Fujitsu D3320 PRIMERGY BX2560 M2 User manual

Reference Manual - English
D3320 BIOS Setup Utility for FUJITSU Server
PRIMERGY BX2560 M2
Reference Manual
Edition February 2016

Copyright and Trademarks
Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Feel free to send us your comments by e-mail to
[email protected].
Certified documentation
according to DIN EN ISO 9001:2008
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2008.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright 2016 FUJITSU LIMITED
All rights reserved.
Delivery subject toavailability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.
– The contents of this manual may be revised without prior notice.
– Fujitsu assumes no liability for damages to third party copyrights or other rights arising from
the use of any information in this manual.
– No part of this manual may be reproduced in any form without the prior written permission
of Fujitsu.
Microsoft, Windows, Windows Server, and Hyper V are trademarks or registered trademarks of
Microsoft Corporation in the USA and other countries.
Intel and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries
in the USA and other countries.

BX2560 M2 D3320 - BIOS Setup Utility
Before reading this manual
For your safety
This manual contains important information for safely and correctly using this
product.
Carefully read the manual before using this product. Pay particular attention to
the accompanying manual "Safety Notes and Regulations" and ensure these
safety notes are understood before using the product. Keep this manual and the
manual "Safety Notes and Regulations" in a safe place for easy reference while
using this product.
Radio interference
This product is a "Class A" ITE (Information Technology Equipment). In a
domestic environment this product may cause radio interference, in which case
the user may be required to take appropriate measures. VCCI-A
Aluminum electrolytic capacitors
The aluminum electrolytic capacitors used in the product's printed circuit board
assemblies and in the mouse and keyboard are limited-life components. Use of
these components beyond their operating life may result in electrolyte leakage
or depletion, potentially causing emission of foul odor or smoke.
As a guideline, in a normal office environment (25°C) operating life is not
expected to be reached within the maintenance support period (5 years).
However, operating life may be reached more quickly if, for example, the
product is used in a hot environment. The customer shall bear the cost of
replacing replaceable components which have exceeded their operating life.
Note that these are only guidelines, and do not constitute a guarantee of
trouble-free operation during the maintenance support period.
High safety use
This product has been designed and manufactured to be used in commercial
and/or industrial areas as a server.
When used as visual display workplace, it must not be placed in the direct field
of view to avoid incommoding reflections (applies only to TX server systems).
The device has not been designed or manufactured for uses which demand an
extremely high level of safety and carry a direct and serious risk of life or body
if such safety cannot be assured.

D3320 - BIOS Setup Utility BX2560 M2
These uses include control of nuclear reactions in nuclear power plants,
automatic airplane flight control, air traffic control, traffic control in mass
transport systems, medical devices for life support, and missile guidance
control in weapons systems (hereafter, "high safety use"). Customers should
not use this product for high safety use unless measures are in place for
ensuring the level of safety demanded of such use. Please consult the sales
staff of Fujitsu if intending to use this product for high safety use.
Measures against momentary voltage drop
This product may be affected by a momentary voltage drop in the power supply
caused by lightning. To prevent a momentary voltage drop, use of an AC
uninterruptible power supply is recommended.
(This notice follows the guidelines of Voltage Dip Immunity of Personal
Computer issued by JEITA, the Japan Electronics and Information Technology
Industries Association.)
Technology controlled by the Foreign Exchange and Foreign Trade
Control Law of Japan
Documents produced by Fujitsu may contain technology controlled by the
Foreign Exchange and Foreign Trade Control Law of Japan. Documents which
contain such technology should not be exported from Japan or transferred to
non-residents of Japan without first obtaining authorization in accordance with
the above law.
Harmonic Current Standards
This product conforms to harmonic current standard JIS C 61000-3-2.
Only for the Japanese market:
About SATA hard disk drives
The SATA version of this server supports hard disk drives with SATA / BC-SATA
storage interfaces. Please note that the usage and operation conditions differ
depending on the type of hard disk drive used.
Please refer to the following internet address for further information on the
usage and operation conditions of each available type of hard disk drive:
http://jp.fujitsu.com/platform/server/primergy/harddisk/

