Onlogic Axial AC101 User manual

Axial AC101 Product Manual

Revision History
Date
Revision History
First release of Axial AC101 manual
1

Table of Contents
1 - System Overview 4
1.1 - Accessories 5
1.2 - Latest Drivers, Firmware, and Additional Information 5
1.3 - Product Specifications 6
1.4 - System Dimensions and Exterior Features 8
1.4.1 - System Dimensions 8
1.4.2 - Front I/O Ports 9
1.4.3 - Rear I/O Ports 9
1.4.4 - Front LEDs & Buttons 10
1.4.5 - Security Bezel 11
1.4.6 - Two Point Locking Lid with Intrusion Detection 11
1.5 - System Label 13
1.6 - Front Service Label 13
1.7 - Motherboard Overview 13
1.7.1 - System Block Diagram 14
1.7.2 - Internal Motherboard Features & Headers 15
2 - I/O Definitions 17
2.1 - Networking 17
2.2 - 1GbE Dedicated BMC Port LEDs 18
2.3 - 1GbE Networking Port LEDs 18
2.4 - 10GbE Networking Port LEDs 19
2.5 - USB Ports 19
2.6 - DisplayPort Video 19
2.7 - HDMI Video 19
2.8 - VGA Video 19
3 - Primary Component Connectors 20
3.1 - M.2 2280/2260/2242/2230 M-key 1 20
3.2 - TPM Header 20
3.3 - SATA Headers 21
3.4 - OCuLink Headers 21
3.5 - PCIe Gen 4.0 x16 Slot 21
3.6 - DDR5 UDIMM Slots 21
3.6.1 - Supported Memory Modes 21
3.6.1.1 - Single-Channel Mode 21
3.6.1.2 - Dual-Channel Mode – Intel® Flex Memory Technology Mode 21
3.6.1.3 - Dual-Channel Symmetric Mode (Interleaved Mode) 22
3.6.2 - DIMM Population Requirements 23
4 - Thermals and Cooling 24
4.1 - System Fans and Airflow Direction 24
4.2 - Temperature Sensors 25
4.3 - Default Fan Settings 26
4.3.1 - Fan Zone Assignments 26
4.3.1.1 - Fan Zone 1 - CPU Area 26
4.3.1.2 - Fan Zone 2 - PCIe / GPU Area 27
2

4.3.2 - Additional Fan Defaults 28
4.4 - Thermal Performance and Validation 28
4.4.1 - Test Conditions 28
4.4.2 - Test Results 30
5 - Power 31
5.1 - Supported Power Supplies 31
5.2 - Power Redundancy 31
5.3 - Wake-Up Events 32
6 - Operating Systems 33
6.1 - Windows 10 IoT Enterprise 2021 LTSC Licensing 33
7 - Mounting Hardware 34
7.1 - Rack Mounting 34
7.1.1 - Rackmount 23" Ball Bearing Slide Rails 34
7.1.2 - Rackmount 23" Ball Bearing Cable Management Arm Slide Rail Kit 35
7.1.3 - Rackmount 28" Simple Locking Ball Bearing Slide Rails 36
7.2 - Wall Mounting 37
7.2.1 - Wall mount kit 37
8 - Regulatory Compliance 38
8.1 - CE 38
8.2 - FCC Statement 38
8.3 - ISED 38
8.4 - UKCA 38
9 - Appendices 39
9.1 - Appendix A: Technical Support 39
9.2 - Appendix E: Compliance Information 39
9.2.1 - Safe use and installation instructions 39
9.2.2 - Précautions et guide d’installation 40
3

1 - System Overview
Axial AC101 without Security Bezel
Axial AC101 with Security Bezel
4

