OPLENIC Pro-MicroScan User manual

User Manual
Pro-MicroScan
Microscope Digital Camera
BASIC USER MANUAL
Version 3.0
USB 2.0 CAMERA

User Manual
WARNING!
TO AVO ID TH E RISK OF FIRE OR ELECT RICAL SHOCK.N EVER EXPOSE THIS PRO DUC T TO WATER OR
OPER ATE IN AH IGH HU MID IT Y ENVIRONME NT.
Keep camera away from the following:
High temperatures and excessive humidity
Direct sunlight or other heat sources
Dust
Extreme vibration
If the camera lens becomes dirty, first try blowing dust particles from it.
Next use a lint free cloth or proper lens cleaning cloth to wipe the lens gently.
Only use approved lens cleaning fluids. Never touch the lens with your
fingers! Do not allow the camera to come into contact with water or any
other liquid. If water or a foreign substance should get in the camera,
unplug the camera immediately and do not attempt to plug in until after a
long period of time to allow for drying. This does not necessarily mean it will
work again! Do not open the camera case or attempt your own repairs.
Internal components may create risk of electrical shock or fire. There are no
user serviceable components inside. Clean the outside of the camera by
wiping with a clean, dry cloth. Never use harsh or abrasive cleaners or
organic solvents on the camera or any of its parts. If you notice smoke or a
strange smell coming from the camera, immediately unplug the camera and
consult an authorized dealer.

User Manual
Trademark and Copyright information
© COPYRIGHT 2008, OPLENIC
All rights are reserved. No part of this document may be photocopied,
reproduced, or translated to another language without the prior written
consent of OPLENIC. The information contained in this document is subject
to change without notice. OPLENIC shall not be liable for errors contained
herein or for consequential damages in connection with the furnishing,
performance or use of this material.
Microsoft®and Windows®are U.S. registered trademarks of Microsoft
Corporation.
Welcome
Thank you for buying OPLENIC Pro-MicroScan high resolution USB2.0 camera. We
suggest you spend a few minutes carefully reading this user manual before
installing and using your camera.
Please keep this user manual in a safe place for future reference.

User Manual
Warnings and Precautions
Precautions when using your Pro-MicroScan
Keep camera away from the following:
·High temperatures and excessive humidity
·Direct sunlight or other heat sources
·Dust
·Extreme vibration
If the imaging sensor lens becomes dirty, first try blowing dust particles from it.
Next use a lint free cloth or proper lens cleaning cloth to wipe the lens gently.
Only use approved lens cleaning fluids. Never touch the lens with your fingers!
Do not allow the camera to come into contact with water or any other liquid. If
water or a foreign substance should get in the camera, unplug the camera
immediately and do not attempt to plug in until after a long period of time to
allow for drying. This does not necessarily mean it will work again! Do not open
the camera case or attempt your own repairs. Internal components may create risk
of electrical shock or fire. There are no user serviceable components inside.
Clean the outside of the camera by wiping with a clean, dry cloth. Never use harsh
or abrasive cleaners or organic solvents on the camera or any of its parts.
If you notice smoke or a strange smell coming from the camera, immediately
unplug the camera and consult an authorized dealer.

User Manual
System Requirements
PC running either Windows ®XP or Vista, 2008
♦DirectX 9.0 or later installed
♦1.8 GHz minimum processor
♦USB 2.0 Port
♦CD-ROM drive
♦512 MB RAM(Recommend 1GB or more)
♦200 MB Free HDD
Performance is dependent on the PC's graphics card.
USB 2.0 is only supported on Windows ®2000, Me, XP, 2003, Vista and 2008. Do not
try to use any other Microsoft ®operating system. will NOT work on a Mac
Computer.
Windows 2000 must have Service Pack 4 (or later) installed and XP Pro must have
Service Pack 2 (or later) installed in order for the camera to function correctly. To
check if you have USB2.0 installed on your computer goes to:
Start > Settings > Control Panel > System⋯or 'right-click' on “My Computer” and
select “properties” from the context menu...
Click on the “Hardware” tab and then onto the button “Device Manager”;
Within Universal Serial Bus controllers (USB controllers) you will see a list of USB
devices installed on your machine. In this example the red arrow is indicating the
USB2.0 device. USB2.0 controllers may be labeled as USB2.0 controllers, however
they may also be labeled as “Enhanced” or “Standard Enhanced” controllers. The
so-called “Standard” or “Standard Universal” controllers are for the slower
USB1.x system.

