Ortek TD-68 User manual

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
1 | P a g e
TD - 68
Car Radio Full User Manual
上海王力电子电器有限公司
Shanghai Ortek Electronics Co.,LTD.
地址：上海市嘉定区曹安公路 16 号桥南首（解放岛路 1号）
Address: Bridge 16 southern, Cao’an Road, Jiading District, Shanghai, China
电话：[phone]（总机） Tel：[phone] (Hotline)
传真：[phone]#8031 Fax：[phone]#8031
邮编：201812 Zip Code：201812
Web：www.orteksh.com
E-Mai：[e-mail]

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
2 | P a g e
Thanks for choosing our product TD-650. To ensure safety and good user experience,
please read this user manual thoroughly before starting to use the product.
Important Note:
1. Please use the rated voltage stated on the product for power supply.
2. Please remain open circuit for BAT connection to avoid short circuit.
3. Please study the connection requirements carefully.
4. Please change a rated fuse if necessary.
5. Please do not knock down the product without professional guidance.
6. Please do not let metal or other things go into the inner part of the product to
avoid unnecessary accident.
7. Please contact our aftersales service department by (86) 021-39117568 #8011.

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
3 | P a g e
Contents
Control Panel……………………………………………………………………………………………………………..
P.4
LCD Display………………………………………………………………………………………………………………..
P.5
Power Up / Down………………………………………………………………………………………………………..
P.6
Effect Adjustment ………………………………………………………………………………………………………
P.6
Time Setting………………………………………………………………………………………………………………
P. 7
Mute Function……………………………………………………………………………………………………………
P. 8
Loud Function……………………………………………………………………………………………………………
P. 8
Volume Adjustment……………………………………………………………………………………………………
P. 9
Mode Switching…………………………………………………………………………………………………………
P. 9
Tune Operation…………………………………………………………………………………………………………
P. 10~13
Auto Seek Function
Manual Seek Function
Auto Preset Stations
Manual Preset Stations
Multiple Region Frequency Selection
USB Play……………………………………………………………………………………………………………………
P. 13~14
USB Mode Operation
BluetoothOperation……………………………………………………………………………………………………
P. 15~18
Bluetooth Connection
Bluetooth Music Player
Bluetooth Phone Function
Phone number display
Phone call volume
Auxin Mode ………………………………………………………………………………………………………………
P. 18
Definitions………………………………………………………………………………………………………………….
P. 19
Connector and Pin Definitions (Reference)………………………………………………………………..
P. 20
Maintenance………………………………………………………………………………………………………………
P. 20
FAQ………………………………….…………………………………………………………………………………………
P. 20

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
4 | P a g e
Control Panel
①Microphone
②LCD Display
③Preset station 1 / Play / Stop
④Preset station 2 / Pre-play song (fast scan)
⑤Preset station 3 / Repeat
⑥Preset station 4 / Random
⑦Preset station 5 / Information display
⑧Preset station 6 / Call pick up
⑨Mute / Loud
⑩FM / AM selection / Auto-save band
⑪AUXIN Port
⑫USB Port
⑬Power on / Mode selection
⑭Clock / Menu / Call End / Call Refuse
⑮Volume +
⑯Volume -
⑰Tune down / Next song
⑱Tune up / Previous song

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
5 | P a g e
LCD Display
①Pre-play indication (fast scan)
②Repeat indication
③Random indication
④Track indication
⑤Loud indication
⑥Bluetooth indication
⑦FM stereo sound indication
⑧Preset station indication
⑨FLAT effect indication
⑩CLASS effect indication
⑪Main display area
⑫ROCK effect indication
⑬POP effect indication

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
6 | P a g e
Power Up / Down
1. Press “ ” to turn on.
2. Press and hold “ ” to turn off.
Effect Adjustment
1. Press “ ” to turn on.
2. Press “ ” to select functions in between volume, TREB, BASS, BAL LxRx.
3. According to below table, adjust the functions you need.
Function
Time
Hour/Minute/Format setting (see later part of this manual)
MAIN-V
Volume lower
Volume higher
TREB
Treble lower
Treble higher
BASS
Bass lower
Bass higher
BAL LxRx
LxRx output lower
LxRx output higher
4. The setting will be completed without any further operations in few seconds.

