Onyx ONX806-C User manual

ONX806-C Room Thermostat
Installation and Operation Manual
ONX806-C series room thermostat is used in industrial, commercial and residential
environments and is especially designed for Cooling to maintain the room temperature.
ONX806-C room thermostat allows users to choose from 3 speeds in order to control the
outlet air speed.
Specification᧶
Set point range : 10ᨺ30 C° Sensor type : Dual Diaphragm Element
Temp accuracy : +/- 1 C° Voltage :AC 220V +/-10᧡50Hz/ 60Hz
Rated current : < 3A Dimension : 85mm×40mm×128mm
Fixing screw width : 60 mm (standard) Wiring diameter : 0.5ᨺ2.5mm
Operation᧶
OFF /
COOL :
Push switch to OFF position as power off.
Push switch to COOL position as cooling mode.
Set Point : Adjust the temperature knob to desire temperature.
Fan Speed : Fan switch to control the fan speed. I,II,III speed

ONX806-C Wiring Diagram:
Frame and dimension:
2
PIPE, 3 WIRE VALVE SYSTEM
2 PIPE, 2 WIRE VALVE SYSTEM
O
NYX