1.1 - Accessories
The following accessories will come with every system:
● PSU Filler (2RALXX5862A1)
● Nvidia 9.5” GPU Mounting Kit w/ screws (2RALXX5861A1)
● SSD Drive Cable Brackets (2RALXX5859A1)
● Spare Motherboard Standoffs (2RALXX282300)
● Spare PCIe Riser Screws (2RALXX585800)
● Cable management ties
● Security Bezel Key
If additional items were purchased, such as rail mounting kits/brackets, they will be boxed separately.
1.2 - Latest Drivers, Firmware, and Additional Information
Drivers, firmware, and product information can be found on the Axial 101 product page.
For the latest information, visit the Axial 101 product page at:
US: https://www.onlogic.com/ac101/
EU: https://www.onlogic.com/eu-en/ac101/
5

1.3 - Product Specifications
OnLogic Axial 100 Series
Variants
AC101 - High-Performance 1U with 150W PCIe 4.0 x16 Expansion
Processor
Intel® 13th Gen Alder Lake-S (LGA1700)
Core i3, i5, i7 & i9 up to 24-core 32-thread
i3-13100E or TE, i5-13500E or TE, i7-13700E or TE, i9-13900E or TE
125W PL2 (Power Level 2)
Memory
Support up to 4x DDR5-4800 UDIMMs (non-ECC or ECC)
Up to 128GB total memory
Maximum operational speed: 4400 MT/s
Chipset
Intel® W680
Integrated Graphics
Intel® UHD Graphics 730 (i3) or 770 (i5, i7, i9)
Front I/O
2x USB 3.2 Gen 1 Type A
1x Power Button / LED (White)
1x ID button / LED (Blue)
Rear I/O
1x 1GbE Dedicated Management (BMC/IPMI)
2x 1GbE LAN Intel® i210
2x 10GbE LAN Intel® X710
2x USB 3.2 Gen 1 Type-A
1x DisplayPort
1x HDMI
1x VGA
1x DB9 (COM)
1x ID button / LED (Blue)
Expansion & Storage
1x M.2 2280/2260/2242/2230 M-key (PCIe Gen 3 x4)
1x PCIe Gen 4 x16 Full Height, Full Length slot (up to 150W)
Up to 4x 2.5” Drives (NVMe or SATA)
Special Features
ASPEED AST2600: Full Web UI, iKVM, vMedia support
1/10 Network Controller Sideband Interface (NC-SI)
Optional TPM 2.0 module ( Infineon SLB9670 ) or Intel PTT (Native)
Chassis Intrusion Detection
Security Bezel
Secure Boot
Operating Systems
Microsoft Windows 10 IoT Enterprise 2021 LTSC (Value/High End) 64-bit
Microsoft Windows 11 Professional 64-bit
LAN Controllers
2x Intel® i210 Controllers (2x 1GbE ports)
1x Intel® X710 Controller (2 x 10GbE ports)
Power Supplies
Up to 2 PSUs with PMBUS monitoring, 100~240 VAC input
450W Gold
750W Platinum
Dimensions
(W x H x D)
430 x 43.5 x 515mm (16.9 x 1.7 x 19.7”) without Security Bezel
483 x 43.5 x 534mm (19.0 x 1.7 x 21.0”) with Security Bezel
Weight
System Maximum: 10.02 kg (22.1 lbs)
Shipping Maximum: 12.88 kg (28.4 lbs)
6

