The Palo Alto Networks M-100 appliance is a multi-function appliance that you can configure
for one of the following two modes:
•Panorama mode—Performs both central management and log collection for Palo Alto
Networks firewalls. This is the default mode.
•Log Collector mode—Functions as a dedicated Log Collector, which either an M-100 or
M-500 appliance in Panorama mode or a Panorama virtual appliance can manage.
Use the following topics to learn about the front and back panel components.
•“Front Panel” in the next section
•“Back Panel” on page 8
Note: The minimum Panorama version that you can install on a M-500 appliance
is 7.0.

Front Panel
6• Overview Palo Alto Networks
Front Panel
Figure 1 shows the front panel of the M-100 appliance and Table 1 describes the front panel
features.
Figure 1. Front Panel
Table 1. Front Panel Features
Item Description
1) Disk Drives/Bays The M-100 has 8 disk drive bays. Starting from left to right, the bays
are labeled A1/A2, B1/B2 C1/C2, and D1/D2.
By default, the appliance ships with 1TB drives installed in drive
bays A1 and A2 and the drive pair is in a RAID 1 array. You can
increase storage by adding 1TB drives to the empty drive bays in
pairs (B1/B2, C1/C2, and D1/D2).
As of Panorama 7.1, you can also upgrade to 2TB drives. For
information on how to increase storage on an M-Series appliance,
refer to the Panorama 7.1 or later Administrator’s guide on the
Technical Documentation Portal.
2) System Health Indicates overall system health. Green indicates healthy, red
indicates a system error.
3) Internal HDD Activity Blinks if there is disk drive activity.
4) LAN Activity Blinks if there is network activity.
5) UID Button (LED) The Unique Identification (UID) feature is a combination LED/button that
is used to assist a technician in locating a device when moving from the
back of a rack to the front of a rack. When you push the button, the rear
UID LED and the front panel LEDs will illuminate bright blue, assisting
the technician in identifying the device in a rack. Push the button again to
stop the LED from flashing.
Note that the UID button is very small and is located slightly to the left of
the UID port hole. Use a small object, such as a paper clip, to press the
button.
6) Power Button/LED Used to power on and off the M-100 device. To power off the system, hold
down the button until the system shuts down. 

Note: When the system in initially plugged in, it will automatically power
on.
7) NMI Button The Non-Maskable Interrupt (NMI) button is currently disabled on the
M-100 appliance.
D1 / D2C1 / C2B1 / B2A1 / A2
1
2
3
4
5
6
7
8910
M-100
11

Palo Alto Networks Overview • 7
Front Panel
8)Drive LEDs • Top LED—Blinks green when there is drive activity.
• Right LED—Illuminates red when a drive failure occurs.
9) Console DB-9 serial port for console access.
10) MGT RJ-45 10/100/1000 management port used for management, log
collection, and log collector to log collector communication.
For information on configuring this port for Panorama services,
refer to the Panorama Administrator’s Guide on the Technical
Documentation Portal for the release that the appliance is running.
11) 1 RJ-45 10/100/1000 Ethernet port (ethernet1/1).
For information on configuring this port, refer to the Panorama
Administrator’s Guide on the Technical Documentation Portal for the
release that the appliance is running.
Table 1. Front Panel Features (Continued)
Item Description

Back Panel
8• Overview Palo Alto Networks
Back Panel
Figure 2 shows the back panel of the M-100 and Table 2 describes the back panel features.
Figure 2. Back Panel
Table 2. Back Panel Features
Item Description
1) Power Port AC power inlet.
2) 2 RJ-45 10/100/1000 Ethernet port (ethernet1/2).
This port functionality is available in version 6.1 and later. Prior to
6.1, this port is not functional.
For information on configuring this port, refer to the Panorama
Administrator’s Guide on the Technical Documentation Portal for the
release that the appliance is running.
3) 3 RJ-45 10/100/1000 Ethernet port (ethernet1/3).
For information on configuring this port, refer to the Panorama
Administrator’s Guide on the Technical Documentation Portal for the
release that the appliance is running.
Prior to Panorama release version 8.0, this port is not functional.
4) USB Ports USB ports for future use.
5) UID Button The Unique Identification feature is a combination LED/button that is used
to assist a technician in determining which device is being worked on when
moving from the front of a rack to the back of a rack. When the button is
pushed (either front or rear), both the front and rear UID LEDs will flash
blue, assisting the technician in identifying the device in a rack. When
either button is pushed again, the flashing LEDs stop flashing.
UID
123
45

Palo Alto Networks Installing the Hardware • 9
Tamper Proof Statement
Chapter 2 
Installing the Hardware
This chapter describes how to install the M-100. For more information, refer to the following
topics:
•“Tamper Proof Statement” on page 9
•“Before You Begin” in the next section
•“Equipment Rack Installation” on page 10
•“Connecting Cables to the Device” on page 15
•“Connecting Power” on page 16
Tamper Proof Statement
To ensure that products purchased from Palo Alto Networks have not been tampered with
during shipping, verify the following upon receipt of each product:
•The tracking number provided to you electronically when ordering the product matches
the tracking number that is physically labeled on the box.
•The integrity of the tamper-proof tape used to seal the box is not compromised.
•The integrity of the warranty label on the appliance is not compromised.
Before You Begin
•It is recommended that two people be available to mount the M-100 in a 19-inch rack.
•Have a Phillips head screwdriver available and a small pliers or nut wrench.
•Verify that the intended location has adequate air circulation and meets the temperature
requirements. Refer “Environmental Specifications” on page 24.
•Unpack the device.
•Verify that power is not connected to the appliance.
•Allow clear space on both sides of the appliance.

