SPECIFICATIONS
Model Name Using Similar Mechanism CDP-XE200/XE300
CD Mechanism Type CDM14-5BD20
Base Unit Type BU-5BD20
Optical Pick-up Type KSS-213BA/F-NP
SERVICE MANUAL
AEP Model
UK Model
COMPACT DISC PLAYER
MICROFILM
Photo: CDP-XE310
CDP-XE210/XE310
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
— 2 —
Thisapplianceisclassifiedas
a CLASS 1 LASER product.
The CLASS 1 LASER
PRODUCT MARKING is
located on the rear exterior.
This caution label is located inside
the unit.
The laser component in this product is ca-
pable of emitting radiation exceeding the
limit for Class 1.
CAUTION
Use of controls or adjustments or performance of
procedures other than those specified herein may result in
hazardous radiation exposure.
Notes on chip component replacement
• Never reuse a disconnected chip component.
• Notice that the minus side of a tantalum capacitor may be
damaged by heat.
Flexible Circuit Board Repairing
• Keep the temperature of soldering iron around 270˚C
during repairing.
• Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
• Be careful not to apply force on the conductor when soldering
or unsoldering.
SAFETY-RELATED COMPONENT WARNING !!
COMPONENTS IDENTIFIED BY MARK !OR DOTTED LINE
WITH MARK !ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
TABLE OF CONTENTS
1. SERVICING NOTE .......................................................... 3
2. GENERAL .......................................................................... 4
3. DISASSEMBLY
3-1. Front Panel ........................................................................... 5
3-2. Base Unit (BU-5BD20)......................................................... 5
4.TEST MODE ....................................................................... 6
5. ELECTRICAL BLOCK CHECKING .......................... 7
6. DIAGRAMS
6-1. Circuit Boards Location ........................................................ 9
6-2. Printed Wiring Board — BD Section —............................. 11
6-3. Schematic Diagram — BD Section — ............................... 13
6-4. Schematic Diagram — Main Section — ............................ 15
6-5. Printed Wiring Board — Main Section —.......................... 17
6-6. Printed Wiring Board — Panel Section — ......................... 19
6-7. Schematic Diagram — Panel Section — ............................ 21
6-8. IC Pin Functions
• IC501 CXP82612-021Q (Master Control) ....................... 23
6-9. IC Block Diagrams ............................................................. 24
7. EXPLODED VIEWS
7-1. Main Section ....................................................................... 26
7-2. Mechanism Deck Section (CDM14-5BD20) ...................... 27
7-3. Base Unit Section (BU-5BD20).......................................... 28
8. ELECTRICAL PARTS LIST ........................................ 29
MODEL IDENTIFICATION
– BACK PANEL –
PARTS No. MODEL PRODUCT
COUNTRY
XE210: 4-988-712-0
XE210: 4-988-712-1
XE310: 4-988-712-2
XE310: 4-988-712-3
XE210: 4-988-712-4
XE210: 4-979-971-5
XE210: 4-988-712-5
XE210: 4-979-971-6
XE310: 4-988-712-6
XE310: 4-979-971-7
XE310: 4-988-712-7
XE310: 4-979-971-8
AEP, EE, CIS
UK
AEP, EE, CIS
UK
AEP, EE, CIS
AEP, EE, CIS
UK
UK
AEP, EE, CIS
AEP, EE, CIS
UK
UK
FRANCE
FRANCE
FRANCE
FRANCE
HUNGARY
HUNGARY
HUNGARY
HUNGARY
HUNGARY
HUNGARY
HUNGARY
HUNGARY
• Abbreviation
EE : East European model
Parts No.
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
— 3 —
SECTION 1
SERVICING NOTE
NOTES ON HANDLINGTHE OPTICAL PICK-UP BLOCK
OR BASE UNIT
The laser diode in the optical pick-up block may suffer
electrostatic breakdown because of the potential difference
generated by the charged electrostatic load, etc. on clothing and
the human body.
During repair, pay attention to electrostatic breakdown and also
use the procedure in the printed matter which is included in the
repair parts.
The flexible board is easily damaged and should be handled with
care.
NOTES ON LASER DIODE EMISSION CHECK
The laser beam on this model is concentrated so as to be focused
on the disc reflective surface by the objective lens in the optical
pick-up block. Therefore, when checking the laser diode emission,
observe from more than 30 cm away from the objective lens.
LASER DIODE AND FOCUS SEARCH OPERATION
CHECK
Carry out the “S curve check” in “CD section adjustment” and
check that the S curve waveform is output two times.
HOWTO OPENTHE DISC TRAY WHEN POWER SWITCH
TURNS OFF
Insert a tapering driver into the aperture of the unit bottom, and turn
in the direction of arrow.
*
To close the disc table, turn the driver in the reverse direction.
Pull out disc table
