Optoma DS316 User manual

www.optoma.co.uk
Bright projection
– 2500 ANSI Lumens
SVGA resolution, 2500:1 contrast ratio for
sharp, detailed presentations and graphics
Easy to use with games consoles,
DVD players, digital satellite/TV boxes
& PCs/laptops
BrilliantColor™ technology
– vibrant life-like colours
Energy saving – <1W standby mode
Low ownership costs
– up to 4000hrs lamp life
�
DLP® filter-free design
– Virtually no maintenance
DS316
DLP®Projector Ultimate Big Screen
Viewing Experience
5
5

HOOK IT UP TO ANYTHING!
Easy to use with most of your home devices; simply connect,
power up and project.
You can even create a genuine movie experience anywhere.
Change the aspect ratio of the screen from 4:3 format to 16:9
– just like a real cinema.
s
s
s
k
k
y
y
CLEAR, FOCUSED IMAGES
High contrast ratio 2500:1, achieved with DLP® technology for
a stunning viewing experience. Crisper whites, ultra-rich
blacks for images that come alive on screen, making it ideal for
unforgettable presentations or movies.
With Without
Big Screen Viewing
Perfect for use with interactive whiteboards at school, delivering an important presentation at work, or watching
a movie on the big screen at home, the Optoma DS316 will exceed your expectations.
Impressive 2500 ANSI Lumens from a small, sleek and stylish design, the DS316 will attract attention for all the
right reasons.
The environmentally friendly DS316 has energy saving features including <1W standby mode. Long lamp-life
of 4000hrs combined with our unique Optoma Colour and Imager guarantees saves you both time and money while
ensuring hassle-free, long lasting projection.
DS316
SMOOTH, SEAMLESS PROJECTION
Even in the fastest moving scenes, the DS316 will project a smooth
and seamless image. The rapid response of DLP® technology
ensures that the projected movie or video game remains perfect
and precise.
With Without
Lightweight projector gives a
clear, bright projection

AMAZING COLOURS
The DS316 incorporates BrilliantColor™ technology to produce
stunningly bright images with perfectly balanced life-like colours.
COLOUR PERFORMANCE
Optoma guarantees colour quality will remain as new
for 5 years*
Once you’ve purchased the DS316, Optoma guarantees that the
colours will not fade and the image performance will not degrade for
a minimum of 5 years.
5
MAINTENANCE FREE = LOWER TOTAL COST
OF OWNERSHIP (TCO)
DLP® technology ensures lower cost of ownership, longer life and
improved reliability compared to other technologies.
Filter-free projector design means no more regular filter cleaning
or replacements, saving you time and money.
FEATURES
6 preset picture modes
Classroom mode - 1500 ANSI Lumens
Quick keystone correction
Security bar and password protection for added security
Easy to use remote with direct source control
TIME AND ENERGY SAVINGS
The DS316 incorporates energy saving features to conserve power
and extend the lamp life:
The timer control functions can automatically switch the
projector off to standby mode <1W, conserving power and
extending the lamp life to an astonishing 4000 hours**.
It takes less than 10 seconds for the projector to power
up and shutdown, so the DS316 not only saves time but
energy too.
IMPROVED SECURITY
Easy to secure with the inclusion of a tough security bar, Kensington™
Lock, keypad lock and password protection.
DS316
Enjoy big colourful
presentations or movies
day or night