Equipment Rack Installation
10 • Installing the Hardware Palo Alto Networks
Equipment Rack Installation
The M-100 rack mount kit is ordered separately and can be used to mount the M-100 on a 2-
post or 4-post 19” rack.
The following safety guidelines apply to rack installation:
•Elevated ambient operating temperature—If the M-100 is installed in a closed or multi-
unit rack assembly, the ambient operating temperature of the rack environment may be
greater than the ambient room temperature. Verify that the ambient temperature of the
rack assembly meets the maximum rated ambient temperature requirements listed in
“Environmental Specifications” on page 24.
•Reduced air flow—Ensure that the airflow required for safe device operation is not
compromised by the rack installation.
•Mechanical loading—Ensure that the rack-mounted device does not cause hazardous
conditions due to uneven mechanical loading.
•Circuit overloading—Ensure that the circuit that supplies power to the device is
sufficiently rated to avoid circuit overloading or excess load on supply wiring. Refer to
“Electrical Specifications” on page 24.
•Reliable earthing—Maintain reliable earthing of rack mounted equipment. Pay special
attention to supply connections other than direct connections to the branch circuit (such
as the use of power strips).
To install the M-100 in a grounded 19-inch rack:
1. Unpack the rail kit and then remove the inner rail from the outer rail and attached the
inner rail to both sides of the M-100. To do this, place the inner rail over the mounting
posts and then slide forward to lock in place. Simultaneously press the inner rail release
latches to allow the inner rail to slide out of the outer rail. The mounting screw holes are
now exposed so you can use the provided screws to secure the inner rail to the M-100 as
shown in Figure 3.

Palo Alto Networks Installing the Hardware • 11
Equipment Rack Installation
Figure 3. Attaching the Inner Rail to the M-100
1
2
2
Attach the inner rail on
both sides of the M-100.
Press the latch to disconnect
the inner rail from the outer rail.

Equipment Rack Installation
12 • Installing the Hardware Palo Alto Networks
2. If this is a 4-post rack install, continue to Step 3. If this is a 2-post install, attached the 2-
post brackets to the outer rail as shown in Figure 4.
Figure 4. Attaching the 2-post Bracket for 2-post Rack Installation
Bracket for 2-post
installation.
Bracket for 2-post
installation.

Palo Alto Networks Installing the Hardware • 13
Equipment Rack Installation
3. Attach the outer rail to the rack. The 2-post install will use the two inner mounting
brackets to attach to the rack and the 4-post install will use the two outer brackets. Both
install methods are shown in Figure 5.
Figure 5. Installing the Outer Rail on a 2-post and 4-post Rack
Note: If you are using a non-threaded rack, install the threaded brackets behind
each rack mount point as shown in Figure 5.
2-post
Two threaded
4-post
Install
mounting brackets
for non-threaded racks.
Install
Two threaded
mounting brackets
for non-threaded racks.

Equipment Rack Installation
14 • Installing the Hardware Palo Alto Networks
4. Lift the M-100 appliance in place and align the inner rail that is mounted on the M-100
with the outer rail that is now mounted on the rack and slide the appliance inward until it
stops. Simultaneously press the release latches on each side of the inner rail to allow the
inner rail to completely slide into the outer rail. The illustration in Figure 6 shows an
M-100 installation in a 2-post and 4-post rack.
Figure 6. Installing the M-100 Into a 2-post or 4-post Rack
2-post Rack
4-post Rack

Palo Alto Networks Installing the Hardware • 15
Connecting Cables to the Device
5. Tighten the thumb screws on the front of the M-100 to secure it to the rail as shown in
Figure 7. It is recommended that you tighten the thumb screws with a Phillips head or
flat-head screwdriver after tightening by hand.
Figure 7. Tightening the Thumb Screws on the M-100.
Connecting Cables to the Device
Figure 8 shows the front M-100 cable connections. Refer to Table 1 for descriptions of the front
panel interfaces and Table 2 for descriptions of the back panel interfaces.
Figure 8. Cable Connections for the Front of the M-100
CAUTION: Shielded interface cables which are grounded shall be used to ensure
agency compliance with electromagnetic emissions (EMC).
D1 / D2C1 / C2B1 / B2A1 / A2
ManagementConsole
Serial
Front

Connecting Power
16 • Installing the Hardware Palo Alto Networks
Connecting Power
To power the M-100, attach a power cable to the device and plug it into a grounded wall
outlet. The device will power on automatically.

