OWI IC5 Operating instructions

Filename:IC5_6 MANUAL
05/13/13
IN-CEILING/IN-WALL MOUNT SPEAKERS
I N S T A L L A T I O N / O W N E R S' M A N U A L
MODEL IC5 / IC6
SPEAKER SPECIFICATIONS:
MODEL IC5
MODEL IC6
DESCRIPTION:
5.25", 2-way, coaxial
6.5", 2-way, coaxial
COVERED OUTDOOR:
Yes
Yes
IMPEDANCE:
8 ohms
8 ohms
SENSITIVITY (1W/1M):
85 dB 1w/M
86 dB 1w/M
DISPERSION:
120 degrees
120 degrees
MAX POWER:
40 watts
50 watts
NOMINAL POWER:
20 watts
25 watts
FREQUENCY RESPONSE:
80Hz - 20KHz
65Hz-20KHz
WOOFER SIZE:
5.25"
6.5"
WOOFER MATERIAL:
Paper, PP coated
Paper, PP coated
TWEETER SIZE:
0.5" (13mm)
0.5" (13mm)
TWEETER MATERIAL:
PEI
PEI
GRILL MATERIAL:
Aluminum
Aluminum
DIMENSIONS:
7.95" (202mm) Dia x 3.2" (80mm)
mounting depth
8.93" (227mm) Dia x 3.5" (88mm)
mounting depth
CUT OUT SIZE:
6 5/8 (6.61) inches (168mm)
7 11/16 (7.68) inches (195mm)
WEIGHT:
2.26 lbs (1025 gms)
2.5 lbs. (1134 gms)
MOUNTING HARDWARE:
Clamps - 4 each
Clamps - 4 each
PAINTABLE:
Yes
Yes
INSTALLATION:
Speaker Placement
Before installing your OWI speakers, consider the placement carefully, taking into effect the location of
electrical, plumbing and other fixtures.
Placement in Ceiling
OWI speakers should be ideally located above the primary listening area.
Placement in Wall
Optimum sound will be achieved when your OWI speakers are installed at ear level or slightly higher and the
listening area is no closer to the speakers than the distance between the speakers themselves.

Filename:IC5_6 MANUAL
05/13113
Page 2 of 4
Mounting your OWI Speakers
Determine the best area to mount your OWI speakers. It will be necessary to run your speaker wires to that
location. This location must be free of obstructions, such as electrical conduits, HVAC ducts, or water lines.
Be sure the mounting surface is between 3/8 and 1 ¼ inches thick, and there is at least a 2 ¾ inch clearance for
the IC5 and 3 ¼ inch clearance for the IC6 behind the mounting surface and no wall studs or other objects block
the back of the speaker.
Remove the round cardboard disc from the template supplied and keep it for later use as a paint mask, if you
decide to paint your speakers.
Use the template to mark the position for the mounting hole at the selected location. If you are not certain that
no obstruction exists (electrical wiring. plumbing. etc.), you should start by cutting a small hole in the center of
your penciled mounting hole with a drywall or keyhole saw, cutting at a 45 degree angle towards the inside of
the hole. Cutting a small hole at this angle will make drywall repair much easier. Once you have determined
there are no obstructions in your desired mounting location, start cutting the finished hole at a 90 degree angle
to the wall/ceiling surface.
Route the speaker wires from your amplifier to your opening. Avoid routing the speaker wire near electrical
wires. If you have to run them parallel, make certain to space the speaker wires at least 2 feet from the AC line.
Do not nail or staple the speaker wire.
Preparing your OWI Speakers for Mounting
Push one of the clamps towards the grill or insert a paper clip into one of the grill holes, then pull upwards to
remove the grill.
Be sure to position the four Mounting Tabs on your OWI speaker inward.

Filename:IC5_6 MANUAL
05/13113
Page 3 of 4
Attach the speaker wires to the speaker terminals.
Insert your OWI speaker into the opening and tighten the four screws. As you tighten the screws, the tabs will
automatically flip into an outward position thereby clamping the drywall between the feet and the flange of the
speaker. BE CAREFUL NOT TO OVER TIGHTEN, OVER TIGHTENING MAY WARP THE BAFFLE,
CRACK THE WALL, CAUSE THE FLANGE TO DISTORT AND MAKE THE GRILL DIFFICULT TO
INSTALL.
Push the grill firmly into the slot in the speaker baffle.
Painting your OWI Speakers
The speakers' other surfaces are primed to accept ordinary latex wall paint or aerosol spray paint. The surface of the
speaker behind the grill should remain black and must not be painted. It is necessary to mask this area with the
center of the template that you have cut out.
The grill can be painted as well, but great care must be taken not to clog the holes in the grill as this will greatly
reduce the sound quality of the speakers. It is recommended that only light spray painting using 5 parts thinning
agent to 1 part paint be used. Do not paint the grills while they are attached to the speaker.
Proper Wire Gauge Selection
The gauge of wire required is determined by the distance between your amplifier/receiver and the speakers. Use
the following chart as a guide:
OWI INC.
17141 KINGSVIEW AVENUE
CARSON, CA 90746
TEL: [phone] FAX: [phone]
[email protected]
www.owi-inc.com
Length
Minimum Gauge
Less than 10 feet
18 - 20 Gauge
10 to 100 feet
16 to 18 Gauge
Over 100 feet
14 Gauge

Filename:IC5_6 MANUAL
05/13113
Page 4 of 4
OWI INC.
LIMITED FIVE YEAR WARRANTY
(IC5/IC6 NON-AMPLIFIED IN-CEILING SPEAKER)
1. Your OWI speakers have been thoroughly tested and inspected at the factory. They are warranted for 5 years
from the date of purchase. It is the owner's responsibility to establish the date of purchase by acceptable
evidence at the time service is sought.
2. If the speaker proves to be defective in materials or workmanship within five years from the date of the original
customer purchase, OWI, at its sole option may repair or replace the unit with a current model of equal or
greater value. In some cases where a new model is substituted, a modification to the mounting surface may be
required. If mounting surface modification is required, OWI assumes no responsibility or liability for such
modification.
3. Exclusion of certain damages
Liability for any defective product is limited to repair or replacement of the product at our option. OWI Inc.
shall have no liability whatsoever for any incidental or consequential damages of any kind of character because
of product defect. The sole responsibility of OWI Inc. under this warranty shall be limited to the repair of
the product or replacement thereof, and is the sole discretion of OWI Inc. Some states do not allow
limitation on how long an implied warranty lasts and/or do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation may not apply.
4. This warranty does not cover:
a. Damage caused by abuse, accident, misuse, negligence, improper operation(installation), overdriven with
excessive amplification.
b.Products that have been altered or modified.
c. Any product whose serial number has been altered or removed.
d.Normal wear and maintenance.
e. Damages caused by shipping. All claims for shipping must be made with the carrier.
5. What OWI Inc. will pay for and what YOU must pay for:
OWI will repair or replace unit(s) covered by this warranty without charge to the customer for labor or
materials. You are responsible for any installation or removal charges and for any initial shipping
charges, if the unit(s) must be shipped for warranty service. However, OWI Inc. will pay the return shipping
charges to any destination within the USA, if the repairs are covered by the warranty.
6. Warranty Service
Units for warranty repair must be sent to OWI Inc., or to the dealer where purchased, postage prepaid. Copy of
original proof of purchase to be included with the speaker(s).
