With its dynamic design and innovative technology throughout, Insignia
takes Opel’s design language to the next dimension. Now discover what
it can do for you.

Contents
This brochure covers Insignia S, SC, SRi Limited Edition, SE and Elite models only. Some of the models shown include options and accessories available at extra cost. Not all of the features described are
available on every model. From time to time, we may also offer alternative Insignia models such as Special Editions, featured in their own separate literature or found on the Opel website: www.opel.ie
Interior styling 04
ecoFLEX 06
Engines and transmissions 08
FlexRide and Adaptive 4X4 10
Safety 12
Sports Tourer 14
Comfort and convenience 16
Insignia range 18
Insignia OPC 24
Insignia trims 26
Insignia colours 27
Wheels and tyres 28
OPC Styling 29
Insignia accessories 30
OP_INS_19209.tif

A premium feel.
Supreme levels of interior style and quality. With obsessive attention
to detail and intuitive ergonomics that put you in total control.

5
OP_INS_17519.tif

Insignia. A perfect financial perspective.
Insignia ecoFLEX engines underline our commitment to saving you
money on your motoring from a business or personal perspective.
The benefit of reduced vehicle tax and company car taxation – not
to mention incredible fuel economy – mean it’s easy to understand
the fiscal benefits. And all this is achieved without compromising the
outstanding performance and driveability ensuring the Insignia’s
dynamic driving experience is never more apparent.
The Insignia 2.0CDTi 16v (160PS) ecoFLEX Start/Stop models, for
example, deliver up to 4.3 litres/100km (combined) and feature
CO2as low as just 114g/km, which, considering their power and
performance, mean they rank amongst the lowest in their class.
We have also been researching ways of developing new cars that
are more efficient than ever before. The new Opel Ampera is an
Extended-Range Electric Vehicle (E-REV) that can drive up to
80 kilometres on battery power alone and over 500 kilometres
utilising an on-board electric generator system.
Insignia ecoFLEX. Discover how our philosophy of forward thinking
makes perfect financial sense too.

7
OP_INS_19210.tif

Insignia’s stylish looks are complemented by
precision engineered engines and transmissions:
Turbo Diesel. Insignia’s two common rail direct
injection turbo diesel engines, in 130PS and 160PS
outputs, have been further refined to decrease
fuel consumption and CO2emissions without
compromising on power and driveability: the
6-speed manual versions benefit from the latest
Start/Stop technology. Our latest generation
turbocharger technology enables these remarkable
engines to generate maximum torque of 300Nm
(130PS version) and 350Nm (160PS) from only
1750rpm, with maximum power developed at only
4000rpm, to ensure efficient progress. A smooth-
shifting 6-speed automatic transmission is also
available with both engines for effortless driving,
featuring Active Select that allows you to choose
to change the gears sequentially.
Turbo Petrol. The 140PS turbo petrol engine utilises
Variable Valve Timing, a water cooled turbocharger
and intercooler to give smooth power throughout
the rev range, with 200Nm maximum torque
available from 1850-4900rpm, and maximum power
from 4900-6000rpm, giving seamless performance.
Start/Stop technology ensures fuel efficiency and
CO2s are kept in check. This engine is complemented
by a slick 6-speed manual transmission.
Turbo Diesel 4X4. Insignia also offers an intelligent
solution for those encountering slippery conditions
as we are increasingly witnessing in winter time: the
Adaptive 4X4 system coupled to our excellent 160PS
diesel engine. This system constantly monitors
driving conditions, smoothly directing drive to the
wheels that need it most in any circumstances: in
normal conditions, 95% of the power goes to the
front wheels, but more power is fed to the rear
wheels if the front loses grip, or while accelerating.
Additionally an electronically controlled Limited Slip
Differential (eLSD) optimises power transfer between
the rear wheels. Opel’s innovative FlexRide system,
which continually monitors and controls the
suspension, is standard with the 4X4 transmission,
meaning unrivalled traction and stability in all
driving conditions. Select Sport mode and drive is
proportioned 40:60 front:rear for a more dynamic
driving experience!
9
Engines and Transmissions
OP_INS_17305.tif

