AG-
Mini-DV Camera-Recorder (NTSC)
Mini
Digital
Video
Cassette

The Image Quality, Mobility and Versatility that Professionals Need
The AG-DVX100 shattered conventional notions of what a DV camera-recorder could do, delivering image quality, functions and
operating ease suitable for professional applications. As the first model in its class to offer the 24p/30p Cinema mode,
the AG-DVX100 was particularly well received by filmmakers and image creators. Now, Panasonic introduces the AG-DVX100A.
This advanced new model takes the DV camera a big step forward, retaining the popular features of its predecessor while adding
enhancements that reflect feedback from professionals who used the AG-DVX100.The AG-DVX100A offers higher image quality
and more functions than its predecessor. Even more important, it provides high-level specifications and design improvements that
cater to the needs of professional camera operators. Mobile, versatile and easy to use, the Diamond Graphite AG-DVX100A has
everything you need for creative content production and active image gathering.
Enhanced 24p/30p Progressive Mode Functions
Focus assist, gain up (+12 dB max.), and a SMPTE color bar display have
been added to enhance shooting in 24p/30p Progressive mode.
Improved Color Reproduction
Optimized color separation optics and a new high-performance lens that
uses low-dispersion glass combine to capture vivid, faithful colors.
New Cine-Like Gamma Curves and Enhanced Image
Adjustments
New modes have been added to the gamma curve and matrix settings.
New V DTL Level, Coring, and Knee adjustments have also been added.
Slow Shutter Function for Higher Sensitivity and
Dramatic Effects
The slow shutter (accumulative mode) drops the shutter speed to 1/4 sec,
1/6 sec, etc., for higher sensitivity low light shooting and dramatic, frame-
by-frame like effects.
Smoother Zooming and Focusing
The operating feel of the manual zoom and manual focus ring has been
further enhanced. You feel virtually the same steady resistance as when
using a conventional professional lens. Slow zoom has been extended from
20 seconds to a dramatic 30 second duration.
Focus Assist and New Recording Mode for Improved
Ease and Versatility
The viewfinder features a B/W display mode and detail (PEAKING) function
for easier focusing. Three user-assignable buttons (USER1, USER2, USER3)
give you instant, one-touch access to three setup functions. A new 15-sec
interval recording mode has also been added.
New Squeeze Mode for 16:9 Recording
The AG-DVX100A provides high-quality wide-image recording in letterbox
mode, the new squeeze mode, or with the optional 16:9 conversion lens
(sold separately)
Further Evolution in the DV Camera-Recorder

Shown with optional unidirectional
microphone AG-MC100G.

Ultimate Creativity
Image quality that far exceeds anything in its class, plus an evolved 24p/30p progressive function
Superior Image Rendering with the Leica Dicomar™ Lens, Plus OIS
The Leica Dicomar lens featured in the AG-DVX100A incorporates
Leica optical technology and know-how. Use of low-dispersion glass
reduces color aberration and increases resolution, while a multi-coating
process minimizes flare and ghosts. The results are sharp, crisp,
beautifully rendered images with delicate nuances and exceptional
shading. The lens system features 15 lens elements in 11 groups,
including three aspherical lenses. Panasonic's advanced OIS (Optical
Image Stabilizer) drastically cuts the blurring caused by hand shake.
Optical processing with an automatic correction function helps assure
consistently clear, sharp images.
*Leica and Dicomar are registered trademarks of Leica Microsystems IR GmbH.
410,000-Pixel, 3CCD Image System Provides F11 Sensitivity for
Superior Image Quality
Panasonic designed the AG-DVX100A
to deliver the highest sensitivity and
picture quality in its class. At its heart is
a 3CCD RGB system comprising three
1/3-inch, 410,000-pixel progressive
CCDs developed especially for
broadcast and professional
applications. The new on-chip lens
design achieves high F11 sensitivity, allowing the AG-DVX100A to
record in light as dim as below three lux, for example, in nighttime
news gathering. Picture quality is outstanding, with a high S/N ratio that
means less noise in darker parts of the image and low smear that allows
shooting in sunlight or under bright spotlights.
High-Sensitivity Slow Shutter (in cumulative) Function
The slow shutter function uses image accumulation to enable shutter
speeds with frame rates reduced by half or more. You get the ultra-high
sensitivity needed for nighttime shooting without illumination, as well
as dramatic frame-by-frame or soft focus effects.
High Image Quality with 12-Bit A/D Conversion
The AG-DVX100A features an A/D converter that uses the same 12-bit
processing as broadcast camera-recorders. Precisely digitizing the
gradation and colors captured by the progressive CCD, this A/D
converter supports gamma switching and other fine downstream image
adjustments — one of the keys to achieving rich image expression.
RGB Gamma Processor Provides Rich, Cine-Like Tones
Panasonic has greatly expanded the expressive
capability of the DV camera by creating
unique gamma functions such as Cine-Like
gamma curves, which produce images
strikingly similar in tone to film images. For
each of the RGB signals, the gamma curve
settings are processed immediately upstream
from the digital signal processing circuit. This
helps achieve outstanding image quality.
The AG-DVX100A now introduces three new
gamma curve settings — Cine-Like-D, Cine-
Like-V, and B.Press — giving you a total of seven to work with.
CINE-LIKE Film-like images
CINE-LIKE-D The Cine-Like mode shifted to prioritize dynamic range
CINE-LIKE-V The Cine-Like mode shifted to prioritize contrast
LOW Images with strong black contrast
B.PRESS Images with even stronger black contrast
NORM Standard video gamma
HIGH Bright images with enhanced gradation in dark portions
and soft contrast
High-Quality, Native Progressive 24p/30p Mode
Choose from three shooting modes: 24p (24 fps, progressive) for images
with the look and motion of film movies, 30p (30 fps, progressive), or
standard 60i (60 fps, interlace). Thanks to its progressive CCD,
the AG-DVX100A creates native progressive images with outstanding
vertical resolution — unlike images produced using conventional
electronic interpolation. With its high mobility and low costs,
the AG-DVX100A is the ideal tool for producing indies, shorts, or
streaming video.
aspherical lens
Optical Image Stabilizer
30p image
(30 progressive frames per second) 60i image (60 interlace fields per second)
Output
Input
NORM
CINE-LIKE_V
CINE-LIKE_D
CINE-LIKE
Gamma Curve image

