Outland Technology FMPPC2-2 User manual

D.823.000.V3
Owner’s
Manual
FMI BRANDS INC.
107 – 19052 26 Avenue | Surrey, B.C. Canada V3Z 3V7 | Toll Free 1-888-514-1663 | Fax [phone]
Model number FMPPC2-2
Series number 823

Owner & Safety Manual
D.823.000.V3
En -1 OUTLAND FIREBOWL®OWNER & SAFETY MANUAL
Model number FMPPC2-2, Series Number 823 - Tested by CSA International
WARNING:
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other
appliance.
WARNING:
Don’t burn yourself! Do not touch or handle the firebowl when hot! To avoid injury always allow
the firebowl to cool down for at least 30 minutes before moving and handling the appliance.
WARNING:
For outdoor use only.
DANGER:
If you smell gas:
1 Shut off gas to the appliance.
2 Extinguish any open flame.
3 If odour continues, keep away from the appliance and immediately call your gas supplier or
fire department.
CARBON MONOXIDE HAZARD
This appliance can produce carbon
monoxide which has no odour.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed
space such as a camper, tent, car or home.

En-2
1-888-514-1663 | WWW.OUTLANDLIVING.COM
LP SAFETY:
a. Do not store a spare LP-gas cylinder under or
near this appliance.
b. Never fill the cylinder beyond 80 percent full.
c. If the information in “(a)” and “(b)” is not followed exactly, a
fire causing death or serious injury may occur.
Do not use this appliance under overhead combustible surfaces.
MINIMUM CLEARANCES:
• Bottom: Non-Combustible Surface
• Top: 80 inches
• Sides: 36 inches
• For Installation on (or over) non-combustible floors only
Max. Input: 58,000 BTU/h (17.0kW)
Max Gas Supply Pressure: 250 PSI
This appliance shall be used only outdoors in a well-ventilated
space and shall not be used in a building, garage or any other
enclosed area.
If this appliance is not in use, the gas must be turned off at the
supply cylinder.
Indoor storage of this appliance is permissible only if the cylinder
is disconnected and removed from the appliance.
Cylinders must be stored outdoors in a well-ventilated area out of
the reach of children.
Disconnected cylinders must have threaded valve plugs tightly
installed and must not be stored in a building, garage or any other
enclosed area.
The gas pressure regulator provided with this appliance must be
used, and must be the same model as supplied with the unit.
The cylinder supply system must be arranged for vapor
withdrawal.
Cylinders used with this unit must have a collar to protect the
cylinder valve.
An approved LP-Cylinder stabilizer, such as the stabilizer ring
included, must be used when the appliance is in use.
Replacement parts and a list of such parts are available from FMI
Brands Inc. through the contact information provided on the last
page of this Manual.
WARNING:
Please ensure that all adults and children which use or are
near a unit in use are aware of the hazard of high-surface
temperatures present on the unit during use and should use
caution and stay away to avoid burns or clothing ignition.
Carefully supervise young children in the area of this
appliance. Clothing or other flammable materials should
not be hung from the appliance or placed on or near the
appliance. Any guard or other protective device removed for
servicing the appliance must be replaced prior to operating
the appliance.
Installation and repair should be done by a qualified
service person. The appliance should be inspected before
use and at least annually by a qualified service person.
More frequent cleaning may be required as necessary. It is
imperative that control compartment, burners and circulating
air passageways of the appliance be kept clean.
WARNING:
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. Read
the installation, operating and maintenance instructions
thoroughly before installing or servicing this equipment.
WARNING:
If the information in this manual is not followed exactly,
a fire or explosion may result causing property damage,
personal injury or loss of life.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.

