Oregon Scientific Boombero GREAT WZP388 User manual

Boombero GREAT
Model: ZP388
Instruction manual
PRODUCT OVERVIEW
1.
NFC / Status LED indicator
6.
Bluetooth activated/ talk
2.
Charging LED light
7.
MAXX
3.
DC in port
8.
Play/Pause
4.
Line in port
9.
Volume up
5.
Power on/off
10.
Volume down
CONTENTS
1. Boombero GREAT.
2. USB cable
3. Line-in cable
SET UP
1. Plug the BOOMBERO GREAT into an outlet using the included wall charger.
2. The Charging LED light will turn white when it is fully charged. It would take
around 2.5 hr for full charge.
Note:
Please charge the battery at least 3 to 4 hours at the first time.
1. Pair your Bluetooth ® device to the speaker when you turn on the speaker for
the first time.
2. The speaker pairs with devices that use the Bluetooth ® Hands Free Profile
(HFP) and/or the Advanced Audio Distribution Profile (A2DP). HFP enables
hands-free communication and the A2DP dictates how audio is streamed from
one device to another over a Bluetooth® connection.
3. When you pair devices to the speaker, the devices operate accounting to their
protocols.
1. Please upload NFC- BT Easy to your Android operated smart phone with NFC
function if your android platform is under 4.1 version
2. Please be reminded to turn on your smart phone’s Bluetooth connection
3. Tap your smart phone to NFC sensor region at the top of speaker. This refers to
“NFC” wording in white color
4. Then your smart phone will instantly pair with Bluetooth speaker for music
enjoyment
5. To disconnect it, please tab your connected smart phone at NFC sensor region
again
Note:
Please ensure your smart phone is equipped with NFC function.
To ensure your smart phone got NFC function, please find updated NFC
phone list at below website at http://www.nfcworld.com/nfc-phones-list/
1. In Press and hold unit the voice “Hi BOOMBERO is on” and press to
enter the pairing mode
2. Prepare your Bluetooth ® device (mobile phone or music player) to pair.
3. Select the searching mode on your Bluetooth ® device
4. Your Bluetooth ® device should find “BOOMBERO Great”, select it and pair it
5. Verify that you are connected to the speaker. The Bluetooth ® LED & the
speaker will change to a solid blue when paring is complete
Status:
1. Status: “OFF” stage with rechargeable batteries not fully charged
a. DC Plug in “RED” charging LED breathe 2 seconds
2. Status: “OFF” stage with rechargeable batteries FULLY charged
a. DC Plug in “RED” charging LED flash and them off
3. Press & Hold the 3 second and power on the unit and then enter into the
Standby mode
4. Status: “Standby mode”
a. Line in plug inPlay music immediately
b. Press & Hold 1second : “BLUE” LED flash alternatively, Enter to
Bluetooth pairing mode and connect with your Bluetooth ® devices
c. Press & Hold in 1second and then turn-off the unit.
5. Status: “Bluetooth connected”
a. “RED” LED Light on ( power-on state )
b. Bluetooth signal disconnected Searching 10second and then enter
standby if no further signal connected
c. Line in plug inMusic channel change to line in signal immediately and
resume Bluetooth channel immediately when line in plug out
d. Press & Hold the in 1second enter Bluetooth pairing mode,
“BLUE” LED indicator flash
6. Status: Music playing
a. Press and then the music volume are going down
7. Status: Music playing
a. Press and then the music volume are going up
8. Speaker Phone
a. When phone calling
b. Answer a call - Press the to enter conference call
c. Reject a call - Press Hold ( 3 seconds ) the to cut the incoming
call
d. Hang-up a call –Press the to hang-up the call
9. Play / Pause Button
When playing music, - Press , music playing Pause
Press again, music resume playing (Volume are resume to before)
10. MaxxBass On / Off Button (Default are ON when power on)
a. When playing music (Bluetooth or Line-in)
