Sanit-ICE®
Installation & Operation Manual
Ozone System
OptiPure, a Division of Aquion, Inc.
Commercial Water Filtration Systems
101 S. Gary Ave., Suite A, Roselle, IL 60172 • 972.881.9797
E-mail: [email protected] • www.optipurewater.com • Copyright © 2018 - OptiPure
Reproduction of any kind is prohibited • LIT375 • REV0083018

- 1 -
O3
INTRODUCTION
This Installation and Operation Manual is written to assist in theinstallation,
operation and maintenance of systems manufactured by OptiPure. This
equipment has been designed using the most modern materials and
technology available.
Please read this manual carefully and in its entirety before proceeding with
any installation, operation, or maintenance procedure associated with this
equipment. Failure to follow these instructions could result in personal injury,
damage to the equipment, or reduced product performance.
In an ongoing effort to improve reliability and operating efficiency, OptiPure
may find it necessary to make changes to its products. Therefore, the
information contained in this manual may not conform in every respect to
earlier versions of OptiPure systems found in the field. If you have any
questions, please contact your OptiPure dealer or the OptiPure service
department.

- 2 -
TABLE OF CONTENTS
Theory of Operation................................................................3
Instructions ..............................................................................4
Installation Procedures ........................................................... 6
Figure 1 – Feature Callout .................................................7
Figure 2 – Typical Installation............................................7
Operating Instructions ............................................................ 8
Figure 3 – Summary of LED Indicators.............................. 8
Trouble Shooting .....................................................................9
Servicing ...................................................................................9
Appendix A – Specifications .................................................10
Appendix B – Warranty Information.................................. 13

- 3 -
THEORY OF OPERATION
This Sanit-ICE® System is an environmentally friendly device allowing you
to infuse dissolved ozone into an ice maker water reservoir. Using only a
small amount of electricity, the Sanit-ICE® System takes oxygen from the air
and converts it into ozone (O3), a very powerful natural oxidizer, and then
bubbles that ozone into the water sump inside the ice machine.
Since ozone is created using only oxygen and electricity, any unused ozone
quickly breaks down to oxygen, leaving no harsh chemical residue and
discharging no harsh chemicals into the water. No chemicals mean the taste
of the water and subsequent ice produced is not negatively impacted.
This unit will adapt to any size ice machine via a simple ozone delivery line
into the water reservoir. The unit delivers ozone through a single hole in the
ice machine to a diffusor in the sump. As the ozone passes through the
diffusor it becomes small bubbles. The small bubbles allow some of the ozone
to become dissolved in the water, providing a sanitizer in the water. Any
ozone that doesn’t dissolve will mix with the air inside the ice machine
sanitizing all the remaining internal surfaces.

- 4 -
INSTRUCTIONS
1. Save These Instructions. Before using, pleaseread
the owner’s manual carefully
2. Disconnect power before servicing
3. Make sure the Sanit-ICE® System is horizontal.
See installation instructions. Do not mount to a
wall vertically or at any angle. The unit may also
be placed on a flat horizontal surface.
4. Do not operate the unit with the cover removed
5. Do not use an extension cord.
6. The Sanit-ICE® System should be cleaned with a
damp cloth. Avoid using harsh chemicals,
abrasives, or cleaners.
7. Warning - The unit has only been evaluated for
mechanical, electric shock, and fire hazards. The
method to control ozone release or the
effectiveness of the water treatment has not been
investigated.
8. Warning – Short term inhalation of high
concentrations of ozone and long-term inhalation
of ozone can cause serious harmful physiological
effects. Do not inhale ozone gas produced by this
device.
9. This appliance is not intended for use by persons
with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge.
10. Children should be supervised to ensure that they
do not play with the appliance.

- 5 -
Instructions
11. GROUNDING INSTRUCTIONS – This
appliance must be grounded. In the event of a
malfunction or breakdown, grounding will reduce
the risk of electric shock by providing a path of
least resistance for electric current. This
appliance is equipped with a cord having an
appliance-grounding conductor and a grounding
plug. The plug must be plugged into an
appropriate outlet that is installed and grounded
in accordance with all local codes and ordinances.
12. WARNING – Improper connection of the
appliance-grounding conductor can result in a
risk of electric shock. Check with a qualified
electrician or service representative if you are in
doubt whether the appliance is properly
grounded. Do not modify the plug provided with
the appliance; if it will not fit the outlet, have a
proper outlet installed by a qualified technician.
13. If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.

