Panasonic AWE350P - COLOR CAMERA User manual

AW-E750P
Operating Instructions
Convertible Camera
Model No. AW-E750P/E655P/E650P/E350P
Before operating this product, please read the instructions carefully and save this manual for future use.
Installation instructions provided
VQT0G71-6
FJ1003MSA062 -FJ
Printed in Japan
AW-E655P AW-E650P AW-E350P

- 2 - indicates safety information.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER TO SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the
user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (service) instructions in the
literature accompanying the appliance.
WARNING:
TO REDUCE THE RISK OF FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS EQUIPMENT
TO RAIN OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF FIRE OR SHOCK
HAZARD AND ANNOYING INTERFERENCE, USE THE
RECOMMENDED ACCESSORIES ONLY.
This class A digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe A est conforme à la
norme NMB-003 du Canada.
For CANADA
The serial number of this product may be found on the
bottom of the unit.
FCC Note:
This device complies with Part 15 of the FCC Rules. To
assure continued compliance follow the attached
installation instructions and do not make any
unauthorized modifications.
This equipment has been tested and found to comply with
the limits for a class A digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications. Operation
of this equipment in a residential area is likely to cause
harmful interference in which case the user will be
required to correct the interference at his own expense.

- 3 -
CONTENTS
PREFACE ................................................................................................................................................................................. 4
STANDARD ACCESSORIES ................................................................................................................................................... 5
FEATURES ............................................................................................................................................................................... 6
SPECIAL NOTES ON OPERATION ......................................................................................................................................... 7
PRECAUTIONS ........................................................................................................................................................................ 8
PRECAUTIONS FOR INSTALLATION ................................................................................................................................... 10
MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS .............................................................................................. 13
MOUNTING ............................................................................................................................................................................ 18
FLANGE BACK ADJUSTMENT (FOR ZOOM LENS) ............................................................................................................ 25
IRIS GAIN CONTROL IN A LENS .......................................................................................................................................... 27
CONNECTIONS ..................................................................................................................................................................... 28
ADJUSTMENT ....................................................................................................................................................................... 33
USE MODE SETTING ............................................................................................................................................................ 42
MENU ITEM SETTING ........................................................................................................................................................... 44
SETTING AND CHANGING THE OPTIONAL CARDS .......................................................................................................... 68
SETTING TO INITIAL SET ..................................................................................................................................................... 70
APPEARANCE ....................................................................................................................................................................... 74
SPECIFICATIONS .................................................................................................................................................................. 78

- 4 -
• The Panasonic AW-E750, AW-E655, AW-E650 and
AW-E350 are digital signal processing color video
cameras that incorporates three CCDs;
2/3˝ 3CCD (AW-E750)
1/2˝ 3CCD (AW-E655, AW-E650)
1/3˝ 3CCD (AW-E350)
A digital video signal processing system is packed in a
compact, lightweight body while assuring high picture
quality, high reliability and high performance.
• System setup and adjustments can be easily
performed by following the setup menu.
• Connection to peripheral devices, such as a RCU, a
ROP and a lens and the camera pan/tilt unit enables a
wide variation of system configurations.
PREFACE
• Option cards may also be installed.
KThe following cards are not available for AW-E750,
AW-E655, AW-E650, AW-E350;
· AW-PB301 Component Studio Card:
Use AW-PB305A.
· AW-PB302 RGB Card: The camera unit contains
this function.
· AW-PB303 High-sensitivity Card:
The camera unit contains
this function.
· AW-PB304 SDI Card: Use AW-PB504.
· AW-PB306 Studio SDI Card: Use AW-PB506 or
AW-PB506A.
· AW-PB307 SVGA card
· AW-PB309 WEB card
· AW-PB310 IEEE 1394 Card
Note
In order to protect the environment when the
convertible camera is to be discarded at the end of its
service life, ask a specialized contractor to dispose of
it properly.