-Press “ “– Turn off MaxxBass function
-Press “ “again – Turn On MaxxBass level 1
-Press “ “again – Turn On MaxxBass level 2
1. Plug in the line in cable into the rear of the speaker Aux in socket.
2. Connect the other end of the line in cable to your devices headphone socket.
3. Recommend to play the speaker unit at maximum sound level.
SPECIFICATIONS
Power input:
5V, 2A
Total output:
8W, (4W/Channel)
Passive Radiator
Playtime (via Bluetooth®connect):
Approximately 8~10 hours
Recharging Time:
25 hours
Dimension:
208 X 65 X 91mm
Audio input
3.5mm Line-in jack, Bluetooth 3.0(A2DP)
Wireless
Bluetooth 3.0, NFC
Built Battery
3.7V, 2200mAh Li-Polymer battery
EN
NFC FUNCTION WORK FLOW
PAIRING MODEL AND PAIRING
KEY FLOWS
LINE-IN FUNCTION
PAIRING BLUETOOTH®DEVICE

WARNINGS
Before using this product, please kindly read these safety warnings and cautions
carefully to ensure your personal safety and prevent property damage. Please retain
this manual for future reference. Please kindly read the instructions for BOOMBERO
Great Bluetooth Speaker.
IMPORTANT SAFETY INSTRUCTIONS
Observe all warnings, precautions and instructions
Please keep out of the reach of the children.
Please read all safety warnings and instructions that require an electrical
devices that require an electrical device or radio product to be switched off in
designated areas such as gas/refueling stations, hospitals, blasting areas,
potentially explosive atmospheres or aircraft.
Dispose of the BOOMBERO Great and its batteries in accordance with local
regulations. Do not dispose of the battery with regular household waste.
PRECAUTIONS
Do not expose the speaker to high temperature, high humidity, rain or direct
sunlight. Do not use the BOOMBERO Great near a bathtub, sink, sauna, pool,
or steam room. Expose of the BOOMBERO Great to moisture could result in
electric shock.
Do not throw or drop the speaker or subject it to strong physical shock.
Do not disassemble, open, crush, bend, deform, puncture, shred, microwave,
incinerate, paint, or insert foreign object into the BOOMBERO Great. Such
actions could result in electric shock.
Do not allow liquid or small particles to get into the speaker
Use a soft and dry cloth to clean the headset. Do not use solvents or other
chemicals. Do not wipe with a chemically treated cleaning cloth.
Do not keep your BOOMBERO Great near open flames such as cooking
burners, candles or fireplaces.
Do not block any ventilation openings.
Do not place the BOOMBERO Great on high surfaces such as shelves. the
speaker may shift and fall off from shelves when the speaker plays .
WHEN CHARGING
Only charge the battery in accordance with the user instructions supplied with
the BOOMBERO Great.
Do not attempt to replace your BOOMBERO Great battery, it is built-in and is
not changeable.
Use only the manufacturer supplied charger to charge your BOOMBERO
Great. Other chargers may look similar, but using them could result in electric
shock and could damage the BOOMBERO Great.
Do not charge the BOOMBERO Great in damp areas or in extremely high or
low temperatures because this could result in electric shock.
Do not clean the BOOMBERO Great when it is being charged. Always unplug
the charger first before cleaning the BOOMBERO Great.
The AC adapter is as disconnect device,the socket-outlet shall be installed
near the equipment and shall be easily accessible
NOTE:
The technical specifications for this product and the contents of the user manual are
subject to change without notice.
ABOUT OREGON SCIENTIFIC
Visit our website www.oregonscientific.com to learn more about Oregon Scientific
products.
For any enquiry, please contact our Customer Services at [e-mail]
EU-DECLARATION OF CONFORMITY
Hereby, Oregon Scientific, declares that this Boombero GREAT (model: ZP388) is in
compliance with the essential requirements and other relevant provisions of Directive
1999/5/EC. A copy of the signed and dated Declaration of Conformity is available on
request via our Oregon Scientific Customer Service.
COUNTRIES RTTE APPROVED COMPLIED
All EU countries, Switzerland
and Norway .
© 2013 Oregon Scientific. All rights reserved..
FCC NOTE：
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED CHANGES OR MODIFICATIONS
TO THIS EQUIPMENT. SUCH CHANGES OR MODIFICATIONS COULD VOID THE
USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
