ORIOLUS CEIBA BD-10 User manual

PortableHeadphoneAmplifier
BD-10(CEIBA)
QuickGuide Oriolus
■INCLUDEDITEMS
・BD-10 ・Micro-USBcable ・SiliconeBelts
■PARTSANDCONTROLS
①Headphonejack  ②BalancedLINEOUTjack ③AUDIOIN/LINEOUTjack
④GAINselectswitch(High/Low)

⑤INPUTselectswitch(Source) ⑥Power/volumeknob
⑦USBconnectingport ⑧COAXIALINPUTport ⑨OPTINport
⑫powerindicator⑩USBtypeDCIN5Vport ⑪Chargeindicator
⑬USB-DACindicator
FrontSide RearSide
■CHARGINGTHEUNIT
①Rotatethepower/volumeknobcounterclockwiseuntilitclickstoturnofftheunit.
(Thebatterychargeswhiletheunitison.)
②ConnectyouracadapterorcomputertotheunitusingtheMicro-USBcable(supplied).
Chargeindicatorlightsupinred.
Chargingiscompletedinabout4hours(ThetimeisuptotheACadapter).Theindicatorturnsoff
whenthebatteryiscompletelycharged.
■TURNONTHECONNECTINGAUDIODEVICE
Whenconnectingtheunittoacomputer,installthedriver.
(ForMac,thereisnoneedtoinstalladriver.Visitourofficialwebsiteanddownloadthedriver.)
https://www.en.oriolus.jp/download/
■SETTHEINPUTSWITCHONTHEUNITANDCONNECTTHEAUDIODEVICE
Selecttheportpositionoftheconnectingaudiodevicefromamongthe5typesinputportswiththe
INPUTselectswitch(Source).
1.USBdigitaloutputsupporteddevice
①SwitchtheleverofSourceto“USB”
②Connecttheunittothedevicebythe“USB”portontherearpanel.
2.Opticaloutputjacksupporteddevice
①SwitchtheleverofSourceto“DIGITAL”
②Connecttheunittothedevicebythe“Optical”portontherearpanel.
(Thedigitalopticalcableisanoptionalaccessory.)
3.Coaxialoutputjacksupporteddevice
①SwitchtheleverofSourceto“DIGITAL”
②Connecttheunittothedevicebythe“Coaxial”portontherearpanel.
(Thedigitalcoaxialcableisanoptionalaccessory.)
4.AnalogLine-outputjacksupporteddevice
①SwitchtheleverofSourceto“AUX”
②ConnecttheunittothedevicebytheAUDIOIN/LINEOUTjackonthefrontpanel.
(Theanalogcableisanoptionalaccessory.)
5.AnalogLine-injacksupporteddevice
a.ConnecttheunittothedevicebytheAUDIOIN/LINEOUTjackonthefrontpanel.
(Theanalogcableisanoptionalaccessory.)
b.ConnecttheunittothedevicebytheBalancedLINEOUTjackonthefrontpanel
whenthedevicesupportbalancedinputmode.
(TheunitisusingthespecialHIROSE6pinsminiXLRtypejackforthebalancedmode.
AndtheHIROSEcableisanoptionalaccessory.)
■Listeningtomusicwiththeheadphones
ConnecttheheadphonestotheunitbytheHeadphonejackonthefrontpanel.
■Specifications
Frequencyrange:12.5Hz~20kHz+/-0.1dB(amponly)
Supportedimpedance:8~300Ω
S/Nratio:118dB(amponly)
Supportaudiofiletype:PCM(16~32bit/44.1~384kHz),DSD(2.8M~11.2M),DXD(24~32bit/352.8~384kHz)
Digitalinput:upto32bit/384kHz,DSD256(USB),upto24bit/192kHz(OPT/COA)
Maximumoutput:340mW+340mW(32Ω)
THD:<0.001%
GAIN:+6dB
Battery:built-in3.7v4000mAhlithiumpolymerrechargeablebattery,10hr~batterylife
Chargingtime:approx11hours
Sizeandweight:W75xH21.5xD135mm,290g
OSenvironment:WindowsXP,Vista,7,8,MacOSX,iOS,Android
Oriolus Japan
www.en.oriolus.jp
CyrasCo.,Ltd.
Zipcode:110-0016
Address:5F,Nichiei-intecOkachimachiNo.2BLDG,
3-42-5,Taito,Taito-District,Tokyo,Japan
Tel:[phone]
EMAIL:[email protected]