- 6 -
INSTALLATION PROCEDURES
Clean Ice Maker
Clean your ice maker to industry standards. The Sanit-ICE® System is
designed to keep a clean ice maker from becoming dirty. It will
sterilize a dirty ice maker, but it will still appear dirty.
Unpacking
Make sure all of the components are in the box before beginning
installation of the Sanit-ICE® System. In addition to this manual, you
should have (1) Sanit-ICE® unit, (1) z-bar mount, (10ft) tube, (1)
rubber grommet, and (1) diffusor.
Locate a Mounting Location
Before beginning the installation, locate a suitable location for the
Sanit-ICE® System. Find a flat portion of a wall, close to the ice maker.
The unit may also be placed on a flat, level surface. Please consider
the following when selecting a mounting location:
• Never install the Sanit-ICE® System in an area where water may
freeze. Freezing water will damage the internal components.
• The Sanit-ICE® System is mounted horizontally. Refer to the
installation instructions. Do not mount vertically or at an angle.
Always use a level when installing this unit.
• The Sanit-ICE® System is close enough to a power outlet so an
extension cord is not necessary.
• The Sanit-ICE® System is to be mounted no further than 10 feet
from the point of use.
• Mount the Sanit-ICE System above the entry point of the ozone
line into the ice machine.
Mount the Sanit-ICE® System
• Use the appropriate tools and mounting hardware (not provided)
for the material the wall is constructed from and install the z-bar.
Use a level to make sure it is horizontal.
• Place the Sanit-ICE® System onto the z-bar.

- 7 -
Connect Diffusor
Installation Procedures
• Drill one Ø7/16-inch hole into ice maker close to and above the
water reservoir. Install grommet provided into hole.
• Attach one end of the supplied tubing to the ozone outlet of the
Sanit-ICE®.
• Run tubing through grommet installed in ice maker. Attach the
opposite end of the tubing to the barbed fitting of the diffuser
provided and place the diffuser into the water reservoir.
• Plug the Sanit-ICE® System into a GFCI protected outlet.
Feature Callout
Figure 1
Typical Installation
Figure 2
Ø7/16” Hole
for grommet
Sump Water Line
Sanit-ICE® System:
• No more than 10 ft from
ice maker
• Above sump water line
• Not using an extension
cord
Ozone Outlet
LED Indicator
Z-Bar Mounting
Cooling Fan
Mode Select Button

- 8 -
OPERATING INSTRUCTIONS
Once installed, the Sanit-ICE® System is ready to use. Simply
press the mode select button to cycle through different flow profiles.
Use the chart below to choose the appropriate profile based off your
ice maker’s 24-hour ice yield and the conditions of your facility.
The Sanit-ICE® System’s LED indicator light stays illuminated,
letting you know the unit is operating normally and in standby mode
waiting for the next ozone cycle. When the integrated timer triggers,
the Sanit-ICE® System will automatically turn on the internal pump.
The indicator LED will blink indicating that ozone is flowing through
the system. The timer is tied to a programmed universal clock that
starts when the unit is plugged in and cycles every ten minutes. Ozone
is only produced at the beginning of a cycle for a time period based on
your profile, and the unit must reach a new cycle before ozone is
produced again.
In the event of power loss, the Sanit-ICE® System will remember
what profile it was set at, and resume function when it receives power
again. If the system is turned off in the middle of producing ozone or
once a cycle completes, the Sanit-ICE® System will leave the pump
and fan on for approximately 10 seconds to purge ozone from the
system and cool down the ozone generator.
Summary of LED Indicators
Figure 3
Light
Color
24 Hour Ice
Yield, Normal
Environment
24 Hour Ice
Yield, Extreme
Environment*
Air
flow
(SCFH)
Repeatin
g
Runtime
(Minutes)
Off
Off
Yellow
<400 lbs
n/a
0.5
1 On / 9 Off
Green
400-600 lbs
<400 lbs
1.0
2 On / 8 Off
Blue
600-1000 lbs
400-600 lbs
1.5
4 On / 6 Off
Purple
1000+ lbs
600+ lbs
2.0
7 On / 3 Off
Red
Service Required
*Examples of extreme operating environments include bakery operations, bar and taverns,
microbreweries, etc.

- 9 -
TROUBLE SHOOTING
Light does not come on
• Verify the unit has power
• Push the mode select button to see if the unit will cycle
through different modes
Bubbles do not come out of diffusor
• Make sure that the indicator LED is blinking. If the light is on
but not blinking, the unit is in standby. Wait for 10 minutes
for another ozone cycle to occur.
• Clean the diffuser (see servicing for details)
SERVICING
Note
Disconnect power from unit before performing any maintenance
procedures.
As Needed
Clean fan filter: Remove fan cover by grasping the fan grill witha
pair of needle nose pliers and gently pulling. Take out foam filter,
wash filter with warm soapy water, allow to dry, and re-install.
Clean Diffuser: submerse diffuser in vinegar for 2 hours and rinse
clean.
Red Light Illuminated
The light on the Sanit-ICE® system will turn red after the ozone cell
has run for approximately 9000 hours. This will typically take
between 1 and 3 years depending on which mode the unit is in. At
this time the unit needs to be serviced. Servicing includes replacing
the ozone generator and barbed ozone outlet fitting.