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
7 | P a g e
Time Setting
Time digit setting method:
Step1 Enter Time setting mode
When the machine is turned on, press “ ” and the display will display time
information. Press and hold “ ” for more than 2sec, hour-digit will flash, press “ ”
or “ ” to adjust the hour-digit.
Step2 Set Minute-digit
On top of step 1, press “ ” and minute-digit will flash. Press “ ” or “ ” to adjust
the minute digit correspondingly.
Time format setting method:
Under time digit setting mode, press and hold “ ” and the enter time format setting
mode. Press “ ” to choose between 12-hour format and 24-hour format.
End of setting
The setting is completed if no operation within 5 secs.
16
15
14

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
8 | P a g e
Mute Function
1. Press “ ” and it will display “MUTE”. Mute function is enabled.
Loud Function
1. Press and hold “ ” can enable LOUD function. When “LOUD”function is turned
on, the display will have “LOUD”display, vice versa.

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
9 | P a g e
Volume Adjustment
1. Press “ ” or “ ” to adjust volume.
Mode Switching
1. Press “ ” to turn on the machine.
2. Press again “ ” can switch repeatedly among difference modes. The sequence is
as stated: RADIO mode, AUXIN mode, Bluetooth mode, USB mode.

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
10 | P a g e
Tune Operation
Frequencies of FM1, FM2, and FM3 are the same (E.g. for China range of FM
frequency is 87.5 –108.0MHz).
Frequencies of AM1 and AM2 are the same (E.g. for China range of AM frequency is
522 - 1620 KHz).
Auto Seek Function
1. Press “ ” to switch from FM1, FM2, FM3, AM1 or AM2.
2. Press “ ” or “ ” to seek radio stations by tuning up or down respectively. The
seeking will be stopped when station is sought.
3. Press “ ” or “ ” during auto seek, seeking will be stopped by interruption.
Manual Seek Function

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
11 | P a g e
1. Press “ ” to switch from FM1, FM2, FM3, AM1 or AM2.
2. Press and hold “ ” or “ ” for 2 seconds to enter single step tuning. Each press
then can increase or decrease the frequency by a designated step width (E.g.
China step width: FM: 0.1MHz and AM: 9 KHz).
3. Press “ ” or “ ” each time to increase or decrease by a step width.
4. Go back to Auto Seek Function without operation in 5 secs.
Auto Preset Stations
1. Press “ ” to switch from FM1, FM2, FM3, AM1 or AM2.
2. Press and hold “ ” for 2 seconds to enable auto preset process. Preset stations
will be stored starting from lower frequency to higher one. During the scanning
process, each effective station will be played for 2 seconds and continue to scan.
Press “ ” again to interrupt and stop the auto preset process.
Every Preset station set can store 6 stations. Preset stations are based on stronger
signal, higher priority to be stored.
After Auto preset station setting, “Preset button 1” will show the corresponding
radio station. (Below is reference)
If you reset again the preset stations, the previous preset stations maybe
overwrite. (Below is for reference)

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
12 | P a g e
Manual Preset Stations
1. Press “ ” to switch from FM1, FM2, FM3, AM1 or AM2.
2. Press “ ” or “ ” to tune until the frequency needed to be stored.
3. Press any “ ” for 2 seconds to overwrite current frequency to
preset station memory correspondingly.
4. Repeat the above procedures, FM1, FM2, FM3, AM1 and AM2 can stored at
most 6 preset stations. If there is already a preset station previously, the new
preset station will overwrite the previous one. (Below is for reference)
Multiple Region Frequency Selection
Operating Procedure
Area
FM/AM
Frequency Range
Step Width
During standby mode,
press accordingly “ ”
“ ” “ ” “ ” and any
1. China/
Europe
FM
87.5 - 108.0MHz
0.1MHz
AM
522 - 1620KHz
9KHz
2: Middle
East
FM
87.5 - 108.0 MHz
0.1MHz
AM
531 - 1602KHz
9KHz
3：America
FM
87.5 - 107.9 MHz
0.2MHz

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
13 | P a g e
of “ ” which
represent the
corresponding area to
complete selection. The
interruption time
between two
consecutive presses is 2
second
AM
530 - 1710KHz
9KHz
4：Japan
FM
76 - 90 MHz
0.1MHz
AM
522-1692KHz
9KHz
5：Russia
FM
65 - 74 MHz
0.1MHz
AM
522-1602KHz
9KHz
USB Play
1. Press “ ” to turn on.
2. Insert USB device into USB Port.
3. If there are MP3 format files, then after several seconds, display total number of
MP3 files.
4. After several seconds, display the current file sequence.
5. After several seconds, display the current sound track time.