The FlexRide system responds instantly to data collected from
every chassis and drive component. Continuous Damping
Control, which adjusts the damper settings in real time, four-
channel Anti-lock Braking System with Electronic Brakeforce
Distribution (EBD), traction control and Electronic Stability
Programme (ESP) – all communicate with each other
continuously. FlexRide simply combines all the elements for
the chosen driving mode.
When you select Sport mode, Insignia sharpens the speed-
sensitive steering response, throttle input and automatic
transmission (when fitted), and stiffens the dampers to ensure
optimum road contact. On some models, the system even allows
you to programme which of the above functions you want more
‘sporty’ via an on-screen menu and the instrument lighting
changes from white to red.
When you select Tour mode, the system adjusts the damper
settings to further enhance Insignia’s ride comfort. Ideal for
long distance motorway journeys.
FlexRide comes as standard on some models and is available
as an optional extra on others.
Sport or Tour? The touch of
a button changes the whole
driving dynamics to taut
sporting excitement or relaxed
long distance cruising.
FlexRide (Adaptive Stability Technology).
Choose an Insignia with FlexRide, and the
driving feel can be changed to match your
mood. Select Sport mode for a more dynamic,
responsive drive. Or Tour mode for a smoother,
more relaxed set-up.

Adaptive 4X4 with FlexRide. Specify the Adaptive
4X4 – permanent four-wheel drive – system with
FlexRide and your Insignia will automatically
distribute drive between the front and rear wheels
as conditions demand. The result? Maximum
traction for smooth, strong acceleration, outstanding driving
dynamics and more stability in cornering. Press the Sport button
and the system distributes more power to the rear wheels in a
40% front:60% rear split for an even more dynamic feel.
Previously only available on selected petrol Turbo models,
Adaptive 4X4 is now standard on its first diesel model – the
Insignia 2.0CDTi 16v (160PS) 4X4. This new combination of
permanent four-wheel drive with low end diesel flexibility offers
Insignia drivers a whole new range of possibilities.
The advantages begin when you pull away, all four wheels
are engaged for stable acceleration with maximum grip.
In normal driving, the power is split 95% front:5% rear, but
under acceleration the system automatically diverts more
power to the rear wheels for maximum traction before
gradually moving power back towards the front wheels.
The electronic Limited Slip Differential (eLSD) fitted to the rear
of all 4X4 models offers even more benefits for the enthusiastic
driver. By sensing which rear wheel has the most grip, eLSD can
transfer more torque to the wheel most able to utilise it. Up to
50% of the rear axle torque can be transferred between the rear
wheels, increasing stability during high speed lane changes
and providing more traction when accelerating out of corners.
11
OP_INS_13353.tif

Pedestrian area light (up to
30km/h). Wider spread of light (an
extra eight degrees left and right)
illuminates potential hazards.
Motorway light (over 100km/h).
140 metre range, higher and
brighter than normal low beam
without dazzle.
Dynamic curve light (any speed).
Activated by steering angle and
speed, the headlights swivel up to
15 degrees into the curve.
Town light (30 – 55km/h).
Wider and lower spread of light.
Activated by vehicle speed
together with street lighting.
Adverse weather light (up to
70km/h). Wiper or rain sensor
activated for better vision in bad
weather conditions.
Static cornering light (up to
40km/h, also when reversing).
Throws light 90 degrees left or
right for enhanced lateral vision.
Country road light (55 – 100km/h).
Wider spread and brighter light
than normal low beam. Longer
illumination of own lane.
High beam with assist (any speed).
Automatically switches from
high to low beam as it detects
oncoming or preceding vehicles.
LED Daytime running light.
Increases your visibility to other
road users without increasing fuel
consumption (unlike low beam).
Intelligent Adaptive Forward Lighting (AFL). Insignia’s Intelligent AFL headlights change
their pattern to suit the location and the weather. Sensing where you need the light most,
they can even help you see around corners and even dip automatically when something is
coming the other way. And you can also adjust the system for European driving. AFL comes
as standard on Elite and OPC models and is available as an option on most other models.