DS316 SPECIFICATIONS
Native Resolution SVGA 800 x 600
Compressed Resolution UXGA (1600 x 1200)
Brightness - BRIGHT mode 2500 ANSI Lumens
Contrast 2500:1
Noise Level 28dB
Lamp Life** 4000/3000 (STD/BRIGHT mode)
Projection Lens F/2.41~2.55; f=21.8~24mm, 1.1x Manual Zoom
Throw Ratio 1.95 - 2.15:1 (Projection Distance:Image Width)
Projection Distance 1.2 - 12m
Image Size 0.70 – 7.70m (27.49” - 303.12”) Diagonal 4:3
Display Technology Single 0.55” SVGA DC3 DMD chip DLP® Technology
by Texas Instruments
Weight / Dimensions (W x D x H) 2.3 kg / 286 x 192 x 84mm
Remote Control Full function remote with direct source selecting
INPUTS 15 Pin D-Sub VGA (SCART & Component via adaptor)
S-Video 4 Pin Mini Din
Composite RCA
3.5mm Audio Mini Jack
CONTROL RS232 - 3 Pin D-sub
OUTPUT 15 Pin D-Sub VGA
Stereo Audio Mini Jack
Audio 2W Speaker
Aspect Ratio 4:3 Native, 16:9 Compatible
Keystone Correction ± 40° Vertical
On Screen Display 18 Languages: English, German, French, Italian, Spanish,
Portuguese, Polish, Dutch, Russian, Finnish, Swedish,
Greek, Norwegian, Danish, Hungarian, Czech,
Turkish & Arabic
Video Compatibility PAL SECAM 576i/p, NTSC 480i/p, HD 720p/1080i/1080p
Uniformity 85%
Displayable Colours 1.07 Billion
Horizontal Scan Rate 15.3 - 91.1kHz
Vertical Scan Rate 24 - 85Hz
Power Supply 100 - 240V, 50 - 60Hz
Power Consumption 233W BRIGHT mode < 1W Standby mode
207W STD mode < 1W Standby mode
Operating Conditions Operating: 5 - 40˚C, 85% Humidity (Max),
3000m Altitude (Max)
Security Security Bar, Kensington Lock Port, Password Protection
Standard Accessories Lens Cover, AC Power Cord, VGA Cable, Full Function
Remote, Batteries x 2, Quick Start Guide, User Manual
CD, Warranty Card, WEEE Card
RoHS Compliant
Lamp Warranty 6 months or 1000 hours - whichever comes sooner
Warranty Warranty may vary by country.
Please see www.optomaeurope.com
or ask your local supplier for details
Colour Guarantee* 5 Years
Imager Guarantee*** 5 Years
Optoma Europe Ltd.
42 Caxton Way, Watford Business Park, Watford, Hertfordshire, UK. WD18 8QZ
www.optoma.co.uk
*Optoma guarantees that in normal use, Optoma DLP® colour quality will be indistinguishable from when new. Please note that worn lamps will give slight variance. Exclusions: *(1) Guarantee is voided if the projector is subject to damage through mis-use.
(2) Guarantee may be void in industrial or commercial entertainment environments where dust or smoke is particularly excessive (3) Guarantee will not apply if lamp brightness is below 50% due to wear or if the projector is not working due to other fault.
**Typical lamp life achieved through testing. Will vary according to operational use and environment conditions. *** Optoma guarantees that in normal use, the DLP® imager guarantee will retain quality for at least 5 years providing consistent pixel performance.
Exclusions: (1) Guarantee is voided if the projector is subject to damage through mis-use. (2) Guarantee may be void in industrial or commercial entertainment environments where dust or smoke is particularly excessive.
Copyright © 2009, Optoma Europe Ltd.All other product names and company names used herein are for identifications purposes only and may be trademarks or registered trademarks of their respective owners. Errors and omissions excepted,
all specifications are subject to change without notice. DLP®, BrilliantColor™ and the DLP logo are registered trademarks of Texas Instruments.
Optoma recommended Screens
www.panoview.eu
DS316
DS316 Remote Control
1Vertical Keystone Correction
2Volume Control
3Brightness Adjustment
4Contrast Adjustment
5AV Mute
6Direct Input Source Selection
DS316 Connections
7VGA - SCART & Component
8S-Video
9Video
10 RS232 - 3 Pin
11 VGA Out
12 Audio Out
13 Audio In
14 Kensington™ Lock
15 Security Bar
EASY TO USE REMOTE CONTROL
12
3
5
4
6
Exceptional Connectivity / Multiple Terminals
7 8 11
DS316 Projection Distance 1.2 - 12m (4:3 Aspect Ratio)
Projection Distance (m) Max. Horizontal
Image Size (m)
Min. Horizontal
Image Size (m) Max. Vertical Image Size (m) Min. Vertical Image Size (m) Max Diagonal Image Size (m) Max Diagonal Image Size (inch) Max. Image Offset (m)
1.20
2.00
2.50
3.00
4.00
5.00
6.00
7.00
8.00
9.00
10.00
11.00
12.00
0.62
1.03
1.28
1.54
2.05
2.56
3.08
3.59
4.10
4.62
5.13
5.64
6.15
0.56
0.93
1.16
1.40
1.86
2.33
2.79
3.26
3.72
4.19
4.65
5.12
5.58
0.46
0.77
0.96
1.16
1.54
1.93
2.31
2.70
3.08
3.47
3.86
4.24
4.63
0.42
0.70
0.87
1.05
1.40
1.75
2.10
2.45
2.80
3.15
3.50
3.85
4.20
0.77
1.28
1.60
1.92
2.57
3.21
3.85
4.49
5.13
5.77
6.42
7.06
7.70
30.31
50.52
63.15
75.78
101.04
126.30
151.56
176.82
202.08
227.34
252.60
277.86
303.12
0.07
0.12
0.14
0.17
0.23
0.29
0.35
0.40
0.46
0.52
0.58
0.64
0.69
For guide purposes only