IEEE1394 Interface cable (4P-6P)
･Apple Power Mac G4 & Final Cut Pro 4
･Avid Xpress Pro
AG-DVX100A
Digral A/V data
ABCDEFGH
AABBBCCDDDEEFFFGGHHH
24p (capture)
60i (record)
24p (capture)
60i (record)
30p (capture)
60i (record)
• 24p Mode (2:3 pulldown)
ABCDEFGH
AABBBCCCDDEEFFFGGGHH
• 24p Advance Mode (2:3:3:2 pulldown)
A
AABBCCDDEEFFGGHH I I JJ
BCDEFGH I J
• 30p Mode
24p/30p Shooting Functions for
Professionals
Acting on requests from professional users, Panasonic gave
the AG-DVX100A several functions that improve shooting ease in
24p/30p Progressive mode.
•Focus assist*
•Gain up (+12 dB max.)
•SMPTE Color bar display and output
*Auto focus in 24p/30p mode requires slightly more focusing time than in 60i mode.
24p Advance Mode — For 24p Non-Linear Editing
In 24p mode, images from the CCD can be 2:3 pulldown-converted
(24p Mode) or 2:3:3:2 pulldown-converted (24p Advance Mode) and
recorded onto tape in the standard 60i TV format. The tape can then be
played back or edited using an ordinary DV system. True 24p editing
can be achieved by uploading 2:3:3:2 pulldown-converted images via
an IEEE1394 DV interface to a compatible non-linear editing system.*
The 24p Advance Mode allows 60i/24p conversion with minimal image
degradation.
*Systems compatible with 24p Advance Mode (as of July 2003):
•Apple Power Mac G4/G5 and Final Cut Pro 4. •Avid Xpress Pro.
Improved Color Reproduction and Advanced Image
Adjustments Built-In
•Optimized color separation optics help provide true-to-life colors
•Matrix setting with new "Enriched" mode for richer colors
•Adjustable V detail level (edge correction in vertical direction), H/V
detail balance, and detail coring (detail noise removal)
•Knee point (luminance compression) settings –
Auto, Low, Mid and High

