P.I. Engineering X-keys XKT-LTRAC User manual

L-Trac Laser Trackball
Product Manual
Model XKT-LTRAC
2.25” ball
Three buttons and scroll roller
Ambidextrous
Sold and supported in the USA and UK
USA: www.xkeys.com
UK: www.x-keys-uk.com
Box Contents
This package contains:
1- X-keys L-Trac Trackball
1- Product Manual (this document)
Quick Start
1. Plug the L-Trac into an available USB port
2. Wait for the operating system to recognize it
Changing the
Resolution
Press and hold the
center button then
press the Right
mouse button. Each
press of the right
mouse button will
cycle the resolution to
the next of three
settings. The default
resolution is 800 CPI.
1600 CPI and 400
CPI are the other two
settings. Test the
three settings until
you determine the
best resolution for
your application. The
L-Trac will remember
the setting.

Compatibility
The L-Trac Trackball is compatible with all operating systems (OS) which
support USB mouse. It uses standard mouse drivers in the OS and requires
no software or driver installation.
Auxiliary Switches and/or Pedals
The two 3.5mm ports on the L-Trac can host switches and trigger mouse
buttons XButton 1 and XButton 2. A wide variety of switches and pedals
designed for this purpose may be purchased from our website.
Support
Should you encounter difficulty with the installation, you may contact our
technical support staff.
USA: [e-mail] | Phone: [phone]
UK: [e-mail] | Tel [phone]
Compatible Accessories
Please visit the Accessories page on our website for details on the following.
X-keys USB Extender –up to 150 feet via CAT 5 cable
X-keys Switches
X-keys Foot Switches
Other Products from P.I. Engineering
X-keys XK-24 –24 programmable keys
X-keys XK-60 –60 programmable keys
X-keys XK-80 –80 programmable keys
X-keys XKE-128 –128 programmable keys
X-keys XKE-40 –40 programmable keys with rack mount option
X-keys XK-12 Joystick –12 keys with a precision joystick
X-keys XK-12 Jog & Shuttle –12 keys with jog & shuttle
X-keys XK-3 Foot Pedal –three programmable pedals
X-keys XK-4 Stick –four programmable keys
X-keys XK-8 Stick –eight programmable keys
X-keys XK-16 Stick –sixteen programmable keys
X-keys XK-68 Joystick - 68 keys with a precision joystick
X-keys XK-68 Jog & Shuttle –68 keys with jog & shuttle
X-keys XKE-124 T-bar –124 programmable keys and a T-bar fader
X-keys USB 3 Switch Interface –up to 3 switch ports with splitter
X-keys USB 12 Switch Interface –up to12 switch ports with splitter
X-keys Encoder Board –128 matrixed switch points