- 5 -
Operating Instructions ................................................. 1
Camera mounting adapter ........................................... 1
Mounting screws for adapter (M4) ............................... 2
<AW-E750/AW-E655>
Mounting screw for wire (Inch screw: 1/4-20UNC) ...... 1
Flat washer for wire (Inch screw) ................................. 1
Spring washer for wire (Inch screw) ............................ 1
<AW-E650/AW-E350>
Mounting screw for wire (M4)
(with flat washer and spring washer) ...................... 1
Round Seal .................................................................. 2
STANDARD ACCESSORIES

- 6 -
1. Digital video signal processing for high quality, high
reliability, high performance, lightweight and compact
size.
2. Resolution: 850 lines (HIGH BAND DTL: ON)
S/N ratio:
67 dB (DNR ON) (AW-E750, AW-E655,
AW-E650)
66 dB (DNR ON) (AW-E350)
3. Minimum illumination:
0.00005 lx (AW-E750, AW-E655, AW-E650)
0.00015 lx (AW-E350)
4. The built-in CCD storage function and digital gain up
function provide an even higher degree of high
sensitivity.
5. RGB, Y/Pr/Pb and Y/C signal output circuits
provided.
6. Motorized filters containing IR through and ND filters
(1/16, 1/64) incorporated (model AW-E655 only).
7. Built-in automatic controls, including ATW, ELC, and
AGC.
FEATURES
8. CCD readout is switchable between field and frame
modes. Vertical resolution can be stepped up in
frame mode and it is effective for shooting still
objects.
9. The built-in synchronized scanning system reduces
noise in computer graphics.
10. Various correction circuits permit video reproduction
with high fidelity.
11. Chroma detail correction enables clear shots of dark
color objects.
12. A dark detail circuit provides natural edge correction
to any object in a dark scene.
13. A digital color matrix enables high fidelity color
images.
14. The 12-axis digital color matrix enables users’ to
create images of their choice.
15. Four use modes for each of your specific
applications can be selected.
16. SMPTE color bar is indicated on the monitor screen.
17. Remote control with a RCU, ROP or a multi hybrid
control panel.

- 7 -
• Turn power off before connecting or disconnecting
cables.
• Connection or disconnection of any studio cable,
RCU cable or other cable to any unit of equipment
must be performed while power is off.
• While the camera is in automatic mode;
Shooting of bright objects in ELC operation mode
may result in a smeared picture unique to the CCD.
The ATW function under fluorescent illumination can
adversely change the white balance.
SPECIAL NOTES ON OPERATION
• There is a cooling fan inside.
Do not cover the port or otherwise block ventilation
during operation. Internal heat buildup can cause a
fire.
It is an expendable part, and must be replaced about
every 30 000 hours. (Whenever fan replacement
is necessary, be sure to ask the store where you
purchased the set.) (AW-E750, AW-E655)

- 8 -
DON’TS
• Do not attempt to disassemble the camera, Remote
Control Unit (RCU) or other units. In order to prevent
electric shock, do not remove screws or covers.
There are no user-serviceable parts inside.
• Do not abuse the camera. Avoid striking, shaking,
etc. The camera contains sensitive components
which could be damaged by improper handling or
storage.
• Do not let the lens remain uncapped when the
camera is not in use. If the lens is not installed,
do not leave the lens mount hole uncovered.
• Do not touch the surface of the lens or prism.
• Do not use strong of abrasive detergents when
cleaning the camera body.
• Do not aim the camera toward the sun, no matter
whether it is turned on or not.
• Do not expose the camera, Remote Control Unit
(RCU) or other units to rain or moisture, and do not
try to operate the equipment in wet conditions.
Do not operate the camera or RCU if it becomes wet.
• Do not operate the camera, Remote Control Unit
(RCU) or other units outdoors during a lightning
storm.
• Do not use the camera in an extreme environment
where high temperatures or high humidity exist.
• Do not leave the camera, Remote Control Unit
(RCU) or other units turned on when not in use.
Do not unnecessarily turn the camera power on and
off repeatedly. Do not block the ventilation slots.
• Do not cover the port otherwise block ventilation
during operation. Internal heat buildup can cause a
fire.
PRECAUTIONS