BX2560 M2 D3320 - BIOS Setup Utility
Content
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 Navigating the BIOS setup utility . . . . . . . . . . . . . . . . 9
2.1 Open the BIOS setup utility . . . . . . . . . . . . . . . . . . . 9
2.2 Open the Boot menu immediately . . . . . . . . . . . . . . . . 9
2.3 Screen design . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.4 Exiting the BIOS setup utility . . . . . . . . . . . . . . . . . 11
3 Main menu . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4 Advanced menu . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1 Onboard Devices Configuration . . . . . . . . . . . . . . . . 17
4.2 PCI Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.3 PCI Subsystem Settings . . . . . . . . . . . . . . . . . . . . 19
4.3.1 PCI Express Settings . . . . . . . . . . . . . . . . . . . . . . 19
4.4 CPU Status . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.5 CPU Configuration . . . . . . . . . . . . . . . . . . . . . . . 23
4.6 Memory Status . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.7 Memory configuration . . . . . . . . . . . . . . . . . . . . . 31
4.8 SATA Configuration . . . . . . . . . . . . . . . . . . . . . . 33
4.9 CSM Configuration . . . . . . . . . . . . . . . . . . . . . . . 35
4.10 Trusted Computing . . . . . . . . . . . . . . . . . . . . . . . 37
4.11 USB Configuration . . . . . . . . . . . . . . . . . . . . . . . 38
4.11.1 USB Port Security . . . . . . . . . . . . . . . . . . . . . . . . 41
4.12 Intel Mezzanine card option ROM configuration . . . . . . . 42
4.13 Super IO Configuration . . . . . . . . . . . . . . . . . . . . 42
4.13.1 Serial Port 1 Configuration . . . . . . . . . . . . . . . . . . . . 42

D3320 - BIOS Setup Utility BX2560 M2
Content
4.14 Network Stack Configuration . . . . . . . . . . . . . . . . . . 43
4.15 Option ROM Configuration . . . . . . . . . . . . . . . . . . . 44
4.16 iSCSI Configuration . . . . . . . . . . . . . . . . . . . . . . . 44
4.17 UEFI Device Driver Setup . . . . . . . . . . . . . . . . . . . . 44
5 Security menu . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5.1 Secure Boot Configuration . . . . . . . . . . . . . . . . . . . 48
5.1.1 Key Management . . . . . . . . . . . . . . . . . . . . . . . . . 49
6 Power menu . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
6.1 Wake-Up Resources . . . . . . . . . . . . . . . . . . . . . . . 54
7 Server Mgmt menu . . . . . . . . . . . . . . . . . . . . . . . 55
7.1 iRMC LAN Parameters Configuration . . . . . . . . . . . . . 60
7.2 Console Redirection . . . . . . . . . . . . . . . . . . . . . . . 64
8 Boot menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
9 Save & Exit menu . . . . . . . . . . . . . . . . . . . . . . . . 69
10 Flash BIOS Update . . . . . . . . . . . . . . . . . . . . . . . 71
10.1 Flash Memory Recovery Mode . . . . . . . . . . . . . . . . . 73
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

BX2560 M2 D3320 - BIOS Setup Utility 7
1 Introduction
BIOS setup utility provides settings for system functions and the hardware
configuration for your system. Any changes you make take effect as soon as
you save the settings and quit BIOS setup utility.
The individual menus in BIOS setup utility provide settings for the following
areas:
●Main – System functions
●Advanced – Advanced system configuration
●Security – Security functions
●Power – Access point to configure several options
●Server Mgmt – Server management
●Boot – Configuration of the start-up sequence
●Save & Exit – Save and quit
The setting options depend on the hardware configuration of your system.
Menus or certain setting options may therefore not be available in your system's
BIOS setup utility, or the menus may be in a different place, depending on the
BIOS revision.

8 D3320 - BIOS Setup Utility BX2560 M2
Introduction
Notational conventions
The meanings of fonts and symbols used in this manual are as follows:
Italics Commands, menu items, path names, and file
names
fixed font System output
semi-bold fixed font Text you have to enter via the keyboard
"Quotation marks" Names of chapters and terms that are being
emphasized
ÊActivities that must be performed in the shown
order
[Abc] Key on the keyboard
IAdditional information, notes and tips
VCAUTION! References, during their neglect your health, the
operability of your system, or the security of your
data is endangered

BX2560 M2 D3320 - BIOS Setup Utility 9
2 Navigating the BIOS setup utility
2.1 Open the BIOS setup utility
ÊStart the system and wait until the screen output appears.
ÊPress the [F2] function key.
ÊIf a password is assigned, enter this password and confirm with the [Enter]
key.
The BIOS setup utility Main menu will be displayed on the screen.
When the Main menu does not appear:
– If the Main menu does not appear by pressing the [F2] function key, press
the [Ctrl] + [Alt] + [Delete] keys at the same time to restart the system, then
start up BIOS setup utility.
2.2 Open the Boot menu immediately
Use this function if you do not want to start your system from the first drive that
is set in the Boot menu under the Boot Option Priorities menu item.
ÊStart the system and wait until the screen output appears.
ÊPress the [F12] function key.
The Boot menu will be displayed as a popup window.
ÊUse the Êor Ëcursor keys to select the drive from which you want to start
the operating system, and confirm your selection by pressing the [Enter] key.
The selection options are the same as in the Boot menu.
IThe selected option applies to the current system start. The next time
you start the system, the settings in the Boot menu will apply again.
ÊTo start the BIOS setup utility, select the Enter Setup parameter and confirm
your selection with the [Enter] key.

