Ozito LWE-1405 User manual

ELECTRIC
LAWN EDGER
1400W 190mm
INSTRUCTION MANUAL
SPECIFICATIONS
Power: 1400W
No Load Speed: 4000/min
Cutting Depths: 15, 25, 38mm
Blade: 190mm x Ø18mm bore
Noise Level: 103dB
Weight: 6.5kg
LWE-1405
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
ozito.com.au
1018
Lawn Edger Housing
Blade Spanners
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from
the original date of purchase. If a product is defective it will
be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts, for example: Blade, blade
nut, flanges and included accessories.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
STANDARD EQUIPMENT
Adjustable Handle,
Lower Tube
Switch
Handle
Upper Tube
Handle Fasteners

ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
KNOW YOUR PRODUCT SETUP & PREPARATION
1. ASSEMBLY
ELECTRIC LAWN EDGER
1
2
3
4
5
6 7 8 9
10
11
1. Switch Handle
2. Front Handle
3. Locking Knob
4. Lower Tube
5. Motor Housing
6. Lock-Off Switch
7. Cord Retainer
8. On/Off Trigger
9. Handle Locking Knob
10. Upper Tube
11. Blade Guard
12. Depth Adjustment Knob
13. Dual Cutting Blade
14. Guide Wheel
3. Place the upper tube onto
the lower tube, t the bolt
through both tubes from
the underside and secure
with washer and locking
knob.
1. Align the groove on the
lower tube with the lug in
the motor housing and
push in until it clicks into
place.
Note: Take care not to
damage the cable while
inserting.
4. Place the switch handle
tube onto the upper tube,
t the bolt through both
tubes from the underside
and secure with washer
and locking knob.
2. Secure in place by
tightening the 2 screws
on each side.
Fitting the Front Handle
WARNING! ENSURE THE TOOL IS SWITCHED OFF AND
DISCONNECTED FROM THE POWER SUPPLY BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.
1. Place the front handle onto
the switch handle. Pass
the bolt through the handle
and secure with the locking
knob.
ACCESSORIES
15. Blade spanners x 2 16. Handle Fasteners x 2
12
13
14
15 16
Tube Assembly

2. ADJUSTMENTS 3. EXTENSION CORD RETAINER
3. Once the desired
cutting depth is
selected, tighten the
depth adjustment
locking knob to secure
in place.
Note: Ensure the lug
on the guide wheel arm
is correctly located into
a preset depth position
before tightening.
3. Once tted, connect the extension lead socket to the lawn
edger power cord plug.
1. Loosen the depth
adjustment locking
knob until the guide
wheel arm moves
away from the
housing. This will allow
the cutting depth to be
adjusted.
1. Make a loop with the extension lead (socket end of lead),
push it through the square hole beneath the handle.
The lawn edger provides 3 cutting depths; 15, 25 and 38mm.
The cord retainer prevents the extension lead (not included)
from being disconnected during use. Only use Heavy Duty
extension lead suitable for outdoor use with electric garden
tools, no longer than 25 meters.
2. Raise the guide
wheel cutting arm to
increase the depth
or lower to decrease
the depth.
2. Place the loop onto the cord retainer and ensure it is pulled
rmly to secure in place.
Adjusting the Cutting Depth
Adjusting the Front Handle
1. Loosen the locking knob,
then slide the handle into the
most comfortable position.
Retighten the locking knob
when in position.

