P1 P4600SPE User manual

P1 Petrol Lawn Mower
P4600SPE
User Manual

This manual should be kept with the product. Please read and understand these instructions
before you use your product. Failure to do this may result in personal injury or damage to the
product.
The safety precautions and warnings are to ensure your safety and protect you from harm or
damage to the product.
The information contained in this manual was accurate at the time of production, however
P1 Power Equipment may make modifications to the product without notification.
GENPOWER LTD
Isaac Way, London Road,
Pembroke Dock, UNITED KINGDOM, SA72 4RW
T: [phone] F: [phone]
www.p1pe.co.uk
Introduction
We work very hard to give all of our customers the best possible service.
If you have any problems, before leaving negative feedback, please contact
us to give us a chance to resolve the issue.
We would be delighted if you left us positive feedback!
Thank you for purchasing this product.
Thank You For Purchasing Your P1 Lawnmower

Contents
Stopping Procedure........................................30
After Each Use......................................30
Stopping Procedure..............................30
Specifications...................................................31
Troubleshooting...............................................32
Spare Parts.......................................................33
Maintenance And Care..............................34-45
Safety.....................................................34
Routine Maintenance.............................35
Oil..........................................................36
Spark Plug.......................................36-37
Air Filter..................................................38
Blade Maintenance..........................39-40
Drive Belt.........................................40-42
Fuel And Carburettor.............................43
Cleaning.................................................43
Storage..................................................44
Transportation & Handling.....................44
Environmental Protection......................45
Recycling & Disposal.............................45
Tips For Mowing..............................................46
General Tips..........................................46
How Often Should I Mow......................46
What Time Should I Mow......................46
Useful Information............................................47
Our YouTube Channel...........................47
Warranty................................................47
Manual Updates....................................47
Returning Your Product.........................47
Leaving A Review..................................47
Ordering Spare Parts.............................47
Notes...........................................................48-49
Contact Us.......................................................50
Service Record......................................50
Declaration Of Conformity...............................51
Features..............................................................4
What’s In The Box..............................................4
Symbols On The Machine..................................5
General Safety..............................................6-17
Understand Your Machine.......................6
Personal Safety....................................8-9
Inspect Your Machine..........................7-8
Engine Safety.......................................8-9
Work Area................................................9
During Use.......................................10-11
Carbon Monoxide..................................12
General Fuel Safety...............................13
Electrical Safety.....................................14
Batteries.................................................14
Vibrations.........................................14-15
Noise......................................................15
Personal Protective Equipment.............16
Getting to Know The Machine...............17
Getting Started.................................................18
Assembly Safety....................................18
Unboxing................................................18
Assembly.....................................................19-20
Cable Attachment............................................21
OPC Cable Adjsutment....................................22
Drive Cable Adjustment...................................23
Preparation.......................................................24
Adding Oil..............................................24
Adding Fuel...........................................24
Operation..........................................................25
Grass Collection Mowing......................25
Cut And Drop........................................25
Starting Procedure......................................26-29
Before Each Use....................................26
Cold Recoil Start..............................26-27
Warm Recoil Start..................................27
Cold Electric Start..................................28
Warm Electric Start................................29

Features
• P4600SPE Lawnmower
• Grass Collector
• Assembly Tools
• User Manual
• Battery Charger
What’s In The Box
4
Upper Handle
OPC (Operator Presence Control) Lever
Self-Propelled Drive Handle
Quick Release Handle
Lower Handle
Fuel Filler Cap
Air Filter
Spark Plug
Exhaust
Oil Filler / Dipstick
Wheel Height
Adjustment Lever
Grass Collector
Recoil Start
Handle
Primer Bulb