- 9 -
• Take immediate action if ever the camera or RCU
should become wet. Turn the power off and have the
unit checked by an authorized service facility.
• Follow normal safety precautions to avoid personal
injury.
• Use the camera in an environment where the
temperature is within –10 °C to +45 °C (14 °F to
113 °F), and the relative humidity is within 30 % to
90 %.
• Always turn the power off when the camera is not
going to be used. Operate the camera and RCU only
when there is adequate ventilation.
DOS
• Refer any servicing to qualified service personnel.
• Handle the camera with care.
• Protect the precision made lens by placing the lens
cap over when the camera is not in use. If the lens
is not installed, protect the surface of the prism by
placing the body cap into the lens mount hole.
• Use a mild blower or lens cleaning tissue designed
for coated lenses, to clean the surface of the lens or
prism in the event that it should become dirty.
• Use a dry cloth to clean the camera if it is dirty. In
case the dirt is hard to remove, use mild detergent
and wipe gently.
• Use caution when operating the camera in the
vicinity of spot lights or bright lights, as well as light
reflecting objects and surfaces.

- 10 -
PRECAUTIONS FOR INSTALLATION
Attach the drop-prevention wire as a way to prevent
the camera from dropping.
pWhen the unit is to be mounted onto a Panasonic
pan-tilt head, use the mounting screws and drop-
prevention wire that are supplied with the pan-tilt head.
pWhen the unit is to be mounted onto a surface other
than a pan-tilt head, provide your own drop-prevention
wire and camera mounting bracket. For details of the
parts to be provided, refer to page 12.
pAttach the drop-prevention wire to the camera mounting
screw hole (Inch screw).
The camera cannot be installed or used in the
following locations.
pOutdoor locations and locations where the camera may
be exposed to dripping, splashing or sprayed water
pLocations such as swimming pools where chemicals are
used
pLocations such as a kitchen where the high levels of
steam and oily vapors are present and locations with
flammable atmospheres or other unusual conditions
pLocations where radioactive rays, X-rays or strong radio
waves or magnetic fields are generated
pLocations where the temperature may be outside the
camera’s operating ambient temperature (–10 °C to
45 °C [14 °F to 113 °F]) range
pLocations near the air outlet of an air conditioner or near
a door where the camera will be exposed to incoming
outside air or other locations where the temperature is
subject to sudden change (since these locations may
cause the lens area to cloud over and/or condensation
to form)
pLocations that are subject to significant vibration, such
as on top of a car
pLocations with high levels of humidity or dust
When the camera is not going to be used, do not leave
it in place but be absolutely sure to remove it from its
mounting, and put it away.
Do not run the camera cable near the wiring of electric
lights.
This may result in noise interference.
Concerning electromagnetic interference
The camera’s images may become distorted or noise
interference may result if the camera is used near a TV
or radio transmission antenna or in strong electrical or
magnetic fields (such as one generated by motors,
transformers, etc.).
Using outdoors
The camera is designed to be used indoors.
When using outdoors, be absolutely sure to use the
AW-PH650 outdoor pan-tilt head.
The connection and installation should be done by
qualified service personnel or system installers.
Refer any servicing to qualified service personnel.
Concerning the mounting screws and drop-prevention wire

- 11 -
Tightening the mounting screws
Tighten using the torque levels shown in the table below.
After tightening, check for play and unsteadiness.
Screws Clamping torque
Mounting screws (M4) 1.5 N • m (15 kgf • cm)
Mounting screws (Inch screws) 2.0 N • m (20 kgf • cm)
Mounting screw for wire (supplied) (Inch screw: 1/4-20UNC)
Mounting screw for wire
(supplied) (M4)
Drop-prevention wire
Pan-tilt head or
camera mounting bracket
Flat washers
Flat washer (supplied)
Spring washer (supplied)
Spring washers
<AW-E750/AW-E655> <AW-E650/AW-E350>
(AW-E350)
(AW-E650)
Mounting screws
(Inch screws: 1/4-20UNC)