User Manual
Package Contents
If you find any contents missing or damaged, contact the place of purchase
1 PCS EYEPIECE CAMERA
1 PCS DUST COVER
1 PCS MINI USB2.0 CABLE
1 PCS SOFTWARE CD (OPTION)
*Software can be download from website DEM page for free.
Installing the Software
(If you do not have the software CD, skip this step.)
1. Insert CD into CD-ROM drive
2. Install image capture software (After installation the image software icon will created
on the desktop)

User Manual
To Connect Camera
Connect the USB cable into a free USB slot on the computer (Requires USB 2.0 interface).
“New Hardware Found” displays at the bottom right of your PC screen. The camera is recognized.
NOTE:
1.Plug the USB connector to board USB2.0 port directly on the back of the PC is recommend,
2.Do NOT use anything to extend the USB cable.
Using the camera
There are 2 ways to get video from the camera.
A. Using Microsoft Windows Viewer
1.Open “My Computer”, you will find the “USB Video Device” with icon.
2.Double Click the “USB Video Device” icon to start video.
3.Capture and delete…
B Using video image software
1. Start the MiniSee
2. Start video
MiniSee--Click on the camera name below “Video” button.
3. Connect the camera to the microscope and turn on the light.
(Please make sure your light system has the option of a BLUE LIGHT FILTER. For the CCD to view
properly, you would need light color temperatures around 5600K-6000K.)
4. Setting the Video source property
5. Capture the image Press to capture image

User Manual
6. Capture the Video and Still images
Trouble Shooting
WARNING:
Please do not attempt to open the camera case. There are no user serviceable parts inside.
USB Device Conflicts
When there are a number of USB devices installed at the same time, unexpected errors can arise. The
cause can be insufficient available USB bandwidth, or possibly too much combined current being drawn
by USB devices. To test for these conditions you should uninstall and unplug as many other USB devices
as possible. This should help to rule out the above, and eliminate possible conflicts with other cameras.
If you are using an extended USB cable, please make sure the cable’s bandwidth is good enough to
support High-Speed USB 2.0 standard. Once the camera is not working well, please remove it.
Image Preview/Capture Problems
If you have installed camera and you get a black screen, Check the setting of camera, make sure
preview is select on

User Manual
Frame rate slow &color noise on the screen
Video Mode: use smaller size video mode will get faster frame rate video
Integration time / luminous intensity setting: longer Integration time and brighter illumination will
make the frame rate faster.
If you have any other problems, please visit our website to get help information
http://www.oplenic.com/support.asp
http://www.oplenic.com/faq.asp

User Manual
Technical Data Sheet
Pro-MicroScan : digital eyepiece camera FOR microscope
Part Number #5820 #5821 #5822 #5823 #5825
Sensitivity
(v/lux-sec @550nm) 2.0 1.0 2.0 1.0 1.0
Max Resolution
(Hardware)
640X480
0.3M pixels
1280X1024
1.3M pixels
1600X1200
2M pixels
2048X1536
3M pixels
2592 X 1944
5M pixels
Full Res. Frame Rate
(Depend on the PC)
30frames/sec@
640X480
15frames/sec@
1.3M pixels
15frames/sec@
1600X1200
3frames/sec@
2048X1536
3frames/sec@
2592 X 1944
Dynamic Range 60dB 68dB 71dB 75dB 75dB
Wave Length(nm) 400-650nm (IR-Cut added)
Exposure ERS (Electronic Rolling Snap)
White Balance Automatic / Advanced Manual
Auto-exposure Automatic / Advanced Manual
Image Output USB2.0, 480Mb/s
Power Supply USB2.0 DC 5V / 250mA
Programmable
Control Image size, exposure time, brightness, gain, Gamma Correction, color,, contrast, Saturation,
Working
Temp e ra t ure -30°C ~ 70°C
USB Cable Mini USB cable, length 1.5m
Accessories Included 2 adaptors (Ф23.2 to Ф30, Ф23.2 to Ф30.50, one each) available for option at extra cost
Output data RGB24, VFW,Direct Show and Twain interface
Software Image software: MiniSee
Operating System Windows 2000 / Me / XP(SP2/SP3) / 2003 / Vista / 2008 32Bit system