Mounting
Rack Mount 28” Toolless Slide Rail
Rack Mount 23” Slide Rail
Rack Mount 23” Slide Rail with Cable Management Arm
Wall Mount
Operating Temperature
5°C ~ 40°C (ASHRAE A3 Operating Temperature)
Maximum ambient temperature decreases by 1°C for every 175m (574 ft)
increase in altitude above 900m (2,953 ft)
Storage Temperature
-40°C ~ 70°C
Operating Humidity
8~85% Relative, non-condensing
Maximum dew point 24°C
Storage Humidity
0~95% Relative, non-condensing
Maximum dew point 24°C
Shock & Vibration
ISTA 6-FEDEX-A
Certifications
FCC 47 CFR Part 15 Subpart B (Class A)
CAN ICES-003(A) / NMB-003(A) (Class A)
(Class B upon request)
EN 63268-1
CISPR 32/EN 55032 (Class A; Class B upon
request)
CISPR 35/EN 55035
Radio Equipment Directive (2014/53/EU)
RoHS 3 (2015/863/EU)
WEEE Directive (2012/19/EU)
IEC/EN/UL 62368-1 (UL File No. E490677)
Countries of Use
Available countries:
Americas:
Canada, United States
Europe: Austria, Belgium, Bulgaria, Croatia, Czech Republic,
Cyprus, Denmark, Estonia, Finland, France, Germany,
Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania,
Liechtenstein, Luxembourg, Malta, Norway, The
Netherlands, United Kingdom, Poland, Portugal, Romania,
Slovakia, Slovenia, Spain, Sweden
Available countries upon request:
Asia: Australia, China, Japan, New Zealand
Other countries may be available, please call
7

1.4 - System Dimensions and Exterior Features
1.4.1 - System Dimensions
Axial AC101 without Security Bezel
Axial AC101 with Security Bezel
8

1.4.2 - Front I/O Ports
1.4.3 - Rear I/O Ports
9

1.4.4 - Front LEDs & Buttons
LED / Button
Color
On
Off
Blink
Power
White
Device is on
Device is off
-
ID
(Identification)
Blue
ID indicator
asserted
ID indicator is
deasserted
ID indicator is
blinking
RST
(Reset)
-
-
-
-
The ID LED/Button is available to assist with locating the system. ID may be physically turned On / Off
by physically pressing the ID button. ID may also be turned On, Off, or set to Blink from the Baseboard
Management Controller (BMC) Web UI.
RST Button will reset the system.
10

1.4.5 - Security Bezel
The Axial AC101 Edge Server comes with a security bezel. The security bezel helps prevent
unauthorized access and tampering with the front ports and buttons of the system.
A barrel lock is used to secure the security bezel in place. A key for the barrel lock is included in the
accessory package.
1.4.6 - Two Point Locking Lid with Intrusion Detection
The Axial AC101 Edge Server chassis lid has a two point locking locking mechanism with an intrusion
mechanism built natively into the system chassis.
For the two point locking mechanisms, the first point is the top latch with a tamper resistant screw
lock.
11

The second lid locking point is a thumb screw located in the rear of the system.
In the event that the system lid is removed while power is present to the system, the intrusion switch
will detect this event and the Chassis Intrusion sensor will be asserted. Relative to the intrusion, this
event will also be logged in the Baseboard Management Controller event log.
12

1.5 - System Label
The system label is located on the bottom of the chassis as depicted in the image below. The system
label will contain the following information:
● System Model
● OnLogic Serial Number
● Regulatory & Compliance Certification Logos
1.6 - Front Service Label
On the front of the chassis, there is a retractable product information label containing pertinent
product information such as:
● System Model
● OnLogic Serial Number
● BMC MAC addresses
13

