Panamax BATT1500-EXT User manual

MB1500 Instructions
A Fully Programmable, Uninterruptible Power Supply, Voltage Regulator & Power Conditioner
INS00852 REV. C EN - 6/09
BANKS
1 2 3 4
POWER MENU
WIRING
FAULT
MB1500
Features:
• 1500 VA Rated Battery Backup
• True Sine Wave Output
• AVM Automatic Voltage Monitoring
• LiFT Linear Noise Filtration Technology
• Protect or Disconnect Voltage Protection
• Voltage Regulation
• Dual Learning IR Output Controls
• RS-232 with Open Source Protocol
• Fully Programmable
• USB Interface
• 2 Programmable Critical Load Management AC Outlet Banks
• 2 Non Critical Load AC Outlet Banks
• IP Card Module for Remote Control Via Internet (Sold Separately)
• Battery Extension Pack Available To Lengthen Battery Life of Unit (Sold Separately)

Table of Contents
Features Descriptions, Important Safety Instructions, Important Rack Mounting Options...................................................................pg. 1
Front Panel Installation and Battery Replacement ..........................................................................................................................pg. 2
Installation & Specications.........................................................................................................................................................pg. 3
Front and Back Panel Descriptions......................................................................................................................................................pg. 4
Operating Modes.............................................................................................................................................................................pg. 5
Advanced Operation.........................................................................................................................................................................pg. 6
Setup Mode Flowchart........................................................................................... .......................................................................pg. 7
Communications Protocol & Command Set..................................................................................................................pgs. 8, 9 , 10 , 11
FCC Notice , Contacting Customer Service, Warranty Information.................................................................................................pg. 12
In addition to this manual the box should contain the following:
MB1500
1. UPS Unit 2. DB 9 Serial Cable 3. Front Rack Mounting Kit
4. Software CD 5. USB Cord
Before You Begin UNPACKING Inspect the UPS upon receipt.
® 2009 Panamax, Inc., 1690 Corporate Circle, Petaluma, CA 94954 • www.panamax.com • 707-283-5900 • Fax [phone]
Thank you for purchasing a Panamax MB1500 Uninterruptible Power Supply, and congratulations on your choice. The MB1500 Uninterrupt-
ible Power Supply features Panamax’s revolutionary AVM (Automatic Voltage Monitoring) circuit, and our exclusive Linear Filtering Technol-
ogy (LiFT). Together, these technologies comprise precisely what our customers have come to expect from Panamax - uncompromised AC
protection and purification.
Introduction
Rear Rack Mounting Kit Available (sold separately)

(Please read prior to installation)
This manual contains important instructions that should be followed during in-
stallation and maintenance of the MB1500 and batteries.
Please read and follow all instructions carefully during installation and operation
of the unit. Read this manual thoroughly before attempting to unpack, install,
or operate.
CAUTION! The MB1500 must be connected to an AC power outlet with fuse or
circuit breaker protection.
DO NOT plug the machine into an outlet that is not grounded, or; without GFCI
protection if it is plugged into an isolation transformer. If you need to de-ener-
gize this equipment, turn off and unplug the MB1500.
CAUTION! DO NOT USE FOR MEDICAL OR LIFE SUPPORT EQUIPMENT!
Panamax does not sell products for life support or medical applications. DO
NOT use in any circumstance that would affect operation or safety of any life
support equipment, with any medical applications, or patient care.
CAUTION! The battery can energize hazardous live parts inside even when the
AC input power is disconnected.
CAUTION! To prevent the risk of fire or electric shock install in a temperature
and humidity controlled indoor area, free of conductive contaminants. (Please
see specifications for acceptable temperature and humidity range).
CAUTION! To reduce the risk of electric shock, do not remove the cover. No
user serviceable parts inside. (only qualified service professionals should re-
place the battery pack).
CAUTION! To avoid electrical shock, turn off the unit and unplug it from the AC
power source before installing a component.
CAUTION! DO NOT USE WITH OR NEAR AQUARIUMS! To reduce the risk
of fire, do not use with or near aquariums. Condensation from the aquarium
can come in contact with metal current contacts and cause the machine to
short out.
NOTE: AC Power management devices, such as a UPS, have certain limitations
with regard to reactive loads and wattage.The MB1500 has a handling capacity
of 1500VA or approximately 7.5 amps. Excessive power consumption beyond
these specifications can affect battery life and performance.
1
Important Safety Instructions
AVM Automatic Over & Under Voltage Protection
Panamax’s power monitoring circuitry constantly monitors the AC line voltage for
unsafe voltage conditions such as momentary spikes or prolonged over-voltages
and under-voltages (brownouts). These unsafe conditions pose a very danger-
ous threat to all electronic equipment within the home. If the MB1500 senses
an unsafe power condition, it will automatically disconnect your equipment from
the power to protect equipment from damage. When MB1500 disconnects from
the power, the Battery Backup Outlets are switched to battery power.
When subjected to a 6,000V (open circuit voltage) / 3,000A (short circuit cur-
rent) surge, the MB1500 limits its voltage output to less than 330V peak, UL’s
lowest rating.The MB1500 will withstand, without damage, 10,000A surges, far
exceeding the UL requirement of only 3000 Ampere surges.
PROTECT OR DISCONNECT
If the magnitude of the surge is greater than the capacity of the surge protec-
tion components, the MB1500’s Protect or Disconnect Circuitry will disconnect
your equipment in order to protect it. The MB1500 will need to be repaired or
replaced by Panamax if this occurs within the 3 yr. product warranty.
LIFT (LINEAR FILTERING TECHNOLOGY)
Unfortunately, traditional AC power conditioners have been designed for unre-
alistic laboratory conditions. Prior technologies, whether multiple-pole or con-
ventional series-mode filters, could actually harm audio and video performance
more than they help, due to the resonant peaking of their antiquated, non-linear
designs. Under certain conditions, these designs can actually add more than
10 dB of noise to the incoming AC line! Worse still, lost digital data, the need to
reboot digital presets, or destruction of sensitive digital converters are frequently
caused by excessive voltage spikes and AC noise contaminating the equipment
ground. Panamax’s LiFT takes a different approach, ensuring optimal perfor-
mance through linear AC noise filtering with no ground contamination.
Features Descriptions
FRONT PANEL
REMOVE SIDE PANEL PLATES FROM BOTH ENDS,
AND PUSH UP THE TWO LATCH MECHANISMS
AND PULL OUT TO REMOVE FRONT PANEL.
SIDE PANEL PLATE
LATCH MECHANISM
POWER
POWER
POWER
FOR ACCESS TO RELEASE CLIPS USE THE HOLES AS INDICATED BELOW.
TO MOUNT PRODUCT IN A FLUSH POSITION IN RELATIONSHIP
WITH THE RACK, USE THE HOLES AS INDICATED BELOW.
IMPORTANT NOTE! PRODUCT MUST BE REMOVED FROM THE
RACK TO GET ACCESS TO RELEASE CLIPS.
FRONT PANEL
FRONT PANEL
USE ALL FIVE OF THE INCLUDED FLAT HEAD SCREWS
TO SECURELY ATTACH RACK EAR TO SIDE OF PRODUCT.
12
45
3
OPTION 1- FOR FLUSH MOUNT OPTION 2- TO MOUNT FOR EASY FRONT PANEL REMOVAL TO REMOVE FRONT PANEL
SIDE PANEL ACCESSIBILITY
FLUSH FRONT
ATTACHING RACK EARS
BEFORE MOUNTING INTO RACK PLEASE READ - Important Rack Mounting Options