10 D3320 - BIOS Setup Utility BX2560 M2
Navigating the BIOS setup utility
2.3 Screen design
Figure 1: Example for a BIOS setup utility screen
The BIOS setup utility screen is divided into the following areas:
1 Menu bar
The menu bar is used to select the different BIOS setup utility menus.
2 Help area
Brief information is displayed in the help area.
3 Operations area
The operations area lists the keys available for use with BIOS setup
utility.
4 Working area
In the working area the parameters of the selected menu are displayed
with their current values. You can modify the parameter values according
to your requirements (if the appropriate fields are not greyed out).
ÊIndicates parameters containing submenus
1
2
4
3

BX2560 M2 D3320 - BIOS Setup Utility 11
Navigating the BIOS setup utility
2.4 Exiting the BIOS setup utility
ÊIn the Save & Exit menu select the required parameter and press the [Enter]
key.

12 D3320 - BIOS Setup Utility BX2560 M2
Navigating the BIOS setup utility

BX2560 M2 D3320 - BIOS Setup Utility 13
3 Main menu
The following parameters can be set in this menu. Some of them are only
available under special preconditions.
Figure 2: Example for the "Main" menu
Open Source Software License Information
This submenu provides licenses information for open source software,
used in this system board.
System Time / System Date
Displays the current date/time set on the system.
The system time has the format HH:MM:SS, and the system date has the
format DOW (day of week)/MM/DD/YYYY.
To change the current time/date settings enter the new time/date in the
System Time/System Date fields respectively. Use the [Tab] key to move the
cursor within the System Time and the System Date fields.

14 D3320 - BIOS Setup Utility BX2560 M2
Main menu
IIf the system time and date are lost after you switch the system off
and back on again, the lithium battery is empty and needs to be
replaced.
Refer to the "FUJITSU Server PRIMERGY BX2560 M2 Server
Blade Upgrade and Maintenance Manual" for information on how
to replace the lithium battery.
Access Level
Displays the current Access Level in BIOS setup utility.
Administrator
In case Administrator password was entered or the system is not
password protected the Access Level is Administrator.
User
If the User Password was set and User password was entered the
user will have User level.
If Administrator and User password are assigned the Access Level
depends on the password used for entering BIOS setup utility.

BX2560 M2 D3320 - BIOS Setup Utility 15
4 Advanced menu
VCAUTION!
Only change the default settings if required for a special purpose.
Incorrect settings in this menu can result in malfunctions on your
computer!
Figure 3: Example for the "Advanced" menu
Onboard Devices Configuration
Calls a submenu used to configure Onboard Devices. Some of them are
only available under special preconditions (see "Onboard Devices
Configuration" on page 17).
PCI Status
Calls a submenu used to watch the status of the PCI Express expansion
cards (see "PCI Status" on page 18).
PCI Subsystem Settings
Calls a submenu used to set up the PCI slots and PCI components on
the system board (see "PCI Subsystem Settings" on page 19).

16 D3320 - BIOS Setup Utility BX2560 M2
Advanced menu
CPU Status
Calls a submenu used to watch the processor status (see "CPU Status"
on page 22).
CPU Configuration
Calls a submenu used to make additional processor settings (see "CPU
Configuration" on page 23).
The adjustment options available in this submenu depend on the
processor being used.
Memory Status
Calls a submenu used to watch the memory modules status (see
"Memory Status" on page 31).
Memory Configuration
Calls a submenu used to setup the memory subsystems (see "Memory
configuration" on page 31).
SATA Configuration
Calls a submenu containing the settings for the corresponding SATA
controller (see "SATA Configuration" on page 33).
CSM Configuration
Opens the submenu for configuring the Compatibility Support Module
(CSM) (see "CSM Configuration" on page 35).
Trusted Computing
Calls a submenu used to make additional system settings (see "Trusted
Computing" on page 37).
USB Configuration
Calls a submenu used to set up the USB components on the system
board (see "USB Configuration" on page 38).
Intel mezzanine card
Calls a submenu used to configure Intel Mezzanine card. Some of them
are only available under special preconditions (see "Intel Mezzanine
card option ROM configuration" on page 42).
Super IO Configuration
Calls a submenu used to configure System Super IO Chip parameters
(see "Super IO Configuration" on page 42).
Network Stack Configuration
Calls a submenu used to set up the UEFI network stack (see "Network
Stack Configuration" on page 43).