5
Symbols On The Machine
CAUTION!
Handle carefully.
INSTRUCTION MANUAL
Read and understand operator’s
manual before using the machine.
Failure to follow instructions could
result in death or serious injury.
DANGER!
Keep hands and feet away from
cutting parts.
DANGER AREA
Keep away from the danger area.
DANGER OF THROWN OBJECTS
Keep all bystanders and animals at
least 15 metres away from the
machine during operation. If
approached, stop the machine
immediately.
WEEE SYMBOL
Waste electrical products should
not be disposed of with household
waste. Please recycle where
facilities exist. Check with your local
authority or local store for
recycling advice.
CE SYMBOL
This product complies with the
applicable European directives and
an evaluation method of conformity
for these directives was done.
WARNING
Always use correct tools and
original spare parts.
HEARING AND EYE PROTECTION
Suitable safety hearing protection is
recommended. Always wear safety
glasses/goggles and/or face shields.
Everyday eyeglasses have
only impact resistant lenses; they are
not safety glasses/goggles.
AIR FILTER
Clean air filter every 50 hours of use
(or more often in dusty conditions).
FLAMMABLE
Petrol is flammable. Allow the
engine to cool down for at least 2
minutes before refilling the petrol.
DANGER
Do not use the lawnmower in an
enclosed area. Danger of carbon
monoxide poisoning.
NOISE MARKING
Single value noise marking
(maximum declared A-Weighted
sound power level in decibals).
OIL AND FUEL
You MUST ensure the
mower has the correct oil and fuel
level before operation.
WARNING!
Remove spark plug cap before
undertaking any maintenance.
WARNING!
Make sure engine has stopped
before making any adjustments.

General Safety
6
WARNING : READ THE INSTRUCTION BOOKLET THOROUGHLY BEFORE
USING THE MACHINE. Keep for future reference and pass it on if the machine
is loaned or sold to another user.
!
•WARNING! You must read these
instructions carefully before operating the
machine. Make sure that you are familiar with
the controls and properly operate the
machine. You must learn how to stop the
machine quickly. If you do not follow the
warnings and instructions, it may result in fire
and/or serious injury. Make sure to save all
warnings and instructions for future reference.
• Read this manual and labels affixed to the
machine to understand its limitations and
potential hazards.
• Be thoroughly familiar with the controls and
their proper operation. Know how to stop the
machine and disengage the controls quickly.
• If the unit is to be used by someone other
than original purchaser, or is to be loaned,
rented, or sold, always provide this manual
and any needed safety training before
operation. The user can prevent and is
responsible for accidents or injuries that may
occur to themselves, to other people, or to
property.
• Do not force the machine beyond its limits.
Use the correct machine for your application.
• Know how to stop the engine quickly in
case of emergency. Understand the use of all
controls.
• ALL MAINTENANCE other than that listed in
this manual, should be carried out by
professionally trained and certified personnel.
Understand Your Machine Personal Safety
• WARNING! Never allow children or people
unfamiliar with these instructions to use the
product. Local regulations can restrict the
minimum age of the operator. Persons not
familiar with the user instructions must not use
this lawnmower.
• Keep children, pets, and other people not
using the unit away from the work area (at
least 15m away). Be alert and shut off the unit
if anyone enters work area. Keep children
under the watchful care of a responsible adult.
• Stay alert, watch what you are doing and
use common sense when operating the
machine. Never operate the machine when
unwell or tired, or if you have taken alcohol,
medicine, drugs or any substances which may
slow your reflexes and compromise
judgement. A moment of inattention while
operating the machine may result in serious
personal injury.
• Appropriate Personal Protective Equipment
(PPE), MUST be worn at all times when
operating or repairing the machine. Always
wear anti-slip and resistant work footwear and
long trousers while using the machine. Do not
use the machine when barefoot, wearing
sandals or similar lightweight footwear. Do not
wear chains, bracelets or clothing that is loose
fitting or hanging ties or cords. Tie long hair
back. Always wear protective earplugs. Loose
clothes, jewellery, or long hair can be caught
in moving parts. Protect eyes, face, and head
from objects that may be thrown from the unit.
Always wear safety goggles or safety glasses
with side shields when operating.
• Always keep hands and feet away from all
moving parts during operation. Moving parts
can cut or crush body parts.
!!