BANKS
1 2 3 4
POWER MENU
WIRING
FAULT
BANKS
1 2 3 4
POWER MENU
WIRING
FAULT
MB1500/F1000-UPS FRONT PANEL INSTALLATION
1.Remove front panel from shipping
inserts (pic, CP to provide)
2.Verify that the battery connectors are
connected, red-to-red, black-to-black.
If not connected, perform steps 2 and 6 in
the BATTERY REPLACEMENT section.
3.(Optional) Install the supplied rubber
end-caps to the sides of the front panel.
Push the curved edge of the end-cap into
the mating slots of the front panel.
4.Carefully align the front
panel connector and latches
with the MB1500.
5.Gradually apply pressure to the
left and right ends of the front panel
until you hear the latches ‘click’.
1.Remove the front panel. Remove the rubber end caps and pull up on the latch mechanism. Once the latch mechanism stops,
gradually pull the front panel off of the MB1500.
2.Remove the screw from the battery connector security plate to release
the battery connector.
3. Disconnect both the red and black connectors. 4.Remove the screws from the battery pack (part number BC-1500) and pull the battery pack out of the unit using the integrated handle.
5.Install the new battery pack into the unit. DO NOT ATTEMPT TO REPLACE THE BATTERIES
IN THE ORIGINAL BATTERY PACK. IMPROPER INSTALLATION CAN RESULT IN FIRE OR
BATTERY LEAKAGE.
6.Reconnect the red and black connectors and reinstall the battery connector security plate.
7.Reinstall the front panel per the Front Panel Installation instructions.
MB1500/F1500-UPS BATTERY REPLACEMENT
The MB1500 is shipped with the front panel unattached to ensure that no damage is caused during shipping. Before the MB1500 can be used, the front panel must be installed.
2
A. CAUTION: RISK OF EXPLOSION IF BATTERY
IS REPLACED BY AN INCORRECT TYPE.”
B. CAUTION: When replacing batteries,
replace with the same type of the original
batteries
C. CAUTION: Before replacing batteries,
remove conductive jewelry such as chains,
wrist watches, and rings. High energy through
conductive materials could cause severe
burns;
D. CAUTION: Do not dispose of batteries in a
fire. The batteries may explode.
E. CAUTION: Do not open or mutilate batter-
ies. Released material is harmful to the skin
and eyes. It may be toxic.

3
Your new MB1500 may be used immediately upon receipt.
However, recharging the battery for at least six to eight hours
is recommended to insure that the battery’s maximum charge
capacity is achieved. Charge loss may occur during shipping and
storage. To recharge the battery, simply leave the unit plugged
into an AC outlet. The unit will charge in both the ON as well as
the OFF position. If you wish to use the software, connect the
enclosed USB cable to the USB port on the MB1500 and an open
USB port on the computer or server.
DO NOT plug a space heater, vacuum cleaner, paper shredder
or other large electrical device into the MB1500. The power de-
mands of these devices will overload and possibly damage the
unit.
Plug the MB1500 into a 2 pole, 3 wire grounded receptacle.
Make sure the wall branch outlet is protected by a fuse or cir-
cuit breaker and does not service equipment with large electrical
demands (e. g. refrigerator, copier, etc.) Avoid using extension
cords. If used, the extension cord must be UL or CSA Listed,
minimum 14 AWG, 3-wire grounded, and rated for 15 Amps.
Press the power switch on the front panel to turn the MB1500
on. The display will say “Initializing”, followed by the normal op-
eration screen.
The rear panel circuit breakers will open and power to the
connected equipment will be turned OFF if an overload is
detected. To correct this, turn the MB1500 off, unplug at
least one piece of equipment, wait 10 seconds, check to make
sure that the circuit breakers are reset, and turn the unit on.
Installation
The MB1500 will automatically charge the battery whenever it is
plugged into an AC outlet.
To maintain optimal battery charge, leave the MB1500 plugged
into an AC outlet at all times.
NOTE: To store your MB1500 for an extended period, cover it and
store with the battery fully charged. Recharge the battery every
three months to ensure battery life.
Communication Interface
The RS-232 communication card provided with the MB1500 al-
lows connection and communication between the MB1500 and
an automation, media server, or computer system. This allows
the installer to program a number of variables including the Criti-
cal Load Battery Threshold. See the software documentation for
more information.
An optional TCP/IP card (sold separately) allows for additional
functions, such as remote diagnostics, control of individual outlet
banks, and configuration of email alerts. Contact Panamax for
price and availability.
External Battery Connectors
Panamax’s BAT1500-EXT external battery pack (sold separately)
offers extended battery runtime when used in conjunction with
the Panamax MB1500. Contact Panamax for price and availabil-
ity.
UPS Output
Voltage 120 ± 5 V True Sine Wave
Frequency 60 Hz ± 1%
UPS Output Capacity 1500VA 900W @ 0.6pf
UPS Backup Time. (full load) 12 minutes
UPS Backup Time. (half load) 32 minutes
Transfer Time < 4ms
Specifications
Input
Voltage 90 – 140 Vac
Frequency 57 – 63 Hz
AC Power
Surge Protection: AVM (Automatic Voltage Monitoring)
Current Rating 12 A maximum (7.5 A maximum battery load
recommended)
Overvoltage Shutoff, fast rise: 150 ± 5 V
Overvoltage Shutoff, slow rise: 140 ± 5 V
Undervoltage Shutoff: 90 ± 5 V
Noise Attenuation: 10 dB @ 10kHz,40 dB @ 100 kHz, 50 dB @ 500kHz
Linear Attenuation Curve: From 0.05 - 100 Ohms line impedance
Automatic Voltage Regulation,
Sensitive Mode Capture Range: 98 – 135 V
Automatic Voltage Regulation,
Sensitive Mode Output Range: 120 ± 5%
Automatic Voltage Regulation,
Standard Mode Capture Range: 93 – 140 V
Automatic Voltage Regulation,
Standard Mode Output Range: 120 ± 10%
Temperature Rating-Units are considered acceptable for use in a max ambient 0f 40
° (or “0 - 40 ° C for ambient Operation

4
Front and Back Panel Descriptions
BANKS
1 2 3 4
POWER MENU
WIRING
FAULT
MB1500
BANK 1 CRITICAL
LOAD
USB
IR1
IR OUT IR STATUS
IR2
15A PUSH
TO RESET
MAIN POWER
125 / 12A
COMMUNICATION CARD
EXTERNAL BATTERY
BANK 2 CRITICAL
LOAD
BANK 3 NON
CRITICAL
LOAD
BANK 4 NON
CRITICAL
LOAD
PUSH TO RESET, 15A
PUSH TO RESET, 15A
NON-CRITICAL LOAD
CRITICAL LOAD
Power Switch
Press to turn the
MB1500 ON or OFF.
Menu Navigation Knob
Rotate clockwise to navigate to the
next screen, counter-clockwise to
return to the previous screen, push
to select menu item.
Removable Battery
Access Panel
Easy to remove for
battery access and
replacement.
Status Display
LCD displays status and
menu navigation items.
Outlet Banks 1, 2, 3, and 4 Indicators
Illuminated blue when outlet bank is switched on.
Line Fault Indicator
This LED will illuminate in red to warn the user that a wiring problem such as a bad/missing
ground or reversed wiring exists within the AC receptacle. If illuminated, disconnect all equip-
ment and contact an electrician to insure outlet is properly wired.
Outlet Bank 3 -
Non-Critical-Load Outlets
Two battery powered, AVM
protected outlets for connected
equipment ensures temporary
uninterrupted operation of
connected equipment during
a power failure. These outlets
will shut off when the batteries
drain to a designated level
to reserve remaining battery
charge for the critical load
outlets.
Outlet Bank 4 -
Non-Critical-Load Outlets
Two battery powered, AVM
protected outlets for connected
equipment ensures temporary
uninterrupted operation of
connected equipment during
a power failure. These outlets
will shut off when the batteries
drain to a designated level
to reserve remaining battery
charge for the critical load
outlets.
AC Power Cord
Captive, heavy-
duty shielded
power cord.
IR Control Section
Indicator LED’s – Indicates
status IR Output Jacks
– Standard 1/8” (3.5mm)
mono jack for connection to
an IR flasher (IR flashers not
included)
Circuit Breakers for
Overload Protection
Resettable circuit
breakers provide
optimal overload
protection.
Ground Lug
IR Detector
IR Detector, for
sampling IR remote
control signals.
Outlet Bank 2 - Critical-Load Outlets
Two battery powered, AVM protected
outlets for critical-load equipment en-
sures temporary uninterrupted operation
of connected equipment during a power
failure.
Outlet Bank 1 - Critical-Load Outlets
Two battery powered, AVM protected
outlets for critical-load equipment en-
sures temporary uninterrupted operation
of connected equipment during a power
failure.
RS-232 Serial Communication Port
The serial port allows connection and communica-
tion between the MB1500 and an automation, media
server, or computer system. This allows the installer to
program a number of variables including the Critical
Load Battery Threshold. See the software documenta-
tion for more information.
An optional TCP/IP card (sold separately) allows for ad-
ditional functions, such as remote diagnostics, control
of individual outlet banks, and configuration of email
alerts. Contact Panamax for price and availability.
USB to Computer
USB port allows
communication
between MB1500
and computer.
External Battery
Connectors
Allows for optional
external battery ad-
dition.
Unit Circuit
Breaker