Palo Alto Networks Service the Hardware • 17
Cautions and Warnings
Chapter 3 
Service the Hardware
This chapter describes how to replace disk drives, interpret LEDs, and troubleshoot hardware
problems. For more information, refer to the following topics:
•“Cautions and Warnings” in the next section
•“Replace an M-100 Appliance Disk Drive” on page 18
•“Interpreting the Port LEDs” on page 22
Cautions and Warnings
CAUTION: Disconnect all power cords before servicing the M-100.
WARNING: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries
according to the battery manufacturer’s instructions.
WARNING: Removal of the equipment’s top cover is to be done only by Palo Alto Networks trained
service person(s).

Replace an M-100 Appliance Disk Drive
18 • Service the Hardware Palo Alto Networks
Replace an M-100 Appliance Disk Drive
The M-100 appliance has eight drive bays and each drive pair (A1 and A2 for example) is in an
independent RAID 1 array. This redundant configuration ensures that there is no service
interruption or loss of log data if a disk drive fails.
1. Place an anti-static wrist strap around your wrist and connect it to ground.
2. Identify the failed drive and note the drive model by running the following operational
command and viewing the status and model fields:
admin@M-100> show system raid detail
For example, the following output shows that disk drive A2 failed and the drive model is
ST91000640NS.
Disk Pair A Available
Status clean, degraded
Disk id A1 Present
model : ST91000640NS
size : 953869 MB
status : active sync
Disk id A2 Present
model : ST91000640NS
size : 953869 MB
status : failed
3. Remove the failed drive from the RAID 1 array. In this example, run the following
command to remove drive A2 from the array:
admin@M-100> request system raid remove A2
CAUTION: Do not attempt to replace a drive with a third-party drive. Also, do not
mix drive models within a RAID 1 array (for example, the drive model must be the same
for both drives in the A1/A2 RAID 1 array). You can, however, mix drive models in
different RAID 1 arrays. For example, the drives in the A1/A2 array can both be model
ST91000640NS and the drives in the B1/B2 array can both be model ST1000NX0423.

Palo Alto Networks Service the Hardware • 19
Replace an M-100 Appliance Disk Drive
4. Press the ejector button on the carrier of the failed drive (A2 in this example) to release the
carrier handle and gently pull the handle toward you and slide the carrier out of the
appliance. Figure 9 shows how to remove a drive carrier (A1 in the illustration) from the
appliance.
Figure 9. Remove or Install an M-100 Appliance Disk Drive Carrier
5. Remove the replacement drive from the packaging and compare the drive model written
on the label with the drive model of the failed drive. Proceed as follows based on your
findings:
– If the replacement drive is the same model number of the failed drive that you
removed, then continue to Step 6.
– If the replacement drive is a different model number than the drive that you removed,
then continue to Step 7.
6. (Same model replacement drive only) Install a replacement disk drive that is the same
model as the other drive in the RAID 1 array:

Replace an M-100 Appliance Disk Drive
20 • Service the Hardware Palo Alto Networks
a. Remove the four screws that hold the failed drive in the drive carrier and then remove
the drive from the carrier.
b. Put the new drive in the carrier and secure it to the carrier using the four screws you
removed from the failed drive.
c. Ensure that the drive carrier lever is in the open position; if it is not, press the ejector
button on the drive carrier to release the lever and pull it out until it is fully open.
d. Slide the drive carrier into the drive bay on the appliance until it is about 1/4” from
being fully inserted. You can do this by pressing the ejector button on the carrier,
which will cause the lever to close part way. When the drive is almost fully inserted,
close the lever to seat the drive in place.
e. Add the replacement drive to the RAID 1 array. In this example, run the following
command to add drive A2 to the array:
admin@M-100> request system raid add A2
The system automatically configures the new drive to mirror the contents of the other
drive in that RAID 1 array.
f. Continue to view RAID status until you see that the disk pair (Disk Pair A in this
example) shows Available and both drives show the status active sync. To view
RAID status, run the following command:
admin@M-100> show system raid detail
The following output shows that the RAID 1 array is functioning properly:
Disk Pair A Available
Status clean
Disk id A1 Present
model : ST91000640NS
size : 953869 MB
status : active sync
Disk id A2 Present
model : ST91000640NS
size : 953869 MB
status : active sync
7. (Different model replacement drive only) Install a replacement disk drive that is a
different model than the other drive in the RAID 1 array:
a. Remove the four screws that hold the drive in the drive carrier and then remove the
failed drive (A2 in this example) from the carrier.
Note: If you are using an empty carrier that does not have a drive installed, you
may have to remove the blank drive insert by removing the four screws that attach
the insert to the carrier.
Note: When you initiate the copy command as described in the following steps,
logging and log query will not be available on the disk pair until the copy is complete
and the disk pair shows Available. If the other drive pairs (B1/B2, C1/C2, and
D1/D2 in this example) are low on disk during the copy process, older logs are deleted
to make room for new logs.
Note: If you are using an empty carrier that does not have a drive installed, you
may have to remove the blank drive insert by removing the four screws that attach
the insert to the carrier.
