Ozito POWER X CHANGE PXBSS-018 User manual

STANDARD EQUIPMENT
PXBSS-018
INSTRUCTION MANUAL
SPECIFICATIONS
Input: 18V
Max. Power: 18W
Sensitivity: 85 ± 3dB
Impedance: 4Ω
Speaker: 2 x Ø40mm
Audio Input: Bluetooth 5.0 (10m Range)
or Ø3.5mm AUX
USB Output: 5V, 2A, 1Wh
Weight: 0.3kg
ozito.com.au
1219
Cordless Bluetooth Speaker
2-in-1 Carabiner / Bottle
Opener & AUX Cable
CORDLESS
BLUETOOTH
SPEAKER
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
OZITO Australia/New Zealand (Head Ofce) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benets provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to
a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this
warranty, however, where you have suffered any additional direct loss as a result of
a defective product you may be able to claim such expenses by contacting our
customer service helpline above.
WARNING
The following actions will result in the warranty being
void.
• If the tool has been operated on a supply voltage other than that specied
on the tool.
• If the tool shows signs of damage or defects caused by or resulting from
abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
5 YEAR REPLACEMENT WARRANTY
Your Product is guaranteed for a period of 60 months from the original date of
purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it
will be replaced in accordance with the terms of this warranty. Lithium Ion
batteries and chargers are covered by a 36 month
warranty and are excluded from the warranty extension. Warranty excludes
consumable parts.

ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
+
-
Installing The Battery Pack
1. Slide the battery into the battery
seating until it clicks into place.
Removing The Battery Pack
1. Hold down the battery release
button.
2. Slide the battery out to remove it.
Switching The Speaker On/Off
1. Press and hold the power
button for 2 seconds to
switch on the device. The
power button will light up
to indicate it is on.
2. Press and hold down the power
button again to turn the speaker
off; the power button LED will
go off.
1. Forward/Volume Up Button
2. Power Button
3. Previous/Volume Down Button
4. USB On/Off LED Button
5. Battery Seating
6. AUX Input Port
7. Lanyard
8. USB Port
This tool is compatible with all batteries & chargers from the Ozito Power X Change
range.
CORDLESS BLUETOOTH SPEAKER
BATTERY & CHARGER
KNOW YOUR PRODUCT
1. POWERING THE DEVICE
SETUP & PREPARATION
+
-
+
-
2 SECONDS
48
7
123
5
6

Bluetooth Pairing
The speaker will automatically go into Bluetooth pairing mode when it is
powered on unless an AUX cord is plugged into the port.
1. The power button LED light
will keep ashing while it is
searching for a Bluetooth pairing.
2. Turn on Bluetooth functionality
on your media device and search
for the ‘PXC Speaker’ to connect
to the speaker.
Note: Only 1 device can be paired via Bluetooth at any time. Turn off
Bluetooth on the rst connected device to pair a new device with the
speaker.
AUX Cable Input
1. Plugging an AUX cable
into the port automatically
changes the speaker mode to
auxilliary input.
Note: This occurs even if a
device currently connected via
Bluetooth. Unplug the AUX
cable to revert to the Bluetooth
connected device.
2. Plug your media device into the other
end of the AUX cable to connect it.
Note: Unplugging the AUX cable automatically changes the speaker back
Bluetooth mode.
Pausing Playback
1. Press the power button
once to pause tracks.
2. Press again to continue
media playback.
Changing The Volume
1. Press the ‘+’ button to increase
the volume.
Note: The speaker will emit a
beep when max. volume is reached.
2. Press the ‘-’ button to
decrease the volume.
Note: The speaker will go
mute at the lowest volume
setting.
Skipping Tracks
1. Press and hold the ‘+’ button for
2 seconds to skip to the next
track.
2. Press and hold the ‘-’
button for 2 seconds
toskip to the previous
track.
Note: This is only works when connected via Bluetooth. Skip tracks from
your media device when in auxilliary mode.
2. CONNECTING AUDIO DEVICES 3. CONTROLS
OPERATION
+
-
+
-
+
-
+
-
+
-
+
-
2 SECONDS
+
-
2 SECONDS

USB Charging Output
The speaker is capable of charging your device during media playback or
even charging a separate device via the USB port. This function is available
even when playing media through the speaker.
1. The USB charge function can be
switched on by pressing the USB
on/off LED button. The LED will
light up when it is outputting
power.
2. Connect the device to be charged
via a USB cable to the USB port.
3. Press and hold the USB on/off
button for 2 seconds to toggle
the charging function on and off.
Note: Turn off the USB charging output when a device is not being
charged to extend the runtime of your Power X Change battery.
Bluetooth not connecting
1. Another device may already be connected.
Disconnect the other device rst and then try connecting the desired
device.
2. Device Bluetooth is off.
Turn on device Bluetooth.
3. Bluetooth speaker is in AUX mode.
Remove the AUX cable from the port on the speaker and device.
Media is inaudible
1. Device is muted or volume is turned down.
Increase the playback volume by pressing the ‘+’ button.
Device is not charging via the USB connection
1. USB output is switched off.
Press and hold the USB on/off button until it lights up.
PXBSS-018
4. CHARGING DEVICES 5. TROUBLESHOOTING
+
-
+
-
+
-
2 SECONDS