5
Operating Modes
Normal Operation (Utility Power) Mode
When connected to a live power source, the MB1500 provides power
and is ready to provide protection from under- and overvoltages.
Rotate the navigation dial to scroll through the screens.
Automatic Voltage Regulation (AVR) Mode
Sensitive AVR setting: when receiving input voltages of 98 VAC – 140
VAC, the MB1500 supplies a regulated voltage of 120 VAC ± 5%. Stan-
dard AVR setting: when receiving input voltages of 93 VAC – 145 VAC,
the MB1500 supplies a regulated voltage of 120 VAC ± 10%. AVR OFF
setting: AVR is disabled, no voltage correction.
UPS Mode
In the event of a loss of power to the unit, over-voltage, or under-volt-
age, the MB1500 will function as a battery back-up. An audible alarm
will sound and the display will indicate the fault as well as the number
of minutes of battery life remaining.
Setup Mode
The setup menu allows the user to adjust several of the operating pa-
rameters of the unit.
Setup Menu Navigation
Clockwise (CW) rotation of the navigation dial advances the menu to
the next item. If the menu is at the last item, SYSTEM INFO, return
to Normal Operation Mode. Counter clockwise (CCW) rotation of the
navigation dial sends the menu to the previous item. If the menu is at
the first item, DISPLAY BRIGHTNESS, it will return to Normal Operation
Mode. Pressing the navigation dial selects the current menu item. If
there is no activity of the navigation dial for 60 seconds, the menu will
automatically return to Normal Operation Mode.
Parameter Selection and Adjustment
CW rotation of the navigation dial INCREASES the selected parameter,
or advances to the NEXT available value. CCW rotation of the navigation
dial DECREASES the selected parameter, or goes back to the PREVIOUS
value. Pressing the navigation dial selects the current parameter value.
If there is no activity of the navigation dial for 60 seconds, it will return
to Normal Operation Mode. If the BACK parameter is selected, it will
return to the menu item selection.
Display Brightness
Display Brightness adjusts the brightness of the display backlight.
Display Scroll Mode
If enabled, the display will automatically advance to the next screen
after the designated interval {5 SEC, 10 SEC}.
Display Sleep Mode
With Display Sleep Mode enabled, the Display will go to the lowest
brightness setting (25%) after the designated time of inactivity of the
Navigation Dial {30 SEC, 60 SEC}.
The display will return to the set brightness level upon entering Setup
Mode, or UPS Mode.
Automatic Regulation Setup
Setup for Automatic Voltage Regulation parameters: Off, Standard
Mode, Sensitive Mode.
Outlet Bank 3 Setup
Adjusts the battery charge threshold in which Outlet Bank 3 is shut off
to conserve power for the critical loads connected to Outlet Bank 1 &
2. If set to OFF, Outlet Bank 3 will shut off immediately when the unit
goes into UPS Mode.
Outlet Bank 4 Setup
Adjusts the battery charge threshold in which Outlet Bank 4 is shut off
to conserve power for the critical loads connected to Outlet Bank 1 &
2. If set to OFF, Outlet Bank 4 will shut off immediately when the unit
goes into UPS Mode.
External Battery
If using the external battery, BATT1500-EXT, set to YES.
IR1 and IR2 Control Setup
IR1 Control Setup is a two-step process in which the IR remote control
signal is sampled, and tested by outputting the learned signal on the
output jack.
IR Output Delay
IR Output Delay is the time delay before outputting the IR signals on the
IR output jacks after the unit goes into UPS mode.
IR Output Delay time starts at 0 sec, incremented in 5 sec intervals,
with a maximum value of 60 sec.
Setup Buzzer Mode
Change the UPS BUZZER MODE to set it to on or off.
UPS Test Mode
UPS Test Mode places the unit in UPS Mode temporarily to verify that
the UPS inverter can adequately supply the connected load.
System Info
Displays Panamax M1500-UPS, firmware revision, and IP address
(with optional TCP/IP card installed).
120 VOLTS
UTILITY POWER
Normal Operation Screen
SETUP
LOST POWER
EST’D BATTERY: 15 MIN
UPS Mode Screen

6
To program IR output:
1. From the setup menu, turn the Menu Navigation Knob until IR1 Setup
is displayed. Push the Menu Navigation Knob to select.
2. Turn the Menu Navigation Knob until IR1 Program is displayed.
3. The screen will display the message “READY TO SAMPLE REMOTE”.
Press the button on the remote.
4. If the signal was learned, then the screen will display the message
“IR1 SAMPLED” and advance to the “TEST IR” screen. Press the navi-
gation knob to test.
5. If the signal was not learned, the screen will display the message
“IR1 SAMPLE FAIL”, then it will return to the IR1 Program screen. Re-
peat steps 3 and 4.
6. To program another IR device, from the Setup menu, turn the Menu
Navigation Knob until IR2 Setup is displayed. Follow steps 3-5.
RS-232 Communications Protocol & Command Set
The RS-232 serial interface can be used in the following ways:
1. Initial system setup. An installer can use a notebook computer to
set the variables within the Power Control software. Once the setup is
completed, the notebook computer can be disconnected. All settings
are stored in the MB1500.
2. Connection to a PC or Network: Functionality is very similar to a
standard UPS with a PC. The MB1500 can provide continued power to
maintain recording capabilities of any number of devices in the event of
a black out or brown out. It is also capable of saving open documents
and shutting down the PC during extended power failures.This requires
a permanent RS-232 connection to the PC and having the Power Con-
trol software running in the background on the PC. (Windows based OS
only; Mac Energy Saver software compatible)
3. Integration with sophisticated automation systems like AMX® and
Crestron®: The serial communications command set and protocol is
open and is published later in this manual.This information can be used
by the automation system programmer for both MB1500 control by the
automation system and reporting of power events by the MB1500 to
the automation system.
A connection to a UPS can benefit projector bulbs, server based prod-
ucts, and units with volatile electronic memories found in but not limited
to High-End Home Theater equipment. The MB1500 takes this to the
next level with a number of features designed specifically for AC Power
back up applications.
Critical Load Function
One of the user programmable settings in the MB1500 software is the
Low Battery Non-Critical Load (NCL) Shutoff threshold. This sets the
battery capacity level at the point where the NCL outlets are turned off
and all remaining battery power is reserved for equipment plugged into
the 4 critical load outlets. This value is stored internally by the UPS and
is not dependent on having the software running on a computer.
Patent-pending Learning IR Control
The learning IR function lets you program the MB1500 to send standby
or shut-down commands to components such as DLP ceiling projec-
tors. If the power fails, the projector’s lamps are turned off while the
MB1500 continues providing battery power to the projector’s cooling
fan. Proper shutdown is ensured and expensive lamps are protected
from damage.
NOTE: This function should only be used with discrete IR codes.
Programming an On/Off toggle command could result in the
equipment being turned ON during a power failure!
IR Power Failure Operation
The MB1500 can learn two IR commands. The learned commands will
be transmitted on both output jacks so you have the ability to control
2 different pieces of equipment or use a 2-step macro for one com-
ponent.
1. After a power failure and the selected delay, the IR codes will be
sent to both outputs. The IR LED’s will flash once per second during the
delay time and will stop flashing after the IR code is sent.
2. If the delay settings are the same for both IR1 and IR2, the IR2 code
will be sent to both outputs 2 seconds after IR1.
3. The IR commands will also be transmitted immediately after the bat-
tery charge falls below the critical load battery threshold. This ensures
that equipment will be shutdown properly if the MB1500’s load level is
extremely high and the backup time would be less than the selected
IR output delay.
4. There is no IR output after the power is restored to the system.
Avanced Operation