- 12 -
When the unit is to be mounted onto a Panasonic pan-tilt
head, use the mounting screws and drop-prevention wire
that are supplied with the pan-tilt head.
Provide the following parts when the unit is to be mounted
onto a surface other than a pan-tilt head.
Drop-prevention wire* (sold separately): 1
(*Be absolutely sure to use the drop-prevention wire.)
Drop-prevention wires in three different lengths (300 mm,
450 mm and 600 mm) are available as optional
accessories.
Use a wire in the length that will have no slack to suit the
installation location and installation method.
Consult your dealer when you purchase one of these
drop-prevention wires.
Mounting screws (Inch screws: 1/4-20UNC): 2
(For mounting the camera)
Determine the length
of these screws by
factoring in the thickness
of the camera mounting
bracket.
Mounting screws (M6) for installation end wire
At the installation location, be absolutely sure to use
the anchor bolts, and ensure that the strength of the
installation surface is at least ten times the total mass of
all units installed.
Flat washers for use with 1/4˝ screws: 2
(For mounting the camera)
Spring washers for use with 1/4˝ screws: 2
(For mounting the camera)
Camera mounting bracket: 1
Use a bracket made of a material and having a shape
that is strong enough to support the total mass of all units
installed, including the camera and lens.
To determine the position of the holes used for mounting
the camera, refer to <Bottom view> on page 13, and
make holes with a diameter of 7 mm (to support 1/4-
20UNC mounting screws).
Parts to be provided by the customer for installation
Wire length (mm) Parts number
300 3CN001064BAA
450 3CN001064BAB
600 3CN001064BAC
Wire length (300, 450 or 600 mm)
ø4.2
ø6.5
ø1.2
ø6.5
ø4.2
11 mm
(Camera
side)
(Installation
side)
Camera
mounting bracket
7 to 9 mm

- 13 -
MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS
(AW-E655 only)
Supplied part (installed on-site)
<Top View>
<Bottom View>
(AW-E350)
20 mm
(13/16˝)
20 mm
(13/16˝)
20 mm
(13/16˝)
32.5 mm
( 1-9/32˝ )
Mounting screws (Inch screws)
1/4-20UNC, Depth: 10 mm (3/8˝)
<Front View>
<Side View>
17.5 mm
(11/16˝)
10 mm (3/8˝)
Mounting screws
(Inch screws)
1/4-20UNC,
Depth: 10 mm (3/8˝)
Mounting screws (Inch screws)
1/4-20UNC, Depth: 10 mm (3/8˝)
Use the adapter mounting screws
(M4, supplied) for mounting. Use the adapter mounting screws
(M4, supplied) for mounting.
32.5 mm
(
1-9/32˝ )
18 mm
(11/16˝)
32.5 mm
( 1-9/32˝ )
18 mm
(11/16˝)
(AW-E650)(AW-E750/AW-E655)
(AW-E350)(AW-E750/AW-E655/AW-E650)

- 14 -
Lens mount
2/3˝ Standard bayonet type (B4 mount) lens
(AW-E750)
1/2˝ Standard bayonet type (B4 mount) lens
(AW-E655, AW-E650)
1/3˝ C mount lens (AW-E350)
One of the lenses listed above or a microscope
adapter is installed on this mount.
Lens fixing ring knob
(AW-E750/AW-E655/AW-E650 only)
Rotate the lens fixing ring knob counterclockwise
and remove the lens mount cap. Mount the lens
on the camera and rotate the lens fixing ring knob
clockwise in order to fix the lens securely.
Mic jack (AW-E655 only)
This is a ø3.5 mm mic jack which supports PLUG IN
POWER. Use the microphone which has more than
1 kjof impedance, unbalanced.
Mounting hole (AW-E750/AW-E655 only)
To install the camera on a wall or ceiling or to use
a pan/tilt head or tripod, secure the unit using this
screw hole (1/4-20UNC) or using the accessory
mounting adapter.
Furthermore, attach the drop-prevention wire into
these screw holes, using the mounting screws for
wire (Inch screw: 1/4-20UNC).
Cooling fan (AW-E750/AW-E655 only)
The cooling fan can be set to “Auto” or “OFF” on the
menu.
Wire mounting hole (AW-E650/AW-E350 only)
When mounting the camera using the bottom panel,
attach the drop-prevention wire to this hole using the
mounting screw for wire (M4) that is supplied.
Camera mounting adapter
When mounting the camera onto an on-site
mounting bracket, pan-tilt head, or tripod, install this
adapter onto the bottom panel of the camera. This
is a part that is supplied so refer to page 20 for its
installation.

