
•To prevent interference, keep
audio and video cables away from
power cords and speaker cables.
Before Making Any Connections
Right (red)
Left (white)
(Yellow)
Analog audio
Composite video
Right (red)
Left (white)
(Yellow)
Right!
Wrong!
AV Cables & Connectors
Video
Component
video
Component video separates the luminance (Y) and
color difference signals (PR, PB), providing the best
picture quality. Some TV manufacturers label their
component video inputs differently.
S Video
S Video provides better picture quality than com-
posite video.
Composite
video
Composite video can be found on virtually all TVs,
VCRs, and video equipment.
Scart
(European
model only)
SCART connections carry audio and video (com-
posite, S Video, RGB) all in one cable.
Audio
Optical digital
Optical digital audio connections provide better
audio quality than analog connections.
Coaxial digital
Coaxial digital audio connections provide better
audio quality than analog connections.
Analog
RCA analog audio connectors can be found on vir-
tually all AV components.
Multichannel
analog audio
cable (RCA)
This cable carries multichannel analog audio and
it’s typically used to connect DV-SP503Es with
individual 5.1 channel analog audio outputs. Sev-
eral standard analog audio cables can be used
instead of a multichannel cable.
C R
C B
Y
C
R
C B
P R
P B
P/ /
//
R
P B
Y
PB
Y
P R
S VIDEO
VIDEO
AV CONNECTOR
OPTICAL
COAXIAL
R
L
1
SURR CENTER
12
FRONT/D. MIX
SUB
WOOFER
Downloaded From Disc-Player.com Onkyo Manuals

19
Connecting the DV-SP503E—Continued
The setup described here is a basic setup that allows you to play discs using just the cables supplied with the player. In
this setup, stereo audio is played through the speakers in your TV.
•This player is equipped with copy protection technol-
ogy. Do not connect this player to your TV via a VCR
using AV cables, as the picture from this player will
not appear properly on your TV. (This player may also
not be compatible with some combination TV/VCRs
for the same reason; refer to the manufacturer for more
information.)
1. Connect the VIDEO OUTPUT and AUDIO OUT-
PUT ANALOG L/R jacks to a set of A/V inputs
on your TV.
Use the supplied AV cable (RCA), connecting the
red and white plugs to the audio outputs and the yel-
low plug to the video output. Make sure you match
up the left and right audio outputs with their corre-
sponding inputs for correct stereo sound.
See the following page if you want to use a compo-
nent or S Video cable for the video connection.
If you need another pair of stereo outputs (and don’t
need to use the multichannel analog outputs), you
can use the FRONT/D.MIX 1 or 2 AUDIO OUTPUT
jacks (page 22).
2. Connect the supplied AC power cord to the AC
INLET, then plug into a power outlet.
Notes:
•Before unplugging the player from the power outlet,
make sure you first switch it into standby using either
the front panel STANDBY/ON button, or the remote
controller, and wait of the “GOOD BYE”message to
disappear from the player’s display.
•For the above reasons, do not plug this player into a
switched power supply found on some amplifiers and
AV receivers.
Basic Setup
AC INLET
REMOTE
CONTROL
SUPER AUDIO CD & DVD AUDIO/
VIDEO PLAYER
MODEL NO. DV-SP 503E
RATING:
AC 120V 60 Hz 11 W
VIDEO
S VIDEO
R
L
SURR CENTER
12
FRONT/D. MIX
AUDIO OUTPUT
DIGITAL
SUB
WOOFER OPTICAL
COAXIAL
PB
Y
PR
COMPONENT
VIDEO OUTPUT
L
R
ANALOG
INPUT
VIDEO IN
To power outlet
TV
AV cable
(Supplied)
Power cord
(Supplied)
Downloaded From Disc-Player.com Onkyo Manuals

20
Connecting the DV-SP503E—Continued
•Connect the DV-SP503E to the TV directly. If you
connect the DV-SP503E to a VCR, TV/VCR combina-
tion, or video selector, the playback picture may be
distorted as DVD videos are copy protected.
Using S Video
If your TV (or other equipment) has an S Video input,
you can use this instead of the standard (composite) out-
put for a better quality picture.
•Use an S Video cable (supplied) to connect the S
VIDEO OUTPUT to an S Video input on your TV (or
monitor or AV receiver).
Line up the small triangle above the jack with the same
mark on the plug before plugging in.
Using Component Video
You can use the component video output instead of the
standard video out jack to connect this player to your TV
(or other equipment).
This should give you the best quality picture from the
three types of video output available.
•Use a component video cable (not supplied) to con-
nect the COMPONENT VIDEO OUTPUT jacks to a
component video input on your TV, monitor or AV
receiver.
Note:
•Watching progressive scan video from the component
video outputs
This player can output progressive scan video from the
component video output. Compared to interlace video,
progressive scan video effectively doubles the scan-
ning rate of the picture, resulting in a very stable,
flicker-free image. To set up the player for use with a
progressive scan TV, see Video Output settings on
page 46. When the player is set to output progressive
scan video, the PROGRESSIVE indicator lights in the
front panel display.
Important:
•If you connect a TV that is not compatible with a pro-
gressive scan signal and switch the player to progres-
sive, you will not be able to see any picture at all. In
this case, switch everything off and reconnect using
the supplied video cable, then switch back to Interlace
(see page 21).
Using SCART (European model only)
If your TV has a SCART-type AV input, you can use a
SCART cable to connect this player to your TV. This
type of connection carries both the sound and the picture,
so there’s no need to connect up the AUDIO OUTPUT
L/R and VIDEO OUTPUT jacks.
•Use a SCART cable (supplied) to connect the AV
CONNECTOR to an AV input on your TV.
This connector can output composite video, S Video, or
RGB video. The default setting is composite, which
should work with all TVs. Consult the manual that came
with your TV to see if you can use one of the higher qual-
ity settings. See page 46 for how to change the video out-
put.
Connecting Your TV
REMOTE
CONTROL
SUPER AUDIO CD & DVD AUDIO/
VIDEO PLAYER
MODEL NO. DV-SP 503E
RATING:
AC 120V 60
Hz 11 W
VIDEO
S VIDEO
SURR CENTER
2
M
IX
AUDIO OUTPUT
DIGITAL
SUB
WOOFER OPTICAL
COAXIAL
PB
Y
P R
COMPONENT
VIDEO OUTPUT
S VIDEO IN
S VIDEO
TV
VIDEO
S VIDEO
R
L
SURR CENTER
12
FRONT/D. MIX
AUDIO OUTPUT
DIGITAL
SUB
WOOFER OPTICAL
COAXIAL
PB
Y
P R
COMPONENT
VIDEO OUTPUT
PB
COMPONENT
Y
Y
PBPR
COMPONENT
VIDEO IN
PR
TV
VIDEO
S VIDEO
DIGITAL
OPTICAL
COAXIAL
PB
Y
P R
COMPONENT
VIDEO OUTPUT
SUPER AUDIO CD & DVD AUDIO/
VIDEO PLAYER
MODEL NO. DV-SP 503E
RATING:AC 100-240 V
50/ 60Hz 12 W
REMOTE
CONTROL
AV CONNECTOR
SCART
AV CONNECTOR
TV
Downloaded From Disc-Player.com Onkyo Manuals