7
SETUP MENU
DISPLAY
BRIGHTNESS
BRIGHTNESS
XXX
DISPLAY
SCROLL MODE
SCROLL MODE
XXX
DISPLAY
SLEEP MODE
SLEEP MODE
XXX
AUTO REGULATION
SETUP
AVR MODE
XXX
NON CRITICAL
BANK 3 SETUP
BANK 3 SHUTOFF
BATTERY XXX
IR1 SETUP
IR OUTPUT DELAY
XXX SEC
BUZZER MODE
XXX
PANAMAX MB1500
FIRMWARE REV A
IR1 TEST IR1 PROGRAM
IR1 SAMPLED
IR2 SETUP
IR OUTPUT DELAY
BUZZER MODE
UPS TEST RUN TEST? XXX
SYSTEM INFO
IR1 SAMPLE FAIL
Pass/
Fail
SEL
SEL
SEL
SEL
SEL
SEL
BACK
BACK
BACK
BACK
SEL
BACK
SEL
SEL
SEL
BACK
SEL
SEL
Fail
Pass
IR2 TEST IR2 PROGRAM
IR2 SAMPLED
IR2 SAMPLE FAIL
Pass/
Fail
SEL
Fail
Pass
NON CRITICAL
BANK 4 SETUP
BANK 4 SHUTOFF
BATTERY XXX
SEL
BACK
EXTERNAL BATTERY SETUP USE EXTERNAL BATTERY
YES / NO
SEL
BACK
Setup Mode Flowchart

8
Communications Protocol
Connector Pin-out:
Pin 2, Transmit. The MB1500 transmits data on this pin.
Pin 3, Receive. The MB1500 receives data on this pin.
Pin 5, SG (signal ground).
Baud Rate: 9600 bps
Start Bits: 1
Data Bits: 8
Stop Bits: 1
Parity: None
Flow Control: None
Controller Commands
Commands and responses are in the form of ASCII character strings terminated
with a carriage return (<CR>,OCh, 13d). If the state variable LINEFEED MODE =
ON, a linefeed character (<LF>, 0Ah, 10d) will follow the carriage return.
Incoming messages (to the MB1500) shall be terminated with one of the follow-
ing characters: NUL (00h, 00d), carriage return, or line feed.
The MB1500 shall discard the incoming message under the following condi-
tions:The message overruns the receiver buffer (32 characters). No terminating
character (NUL, <CR>, <LF>) is received within 500ms of receipt of the last
character. The following are commands sent by the controlling equipment to
the MB1500.
NOTE: Responses are only transmitted automatically if unsolicited feedback is
enabled (!SET_FEEDBACK)
ALL ON
Turns on all outlets. Turn on is immediate with no delay.
Send to UPS: !ALL_ON<CR>
If power is not switched off due to low battery conditions:
Action: Turn on Outlet Bank 1 & 2
Response from UPS: $BANK 1 = ON<CR>
$BANK 2 = ON<CR>
If UPS battery level > Shutoff Threshold
Action: Turn on Outlet Bank 3 & 4
Response from UPS: $BANK 3 = ON<CR>
$BANK 4 = ON<CR>
If UPS battery level < Shutoff Threshold
Action: Turn off Outlet Bank 3 & 4
Response from UPS: $BANK 3 = OFF<CR>
$BANK 4 = OFF<CR>
$BATTERY = charge%<CR>
Action: Activate Power Button
Response from UPS: $BUTTON = ON<CR>
ALL OFF
Turns off all outlets. Turn off is immediate with no delay.
Send to UPS: !ALL_OFF,
Action: All outlets will turn off
$BANK 1 = OFF<CR>
$BANK 2 = OFF<CR>
$BANK 3 = OFF<CR>
$BANK 4 = OFF<CR>
Response from UPS: $BUTTON = OFF<CR>
SWITCH OUTLET BANK
Turns a specific outlet bank on or off. Switching is immediate with no delay.
Send to UPS: !SWITCH bank state<CR>
bank = {1, 2, 3, 4,} state = {ON, OFF}
Example: !SWITCH 2 ON<CR> (turns on outlet bank 2)
If power to bank 1 or 2 is switched:
Action: Switch power to Outlet Bank 1 or 2
Response from UPS: $BANK 1 = state<CR>
or $BANK 2 = state<CR>
If power to bank 3 or 4 is switched AND battery level > Shutoff Threshold:
Action: Switch power to Outlet Bank 3 or 4
Response from UPS: $BANK 3 = state<CR>
$BANK 4 = state<CR>
Pin 2 -Transmit
Pin 3 - Receive Pin 3 - Receive
Pin 2 -Transmit
1
6
2
7
3
8
4
9
5
1
6
2
7
3
8
4
9
5Pin 5 - Signal Ground
RS232 Pin-out

9
If UPS battery level > Shutoff Threshold
Action: Turn on Outlet Bank 3 or 4
Response from UPS: $BANK 3 = ON<CR>
$BANK 4 = ON<CR>
If UPS battery level < Shutoff Threshold
Action: Turn off Outlet Bank 3 or 4
Response from UPS: $BANK 3 = OFF<CR>
$BANK 4 = ON<CR>
$BATTERY = charge%<CR>
If power button is OFF and state is changed to ON
Action: Activate Power Button
Response from UPS: $BUTTON = ON<CR>
If entered bank or state are invalid
Response from UPS: $INVALID_PARAMETER<CR>
SET BANK 3 & 4 THRESHOLD
Sets the battery level threshold in which Outlet bank 3 or 4 shuts off.
Send to UPS: !SET_BATTHRESH bank level<CR>
level is a number between 20 and 100 represents the battery charge level where
Outlet Banks 3 and 4 are shut off to the reserve remaining battery charge for the
equipment connected to Outlet Bank 1. level shall be rounded up to the nearest
interval of 10.
bank is the outlet bank number (3 or 4) to set.
If level is >19 AND level <101
Action: SHUTOFF THRESHOLD will be set to a value between 20 and 100.
Response from UPS: $BTHRESH = level<CR>
If specified level is invalid
Action: No action will be taken
Response from UPS: $INVALID_PARAMETER<CR>
SET BUZZER MODE
With Buzzer Mode ON, the buzzer will sound during UPS Mode.
Send to UPS: !SET_BUZZER mode<CR>
mode = {ON, OFF}
If specified mode is invalid
Action: No action will be taken, UPS will request a valid mode setting
Response from UPS: $INVALID_PARAMETER<CR>
$BUZZER = mode<CR>
SET AVR MODE
Sets AVR (Automatic Voltage Regulation) MODE.
Send to UPS: !SET_AVR mode<CR>
mode = {OFF, STANDARD, SENSITIVE}
If specified mode is invalid
Action: No action will be taken, UPS will request a valid mode setting
Response from UPS: $INVALID_PARAMETER<CR>
$AVR = mode<CR>
SET FEEDBACK MODE
Sets the feedback mode to ON (unsolicited) or OFF (polled). When ON, a mes-
sage will be sent to the controller every time the status of an input (i.e. button),
output (i.e. outlet) or power state (i.e. overvoltage) changes. If feedback is OFF,
the controller must request status with a query (see Queries section for more
details).
Send to UPS: !SET_FEEDBACK mode<CR>
mode = {ON, OFF}
If specified mode is invalid
Action: No action will be taken, UPS will request a valid mode setting
Response from UPS: $INVALID_PARAMETER<CR>
$FEEDBACK = mode<CR>
SET LINEFEED MODE
With LINEFEED MODE set, a linefeed character (<LF>, 10d, 0Ah) is appended
to each response.
Send to UPS: !SET_LINEFEED mode<CR> mode = {ON, OFF}
If specified mode is invalid
Action: No action will be taken, UPS will request a valid mode setting
Response from UPS: $INVALID_PARAMETER<CR>
$LINEFEED = mode<CR>