- 10 -
APPENDIX A -SPECIFICATIONS
System
Dimensions
10W x 5.6T x 3.6D inches
(254W x 142T x 92D mm)
Outlet
3/16” Barb
Power
120/240 VAC, 50/60 Hz
Power Connection
6’ (1.8m) 3-prong cord
Mounting
Z-bar
Ambient Conditions
32-95 °F (0-35 °C)
10-90% RH non-condensing
Shipping Weight
3.5 lbs (1.6 kg)
Performance
Air Flow
2-4 SCFH (1.0-1.9 L/min)
Ozone Output
(Continuous)
250 mg/hr at 4 SCFH
on ambient air

- 11 -
Appendix A – Specifications
Ozone Generator
Power Supply Ozone Outlet
Air Compressor
Power Cord
Control Board
Ozone Cell
Fan

- 12 -
APPENDIX B – WARRANTYINFORMATION
OptiPure. Limited One-Year Warranty
Summary of the Warranty
OptiPure makes every effort to assure that its products meet high quality and durability
standards and warrants the products it manufactures against defects in materials and
workmanship for a period of one (1) year, commencing on the date of original shipment
from OptiPure, with the following exceptions: 1) The warranty period shall begin on
the installation date if the installation is performed within 90 days of the original
shipment from OptiPure; 2) The warranty period shall begin on the date of the bill of
sale to the end user if the installation date is more 90 days after the original shipment
date.
Repairs and replacement parts provided under this warranty shall carry only the
unexpired portion of this warranty or 90 days, whichever is longer.
Items Excluded from the Warranty
This warranty does not extend to any product and/or part from which the factory
assigned serial number has been removed or which has been damaged or rendered
defective as a result of:
• An accident, misuse, alteration or abuse
• An act of God such as flood, earthquake, hurricane, lightning or other disaster
resulting only from the forces of nature
• Normal wear and tear
• Operation outside the usage parameters stated in the product user’s manual
• Use of parts not sold by OptiPure
• Service or unit modification not authorized by OptiPure
• Damage which may occur during shipping
• Failure to meet service requirements as outlined in the I & O manual
• Damage due to exposure to other chemicals
Obtaining Service Under the Warranty
Any product and/or part not performing satisfactorily may be returned to OptiPure for
evaluation. A Return Goods Authorization (RGA) number must first be obtained by
either calling or writing your local authorized dealer, distributor or OptiPure direct,
prior to shipping the product. The problem experienced with the product and/or part
must be clearly described. The RGA number must appear prominently on the exterior
of the shipped box(es). The product and/or part must be packaged either in its original
packing material or in comparable and suitable packing material, if the original is not
available. You are responsible for paying shipping charges to OptiPure and for any
damages to the product and/or part that may occur during shipment. It is recommended

- 13 -
Appendix B – Warranty Information that you insure the shipment for the amount you
originally paid for the product and/or part.
If, after the product and/or part is returned prepaid and evaluated by OptiPure, it proves
to be defective while under warranty, OptiPure will, at its election, either repair or
replace the defective product and/or part and will return ship at lowest cost
transportation prepaid to you except for shipments going outside the 50 states of the
United States of America. If upon inspection, it is determined that there is no defect or
that the damage to the product and/or part resulted from causes not within the scope of
this limited warranty, then you must bear the cost of repair or replacement of damaged
product and/or part and all return freight charges. Any unauthorized attempt by the end
user to repair OptiPure manufactured products without prior permission shall void any
and all warranties. For service, contact your authorized dealer or distributor or OptiPure
direct at [phone].
Exclusive Warranty
There is no other expressed warranty on OptiPure products and/or parts. Neither this
warranty, nor any other warranty, expressed or implied, including any implied
warranties or merchantability of fitness, shall extend beyond the warranty period.
Some states do not allow limitation on how long an implied warranty lasts, so that the
above limitation or exclusion may not apply to you.
Disclaimer of Incidental and Consequential Damages
No responsibility is assumed for any incidental or consequential damages; this
includes any damage to another product or products resulting from such a defect. Some
states do not allow the exclusion or limitation of incidental or consequential damages,
so that above limitation or exclusion may not apply to you.
Legal Remedies of Purchaser
This warranty gives you specific legal rights and you may also have other rights, which
vary from state to state.
THIS STATEMENT OF WARRANTY SUPERSEDES ALL OTHERS
PROVIDED TO YOU AT ANY PRIOR TIME.