General Safety
7
• Always keep hands and feet away from all
pinch points.
• Do not touch parts that might be hot
from operation. Allow parts to cool before
attempting to maintain, adjust, or service.
• Do not overreach. Keep proper footing and
balance at all times. This enables better
control of the machine in unexpected
situations. Extending your body too far can
result in a loss of balance and you may fall
which will result in injury.
• Never place any part of your body where it
would be in danger if movement should occur
during assembly, installation, and operation,
maintenance, repairing or moving.
• Start the engine carefully according to
instructions and with feet away from the
moving parts.
• Do not place your hands or feet near or
under rotating parts. Keep away from any
discharge openings.
• Keep in mind that the operator or user is
responsible for accidents, hazards or
unexpected events involving the machine that
occur to other people or their property. It is
the responsibilty of the user to assess the
potential risk of the area where work is being
carried out. The operator or user must take
all necessary precautions to ensure their own
safety and that of others, especially on slopes
or rough, slippery and unstable ground.
• This machine is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been
given supervision or instruction concerning
use of the machine by a person responsible
for their safety. Children should be supervised
to ensure that they do not play with the
machine.
Inspect Your Machine
• Check your machine before starting it. Keep
guards in place and in working order. Make
sure all nuts, bolts, etc., are securely
tightened.
• You must check the general condition of the
machine before use.
• Never operate the machine when it is in
need of repair or is in poor mechanical
condition. Replace damaged, missing, or
failed parts before using it. Check for fuel
leaks. Keep the machine in safe working
condition.
• Do not use the machine if the engine’s
switch does not turn off the engine when
running. Any petrol powered machine that
can’t be controlled with the engine switch is
dangerous and must be replaced.
• Regularly check to see that keys and
adjusting wrenches are removed from the
machine area before starting it. A wrench or
a key that is left attached to a rotating part of
the machine may result in personal injury.
• Avoid accidental starting. Be sure the
engine’s switch is off before transporting the
machine or performing any maintenance or
service on the unit. Transporting or performing
maintenance or service on a machine with its
switch on invites accidents.
• If the machine should start to vibrate
abnormally, stop the engine and check
immediately for the cause. Vibration is
generally a warning sign of trouble.
• Do not tamper with or disable safety
systems.
• Only use manufacturer-recommended
attachments.
• Before using, always visually inspect to see
that the tools are not worn out or damaged.
!

General Safety
8
Engine Safety
Replace worn out or damaged elements and
bolts in set to preserve balance.
• Keep the machine in good operating
condition. Operating a machine in poor or
questionable condition could result in serious
injury.
• Be sure all safety devices are in working
order and warning labels are in place. These
items are installed for your safety.
• Be sure the safety covers are in place. If the
attachments/tools are not installed in their
seats, do not use the machine.
• The use of an unbalanced blade, the
excessive speed of movement, or the absence
of maintenance have a significant influence on
noise emissions and vibrations. It is necessary
to take preventive steps to eliminate possible
damage due to high levels of noise and stress
from vibration. You must maintain the machine
well, wear ear protection and take breaks from
working.
• Where applicable, check the battery status
regularly. If there is any damage to the casing,
cover or terminals, you must replace it.
• Make sure to replace faulty silencers.
• You must check the general condition of the
machine before using and in particular:
- Check that the blade is not worn or
damaged. Replace the entire blade and all
worn or damaged fittings to preserve balance.
Any repairs must be done at a specialised
centre.
- Do not force the OPC safety lever as it must
move freely; it should return automatically and
quickly back to the neutral position, resulting
in the stopping of the blade.
• Before mowing make sure that the blade
and blade fixing screw are securely fastened.
When blade requires sharpening this must be
done evenly on both sides of the blade to
prevent any imbalance. If the blade is
damaged it must be replaced.
• This machine is equipped with an internal
combustion engine. Do not use on, or near,
forest-covered or brush-covered land unless
the exhaust system is equipped with a spark
arrester meeting applicable local, state, or
federal laws.
• A spark arrester, if used, must be maintained
in effective working order by the operator.
• Never start or run the engine inside a closed
area. The exhaust fumes are dangerous,
containing carbon monoxide, an odourless
and deadly gas. Operate this unit only in a
well-ventilated outdoor area. (See carbon
monoxide safety).
• Do not tamper with the engine in an effort to
get it to run at higher speeds. The maximum
engine speed is preset by the manufacturer
and is within safety limits.
• Keep a fire extinguisher on hand when
operating this machine in dry areas as a
precautionary measure.
• Never leave the operating position when the
engine is running.
• The engine parts get very hot when
running, do not touch. Danger of burns.
• Follow the instructions to ignite the engine
carefully whilst keeping feet away from moving
parts.
• Never incline the machine during ignition.
Ignite the machine on a flat surface without
obstacles or high grass.
• Do not over-rev the engine or change the
engine settings.
!
• Keep all nuts, bolts and screws tight to
ensure the equipment is in safe working
condition.