13
A proven Opel safety feature, active front seat head
restraints guard against whiplash and other head and
upper body injuries. Standard on all models except S.
Safety is always a top priority for Opel. You wouldn’t
expect it any other way. In the Insignia, it starts with
an optimised body structure that protects you and
your fellow passengers in every kind of impact situation.
And extends to the latest restraint technology – double
pretensioned front seatbelts, pedal release system,
side-impact protection beams, active-safety front seat
head restraints and a whole lot more.
Insignia’s front airbags are two-stage to prevent the
kind of injuries caused if they inflate too quickly.
There’s a switch to deactivate the passenger airbags
when a child seat is used in the front seat. And front
seat side airbags and full-length curtain airbags are
standard on every model.
Safety
OP_INS_14846.tif

Comprising four side rails with sliding side rail hooks, plus
a specially devised 3D storage net and side net pocket, the
optional FlexOrganiser®system provides a versatile way to
manage the Insignia Sports Tourer load area. A range of
FlexOrganiser®accessories is also available including: storage
box, adjustable fixing straps and additional side rail hooks.
Sports Tourer takes Insignia’s dynamic looks to a new dimension,
with innovative use of space throughout. A deep, wide tailgate
aperture with a low loading height makes it easy to use. And
FlexOrganiser®technology extends loadspace versatility.
That curved, wrap-around tailgate is not just attractive to look at.
It’s intelligently designed, with powered, remote-control opening
on SE and Elite models, activated via the key fob, driver’s door
switch or a touch-pad on the tailgate. There are three tailgate
operating modes. In normal mode the tailgate opens to full
height. In intermediate it opens to a reduced height, which can
even be pre-programmed, to avoid damage in low clearance
areas. In ‘off’ mode the tailgate is operated manually. With a
load volume of 530 litres, extendable to 1470 litres with the 60/40
split rear seat folded, the Insignia hatchback models already
feature incredible luggage capacity. But the Sports Tourer adds
even more – as much as 1530 litres with the rear seats folded.

15
Sports Tourer
OP_INS_14842.tif

Ergonomic Front Seats. Insignia’s front seats offer
incredible comfort and support, with manual or
electric operation. There’s a huge range of adjustment
– not just for seat travel and recline, but height and
lumbar adjustment too – allowing all drivers and
passengers to find their ideal seating position.
The Ergonomic Driver's Sport Seat comes as standard on SRi
Limited Edition models. It is available as an optional extra on SC
and Elite models and features tilt adjustment, four-way power
lumbar support and ergonomic seat contours, including excellent
side support. An adjustable seat extension cushion, extending by
up to 60 millimetres, also adds superior thigh support for taller
drivers. The optional Ergonomic Sport Seats Leather Pack on
SRi Limited Edition and SE offers the same features.
With one in two drivers spending more than 90 minutes a day in
their car, and as much as two-thirds of the body in contact with
the seat while driving, optimum adjustment is a key benefit.
Experts agree that the most important requirement is high flexibility,
allowing the contour of the seat back to match the natural posture
of each individual’s spine. And with no less than 18 adjustment
options, the Insignia ergonomic seat succeeds in every area.
It is little wonder it has been awarded a coveted seal of approval
from AGR, an independent panel of German doctors and
ergonomics experts. The AGR seal is only awarded to ergonomic
products that comply with strict medical requirements; in this case,
a scientifically proven Insignia seat that effectively helps prevent
the back pain and tension suffered by some car occupants.
Climate control is a major factor for Insignia interior comfort.
Models featuring single-zone electronic climate control provide
constant control of the atmosphere inside the car, with both front
and rear air outlets optimised for maximum efficiency and noise
reduction. The dual-zone system, standard on Elite and optional
on most other models, also features individual temperature control
between driver and front passenger. Or if that isn’t enough for you
the new optional Winter Pack, available on most models, adds
heated front seats and a heated steering wheel, as well as high-
pressure headlight washers too.