1.7 - Motherboard Overview
1.7.1 - System Block Diagram
14

1.7.2 - Internal Motherboard Features & Headers
15

Item
Description
Item
Description
1
Front VGA Header, (FRNT_VGA1), Unused
19
2x SATA Header (SATA3_7)(Upper),
(SATA3_6)Lower
2
PWM Configuration Header (PWM_CFG1),
Unused
20
System Front Panel Header (PANEL1)
3
2x DDR5 DIMM Slots (DDR5_A1, DDR5_B1)
21
Auxiliary Front Panel Header (AUX_PANEL1)
4
ATX 12V Power Connector (ATX12V1)
22
SATA SGPIO Connector (SATA_SGPIO1), Unused
5
ATX 12V Power Connector (ATX12V2)
23
SPI TPM Header (TPM_BIOS_PH1)
6
CMOS CR2032 Battery
24
USB 2.0 Header (USB_1_2), Unused
7
PSU SMBus Header (PSU_SMB1)
25
CPU PECU Mode Jumper (PECI1)
8
ATX Power Connector (ATXPWR1)
26
Ambient Temperature Sensor Header (TR1)
9
2x DDR5 DIMM Slots (DDR5_A2, DDR5_B2)
27
Intelligent Platform Management Bus Header
(IPMB_1)
10
Chassis Fan Header (FAN4)
28
BMC SMBus Header (BMC_SMB_1)
11
Chassis Speaker Header (SPEAKER1),
Unused
29
Non Maskable Interrupt Button (NMI_BTN1)
12
Buzzer (Audible boot error indicator)
30
Security Override Jumper (SEC_OR1)
13
Front USB 3.2 Gen 1 Header
31
LAN LED
14
4x OCuLink PCIe 3.0 x4 for NVMe drives
32
Clear CMOS Pad (CLRMOS1)
15
Chassis Fan Header (FAN3)
33
M.2 Socket (M.2) (Type 2230/2242/2260/2280)
16
Chassis Fan Header (FAN2)
34
Chassis Fan Header (FAN5)
17
Chassis Fan Header (FAN1)
35
2x Chassis Fan Header (FAN6, FAN7), Unused
18
2x SATA Header (SATA3_5)(Upper),
(SATA3_4)Lower
16

2 - I/O Definitions
2.1 - Networking
The Axial AC101 features the following onboard Ethernet ports:
Port
Chipset
Capabilities
1GbE Mgmt
Realtek
RTL8211F
(Attached to
ASPEED
AST2600)
Dedicated BMC Management port.
Port is only used for system management
functions such as IPMI, RedFish, Remote
Management, etc.
This port is not usable as an Ethernet port by the
operating system.
1GbE Port 1
Intel® I210
1GbE Port
This port may be configured to operate in a
Shared NIC mode, enabling access to the BMC
network connection and supporting the system
management functions such as IPMI, RedFish,
Remote Management, etc.
1GbE Port 2
Intel® I210
1GbE Port
10GbE Port 3
Intel® X710
10GbE Port
This port may be configured to operate in a
Shared NIC mode, enabling access to the BMC
network connection and supporting the system
management functions such as IPMI, RedFish,
Remote Management, etc.
10GbE Port 4
10GbE Port
17

2.2 - 1GbE Dedicated BMC Port LEDs
LED
Color
State
Condition
Link
-
Off
No Link
Yellow
On
Link established
Blinking
Data activity
Speed
-
Off
10Mbps data
rate or no link
Yellow
On
100Mbps data
rate
Green
On
1Gbps data rate
2.3 - 1GbE Networking Port LEDs
LED
Color
State
Condition
Link
-
Off
No Link
Orange
On
Link established
Blinking
Data activity
Speed
-
Off
10Mbps data
rate or no link
Yellow
On
100Mbps data
rate
Green
On
1Gbps data rate
18

2.4 - 10GbE Networking Port LEDs
LED
Color
State
Condition
Link
-
Off
No Link
Green
On
Link established
Blinking
Data activity
Speed
-
Off
100 Mb/s data
rate or no link
Yellow
On
1Gbps data rate
Green
On
10Gbps data
rate
2.5 - USB Ports
There are 4 USB 3.2 Gen 1 Type A ports on the Axial AC101 Edge Server.
Two ports are on the front of the system. Two ports are on the rear of the system.
All USB ports also support USB 2.0 connectivity.
2.6 - DisplayPort Video
There is one full-size DisplayPort (1.4a) located on the back of the Axial AC101 Edge Server.
2.7 - HDMI Video
There is one full-size DisplayPort (1.4a) located on the back of the Axial AC101 Edge Server.
2.8 - VGA Video
There is one full-size DisplayPort (1.4a) located on the back of the Axial AC101 Edge Server.
19