10
SET METER BRIGHTNESS
Sets the LCD display and outlet bank indicator brightness.
Send to UPS: !SET_BRIGHT xxx<CR>
xxx = {100, 075, 050, 025}
If specified brightness setting is invalid
Action: No action will be taken, UPS will request a valid brightness setting
Response from UPS: $INVALID_PARAMETER<CR>
$BRIGHTNESS = xxx<CR>
SET DISPLAY SCROLL MODE
Sets the LCD display SCROLL mode
Send to UPS: !SET_SCROLLMODE xxx<CR>
xxx = {5SEC, 10SEC, OFF}
If specified display scroll mode is invalid
Action: No action will be taken, UPS will request a valid mode setting
Response from UPS: $INVALID_PARAMETER<CR>
$SCROLL_MODE = xxx<CR>
SET DISPLAY SLEEP MODE
Set the LCD display SLEEP mode
Send to UPS: !SET_SLEEPMODE xxx<CR>
xxx = {30SEC, 60SEC, OFF}
If specified display sleep mode is invalid
Action: No action will be taken, UPS will request a valid mode setting
Response from UPS: $INVALID_PARAMETER<CR>
$SLEEP_MODE = xxx<CR>
RESET FACTORY SETTINGS
Resets all of the custom configuration settings
Send to UPS: !RESET_ALL<CR>
Action: Sets all state variables to the default values
Response from UPS: $FACTORY SETTINGS RESTORED<CR>
SEND QUERIES IDENTIFY
Request that the unit identify itself.
Send Query to UPS: ?ID<CR>
Action: Model number and firmware revision will be provided.
Response: $PANAMAX<CR>
$MB1500<CR>
$FIRMWARE revision<CR>
OUTLET STATUS
Requests the on/off status of the outlet banks
Send Query to UPS: ?OUTLETSTAT<CR>
status = {ON, OFF}
Action: On/off status for outlets will be provided.
Response: $BANK1 = status<CR>
$BANK2 = status<CR>
$BANK3 = status<CR>
$BANK4 = status<CR>
POWER STATUS
Requests the status of the input voltage. The responses are the same as
Power Fault Status Change.
Send Query to UPS: ?POWERSTAT<CR>
Action: Power status messages will be returned
Response:
Normal operation = $PWR = NORMAL<CR>
Overvoltage $PWR = OVERVOLTAGE<CR>
Undervoltage $PWR = UNDERVOLTAGE<CR>
Lost Power $PWR = LOST POWER<CR>
Test Mode $PWR = TEST<CR>
POWER
Requests the input and output voltages
Send Query to UPS: ?POWER<CR>
Action: Voltage status messages will be displayed
Response: $VOLTS_IN = vvv<CR>
$VOLTS_OUT = vvv<CR>
$WATTS = xxxx<CR>
$VA = xxxx<CR>
xxx is expressed in decimal format. If the value is less than 100, the hundreds
digit is represented with a 0. For example a line voltage of 92VAC would be
expressed as: $VOLTAGE = 092<CR>

11
LOAD LEVEL STATUS
Requests the load level, expressed as percentage of maximum.
Send Query to UPS: ?LOADSTAT<CR>
Action: Load level will be displayed
Response: $LOAD = xxx<CR>
xxx is the load level (percentage of maximum load) expressed in decimal
format. If the value is less than 100, the hundreds digit is
represented with a 0.
BATTERY LEVEL STATUS
Requests the battery level, expressed as a percentage of maximum (full
charge).
Send Query to UPS: ?BATTERYSTAT<CR>
Action: Load level will be displayed
Response: $BATTERY = xxx<CR>
xxx is the battery charge level (percentage of maximum charge) expressed in
decimal format. If the value is less than 100, the hundreds digit is represented
with a 0.
LIST CONFIGURATION
Requests a list of all configurable parameters and current settings.
Send Query to UPS: ?LIST_CONFIG<CR>
Action: List of configurable parameters and current settings will be displayed.
Response: $BTHRESH = level<CR>
$BUZZER = mode<CR>
$AVR = mode<CR>
$FEEDBACK = mode<CR>
$LINEFEED = mode<CR>
$BRIGHTNESS = xxx<CR>
$SCROLL_MODE = xxx<CR>
$SLEEP_MODE = xxx<CR>
VOLTAGE
Requests the input voltage level.
Send Query to UPS: ? VOLTAGE <CR>
Response: $ VOLTS-IN = v v v <CR>
v v v is the input voltage.
CURRENT
Requests the output current.
Send Query to UPS: ? CURRENT <CR>
Action: send Query to UPS: ? CURRENT <CR>
Response: $ CURRENT = c c c <CR>
c c c is the output current in amps.
LIST OF ALL COMMANDS AND QUERIES
Send Query to UPS: ?HELP<CR>
Action: List of all commands and queries will be displayed
Response:
!ALL_ON<CR>
!ALL_OFF<CR>
!SWITCH<CR>
!SET_BATTHRESH<CR>
!SET_BUZZER<CR>
!SET_AVR<CR>
!SET_FEEDBACK<CR>
!SET_LINEFEED<CR>
!RESET_ALL<CR>
!SET_BRIGHT<CR>
RESPONSES & MESSAGES OUTLET STATUS CHANGE CONDITION
RESPONSE
Outlet Bank 1 changes state $BANK1 = status<CR>
Outlet Bank 2 changes state $BANK2 = status<CR>
Outlet Bank 3 changes state $BANK3 = status<CR>
Outlet Bank 4 changes state $BANK4 = status<CR>
status = {ON, OFF}
POWER BUTTON STATUS CHANGE CONDITION RESPONSE
Power Button changes ON/OFF status $BUTTON = status<CR>
status = {ON, OFF}
POWER FAULT STATUS CHANGE CONDITION RESPONSE
Overvoltage State $PWR = OVERVOLTAGE<CR>
Undervoltage State $PWR = UNDERVOLTAGE<CR>
Lost Power State $PWR = LOST POWER<CR>
Test Mode $PWR = TEST<CR>
Recovery Mode $PWR = RECOVERY<CR>
Normal Operation Mode $PWR = NORMAL<CR>
Low Battery $LOWBAT<CR>
AVR Stage $AVRSTATE = state<CR>
state = {BOOST, BUCK}
Remaining Backup Time $TIME = xxx<CR>
xxx = backup time
Battery State $BATTSTATE = xxx<CR>
xxx = {CHARGE, DISCHARGE, FULL}
Power Control Software
Complete Instructions are available by clicking on Help on the Power
Control Software welcome screen
!SET_SCROLLMODE<CR>
!SET_SLEEPMODE<CR>
?ID<CR>
?OUTLETSTAT<CR>
?POWERSTAT<CR>
?VOLTAGE<CR>
?LOADSTAT<CR>
?BATTERYSTAT<CR>
?LIST_CONFIG<CR>
?HELP<CR>