4. STARTING & STOPPING 5. EDGING
OPERATION
3. Start the edger and allow the
blade to reach full speed.
5. Walk forward slowly, keeping
the blade pressed lightly
against the edge to be cut.
Note: If the edger begins to slow down due to a build up of
grass in the blade guard, walk back slightly to allow the grass
to fall out and let the cutting blade to return to normal speed
before continuing forward.
2. To start the edger, press
and hold the lock-off switch
(1), then squeeze the
trigger (2) to start the lawn
edger.
1. To stop the edger, simply
release the trigger.
For your safety the edger is designed with a lock-off switch. If
only the On/Off trigger is squeezed, the edger will not operate.
This prevents accidental start up of the edger.
1. Before starting, line the
edger cutting blade with
the edge to be cut. Use the
arrows on the blade guard to
assist in guiding you where
the cutting blade will cut.
3. Once started, release the
lock-off switch and hold
down trigger to maintain
power.
2. Tilt the handle down
so the cutting blade
is sufciently above
the ground before
starting.
4. Slowly raise the
handle to lower the
cutting blade within
the edge to be cut.
Starting the Lawn Edger
Stopping the Lawn Edger
2
1
CAUTION! TO AVOID KICKBACK OF THE EDGER, TILT THE
HANDLE DOWN SUFFICIENTLY SO THE BLADE DOES NOT
CONTACT THE GROUND BEFORE SWITCHING ON.
WARNING! THE LAWN EDGER RUNS FOR A FEW
SECONDS AFTER IT HAS BEEN SWITCHED OFF. LET THE
MOTOR COME TO A COMPLETE STANDSTILL BEFORE
SETTING THE TOOL DOWN.
WARNING!: THE POWER SUPPLY FOR THIS PRODUCT
SHOULD BE PROTECTED BY A RESIDUAL CURRENT
DEVICE RATED AT 30mA OR LESS.
WARNING: BEFORE EDGING, ENSURE THE WORK AREA
IS FREE OF ROCKS, DEBRIS, LINES AND OTHER FOREIGN
OBJECTS.
Note: Some sparks may be generated from the cutting blade
while pressed against a solid edge (eg; concrete) to be cut,
simply align the blade so no contact is made.
LWE-1405
2
1
1. Hold the lawn edger rmly
with both hands.
2
1
2
1
2
1
Always wear adequate protective clothing when operating the
tool to avoid injuries to face, eyes, hands, feet and hearing.

TROUBLESHOOTING
The Depth Adjustment Locking Knob Will Not
Tighten
The guide wheel cutting arm may not be located correctly in 1 of the 3
preset cutting depths. Move the guide wheel cutting arm up or down into a
preset location and then tighten the depth adjustment locking knob.
The Edger Will Not Start
• Ensure the edger is connected to a sufcient power supply.
• Ensure that the lock-off switch is fully pressed down and then squeeze
the trigger to start the lawn edger.
CARING FOR THE ENVIRONMENT
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito customer service
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
SPARE PARTS
DESCRIPTION OF SYMBOLS
MAINTENANCE
• Keep the ventilation vents of the tool clean at all times, if possible,
prevent foreign matter from entering the vents.
• After each use, blow air through the motor housing to ensure it is
free from all dust particles which may build up. Build up of dust
particles may cause the unit to overheat and fail.
• If the enclosure of the tool requires cleaning do not use solvents
but a moist soft cloth or soft brush only. Never let any liquid get
inside the tool; never immerse any part of the tool into a liquid.
NOTE: Ozito Industries will not be responsible for any damage or
injuries caused by the repair of the tool by an unauthorised person or
by mishandling of the tool.
2. Turn the small spanner
clockwise and remove the
nut, outer ange and blade.
Note: Ensure the nut and outer
ange are clean of any dirt or
grass prior to tting.
4. Fit the nut and tighten rmly
in an anti-clockwise direction
using the 2 supplied
spanners.
1. Lay the edger on
its side and place
the large supplied
spanner over the
outer blade ange
and the small
spanner on the nut.
3. Fit the new blade
over the inner ange,
then the outer
ange, ensuring they
are located correctly
and in the correct
direction.
Changing the Cutting Blade
General Maintenance
WARNING! ENSURE THE TOOL IS SWITCHED OFF AND
DISCONNECTED FROM THE POWER SUPPLY BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.
Regulator compliance mark
Remove plug from the mains immediately
if cabel is damaged or cut.
Do not expose to or
operate in the rain
VVoltage Hz Hertz
~Alternating current
/min Revolutions or
reciprocation per minute
Double insulated
Read operating instructions before use
Wear hearing protectionWear eye protection
Thrown objects
Rotating cutting blade
Direction of edger blade rotation
Warning
WWatts
dB Decibel (noise) rating IPX4 Ingress protection rating
no No load speed
Keep bystanders at
a safe distance
Disconnect the power and
remove the plug from the
power supply before caring
out any maintenance. Keep
the extension cord away
from the blade.
Power tools that are no longer usable should not be disposed of
with household waste but in an environmentally friendly way. Please
recycle where facilities exist. Check with your local council authority
for recycling advice.
Recycling packaging reduces the need for landll and raw materials.
Reuse of recycled material decreases pollution in the environment.
Please recycle packaging where facilities exist. Check with your local
council authority for recycling advice.