- 15 -
MENU switch (MENU/©)
A menu will appear on the monitor screen when this
switch is pressed for about 5 seconds. This item can
be selected by pressing the switch while the menu is
on the screen.
ITEM/AWC switch (ITEM/AWC/ª)
The item just below can be selected by pressing this
switch while the menu is on the screen. When the
menu is not displayed or the camera is in shooting
mode, the automatic white balance control can be
set with this switch.
YES/ABC switch (YES/ABC/+)
The Sub Menu for each item of the Main Menu is
displayed when this switch is pressed while the Main
Menu is on the screen.
While the Sub Menu is displayed, any setting can be
brought up to a higher value with this switch.
When the menu is not displayed or the camera is in
shooting mode, the automatic black balance control
can be set with this switch.
NO/BAR switch (NO/BAR/–)
The item just below can be selected by pressing this
switch while the Sub Menu is on the screen.
While the Sub Menu is displayed any setting can be
brought down to a lower value with this switch.
When the menu is not displayed or the camera is
in shooting mode, the color bar and the shooting
conditions are indicated by pressing the switch.
Video output connector (VIDEO OUT)
A composite video signal is provided at this
connector.
<Rear View>

- 16 -
Iris connector (IRIS)
Input terminal for lens with an iris control function.
Zoom/Focus connector (ZOOM/FOCUS)
(AW-E655 only)
This connector is for the remote cable of the lens
and is a standard input connector for lenses with
remote functions for zooming and focusing.
When the camera is to be mounted on a Panasonic
pan/tilt head (such as the AW-PH360/AW-PH400/
AW-PH405/AW-PH650), do not use this connector —
connect the remote cable of the lens to the LENS I/F
connector on the pan/tilt head instead.
I/F Remote connector (I/F REMOTE)
Input terminal dedicated to control signals from the
optional Remote Operation Panel (ROP) (such as
the AW-CB400) and the RCU (such as the
AW-RC600) and the camera pan/tilt unit (such as the
AW-PH360/AW-PH400/AW-PH405/AW-PH650).
• AW-CB400 is connected through the optional
connecting cable (AW-CA50T8).
• AW-RC600 is connected through the optional RCU
cable (AW-CA50A26).
• Use the cable supplied with the pan/tilt head to
connect the AW-PH360, AW-PH400, AW-PH405 or
AW-PH650.
Power indicator
Red LED lamp lights to indicate that the specified
DC power is supplied to the camera.
Pin No. Signal Pin No. Signal
1 Return Control 7 Iris Follow
2 Not Used 8
Auto/Remote Control
3 GND 9 Not Used
4 Auto/Manual Control 10 Not Used
5 Iris Control 11 Not Used
6 Lens Power 12 Not Used
Pin No. Signal Pin No. Signal
1
Focus Mode
Position/Speed/
Auto Focus
7Signal Control
(+5.0 V)
2Zoom Mode
Position/Speed 8 Focus Control
3 GND 9 Zoom Control
4Iris
Remote/Camera 10 Iris Mode Position/Speed
5 Iris Control 11 +V (+7.5 V)
6 Lens Power 12 –V (+2.5 V)

- 17 -
DC 12 V input connector (DC 12V IN)
12 V DC is supplied through the DC cable with ø6.5
plug. (Supplied with the recommended AC adapter
AW-PS505A)
G/L Input connector (G/L IN)
Signals synchronized with the reference signal are to
be supplied to this connector when the camera is to
be synchronized with the reference signal BB.
Cable clamp
Clamp the DC cable with ø6.5 plug connected to
the DC 12 V Input connector to prevent it from
slipping out.
Optional card slot
Slot for inserting an optional card. For details, refer to
the manual for optional cards.
1. Connect this to a DC 12 V class 2 power supply
only.
2. To prevent fire or shock, the UL listed wire VW-1,
style 1007 should be used as for the cable for DC
12 V Input Connector.
Cautions