12
Warranty Information
FCC NOTICE
This equipment has been tested and found to comply with the limits for a Class B Digital
Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide rea-
sonable protection against harmful interference in residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communica-
tions. However, there is no guarantee that interference will not occur in a particular instal-
lation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
(1) Reorient or relocate the receiving antenna.
(2) Increase the separation between the equipment and receiver.
(3) Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
(4) Consult the dealer or an experienced radio/TV technician for help. Any special acces-
sories needed for compliance must be specified in the instruction.
CAUTION: A shielded-type power cord is required in order to meet FCC emission limits
and also to prevent interference to the nearby radio and television reception. It is essen-
tial that only the supplied power cord be used. Use only shielded cables to connect I/O
devices to this equipment.
CAUTION: Any changes or modifications not expressly approved by the guarantee of this
device could void the user’s authority to operate the equipment.
Please contact Panamax Customer Service for information regarding
battery replacement.
If you require technical support or equipment service, please contact
the Panamax Service Department at 800-472-5555. You may also
email [email protected].
All equipment being returned for repair must have a Return Authori-
zation (RA) number. To get an RA number, please call the Panamax
Service Department.
Before returning any equipment for repair, please be sure that it is ad-
equately packed and cushioned against damage in shipment, and that
it is insured.We suggest that you save the original packaging and use it
to ship the product for servicing. Also, please enclose a note giving your
name, address, phone number and a description of the problem.
Warning Notice
WARRANTY LIMITATION FOR INTERNET PURCHASERS
Panamax audio video products purchased through the Internet do not carry a valid War-
ranty unless purchased from an Authorized Panamax Internet Dealer! Authorized Pana-
max Audio Video Internet Dealers have sufficient expertise to insure warranty compliant
installations. For a list of Authorized Panamax Audio Video Internet Dealers go to www.
panamax.com.
CAUTION: Audio/Video, computer and/or telephone system installations can be very
complex systems, which consist of many interconnected components. Due to the nature
of electricity and surges, a single protector may not be able to completely protect complex
installations. In those cases, a systematic approach using multiple protectors must be
employed. Systematic protection requires professional design. AC power, satellite cables,
CATV cables, A/V signal line cables or telephone/network lines entering the system must
pass through a Panamax surge protector. For additional information on how to protect
your system, please contact Panamax before connecting your equipment to the surge
protector.
THE LIMITED PRODUCT WARRANTY IS THE ONLY WARRANTY PROVIDED WITH
THIS PANAMAX PRODUCT AND ANY OTHER IMPLIED OR EXPRESSED WARRAN-
TIES ARE NON-EXISTENT.
This warranty may not be modified except in writing, signed by an officer of the Panamax
Corporation.
More detailed information is available at www.panamax.com. If you have any questions
regarding these requirements, please contact Customer Relations.
® 2009 Panamax, Inc., 1690 Corporate Circle, Petaluma, CA 94954 • www.panamax.com • 707-283-5900 • Fax [phone]
Contacting Customer Service
LIMITED PRODUCT WARRANTY
Panamax warrants to the purchaser of this Panamax audio/video component style unin-
terruptible power supply, for a period of three (3) years from the date of purchase, that
the unit shall be free of defects in design, material, or workmanship, and Panamax will
repair or replace any defective unit.
You must notify Panamax within ten days of any event precipitating request for product
replacement. A return authorization (RA) number must first be obtained from the Pana-
max Customer Relations Department at www.panamax.com before returning the protec-
tor to Panamax. Once you obtain an RA number, please mark the number on the bottom
of the unit and pack it in a shipping carton/box with enough packing material to protect it
during transit. The RA number must also be clearly marked on the outside of the carton.
Ship the unit to Panamax. Please note that you are responsible for any and all charges
related to shipping the unit to Panamax. Original purchase receipts must accompany
any product return.
Upgrade Policy
Valid only in the United states and Canada
If your Panamax UPS sacrifices itself while protecting your connected equipment, you
have an option to upgrade to the latest technology.
Please go to our web sites www.panamax.com or contact Customer Relations at 800-
472-5555 for details.
2 Year Battery Warranty
Panamax warrants to the purchaser of this uninterruptible power supply for a period of
two (2) years from the date of purchase, that the batteries shall be free of defects in
design, material or workmanship, and Panamax will replace any defective battery.

® 2009 Panamax, Inc., 1690 Corporate Circle, Petaluma, CA 94954 • www.panamax.com • 707-283-5900 • Fax [phone]
INS00852 REV. C ENGLISH

MB1500 Instructions
A entièrement programmables, Uninterruptible Power Supply, Voltage Regulator & Power Conditioner
INS00852 REV C FRENCH 6/09
BANKS
1 2 3 4
POWER MENU
WIRING
FAULT
MB1500
FONCTIONNALITÉS
• 1500 VA Rated Battery Backup
• True Sine Wave Output
• AVM (Automatic Voltage Monitoring – Surveillance automatique de la tension)
• Filtrage du bruit LiFT (Linear Filtering Technology - Technologie de ltrage linéaire)
• Protection contre les surtensions Protect or Disconnect (protection ou déconnexion)
• Sortie à onde sinusoïdale réelle
• Double fonction d’apprentissage de commandes infrarouges
• Port RS-232 à code source libre entièrement programmable
• Interface USB
• (4) groupes de prises c.a. pour la gestion de la charge critique (CL) programmables
• Module d’adressage IP à monter sur le panneau arrière en option pour le contrôle distant via Internet
• Kit d’extension de batterie disponible en option pour les applications haute tension

Table des matières
Description Caracteristiques, Mesures de Securite Imporrtantes.......................................................................................................pg. 1
Installation du panneau avant, Remplacement de la batterie...........................................................................................................pg. 2
Installiation, Spécications..........................................................................................................................................................pg. 3
Description du panneau..............................................................................................................................................................pg. 4
Modes de Fonctionnement.........................................................................................................................................................pg. 5
Maneuvres Complexes.................................................................................................................................................................pg. 6
Mode d’installation Flowchart..........................................................................................................................................................pg. 7
Protocole de communication........................................................................................................................................pgs. 8 , 9 , 10 , 11
Avis FCC, Entretien, Garantie Information.....................................................................................................................................pg. 12
MB1500
1. l’appareil MB1500 2. un câble série DB 9 3. un kit de montage en baie
4. un CD comportant le logiciel de
gestion de l’alimentation 5. un câble USB
INFORMATIONS DE SÉCURITÉ
® 2009 Panamax, Inc., 1690 Corporate Circle, Petaluma, CA 94954 • www.panamax.com • 707-283-5900 • Fax [phone]
Nous vous remercions d’avoir acheté un onduleur MB1500 Panamax. L’onduleur MB1500 est doté des technologies révolutionnaires de
Panamax que sont le circuit AVM (Automatic Voltage Monitoring – Surveillance automatique de la tension), ainsi que notre technologie ex-
clusive LiFT (Linear Filtering Technology – Technologie de filtrage linéaire). Ensemble, ces technologies offrent exactement ce que nos clients
attendent de Panamax : une purification et une protection du courant alternatif sans compromis.
INTRODUCTION
Rear Rack Mounting Kit Available (sold separately)
Avant de déballer votre appareil, inspectez le MB1500 dès sa réception. Outre ce manuel, l’emballage doit contenir les élé-
ments suivants :

