OPHIR 5100F User manual

OWNER’S MANUAL
Model 5100F
RF POWER AMPLIFIER
0.8 – 2.5 GHz, 25 Watts
Ophir RF
5300 Beethoven Street
Los Angeles, CA 90066
USA
Tel.: [phone]
FAX: [phone]
E-mail: [email protected]
Website: www.ophirrf.com
OM_5100F 12/12/01
Advanced Test Equipment Rentals
www.atecorp.com 800-404-ATEC (2832)
®
E
s
t
a
b
l
i
s
h
e
d
1
9
8
1

OM_5100F 12/12/01 Page 1 of 14
___________________________________________________
Certification
Ophir RF certifies that this product met its published specifications at the time of
shipment from the factory.
_____________________________________________________________________
Warranty
This Ophir RF product is warranted against defects in material and workmanship for a
period of two (2) years from date of receipt. During the warranty period, Ophir RF, will,
at its option, either repair or replace products that prove to be defective. For warranty
service or repair, this product must be returned to a service facility designated by
Ophir RF.
Limitation of Warranty
The foregoing warranty shall not apply to defects resulting from improper or
inadequate maintenance by Buyer, Buyer-supplied software or interfacing,
unauthorized modification or misuse, operation outside of the environmental
specifications for the product, or improper site preparation or maintenance.
NO OTHER WARRANTY IS EXPRESSED OR IMPLIED. OPHIR RF
SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Exclusive Remedies
THE REMEDIES PROVIDED HEREIN ARE BUYER’S SOLE AND EXCLUSIVE
REMEDIES. OPHIR RF SHALL NOT BE LIABLE FOR ANY DIRECT,
INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES,
WHETHER BASED ON CONTRACT, TORT, OR ANY OTHER LEGAL
THEORY.
_____________________________________________________________________
Assistance
For any assistance, contact your Ophir RF Sales and Service Office.

_____________________________________________________________________
Safety Information
The following safety notes and symbol are used in this manual and on the equipment.
Familiarize yourself with each and its meaning before operating this equipment.
Caution Caution denotes a hazard. It calls attention to a procedure that, if not
correctly performed or adhered to, would result in damage to, or
destruction of, the equipment. Do not proceed beyond a caution note
until the indicated conditions are fully understood and met.
_____________________________________________________________________
Warning Warning denotes a hazard. It calls attention to a procedure which, if
not correctly performed or adhered to, could result in injury or loss
of life. Do not proceed beyond a warning note until the indicated
conditions are fully understood and met.
_____________________________________________________________________
The instruction documentation symbol. The product is marked with this
symbol when it is necessary for the user to refer to the instructions in the
documentation.
_____________________________________________________________________
General Safety Considerations
Warning This is a safety Class I product provided with a protective earthing
ground incorporated in the AC power cord. The AC power cord
shall only be inserted in a socket outlet provided with a protective
earth contact. Any interruption of the protective conductor, inside
or outside of the equipment, is likely to make the equipment
dangerous. Intentional interruption is prohibited.
_____________________________________________________________________
Warning No operator serviceable parts inside. Refer servicing to qualified
personnel. To prevent electrical shock, do not remove covers.
_____________________________________________________________________
Warning If this equipment is used in a manner not specified by Ophir RF, the
protection provided by the equipment may be impaired.
_____________________________________________________________________
Caution Before switching on this equipment, make sure that the line voltage is
correct and that an External Load has been applied. (Refer to 2.2.3)
OM_5100F 12/12/01 Page 2 of 14

Contents
Section Page
IGeneral Information 5
Declaration of Conformity 5
Scope 5
Description 5
Equipment Specifications 6
II Installation 7
Incoming Inspection 7
Preparation for Use 7
Power Requirements 7
Earthing 7
Load Requirements 7
Cable Connections 7
III Operation 8
Introduction 8
Statement Against Unspecified Use 8
Controls, Indicators, and Connectors 8
Basic Operating Procedures 8
Before Turn On 8
Turn On 9
Operation 9
Turn Off 9
IV Maintenance 10
Introduction 10
Performance Test 10
Adjustment Procedures 10
Troubleshooting Procedures 10
Improper Power Distribution 10
Low or No RF Output Power 10
Cleaning 10
V Customer Service 11
Servicing 11
Return Material Authorization (RMA) 11
Repackaging for Shipment 11
RMA Request Form 12
OM_5100F 12/12/01 Page 3 of 14

Figures
Figure 1 Block diagram 13
Figure 2 System View 14
Tables
Table 1 Equipment Specifications 6
OM_5100F 12/12/01 Page 4 of 14

SECTION I
General Information
1.1 Declaration Of Conformity
DECLARATION OF CE CONFORMITY
Ophir RF Inc., 5300 Beethoven Street, Los Angeles, CA 90066, declares under
sole responsibility that the RF Power Amplifier, Model 5100F, to which this
declaration relates, meets essential health and safety requirements and is in
conformity with ISO 3864. The CE marking has been applied according to the
relevant Safety and CE Directives listed below using the relevant section of the
following EC standards and other normative documents:
EU EMC DIRECTIVE 89/366/EEC - Essential health and safety requirements
relating to electromagnetic compatibility
ENEN55022 Class B
EN50082-1 EC generic immunity requirements, Category A & B
IEC801-2, IEC801-3, IEC801-4
EC Low Voltage Directive 72/23/EEC Essential health and safety
requirements relating to electrical equipment designed for use within certain
violate limits.
EN61010-1 Safety requirements of Test Measurement and Laboratory
Equipment.
1.2 Scope
This owner’s manual contains operating instructions for a model 5100F
amplifier.
1.3 Description
The power amplifier operates in the RF frequency. The input to the power
amplifier is rated at 0 dBm nominal CW signal between the 0.8 – 2.5 GHz
frequency range. The output of the power amplifier is specified at 25 Watts CW
RF signal. Detailed specifications for the power amplifier are given in table 1-1.
OM_5100F 12/12/01 Page 5 of 14