WARNING! Do not touch rotating parts;
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
Children should be supervised to ensure that they don’t play with the appliance.
Always wear adequate protective clothing when operating the tool to avoid injuries to
face, eyes, hands, feet, head or hearing.
Use safety glasses or a face shield, high boots or sturdy shoes, long trousers, work
gloves, a hard hat and ear defenders.
Do not start the tool when it is upside down or when it is not in the operating position.
Switch the motor off and remove the plug when the tool is not being used, left
unattended, being cleaned, being moved from one place to another or when the
extension cord is entangled or damaged.
Do not operate the tool near people, especially children or pets. Turn it off if they get too
close. Maintain a safe distance of at least 5m from other people when using the tool.
• Do not expose to moisture
• Do not operate the appliance when barefoot or wearing open toe shoes.
• While operating the appliance, always wear substantial footwear and long trousers.
• Operate the appliance only in daylight or in good articial light.
• Avoid operating the appliance in wet grass, where feasible.
• Always be sure of your footing on slopes.
• Walk, never run.
• Always work across the face of slopes, never up and down.
• Exercise extreme caution when changing direction on slopes.
• Do not operate the appliance on excessively steep slopes.
• Use extreme caution when reversing or pulling the appliance towards you.
• Stop the rotating parts if the appliance has to be tilted for transportation. Do not
operate the cutting means when crossing surfaces other than grass, and when
transporting the appliance to and from the working area.
• Never operate the appliance with defective guards or shields, or without safety
devices, for example deectors and/or catchers in place.
• Switch on the motor according to instructions and with feet well away from rotating
parts.
• Do not tilt appliance when switching on the motor, except if the appliance has to be
tilted for starting. In this case, do not tilt it more than absolutely necessary and lift only
the part which is away from the operator. Always ensure that both hands are in the
operating position before returning the appliance to the ground.
• Do not put hands or feet near or under rotating parts.
• For rotary appliances keep clear of the discharge opening at all times.
• Never pick up or carry an appliance while the motor is running.
• Pull the plug from the socket:
- whenever you leave the machine;
- before clearing a blockage;
- before checking, cleaning or working on the appliance;
- if the cord is damaged or entangled;
- after striking a foreign object. Inspect the appliance for damage and make repairs as
necessary.
• If the appliance starts to vibrate abnormally, check immediately.
LAWN EDGER SAFETY WARNINGS
WARNING! When using mains-powered tools, basic safety precautions, including the
following, should always be followed to reduce risk of re, electric shock, personal injury
and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before
operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
The manufacturer cannot accept any liability for damage or accidents which arise due to a failure to follow
these instructions and the safety information.
The electric motor has been designed for 230V and 240V only. Always check that the power supply
corresponds to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand.
This tool is double insulated in accordance with AS/NZS 60335-1;
therefore no earth wire is required.
The power supply for this product should be protected by a residual current device (rated at 30mA or less). A
residual current device reduces the risk of electric shock.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid
a hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The
insulation system is for added protection against injury resulting from a possible electrical insulation failure
within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the
extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not
suitable for the power input of the tool or which is damaged or defective may result in a risk of re and electric
shock.
Supply cords shall not be lighter than:
- if rubber insulated, ordinary tough rubber sheathed exible cord (code designation 60227 IEC 53);
- if polyvinyl chloride insulated, ordinary polyvinyl chloride sheathed exible cord (code designation 60227
IEC 53).
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the
warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will reduce risk of
electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk
of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk
of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power
source and/or battery pack, picking up or carrying the tool. Carrying power tools with your nger on
the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure these
are connected and properly used. Use of dust collection can reduce dust-related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct power tool
will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of
untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and
any other condition that may affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
5. Service
a. Have your power tool serviced by a qualied repair person using only identical replacement parts.
This will ensure that the safety of the power tool is maintained.
GENERAL POWER TOOL SAFETY WARNINGS
ELECTRICAL SAFETY
Table of contents
Other Ozito Edger manuals
Popular Edger manuals by other brands

Black & Decker
Black & Decker GH710 instruction manual

Craftsman
Craftsman 77237 - 29cc 4 Cycle Gas Edger Operator's manual

Little Wonder
Little Wonder 6232 Parts list, operating and assembly instructions

Maruyama
Maruyama ED260 instruction manual

MTD
MTD 520 Series Operator's manual

Murray
Murray EV3850x4NA Instruction book