(à lire absolument avant l’installation)
Ce manuel contient des instructions importantes qu’il convient de suivre lors des opéra-
tions d’installation et de maintenance du système MB1500 et de la batterie.
Veuillez prendre soin de lire ces instructions et de les suivre scrupuleusement lors de
l’installation et de l’utilisation de l’appareil. Lisez ce manuel dans son entier avant de
procéder au déballage, à l’installation ou à la mise en route de votre onduleur.
ATTENTION ! Le MB1500 doit être branché sur une prise de courant alternatif protégée
par un fusible ou un disjoncteur.
Ne branchez JAMAIS cet appareil sur une prise qui n’est pas reliée à la terre ou sans
la protection d’un disjoncteur différentiel en cas d’isolation par transformateur. Si vous
souhaitez mettre l’appareil hors tension, éteignez-le avant de le débrancher.
ATTENTION ! CET APPAREIL NE DOIT PAS ÊTRE UTILISÉ AVEC DES ÉQUIPEMENTS
MÉDICAUX OU DE MAINTIEN DE LA VIE. Les dispositifs fournis par Panamax ne sont
pas destinés à des applications médicales ou de maintien de la vie. N’utilisez JAMAIS
cet appareil dans des circonstances où le fonctionnement ou la sécurité d’équipements
de maintien de la vie, d’applications médicales ou de soin des patients pourrait être
affecté.
ATTENTION ! Même lorsque le cordon d’alimentation est débranché, les parties internes
peuvent recevoir suffisamment de courant de la batterie pour être dangereuses.
ATTENTION ! Pour éviter les risques d’incendie ou de choc électrique, l’appareil doit
être installé dans un local libre de contaminants conducteurs et dont la température
et l’humidité sont contrôlées (reportez-vous aux spécifications techniques pour prendre
connaissance des plages de température et d’humidité acceptables).
ATTENTION ! Pour réduire les risques de choc électrique, ne soulevez pas le couvercle.
Il n’y a aucune pièce remplaçable par l’utilisateur à l’intérieur. (le remplacement de la
batterie doit être effectué par un professionnel de l’entretien qualifié uniquement.)
ATTENTION ! Pour éviter les risques de choc électrique, éteignez l’appareil et débran-
chez l’alimentation avant d’installer un composant quelconque
ATTENTION ! CET APPAREIL NE DOIT PAS ÊTRE UTILISÉ AVEC, NI À PROXIMITÉ
D’UN AQUARIUM ! Pour éviter les risques d’incendie, n’utilisez pas cet appareil avec,
ni à proximité d’un aquarium. Si elle atteignait les contacts en métal, la condensation
provenant de l’aquarium pourrait provoquer un court-circuit.
REMARQUE : Comme tous les dispositifs de gestion du courant alternatif, les onduleurs
sont limités à certaines valeurs en termes de charges réactives et de puissance. Le
MB1500 a une capacité maximale de 1 500 VA, soit environ 7,5 A. Si la consommation
d’énergie dépasse cette capacité de façon excessive, la durée de vie de la batterie et les
performances de l’appareil en seront affectées.
1
MESURES DE SÉCURITÉ IMPORTANTES
AVM (Automatic Voltage Monitoring – Surveillance automatique de la tension)
Les circuits de contrôle de Panamax contrôlent en permanence l’alimentation c.a. pour
repérer les fluctuations de tension dangereuses comme, par exemple, les pointes tem-
poraires ou les périodes prolongées de surtension ou de sous-tension. Ces conditions
dangereuses risquent d’endommager tous les équipements électroniques dans votre do-
micile. Si le MB1500 détecte un danger dans l’alimentation, il coupe automatiquement
l’alimentation de vos appareils pour les protéger contre les dommages. Quand le MB1500
coupe l’alimentation, les prises de secours passent à l’alimentation par batterie
S’il est soumis à une surtension de 6 000 V (tension en circuit ouvert) / 3 000 A (courant
de court circuit), le MB1500 limite la tension de sortie de crête à moins de 330 V la valeur
la plus faible accordée par les laboratoires américains instigateurs des normes UL. Le
MB1500 peut supporter sans subir de dommages jusqu’à 10 000 A en surtension, ce qui
excède de loin la norme des laboratoires UL qui spécifient une résistance à une surtension
de seulement 3 000 ampères.
PROTECTION OU DÉCONNEXION
Si la surtension dépasse la capacité de protection du MB1500, les circuits Protect or
Disconnect (protection ou déconnexion) déconnecteront l’équipement pour le protéger. Si
cela arrive pendant les 3 ans de garantie du produit, il faudra faire réparer ou remplacer
le MB1500 par Panamax.
LIFT (LINEAR FILTERING TECHNOLOGY – TECHNOLOGIE DE FILTRAGE LINÉAIRE)
Malheureusement, les conditionneurs de puissance c.a. classiques sont conçus pour
fonctionner dans des conditions de laboratoires irréalistes. Les technologies précédentes,
qu’il s’agisse de filtres à plusieurs pôles ou de filtres en mode série conventionnels, pou-
vaient en fait endommager les performances audio et vidéo, à cause des crêtes oscillan-
tes dues à leurs designs non linéaires obsolètes. Dans certaines conditions, ces designs
peuvent ajouter plus de 10 dB de bruit à la ligne d’entrée c.a. ! Pire encore, les surtensions
excessives et le bruit c.a. peuvent contaminer la masse de l’équipement, provoquant
fréquemment des pertes de données numériques, le besoin de réinitialiser les réglages
numériques pré-programmés, voire la destruction des convertisseurs numériques sen-
sibles. La technologie LiFT de Panamax adopte une approche différente, garantissant
des performances optimales grâce au filtrage linéaire du bruit c.a. sans contamination
de la masse.
Description Caractéristiques
FRONT PANEL
REMOVE SIDE PANEL PLATES FROM BOTH ENDS,
AND PUSH UP THE TWO LATCH MECHANISMS
AND PULL OUT TO REMOVE FRONT PANEL.
SIDE PANEL PLATE
LATCH MECHANISM
POWER
POWER
POWER
FOR ACCESS TO RELEASE CLIPS USE THE HOLES AS INDICATED BELOW.
TO MOUNT PRODUCT IN A FLUSH POSITION IN RELATIONSHIP
WITH THE RACK, USE THE HOLES AS INDICATED BELOW.
IMPORTANT NOTE! PRODUCT MUST BE REMOVED FROM THE
RACK TO GET ACCESS TO RELEASE CLIPS.
FRONT PANEL
FRONT PANEL
USE ALL FIVE OF THE INCLUDED FLAT HEAD SCREWS
TO SECURELY ATTACH RACK EAR TO SIDE OF PRODUCT.
12
45
3
OPTION 1- FOR FLUSH MOUNT OPTION 2- TO MOUNT FOR EASY FRONT PANEL REMOVAL TO REMOVE FRONT PANEL
SIDE PANEL ACCESSIBILITY
FLUSH FRONT
ATTACHING RACK EARS
Un kit de montage en baie