Owner & Safety Manual
D.823.000.V3
En-3 OUTLAND FIREBOWL®OWNER & SAFETY MANUAL 2
All LP cylinders to be used with this appliance must be:
a. Constructed and marked in accordance with the
specifications for LP-gas cylinders Standard,
CAN/CSA B339, Cylinders, Spheres and Tubes for the
Transportation of Dangerous Goods.
b. Provided with a listed overfilling prevention device.
c. Provided with a cylinder connection device compatible with
the connection for outdoor cooking appliances.
d. Only a 20 lb. (9 kg) LP gas cylinder is to be used for this
appliance, approximately 18” (46 cm) high & 12” (30 cm)
diameter.
e. The use of an approved LP gas cylinder stabilizer, such as the
one included, must be used when using this appliance in order
to prevent the LP gas cylinder from tipping over.
ENCLOSURES FOR SELF-CONTAINED
LP GAS SYSTEMS:
An enclosure for an LP-gas cylinder shall be ventilated by
openings at both the upper and lower levels of the enclosure. This
shall be accompanied by one of the following:
a. One side of the enclosure shall be completely open; or
b. For an enclosure having four sides, a top, and a bottom:
At least two ventilation openings (see Part IV, Definitions) shall
be provided in the sidewalls of the enclosure, located within 5
in (217 mm) of the top of the enclosure, equally sized, spaced
at a minimum of 90 degrees (1.57 rad), and unobstructed. The
opening(s) shall have a total free area of not less than 1 in
2
per lb
(14.2 cm
2
per kg) of stored fuel capacity.
Ventilation opening(s) shall be provided at floor level of the
enclosure and shall have total free area of not less than 1/2 in
2
per
lb (7.1 cm
2
per kg) of stored fuel capacity. If ventilation openings
at floor level area are in the side wall, there shall be at least two
openings. The bottom of the openings shall be 1 in (25.4 mm) or
less from the floor level and the upper edge no more than 5 in (127
mm) above the floor level. The openings shall be equally sized,
spaced at a minimum of 90 degrees (1.57 rad), and unobstructed.
Every opening shall have minimum dimensions so as
to permit the entrance of a 1/8 in (3.2 mm) diameter rod.
Ventilation openings in sidewalls shall not communicate directly
with other enclosures of the appliance.
CONNECTION:
1. Be sure the cylinder valve and appliance valves
are “of f ”.
2. Place full LP gas cylinder on tank stabilizer ring.
3. Center the nipple in the cylinder valve and hold in place.
4. Using the other hand, turn the hand wheel clockwise until
there is a positive stop. Do not use tools.
5. Hand tighten only. When making the connection,
hold the regulator in a straight line with the cylinder valve, so
as not to cross thread the connection.
6. Leak test the connection. See section named “LEAK TEST”.
WARNING:
Ensure that the LP gas cylinder is kept at a minimum
distance of three feet (36 inches) away from the appliance.
LP Cylinder
Appliance Tank Ring
Minimum 36”
(0.91m)
LEAK TEST: Apply the solution to the LP gas delivery system at points.
Valve coupling regulator & Cylinder Coupling.
LEAK TEST: Apply the solution to the LP gas
delivery system at points:
1. Firebowl Valve Coupling
2. Gas Hose Regulator
3. Cylinder Valve Coupling
2. Gas Hose
Regulator
Heat Sensitive
Hand Wheel
Cylinder
Shut Off
Valve
Check Valve
Nipple with
Flow Limiting Device
3. Cylinder Valve
Coupling
!
Caution:
Trip Hazard!
Tank Ring