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
14 | P a g e
USB Mode Operation
Button
Function Descriptions under USB Mode
Press to pause or start to play, press and hold to stop.
Press to play next song, press and hold for fast forward.
Press to play previous song, press and hold for fast backward.
Press “SCAN” and LCD displays “INT”. Starting from next song, each song will
be played for 8 seconds and jump to next song until pressing “SCAN” again.
Press “RPT” and LCD displays “RPT”. The current song will be played
repeatedly until pressing “RPT” again.
Press “RDM” and LCD displays “RDM”. The play list will become random and
until pressing “RDM” again.
Press “DISP”and switch display between current track number and played
time.

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
15 | P a g e
Bluetooth Operation
When you turn on ACC, Bluetooth is ready for connection.
When you need to use the Bluetooth function, please enable the Bluetooth module
of the phone device needed to be connected. Search and connect to our machine
named: ORTEK TD68XXXXX. Connect successfully to start the below.
Bluetooth Connection
1. Turn on phone Bluetooth.
2. Search for new device. When the machine is detected by the phone, click
“connect”. When the connection is successful, LCD will display “”to represent
effective connection.
3. After connection, press “ ” to switch the mode to BT PLAY
Different phone may lead to different operation procedure. The above illustration is
for your reference only.

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
16 | P a g e
Bluetooth Music Player
Functions of corresponding buttons under Bluetooth Mode:
Button
Functions
Press to Pause / Play the music. If the music is paused, then
LCD displays “PAUSE”. (Need phone support)
Press to play the next song (Need phone support)
Press to play the previous song (Need phone support)
Bluetooth phone function

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
17 | P a g e
Functions of corresponding buttons under Bluetooth Mode:
Button
Functions
Press to refuse the call when ringing.
Press to end the call when calling.
Press to pick up the call when ringing.
Press to end the call when calling.
Microphone for voice input.
Phone number display
1. When a phone is calling in
2. The phone number is displayed on the LCD display
3. If the Phone number is hidden by the caller, the LCD will display “CALL”

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
18 | P a g e
Phone call volume
Press “ ” or “ ” to adjust phone call volume.
AUXIN
1. Press “ ” to switch to “AUX IN” mode.
2. Through 3.5mm AUX in cable, play external MP3 files in external device including
MP3 device / Phone device.

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
19 | P a g e
Definitions
LCD Display
Definition
FM1+Digit
Radio FM1 (Each set can store 6 preset stations)
FM2+Digit
Radio FM2
FM3+Digit
Radio FM3
AM1+Digit
Radio AM1
AM2+Digit
Radio AM2
USB IN
USB Mode
MAX+Digit
USB device total MP3 files
CUR+Digit
USB device current MP3 file number
PASE
Pause
MUTE
Mute
MAIN-V+Digit
Volume
VOL+Digit
Volume, same as MAIN-V
TREB+Digit
Treble
BASS+Digit
Bass
BAL L+Digit/ R+Digit
Balance
LOUD ON
Loud On
LOUD OFF
Loud Off
BT PLAY
Bluetooth Mode
CALL
Call in display
AUX IN
Auxin Mode
12 HOUR
12-hour format
24 HOUR
24-houar format

上海王力电子电器有限公司 Shanghai Ortek Electronics Co., Ltd. P0068X04A8
20 | P a g e
Connector and Pin Definitions (Reference)
Definition of each Pin for connector is shown as below:
Pin No.
Function
Pin No.
Function
1
Battery -（GND）
2
Battery +（BAT+）
3
Battery -（GND）
4
ACC
5
——
6
——
7
——
8
——
9
——
10
——
11
Right Speaker -
12
Right Speaker +
13
Left Speaker -
14
Left Speaker +
The above connector and Pin definition is for reference only. You have to check with
your engineer or our aftersales service department for more information.
Maintenance
When you need to clean the panel, please do not use with alcohol, phenyl-related or
any corrosive solvent or water. Instead you can use tissue paper or some soft towel
for cleaning.
FAQ
FAQ
Possible reasons
How to deal with
No sound after
turning on the
machine
1. Volume to low
2. Speaker not connected
1. Volume Up
2. Check with the Speakers
No Power
1. ACC not turn on yet
2. Fuse broken
1. Turn on ACC
2. Change the fuse
Radio no signal
1. Antenna not
connected
2. Bad signal in the
region
1. Check with the Antenna
2. Try again at open area
Can do with auto
seek
Bad signal in the region
Use manual seek instead
USB can’t charge
phone
This machine may not
have USB charging
functions
Check with your vendor and
don’t charge if not this function