General Safety
9
•Make sure you thoroughly inspect the entire
work area and remove all objects and anything
that could be thrown by the machine or could
damage the engine or machine (branches,
stones, wire, toys, etc). Stay alert for any
foreign objects which may have been missed.
If a stone or any foreign object is
contacted by the blade, it can be thrown out
of the cutting area at very high speed,
causing injury or damage. Attempting to clear
the work area whilst using the machine will
reduce your concentration and creates a trip
hazard. Any liquid spilled on the floor may
result in you slipping.
•You must only work in daylight or with good
artificial light in good visibility conditions. Keep
people, children and animals away from the
working area.
• Operate on flat, level ground.
• DO NOT work on wet ground. If there has
been heavy rain on the working site, wait until
the ground has dried up.
• Never park the machine in a place with
unstable ground which could give way.
• You must pay special attention when
approaching obstacles that could compromise
visibility.
Work Area
• Never pick up or carry the machine while the
engine is running.
• Never change the rated speed of the engine.
• Stop the engine whenever you leave the
machine, or before refuelling, when cleaning
or while maintaining.
• Reduce the throttle setting during engine
shut down and, if the engine is provided with a
shut-off valve, turn the fuel off at the
conclusion of working.
• If your machine is suitable to work on
slopes, you must work across the slope and
not up and down it. When changing direction,
you need to be careful that the wheels do not
hit any obstacles (such as roots, branches,
stones, etc) that can cause the machine to
slide sideways or make you lose control of it.
The lawnmower must never be used on slopes
of over 20°, regardless of the mowing
direction. Make sure on slopes you have a
steady foothold.
• Find and locate all fixed objects in the
ground, such as sprinkler systems, poles,
water valves, bases for washing lines etc
Make sure that you check for hidden
electrical cables or similar on the surface of
the lawn. ALWAYS run the machine around
these objects. NEVER intentionally run the
machine over foreign objects.
• You must be careful near ravines, ditches or
embankments.
• Exercise extreme caution when operating on
or crossing gravel drives, walks, or roads. Stay
alert for hidden hazards or traffic.
• Pay the utmost attention when working on
frozen ground as the machine may tend to
skid.
• Do not work in the rain and when there is a
thunderstorm or lightning risk. If there is bad
weather conditions, do not use the machine.
• You must pay special attention when
approaching obstacles that could compromise
visibility.
!

• The excessive speed of movement or the
absence of maintenance have a significant
influence on noise emissions and vibrations.
It is necessary to take preventive steps to
eliminate possible damage due to high levels
of noise and stress from vibration. You must
maintain the machine well, wear ear protection
and take breaks from working.
• Always stop the engine before emptying the
grass catcher or changing the cutting height.
• Never place your hands or feet under the
lawnmower or grass ejection area whilst the
engine is running.
• This petrol lawnmower is to be used for
cutting natural grass, never use the
lawnmower for any other purposes. Any other
use can put your safety at risk and damage to
lawnmower.
• Never place your hands and feet underneath
the deck or into the rear or side discharge
chutes when the engine is running.
• You must immobilise the blade if the
machine must be inclined for transport, when
moving over surfaces other than grass and
when the lawnmower is transported from or to
an area that must be cut.
• Do not operate the machine with damaged
guards or without the grass collector, side
discharge guards or rear discharge guards.
• Do not place your hands or feet near or
under rotating parts. Keep away from the
discharge opening.
• Do not over-rev the engine or change the
engine settings.
• The engine parts get very hot when running,
do not touch. Danger of burns.
General Safety
10
During Use
• Always hold the unit with both hands when
operating. Keep a firm grip on the handlebars.
Be aware that the machine may unexpectedly
bounce upward or jump forward if the
machine should strike buried obstacles such
as large rocks or roots.
• Do not operate the machine in confined
areas where there may be a risk of crushing
the operator between the machine and
another object.
• Be very careful when pulling the
machine toward you. You must look behind
you to make sure there are no obstacles
before and during operations in reverse gear
(if applicable).
• Always use the lawnmower with the grass
catcher and/or deflector in position.
• Do not allow the machine to pull you along,
you must walk and never run.
• Before leaving the machine to clear
blockages, check, clean, refuel or after
striking foreign object, stop the engine and
make sure that the blades have come to a
complete stop.
• WARNING! If something breaks or an
accident happens whilst working, you must
turn off the engine immediately and move the
machine away to prevent further damage. If
an accident happens with injuries or third
parties are injured, carry out the first aid
measures most suitable for the situation
immediately and contact the medical
authorities for any necessary health care.
Carefully remove any debris that might cause
damage or harm persons or animals should it
not be seen.
• Keep a firm hold on the handlebars, they
may tend to lift during clutch engagement (if
applicable).
!