En-4
1-888-514-1663 | WWW.OUTLANDLIVING.COM
LEAK TEST:
1. DO NOT USE OR PERMIT SOURCES OF IGNITION
IN THE AREA WHILE DOING THE LEAK TEST.
THIS INCLUDES SMOKING.
2. Leak testing should be done once per year or whenever the
LP gas cylinder or any other gas system part is taken apart,
serviced or replaced, whichever is more frequent.
3. Ensure all gas system coupling joints are tight
and properly attached.
4. Prepare a leak testing solution of half liquid detergent
and half water.
5. Apply the solution to the LP gas delivery system at points as
shown in illustration indicated on page 3.
6. If parts of the fitting begin to produce bubbles, spray liquid, or
if you smell liquid propane gas, immediately close the valve on
the tank.
7. Wait 5 minutes for any gas to dissipate.
8. After waiting for 5 minutes, the leak(s) must be stopped by
tightening the loose joints, if possible, or by replacing the
faulty parts(s) with the part(s) recommended by the appliance
manufacturer.
THE APPLIANCE IS NOT TO BE USED UNTIL
ANY LEAK IS CORRECTED.
A gas appliance repairman or LP gas dealer should be called if
attempts to stop the leak(s) are unsuccessful and, in such case, the
LP gas supply must be shut off at the cylinder valve or the cylinder
must be removed from the appliance until the leak(s) is corrected.
Inspect hose prior to each use of the unit. The hose assembly
must be replaced prior to the appliance being put into operation
if there is evidence of excessive abrasion or wear, or if the hose
is damaged. Contact FMI Brands Inc. should you require a
replacement hose.
Inspect burner prior to each use. Burner must be replaced prior
to the appliance being put into operation if there is evidence of
damage. Replacement burners are available from FMI Brands Inc.
Should any part of this appliance (including the burner) become
soiled or dirty, wipe lightly with a damp cloth. Do not use
flammable or corrosive cleaning products on or near this unit.
Ensure that gas hose is placed in an area where it is unlikely to
be tripped over (such as pathways or trails) or subject to other
accidental damage.
Keep the appliance area clear and free from combustible
materials, gasoline and other flammable vapors and liquids.
Solid fuels shall not be burned in this appliance.
Installation must conform with local codes or, in the absence of
local codes, with either the National Fuel Gas Code, ANSI Z223.1/
NFPA 54, Natural Gas and Propane Installation Code, CSA B149.1
or Propane Storage and Handling Code, B149.2, or the Standard for
Recreational Vehicles, ANSI A 119.2/NFPA 1192, and CSA Z240 RV
Series, Recreational Vehicle Code, as applicable.
NOTE TO INSTALLER:
Leave this guide with the consumer.
NOTE TO CONSUMER:
Please retain this guide for future use.
WARNING:
If the information in this manual is not followed exactly,
a fire or explosion may result causing property damage,
personal injury or loss of life.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.

Owner & Safety Manual
D.823.000.V3
En-5 OUTLAND FIREBOWL®OWNER & SAFETY MANUAL
SECTION 1: ASSEMBLY
STEP 1 Enclosed are four bags of rocks, one factory installed 10'
propane-rated hose with attached regulator, and one propane tank
stabilizer ring.
STEP 2 Remove plastic bags containing the rocks and propane
stabilizer ring.
STEP 3 Open the two bags containing mid-sized rocks, labelled
conveniently for you “M” and arrange in burner area.
STEP 4 Open the single bag containing larger sized rocks, labelled
conveniently for you “ L” and arrange on top of the medium sized
rocks.
STEP 5 The fourth bag of rocks are included as spares and labelled
“Spare Rocks”. These can be stored and used as replacements or
deployed for additional coverage depending on preference.
Our preferred configuration is
pictured here.
Never handle rocks which
have not been allowed to
cool from exposure to flame.
Never attempt to rearrange
rocks while unit is ignited.
Note:
• Rocks are not to exceed a maximum weight of 2 kgs
or 4.4 lbs.
SECTION 2: IGNITION
STEP 1
Ensure that unit valve dial is in the
“OFF” position by pushing and
turning clockwise until the dial
stops.
STEP 2
Securely attach regulator (large
end of hose) to your propane
cylinder.
NOTE TO USER:
Before igniting the unit for the first time, follow steps one
through 5 in the below Ignition section.
STEP 3
Extend hose to full length and ensure that the propane tank is as
far as safely possible from the Firebowl and place the tank in the
included stabilizer ring.
STEP 4
***SLOWLY*** turn cylinder valve to the open position to avoid
tripping the CSA excess flow safety device in the gas regulator.
For more information about the CSA excess flow safety device see
STEP 8 (What is an Excess Flow Safety Valve? (EFV).
STEP 5
Leak Test all connections. See section labeled “Leak Test”.
!
Caution:
Trip Hazard!
LP Cylinder
Tank Ring