- 18 -
MOUNTING
wLens mounting
AW-E750, AW-E655, AW-E650
(Bayonet mount type of lens)
• Use the lens extension cable AW-CA12T12A (6˝/15 cm)
if your lens cable is too short.
Rotate the lens fixing ring knob counterclockwise and
remove the lens mount cap.
Mount the lens on the camera and rotate the lens
fixing ring knob clockwise in order to fix the lens
securely.
Connect the camera cable to the IRIS connector on
the back panel of the camera.
AW-E350 (C mount type of lens)
• A 1/3-inch C mount type of lens can be used.
Be absolutely sure that a lens whose mount threads
extend no more than 4.3 mm from the lens mount
surface is used. Use of any other kind of lens may
damage the camera unit.
• Some lenses need to be attached in a different way.
Therefore, reference should also be made to the
operating instructions that accompany the lens.
Remove the lens mount cap, align the lens with
the thread ridges on the lens mount and screw it
securely into place.
Connect the lens cable to the IRIS connector.
Less than 4.3 mm Camera Lens
AW-E350 AW-LZ16MD55P
AW-E650 AW-LZ16MD73P
AW-E655
AW-E750 AW-LZ17MD9AG
<Recommended lenses>
Note
pTighten the lens mount lock ring securely to secure
the lens, and check that there is no unsteadiness in
the lens. Also check that there is no unsteadiness
in the hood.
The connection and installation should be done by
qualified service personnel or system installers.
Refer any servicing to qualified service personnel.
Control Cable
Camera Cable
(AW-E750, AW-E650, AW-E350) (model AW-E655
only)
To Iris
Connector
To Lens I/F Connector of
Camera Pan/tilt Unit
Lens fixing
ring knob

- 19 -
AW-E750 or AW-E655 models:
Use the screws provided to attach the accessory
camera mounting adapter to the bottom panel of the
camera.
AW-E650 or AW-E350 models:
Use the screws provided to attach the accessory
camera mounting adapter to the top or bottom panel
of the camera.
wMounting the camera onto a camera mounting base (pan-tilt head or tripod)
Fix the camera mounting base, pan/tilt unit, and
tripod securely in the camera mounting screw hole
(Inch screw: 1/4-20UNC) of the attached camera
mounting adapter.
Camera mounting
adapter
For use in a very bright location, paste
the supplied round seal on the hole
not used by the camera mounting
adapter.
Use a screwdriver or similar to tighten the screws to
secure the camera mounting adapter.
Make sure that the camera mounting adapter is attached
the right way round.
Camera mounting adapter (supplied)
Mounting screws for
adapter (supplied)
Note
pInstall the camera mounting adapter by tightening
it securely with a torque of 1.5 N • m (15 kgf • cm),
and check that there is no unsteadiness.

- 20 -
Use the camera mounting screw holes (Inch screw:
1/4-20UNC) to mount onto a pan-tilt head, tripod,
camera mounting bracket, or other part.
[AW-E750/AW-E655]
Attach the drop-prevention wire using the mounting
screw (Inch screw: 1/4-20UNC) into the camera
mounting screw holes on the camera’s top surface
when mounting the camera with its bottom surface,
or on the camera’s bottom surface when mounting
the camera with its top surface.
[AW-E650/AW-E350]
Attach the drop-prevention wire using the mounting
screw (M4) into the mounting screw hole for camera
mounting adapter on the camera’s top surface when
mounting the camera with its bottom surface, or on
the camera’s bottom surface when mounting the
camera with its top surface.
When the unit is to be mounted onto a Panasonic
pan-tilt head, use the mounting screws and drop-
prevention wire that are supplied with the pan-tilt
head.
When the unit is to be mounted onto a tripod,
camera mounting bracket, or other part, refer
to pages 10 to 12, and provide your own drop-
prevention wire, mounting screws, and washers.
wMounting the camera onto a pan-tilt head, tripod, camera mounting bracket, or other part
Notes
Preventing the camera from falling or coming off
pWhen attaching a camera to the pan/tilt head
(AW-PH360/AW-PH400/AW-PH405/AW-PH650),
follow the directions in the Operating Instructions to
fix the camera firmly in position.
In addition, link the camera to the pan/tilt head
using the drop-prevention wire and the mounting
screws to help ensure the camera does not fall.
pWhen attaching the camera on any mounting or
other pan/tilt head (AW-PH360/AW-PH400/
AW-PH405/AW-PH650), check that the mounting
can safely bear the total mass of the camera,
lens, connection cables, etc., fix the camera firmly
in position using the prescribed tool, and take
appropriate measures to prevent the camera from
falling.
Camera mounting screw holes
(Inch screws: 1/4-20UNC)
Depth: 10 mm (3/8˝)
Camera mounting adapter