Equipment Specifications
Table 1-1. Specifications @ 25º C
Class of Operation: A/AB
Frequency Range: 0.8 – 2.5 GHz
Output Power @ Saturation: 25 Watts CW Typical
Output Power @ 1 dB Compression: 20 Watts CW minimum
Small Signal Gain: +45 dB minimum
Small Signal Gain Flatness: ± 2.0 dB maximum
Input/Output Impedance: 50 ohms nominal
Input VSWR: 2:1 maximum
Max. RF Input +10 dBm
Operating Temperature Range: 0º C to 50º C
Operating Humidity Range: 95%, Non-condensing
Temp. Protection: Shut down @ 80º C minimum
Cooling system: Internal Forced Air
AC Input: 100 - 240 VAC, 50/60 Hz, 1¯
AC Input Power: 200 Watts maximum
Dimensions: 19" W x 3.5" H x 18" D
Weight: 30 Pounds maximum
Option(s) included:
-Type-N Connectors on Front Panel.
*NOTE – Specifications subject to change without notice
OM_5100F 12/12/01 Page 6 of 14

SECTION II
Installation
2.1 Incoming Inspection WARNING!
Do not apply power until you have read Sections II and III and you have
performed all specified procedures. If you fail to observe this warning,
damage to the equipment and/or bodily injury may result.
The power amplifier has been mechanically and electrically inspected prior to
shipment. If the equipment has been damaged or if electrical performance is
not within specification, notify the carrier and OPHIR RF immediately.
2.2 Preparation For Use
2.2.1 Power Requirements
The power amplifier requires a power source of 100 – 240 VAC, 50/60
Hz capable of delivering 200 Watts. Turn off the front panel ‘ON/OFF’
switch before connecting the AC power source.
2.2.2 Earthing
Earthing is achieved simultaneously with connection of the AC power
cords to a properly grounded power source.
2.2.3 Load Requirements
The power amplifier requires a load, antenna, or dummy load with a 50-
Ohm nominal impedance.
CAUTION!
Make this external load connection before applying any power to the
equipment.
2.2.4 Cable Connections
The AC power cable connection is made at the rear of the power
amplifier via the receptacle connector. RF connections for Input and
Output are made at the front via Type-N connectors. (Refer to Figure 2)
OM_5100F 12/12/01 Page 7 of 14

SECTION III
Operation
3.1 Introduction
This section describes the operating controls and procedures of the power
amplifier.
3.2 Statement Against Unspecified Use
This amplifier must be used as specified by the manufacturer. Use of this
equipment in any way not specified by the manufacturer may result in bodily
injury and/or damage to the equipment.
3.3 Controls, Indicators, and Connectors
When set to ‘ON’, the ON/OFF switch will light indicating that AC power is
present. The RF INPUT and OUTPUT connections are located on the front of
the power amplifier. Refer to figure 2 and the following discussion for the
location and functional description of all controls, indicators, and connectors.
3.4 Basic Operating Procedures NOTE!
The operation of the power amplifier is passive; that is, after an External Load
and Input power have been applied, no procedures other than turn off are
required.
3.5 Before Turn On CAUTION!
Do not obstruct the airflow at the front and rear of the power amplifier. If
you do not verify that this equipment has an unobstructed airflow, you
may cause this equipment to overheat or otherwise impair its operation.
Perform the following preliminary procedures before energizing the equipment:
a. Check that the ON/OFF switch is set to the ‘OFF’ position.
b. At the rear of the RF power amplifier, verify that the AC cord is properly
inserted into the receptacle connector.
c. Verify that 50 ohm loads are connected to the RF Input and Output ports.
3.6. Turn On
Perform the following procedures to energize the equipment:
a. Set the ON/OFF switch to the ‘ON’ position. Verify that the green switch
lamp is lit.
b. Apply RF power.
OM_5100F 12/12/01 Page 8 of 14

OM_5100F 12/12/01 Page 9 of 14
CAUTION!
To maintain specified performance and retain certain operating
characteristics, RF input power should not exceed +10 dBm.
3.7. Operation
3.7.1 ON/OFF Switch
In the ‘ON’ position, AC power is supplied to the power amplifier.
3.7.2 ON/OFF Switch Lamp
Lights to indicate the distribution of AC power throughout the power
amplifier.
3.7.3 TEMP. FAULT Indicator
Lights at an internal temperature exceeding 80º C with the amplifier
turning off DC bias voltage to the main amplifiers’ modules. DC bias
voltage will automatically return at temperatures below 75º C.
3.8 Turn Off. WARNING!
In the event of ANY power failure, whenever possible and practical, it is
advisable to reset the ON/OFF switch on the front panel to the “OFF”
position before you reconnect AC power to the power amplifier. This is to
prevent any possible electrical damage to the amplifier, due to the initial
power surge, once power is restored.
Turn off the RF power amplifier by first lowering or removing the RF Input drive
level and then placing the ON/OFF switch in the ‘OFF’ position.