En-6
1-888-514-1663 | WWW.OUTLANDLIVING.COM
SECTION 2: IGNITION (continued)
If there are no flames present,
as demonstrated in the image
to the left, the appliance is likely
not burning. If this is the case,
IMMEDIATELY turn the valve
to the “off” position if it is not
already and repeat the ignition
procedure as outlined in Section 2.
Upon igniting the appliance,
visually verify that the burner is
indeed burning as demonstrated
in the image to the left. The
presence of flames will confirm
that the burner is burning.
Periodically check that the burner
flame is present during operation
by visually inspecting the burner to ensure the presence of flames.
STEP 6
Using a lighter or match, ignite
lighter and hold flame slightly
above the burner, then open the
valve on the appliance slowly
by turning (counter-clockwise)
until the unit ignites.
STEP 7
Once the unit is burning normally
set the dial to desired flame
height.
WARNING: Ensure that no parts of your body, clothing, or any other combustible material are above the burner before, during
and after ignition.
SECTION 3: PERIODIC INSPECTION OF BURNER FLAMES
STEP 8
GOT A LOW FLAME?: If your firebowl experiences low flame, or flame height does not appear to be normally adjusted by the
gas knob, it is likely that the CSA excess flow safety device has been tripped in the hose regulator.
CORRECTIVE ACTION: Close propane cylinder valve. Open and then close Firebowl gas knob valve to release pressure.
Disconnect and reconnect the propane cylinder valve connection. Slowly open propane cylinder valve. Perform Leak Test and
follow Ignition sequence.
WHAT IS AN EXCESS FLOW SAFETY VALVE? (EFV)
The EFV is a safety mechanism contained within every propane gas
regulator. The purpose of the EFV is to restrict the gas supply if too
much gas is flowing too quickly through the gas hose. For example,
this could happen if the gas hose was severed.
It is normal that your Fire Bowl EFV trips if you open the propane tank
valve too quickly or if you leave the Fire Bowl gas knob open before
lighting, or both.
EXCESS FLOW
VALVE
GAS REGULATOR
GAS
HOSE

Owner & Safety Manual
D.823.000.V3
En -7 OUTLAND FIREBOWL®OWNER & SAFETY MANUAL
SECTION 4: EXTINGUISHING THE APPLIANCE
STEP 1
Turn cylinder valve to the “Closed” position.
STEP 2
Turn appliance valve to the “Off” position
by pushing and turning knob clockwise.
STEP 3
Allow unit to cool for at least five
(5) minutes before relighting.
SECTION 5: FIREBOWL MAINTENANCE
Your Outland Firebowl®requires periodic maintenance to keep it in good running order. Follow the steps below to ensure your appliance
will provide you with the best possible performance:
1Keep your Firebowl out of the rain and store it in a dry place.
2 This device has been engineered to provide the maximum amount of heat and comfort. If you experience any signs of your propane
cylinder ‘freezing off’ or start to experience lower flames than usual, please simply turn the burner control setting to low for 5–10
minutes, or replace the cylinder with a full one.
3 Ensure that you clean the bowl of your Outland Firebowl®after every use to keep it looking GREAT. Simply wiping the outer edge of the
Firebowl with a damp paper towel or cloth to remove any combustion particulates.
WARNING NOTES:
• Expected burn time; the anticipated burn time for your Outland
Firebowl®using a full 20 lb (9kg) propane cylinder is between 7
and 11 hours depending on where the flame height is set.
• FMI Brands Inc. recommends that you ignite this unit only when
safely placed on a non- combustible surface as pictured above.
• This is NOT a toy. Children should be supervised at all times when
using this unit without exception.
• Do not place any objects other than supplied rocks inside the
burner component of the Firebowl.
• Do not add wood or any other materials to the fire. It is designed
to safely combust propane only.
• Do not connect to a remote gas supply.
• Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect the
appliance and to replace any part of the control system and any
gas control which has been under water.
• Do not leave this appliance in the rain.
• Replacement rocks/parts can be purchased at
www.outlandliving.com or by calling 888-514-1663.
• Always inspect and clear all valve and gas orifices of any foreign
debris including spider webs prior to lighting.
FOR ALL PART ORDERS PLEASE VISIT WWW.OUTLANDLIVING.COM
The owner’s manual is available as a free download from www.outlandliving.com
Replacement part orders can be sent by mail to the address on the cover of this booklet, or faxed to [phone]. Should you have any questions or
comments regarding this appliance, please do not hesitate to contact FMI Brands Inc. at [phone] or E-Mail to inf[email protected].