Comfort and Convenience
17
A place for everything. Insignia provides a multitude of storage and stowage features – all
within easy reach of the driver and passengers. In addition to a large glovebox, there’s a
driver’s side storage compartment, handy door pockets, drinks holders and front seat back
map pockets.
Standard across the range, Insignia’s touch-operated Electric
Parking Brake (EPB) with Hill Start Assist (HSA) epitomises the
innovation at the heart of this award-winning model. Designed to
boost driver comfort and increase parking security, it features a
drive away function, which releases the parking brake allowing you
to pull away smoothly, and HSA which keeps the brake pressure
applied momentarily after you’ve taken your foot off the pedal,
preventing you from rolling back on a slope if you haven’t first
applied the parking brake. There’s also a hill hold assist function
which again stops the vehicle rolling back when moving off on an
incline by making sure there’s sufficient engine torque available.
OP_INS_17522.tif

Engine availability
1.4i 16v Turbo Start/Stop*
2.0CDTi 16v (130PS) ecoFLEX Start/Stop*
2.0CDTi 16v (130PS) automatic
*Manual transmission only.
Model illustrated features front and rear parking
distance sensors, optional at extra cost.
Insignia S
Hatchback | Saloon | Sports Tourer
Standard features include:
•
Automatic lighting featuring daytime
running lights
•
Air conditioning
•
Cruise control
•
Leather-wrapped multi-function
steering wheel
•
Stereo radio with CD player (CD 300)
•
Trip computer
•
Electric parking brake with hill-start assist
•
Front centre armrest with storage facility
•
Electrically operated front windows
•
Electrically adj./heated door mirrors
•
12-volt power outlet (centre console)
•
Electric height-adjustable driver’s seat
•
Electric four-way lumbar adjustment
on driver’s seat
•
Adjustable steering column –
reach and tilt
•
Driver’s and passenger’s front, side
and curtain airbags
•
USB connection within centre armrest
•
ISOFIX preparation on all three rear seats
•
Electronic Stability Program (ESP)
•
ABS
•
60/40 split-folding rear seat
•
Front and rear reading lights
•
Remote control central locking
•
Remote control security alarm system
•
Electronic boot lid opening (Saloon
models only)
•
Spare wheel and emergency tool kit
18
S

SC
19
Engine availability
1.4i 16v Turbo Start/Stop*
2.0CDTi 16v (130PS) ecoFLEX Start/Stop*
2.0CDTi 16v (130PS) automatic
*Manual transmission only.
Model illustrated features front and rear parking
distance sensors, optional at extra cost.
Insignia SC
Hatchback | Saloon | Sports Tourer
Additional features over and
above S models:
•
17-inch Structure wheels
•
Fully integrated Satellite Navigation
system (Navi 600) with 7-inch colour
screen, SD memory card, centre console
multi-function controller, USB connection,
CD player with MP3 functionality, stereo
radio, 7 speakers and shark fin aerial
•
Electronic Climate Control
•
Chrome-effect surround on exterior
side windows
•
Chrome-effect Opel door sill plates
•
Active-safety front seat head rests
•
Illuminated vanity mirrors
•
Front seat back storage pockets
•
Rear seat centre armrest with load-
through facility, drinks holders and
storage box
•
Silver-effect roof rails (Sports Tourer)

Engine availability
2.0CDTi 16v (130PS) ecoFLEX Start/Stop*
2.0CDTi 16v (130PS) automatic
2.0CDTi 16v (160PS) ecoFLEX Start/Stop*
2.0CDTi 16v (160PS) automatic
2.0CDTi 16v (160PS) 4X4 Start/Stop*
*Manual transmission only.
SRi Limited Edition model illustrated also features Adaptive Forward Lighting (AFL) and
20-inch alloy wheels optional at extra cost. Power Red is available at no extra cost.
Additional features over and
above SC models:
•
Bluetooth mobile phone
system (does not include
phone or cradle)
•
Lowered and uprated sports
suspension
•
Sports pedals
•
Rear centre seat head
restraint
•
Front fog lights
•
Sports front seats with
ergonomic driver's seat
including extendable
seat cushion
•
Dark-tinted glass rear
windows (Sports Tourer)
•
Tyre inflation kit (in lieu
of steel space saver
spare wheel)
•
18-inch 5-twinblade
alloy wheels
•
OPC Styling Pack comprising:
Front lower spoiler
Side sills
Rear lower skirt
Rear spoiler (not Sports
Tourer models)
•
OPC-line leather-wrapped
three-spoke sports steering
wheel, leather-wrapped gear
knob and dark headlining
•
Front and rear parking
distance sensors
Insignia SRi Limited Edition
Hatchback | Saloon | Sports Tourer