MAINTENANCE DESCRIPTION OF SYMBOLS
Amperes Watt • hours
Warning Regulatory Compliance Mark
(RCM)
VVolts
W
Direct Current
Ø
Ω
dB
WhA
Diameter Watts
OhmsDecibels
Read Instruction Manual
Power tools that are no longer usable should not be disposed
of with household waste but in an environmentally friendly
way. Please recycle where facilities exist. Check with your local
council authority for recycling advice.
Recycling packaging reduces the need for landll and raw
materials. Reuse of recycled material decreases pollution in the
environment. Please recycle packaging where facilities exist.
Check with your local council authority for recycling advice.
CARING FOR THE ENVIRONMENT
SPARE PARTS
Spare parts can be ordered from the Special Orders
Desk at your local Bunnings Warehouse.
For further information, or any parts not listed here,
visit www.ozito.com.au or contact Ozito Customer
Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
WARNING! BEFORE CLEANING OR CARRYING OUT
ANY MAINTENANCE PROCEDURE, ENSURE THAT
THE BATTERIES HAVE BEEN REMOVED.
Cleaning
• Keep the ventilation slots of the tool clean at all times to ensure efcient
operation.
• After each use, blow air through the tool housing to ensure it is free from
all dust, dirt, etc. Build up of dust or dirt particles may cause the tool to
overheat and shorten the life of the tool.
• If the housing of the tool requires cleaning, do not use solvents. Use of a
cloth only is recommended.
• Never allow any liquid to get inside the tool, never immerse any part of
the tool into liquid.
Storage
When not in use, the tool should be stored in a dry, frost free location, keep
out of children’s reach.
Note: Ozito Industries will not be responsible for any damage or
injuries caused by repair of the tool by an unauthorised person or by
mishandling.

ELECTRICAL SAFETY
WARNING! When using mains-powered tools, basic safety precautions, including the
following, should always be followed to reduce risk of fire, electric shock, personal injury
and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an
emergency, before operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
The charger has been designed for 230V and 240V only. Always check that the power supply
corresponds to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New
Zealand.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in
order to avoid a hazard.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect
the extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged
or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension
lead not suitable for the power input of the tool or which is damaged or defective may result in a
risk of fire and electric shock.
The power supply for this products charger should be protected by a residual current device (rated
at 30mA or less). A residual current device reduces the risk of electric shock.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the
warnings refers to your mains-operated (corded) power tool or battery-operated (cordless)
power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you
to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase
the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use
of a cord suitable for outdoor use reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious personal
injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with
your finger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of
the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related
hazards.
h. Do not let familiarity gained from frequent use of tools allow you to become complacent and
ignore tool safety principles. A careless action can cause severe injury within a fraction of a
second.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power
tool before making any adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous in
the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts
and any other condition that may affect the power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power
tool for operations different from those intended could result in a hazardous situation.
h. Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles
and grasping surfaces do not allow for safe handling and control of the tool in unexpected
situations.
5. Service
a. Have your power tool serviced by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
BLUETOOTH SPEAKER SAFETY WARNINGS
WARNING! This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Avoid contact with liquids; keep away from water and high moisture conditions.
• Do not place a naked flame source such as candles near or on the speaker.
• Do not hit the product severely, or insert any conductive objects into the speaker or
charging port.
• Do not block the speaker grill when the speaker is running.
• Stop using at once if high temperature, smoke, a burning smell, abnormal noise or fire are
noticed emitting from the product.
• Do not attempt to repair the speaker.
• Keep the speaker housing dry, clean and free from grease and oil. Always use a clean cloth for
cleaning. Never use brake uid, gasoline, petroleum-based products, or any strong solvents to clean your speaker. Following
this rule will reduce the risk of loss of control and deterioration of the enclosure plastic.
• Do not install near any heat sources such as radiators, heat registers or other products
(including amplifiers) that produce heat.
• Only use attachments/accessories specified by the manufacturer.
• To reduce the risk of personal injury and electric shock, do not expose to water or rain.
• Do not use the speaker or listen to music or other audio programs while operating
machinery. Doing so may cause distractions that could result in personal injury.
• This speaker is capable of producing sound levels that can be dangerous to long-term
hearing. Listening to music at a high volume for any period of time may cause the listener noise-induced hearing loss. The
higher the volume, the less time required before your hearing may be affected.