BX2560 M2 D3320 - BIOS Setup Utility 17
Advanced menu
Option ROM Configuration
Calls a submenu to enable or disable the legacy Option ROMs of the PCI
Express expansion cards (see "Option ROM Configuration" on page 44).
iSCSI Configuration
Calls a submenu used to configure a UEFI driver for a LAN controller
(see "iSCSI Configuration" on page 44).
4.1 Onboard Devices Configuration
Opens the submenu to configure Onboard Devices. Some of them are only
available under special preconditions.
Onboard CNA
Specifies whether the CNA (converged network adapter) on the system
board is available.
Enabled
CNA on the system board is available.
Disabled
CNA on the system board is not available
Onboard CNA OpROM
CNAs (converged network adapter) may be used as boot devices if a
suitable option ROM was started during BIOS POST. This parameter
specifies whether an option ROM should be started for the CNA.
Enabled
Starts the option ROM for booting the CNA.
Disabled
No option ROM is started.

18 D3320 - BIOS Setup Utility BX2560 M2
Advanced menu
4.2 PCI Status
This submenu displays the current status of the expansion card in the slots.
PCI Slot n
Displays the current status of the expansion card in this slot.
Enabled
No errors were reported for this slot. The expansion card in this
slot can be used without restriction.
Failed
An error was detected for this slot. The expansion card in this slot
may have a problem.
Empty
There is no expansion card in this slot.
IPCI SLOT 1/2 are for Mezzanine Card1.
PCI SLOT 3/4 are for Mezzanine Card2.
PCI SLOT 5 is for an I/O Blade (PCI card in the Storage Blade).
PCI SLOT6 is for a SAS RAID HDD module.
PCI SLOT7 is for PCIe SSD (HDD 0).
PCI SLOT8 is for PCIe SSD (HDD 1).

BX2560 M2 D3320 - BIOS Setup Utility 19
Advanced menu
4.3 PCI Subsystem Settings
The following parameters can be set in this menu. Some of them are only
available under special preconditions.
4.3.1 PCI Express Settings
ASPM Support
Active State Power Management (ASPM) is used to power-manage the
PCI Express links, thus consuming less power. Even if ASPM is
generally enabled by this selection, it will only be enabled for a specific
link if the appropriate PCI Express expansion card or onboard controller
supports it also.
Disabled
ASPM is disabled. Power consumption for PCI Express links is
not reduced. Best compatibility.
L1 only
Low power mode of the PCI Express links is set to L1. Tradeoff
between compatibility and energy saving.
IThe latency for PCI Express devices may increase if ASPM is not
disabled. Several expansion cards do not support this feature
correctly, which may lead to an undefined system behavior.
PCIe Hot Plug
Specifies if the Hot Plug support of the PCIe slot is activated.
Disabled
Hot Plug support of the PCIe slot is disabled.
Enabled
Hot Plug support of the PCIe slot is enabled.
Above 4G Decoding
Specifies if memory resources above the 4 GB address boundary can be
assigned to PCI devices. The selection depends on the operating system
and the populated adapter cards.

20 D3320 - BIOS Setup Utility BX2560 M2
Advanced menu
Disabled
Only memory resources below the 4 GB address boundary will be
assigned to the PCI devices. This selection is mandatory when
using a 32-bit operating system, but is also supported on 64-bit
operating systems.
Enabled
Memory resources above the 4 GB address boundary may be
assigned to PCI devices, which are capable of 64-bit address
decoding. This selection is supported only on 64-bit operating
systems. It may be required if the populated PCI Express devices
(e.g. coprocessors adapter cards) are claiming a huge amount of
memory resources, which no longer fits into the address space
below 4 GB.
IThe PCI address decoding of 32-bit operating systems is limited
by the 4 GB address boundary, even if the available PCI devices
would also support 64-bit address decoding.
DMI Control
Selects the speed of the bus connection between CPU and chipset.
Lower speed means less power consumption but also lower system
performance.
GEN1
The bus connection between CPU and chipset is configured to run
at 2.5GT/s.
GEN2
The bus connection between CPU and chipset is configured to run
at 5.0GT/s.
Memory Hole Size
Selects the memory hole size below the 4 GB address boundary. This
memory hole also includes allocated memory resources, requested by
PCI devices. The DRAM address space that was replaced by the
memory hole is remapped to above the 4 GB address boundary and still
useable.
2GB
The memory hole has a size of 2 GB. The remaining 2 GB address
space below the 4G address boundary is available for DRAM.
