ORANGE CR6S User manual

1
CR6S
Stereo Micro Crush
ENGLISH

2
CR6S
Stereo Micro Crush
ENGLISH
THANK YOU!
Thank you for choosing Orange. You are now a member of the
‘Legendary British Guitar Amplifier’ owners club!
Since 1968 when the company was founded, Orange has been a
pioneering force in the guitar amplification industry. Today, with
a team of the world’s finest amplifier engineers, Orange
continues to push back the boundaries of conventional amplifier
design.
Our commitment to craftsmanship and quality control has
allowed our amplifiers to stand the test of time, giving their owners as much pleasure now, as the day
they were bought. To maintain this level of excellence, each Orange amplifier is put through many
rigorous test procedures before leaving the factory.
This booklet contains valuable technical and safety information Please t ake the time to read this manual
as the information may enhance the sound and performance of your amplifier. We are confident that
you will be delighted with your new purchase and that it will provide you with many years of enjoyment.

3
CR6S
Stereo Micro Crush
ENGLISH
CONTENTS
CONTACT DETAILS...................................................................................................................................4
IMPORTANT SAFETY INFORMATION.......................................................................................................5
POWER .................................................................................................................................................... 8
FRONT PANEL FEATURES ........................................................................................................................9
REAR PANEL FEATURES.........................................................................................................................10
TROUBLESHOOTING.............................................................................................................................. 11
FREE EXTENDED WARRANTY OFFER .....................................................................................................12

4
CR6S
Stereo Micro Crush
ENGLISH
CONTACT DETAILS
Orange Amplification
OMEC House
108 Ripon Way
Borehamwood
Hertfordshire
WD6 2JA
ENGLAND
Tel: [phone]
Fax: [phone]
[email protected]
Orange USA
2065 Peachtree Industrial Ct.
Suite 208
Atlanta, GA 30341
USA
Tel: [phone]
Fax: [phone]
[e-mail]

5
CR6S
Stereo Micro Crush
ENGLISH
IMPORTANT SAFETY INFORMATION
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of un-insulated ‘dangerous voltage’
within the product’s enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons. Terminals labelled as
“Speaker Outputs” must be connected to a speaker cabinet of the designated
load rating using an un-shielded two conductor cable for speaker use at all times
during operation
The exclamation point within an equilateral triangle and "WARNING" are
intended to alert the user to the presence of important operating instructions.
Failure to heed the instructions will result in severe injury or death.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near liquid.
• Clean only with dry cloth.

6
CR6S
Stereo Micro Crush
ENGLISH
• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades, one wider than the other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the obsolete outlet.
• Servicing: Do not attempt to service this product yourself as opening or removing covers may
expose you to dangerous voltage or other hazards.
• Refer all servicing to qualified service personnel.
• Damage Requiring Service: Unplug this product from the wall outlet and refer servicing to
qualified service personnel under the following conditions: (a) When the power-supply cord or plug
is damaged; (b) If liquid has been spilled, or objects have fallen into the product; (c) If the product
has been exposed to rain or water; (d) If the product does not operate normally by following the
operating instructions. Adjust only those controls that are covered by the operating instructions.
Improper adjustment of other controls may result in damage and will often require extensive work
by a qualified technician to restore the product to its normal operation; (e) if the product has been
dropped or damaged in any way; (f) when the product exhibits a distinct change in performance -
this indicates a need for service.
• Replacement Parts: When replacement parts are required, be sure the service technician has
used replacement parts specified by the manufacturer or have the same characteristics as the
original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

7
CR6S
Stereo Micro Crush
ENGLISH
This Orange Amplifier conforms to UL Standard 60065 for Audio, Video and Similar Electronic
Apparatus - Safety Requirements;
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try and correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.

8
CR6S
Stereo Micro Crush
ENGLISH
POWER
ABOUT POWER
Since power consumption of this unit is fairly high, we recommend the use of an AC adapter
whenever possible. When powering the unit from a battery, use only an alkaline type.
AC ADAPTER OPERATION
Be sure to use only an AC adapter regulated 18V, 800mA and equipped with a
"centre minus" plug.
The use of an adapter other than the specified type may damage the unit and pose a
safety hazard.
The use of a non-regulated adapter could cause a low frequency hum in your
amplifier.
If the amplifier is not to be used for long time, disconnect the AC adapter from the
main socket.
BATTERY OPERATION
Use a generic 9V x 2 dry battery (6F22) (alkaline or manganese).
The Stereo Micro Crush cannot be used for recharging.
Pay close attention to the labelling of the battery to make sure you choose the correct
type.
If the Stereo Micro Crush is not to be used for an extended period of time, remove
the battery from the unit.
If batteries leakage has occurred, wipe the battery compartment and the battery
terminals carefully to remove all remnants of battery fluid.
While using the unit, the battery compartment cover should be closed.
9V x 2 battery compartment is on the bottom of the Unit.
To access pull on small tab labelled "OPEN". Replace with 2x new 9 V batteries.

9
CR6S
Stereo Micro Crush
ENGLISH
FRONT PANEL FEATURES
1. Input Jack Socket
Plug your instrument into this jack socket. A jack must be plugged into this socket for the
amplifier to ‘power up’. This is a battery saving feature.
2. Gain Control
This controls pre-gain level.
3. Tone Control
This controls the overall sound of the amplifier. Turning clockwise produces brighter tones.
4. Volume Control
This controls the output volume.
5. Aux In
Use this 1/8" stereo mini jack to connect the output of a CD or, MP3 player,Laptop,etc.,to the
amp (the jacks are internally summed to a mono signal).
6. Headphone Socket.
Connect headphones for silent practice.

10
CR6S
Stereo Micro Crush
ENGLISH
REAR PANEL FEATURES
1. Aux in/Stereo
Use this socket to connect your MP3 player or computer via 3.5mm jack
2. Line Out
Connect to external speakers or recording interface

11
CR6S
Stereo Micro Crush
ENGLISH
TROUBLESHOOTING
No Sound
Is there a cable plugged into the Input jack socket?
Check the connections and cable.
Is the battery connected?
If using a power adaptor, make sure that the adapteor is connected correctly.
Is the guitar volume or volume control of the Micro Crush turned down?
Noise is heard
Is the cable good quality?
Low quality cables can cause noise. Use a shorter and good quality cable.
Is the unit used in the vicinity of a computer monitor, fridge, fluorescent lamp, or similar
device? The guitar or cable can pick up noise from such devices. In case of problems,
increase the distance to such devices.
Is an adaptor other than the specified type used?
Be sure to use only the correct AC adaptor
Strange buzzes/unusual distortion are signs that the batteries are low. Replace the batteries.

12
CR6S
Stereo Micro Crush
ENGLISH
FREE EXTENDED WARRANTY OFFER
Orange amplifiers are under warranty for one year subject to consumer protection laws in the
country of purchase and distributor’s terms and conditions, an additional year can be added by
registering.
Valves and speakers supplied with an Orange amp or purchased separately at our online store are
covered for 90 days from the date of purchase.
The warranty status of any Orange product is subject to its being used for its intended purpose in
suitable conditions. As the manufacturer we reserve the right to refuse to warranty any Orange
product which has been misused in any way whatsoever.
REGISTER RIGHT NOW AT www.orangeamps.com