BANKS
1 2 3 4
POWER MENU
WIRING
FAULT
BANKS
1 2 3 4
POWER MENU
WIRING
FAULT
INSTALLATION DU PANNEAU AVANT MB1500/F1500-UPS
1.Retirer le panneau avant des
emballages.
2.Vérifier que les raccords de la batterie sont
connectés, rouge au rouge, noir au noir. S’ils ne
sont pas connectés, réaliser les étapes 2 à 6 de
la section REMPLACEMENT DE LA BATTERIE.
3.(Facultatif) Installer les capuchons
en caoutchouc sur les côtés du panneau
avant. Pousser le bord arrondi du
capuchon dans les fentes d’appui du
panneau avant.
4.Aligner avec précaution le
connecteur du panneau avant et les
attaches avec le MBS1500/F1500-
UPS.
5.Appliquer progressivement une
pression sur les extrémités gauche et
droite du panneau avant jusqu’à ce
que vous écoutiez les attaches
émettre un « clic ».’
1.Retirer le panneau avant. Retirer les capuchons en caoutchouc et tirer sur le mécanisme de verrouillage. Une fois que le
mécanisme de verrouillage s’arrête, retirer progressivement le panneau avant du MB1500/F1500-UPS.
2.Retirer la vis de la plaque de serrage du connecteur de la batterie pour dégager
le connecteur de la batterie.
3. Déconnecter les deux connecteurs rouge et noir. 4.Retirer les vis du bloc de batteries (numéro de pièce BC-1500) et le tirer hors de l’unité en employant la poignée intégrée.
5.Installer le nouveau bloc de batteries dans l'appareil. NE PAS TENTER DE REMPLACER DES
BATTERIES DANS LE BLOC DE BATTERIES ORIGINAL. UNE MAUVAISE INSTALLATION
PEUT ENTRAÎNER UN INCENDIE OU UNE FUITE DE BATTERIE.
6.Reconnecter les connecteurs rouge et noir et réinstaller la plaque de serrage du connecteur de batterie.
7.Remettre le panneau avant conformément aux instructions d’installation du panneau avant.
REMPLACEMENT DE LA BATTERIE DU MB1500/F1500-UPS
Le MB1500/F1500-UPS est livré avec le panneau avant non fixé pour garantir qu'il n’y ait aucun dommage pendant l’expédition. Avant de pouvoir utiliser le MB1500/F1500-UPS, le panneau avant
doit être installé.
2
A. ATTENTION: Risque d’explosion si la batterie
est remplacée par un type incorrect. “
B. MISE EN GARDE: Lorsque vous remplacez
les piles, les remplacer par le même type de
l’original de piles
C. ATTENTION: Avant de remplacer les piles,
retirez-conducteurs tels que les chaînes de
bijoux, montres-bracelets et des anneaux. De
haute énergie par le biais de matériaux conduc-
teurs peuvent provoquer des brûlures graves;
D. ATTENTION: Ne pas jeter les piles dans un
feu. Les piles mai exploser.
E. ATTENTION: Ne pas ouvrir ni mutiler des
batteries. Paru matériau est nocif pour la peau
et les yeux. Il mai être toxique.

3
Votre nouvel MB1500 est prêt à l’emploi dès sa réception. Toutefois,
il est recommandé de charger la batterie pendant au moins six à huit
heures pour lui assurer une charge maximale. En effet, une perte
d’énergie a pu se produire au cours du stockage ou du transport. Pour
recharger la batterie, il suffit de laisser l’appareil branché sur une prise
de courant alternatif. L’appareil se chargera aussi bien en position de
marche (ON) qu’en position d’arrêt (OFF). Si vous souhaitez utiliser le
logiciel, branchez le câble USB inclus sur le port USB du MB1500 et
connectez-le à un port USB de votre ordinateur ou de votre serveur.
N’y connectez JAMAIS un radiateur électrique, un aspirateur, une
déchiqueteuse de documents, ni aucun autre gros appareil électrique.
Les besoins en électricité de ces appareils pourraient provoquer une
surcharge et l’endommager.
Branchez le MB1500 sur une prise à la terre à deux pôles et trois fils.
Assurez-vous que la prise murale est protégée par un fusible ou un
disjoncteur et ne dessert pas d’autre équipement ayant des besoins
électriques importants (par ex. : réfrigérateur, photocopieur, etc.). Évitez
d’avoir recours à des rallonges. Si vous devez utiliser une rallonge, elle
doit être homologuée UL ou CSA, minimum 14 AWG, à trois fils avec
mise à la terre et d’une capacité nominale de 15 Amp.
Appuyez sur l’interrupteur qui se trouve sur le panneau frontal pour
allumer le MB1500. La mention « Initializing » (Démarrage) s’affiche,
suivie de l’écran de fonctionnement usuel.
Si une surcharge est détectée, les disjoncteurs du panneau arrière
s’ouvriront pour couper l’alimentation des équipements connectés. Pour
remédier à ce problème, éteignez le MB1500, débranchez au moins un
appareil, attendez 10 secondes, vérifiez que les disjoncteurs sont réini-
tialisés et rallumez le MB1500. La batterie se charge automatiquement
dès que l’appareil est branché.
INSTALLATION
Pour assurer le chargement optimal de la batterie, laissez le MB1500
branché en permanence.
REMARQUE : Si vous n’avez pas l’intention d’utiliser votre MB1500
pendant une longue période, couvrez-le et mettez-le de côté avec une
batterie chargée au maximum. Pour conserver la durée de vie de la
batterie, rechargez-la tous les trois mois.
Interface de communication
La carte de communication RS-232 fournie avec le MB1500 permet
la connexion et la communication entre le MB1500 et un serveur
d’automatisation ou un système informatique. Ceci permet à l’utilisateur
de contrôler les blocs de prises et de programmer un certain nombre
de variables, dont le seuil de charge plancher de la batterie. Voir la
documentation du logiciel pour plus d’informations.
Une carte TCP/IP en option (vendue séparément) permet l’accès à
des fonctions supplémentaires, notamment les diagnostics distants, le
contrôle des blocs de prises et la configuration d’alertes par courrier
électronique. Contactez Panamax pour connaître les tarifs et les di-
sponibilités.
Connecteurs de batterie externe
Le kit de batterie externe BAT1500-EXT de Panamax (vendu séparé-
ment) prolonge la durée de vie de la batterie quand il est utilisé avec
le MB1500 Panamax. Contactez Panamax pour connaître les tarifs et
les disponibilités.
ENTRÉE
Tension secteur : 90 – 140 V c.a.
Fréquence : 57 – 63 Hz
ALIMENTATION C. A.
Protection contre les survoltages : AVM (Automatic Voltage Monitor-
ing – Surveillance automatique
de la tension) non sacrificielle
Intensité totale : 12 A maximum (7,5 A maximum
recommandés pour la charge de
a batterie)
Disjoncteur de surtension rapide : 150 ± 5 V
Disjoncteur de surtension lente : 140 ± 5 V
Disjoncteur de sous-tension : 90 ± 5 V
Atténuation du bruit : 10 dB @ 10kHz, 40 dB @ 100
kHz, 50 dB @ 500kHz
Courbe d’atténuation linéaire : Impédance de ligne de 0,05 -
100 Ohms
Régulation automatique de la tension (AVR),
plage de capture du mode sensible : 98 – 135 V
Régulation automatique de la tension (AVR),
plage de sortie du mode sensible : 120 ± 5%
Régulation automatique de la tension (AVR),
plage de capture du mode standard : 93 – 145 V
Régulation automatique de la tension (AVR),
plage de sortie du mode standard : 120 ± 10%
SORTIE ONDULEUR
Tension secteur : Onde sinusoïdale pure 120 ± 5 V
Fréquence : 60 Hz ± 1%
Puissance nette onduleur : 1 500 VA, 900 W @ 0,6 pf
Temps d’autonomie de l’onduleur : 12 minutes à pleine capacité
(900 W)
32 minutes à demi-capacité
(450 W)
Temps de transfert : < 4 ms
SPÉCIFICATIONS
Note-Les unités de température sont considérés comme acceptables pour une utilisation
dans un max 0f ambiante de 40 ° (ou 0 - 40 ° C pour l’air ambiant opération