Ideal for Active Use
Improvements in operating ease, mobility and reliability make the AG-DVX100A ideal for professionals.
Wide-Angle/Zoom Lens Answers Professional Needs
The AG-DVX100A's zoom lens extends all the way to 4.5 mm
(equivalent to 32.5mm on a 35mm lens), covering the full wide-angle
range needed in most broadcast and professional shooting. It gives you
ample range for close-ups, recording in small rooms, and self-recorded
interviews. There's no need to carry around a bulky wide-angle
conversion lens. And with a minimum object distance (MOD) of
approximately 0.6 meter (1.9 ft) in telephoto mode, the AG-DVX100A
has the maneuverability of a handheld camera.
Fast, Smooth Cam-Driven Manual Zoom
The cam-driven (mechanical) manual zoom ring provides the same
smooth, easy zooming as cameras with interchangeable lenses.
Its direct operation gives you fast, precise zooming control. You'll also
notice the AG-DVX100A's improved operating feel. When you turn the
zoom ring, you experience the similar steady resistance as with familiar
35mm lenses.
The AG-DVX100A is also equipped with a servo-driven zoom that
allows slow zooming at a speed of approximately 50% slower than its
predecessor. Slowest zoom has been reduced to a dramatic 30 seconds
from 20 seconds.
Focus Assist
Enjoy quick, sharp focusing manually or automatically. In manual
mode, the focus ring provides the similar operating feel and responsive
control as conventional cameras with interchangeable lenses. In auto
mode, you get the quick, sharp focusing needed in news gathering or
when shooting at a high or low angle.
When set to infinity, the focal distance is immediately prepared for the
next manual focus. When in manual mode, pressing the Push Auto
button temporarily activates auto focus.
Macro Focus can be achieved either Manually or Automatically when
the zoom lens is in the wide angle position.
Three User Buttons for Customized Operation
The AG-DVX100A provides three user buttons, each of which can be
assigned any one of the 11 functions described below.
The assigned functions can then be accessed at the touch of a
button. This lets you customize the AG-DVX100A for quicker,
easier, more versatile operation.
Assignable Functions
COLOR BAR Display/hide the SMPTE color bar
SPOTLIGHT Auto iris spotlight correction ON/OFF
BACKLIGHT Auto iris backlight correction ON/OFF
BLACKFADE Fade out to a black screen (linked with audio)
WHITEFADE Fade out to a white screen (linked with audio)
MODECHECK Display camera settings in viewfinder/monitor
ATW Auto tracking white balance function ON/OFF
ATWLOCK Lock/unlock white balance in ATW operation
GAIN 18dB Switch the gain to +18 dB
INDEX Write the index signal
SLOW SHUT Slow shutter mode ON/OFF
Scene File Dial Provides Quick, Easy Setup
Set this dial for any particular shooting
conditions, and later you can retrieve the
settings instantly. Six preset files are provided
(F1 to F6, described below); you can change
any of the six file names and their settings as
desired. The AG-DVX100A also introduces a
new design in which a rib protects the scene
file dial to prevent unintentional file changes.
File Description
F1: — Standard settings
F2: FLUO. Indoor shooting under fluorescent lights
F3: SPARK Highlighting subjects at receptions, dinners,
and other gatherings
F4: B-STR Enhanced gradations of luminance in low light scenes
F5: 24P 24p mode + Cine-Like-V gamma
F6: ADVANC Advanced 24p mode + Cine-Like-D gamma
3-Position White Balance with Auto Tracking White Function
One press of the AWB button is all it takes to adjust the white balance
and black balance. There are three white balance values to select from:
one that's preset, and two (A, B) that you can set and save in memory.
The auto tracking white balance (ATW) function can also be assigned to
any of the three positions. The ATW mode supports fast, active shooting
by adjusting the white balance in real-time as lighting conditions
change.
Auto Button for Instant, Easy Shooting
Just press the Auto button to turn on Auto Iris, Auto Gain, Auto Tracking
White Balance, and Auto Focus — and you are quickly ready to shoot.
You can also customize the Auto button by removing functions and
setting the gain to any value desired.
With this new Auto function, the AG-DVX100A gives you the best of
both worlds -- the speed and ease of automatic operation, and the
precision of manual control.

Magnesium Alloy Chassis
– The Rugged Durability Professionals Need
The AG-DVX100A features the
same magnesium alloy diecast
chassis as our DVCPRO
broadcast models. This tough,
rigid unit protects the high-
precision mechanism, giving
the AG-DVX100A outstanding
reliability and durability.
Built for professionals,
the AG-DVX100A stands up to
the bumps and jolts that occur in the field.
Highly Reliable DV Mechanism
Panasonic chose a DV
mechanism for the
AG-DVX100A because of its
superior mobility, low running
costs, extended recording
capability, and easy tape
availability. However, for the
AG-DVX100A we developed a
greatly enhanced, vastly more
reliable mechanism than the
ones used in home DV cameras
and recorders. To minimize
dropout and head clogging, we incorporated the same forward cleaning
head and automatic head cleaning function found in DVCPRO models.
The sturdy loading system allows quick tape changes.
Lightweight Design with Balanced Grip
The AG-DVX100A introduces a new design that ends the contradiction
between a compact, lightweight body and a stable, secure hold. The
center of balance is located precisely at the handgrip. Because there's
no need for a wide-angle conversion lens, the weight balance is ideal
for comfortable shooting. The AG-DVX100A's short body and light
weight — it weighs only 4.189 lb (1.9Kg) in operating condition* —
means free, easy maneuverability. Plus, the low-center-of-gravity design
and new skeleton lens hood greatly improve forward vision.
*Camera-recorder with DV cassette tape and supplied battery.
Competitor
standard（f=6.0mm）
with a Wide Converter Lens（f=4.2mm）
AG-DVX100A
Standard（f=4.5mm）

Ideal for Active Use
Improvements in operating ease, mobility and reliability make the AG-DVX100A ideal for professionals.
XLR Audio Input with +48-V Phantom Power Supply
In addition to built-in stereo microphones, the AG-DVX100A is
equipped with two XLR audio input terminals with a 48-V phantom
power supply for broadcast use. The terminals are positioned low on
the camera to minimize the possibility of the cables being snagged
when a hand mic is in use. Both input 1 and input 2 can be switched
between line and mic, and Audio is locked to the Video unlike
consumer DV camcorders.
Large Audio Dials and Flexible Input Selection
The AG-DVX100A has the same
kind of large level-adjustment dials
as DVCPRO camera-recorders.
This practical new design
incorporates professional
operating features that have been
refined over years of use on
location. A switch lets you select built-in mic, input 1, or input 2 for the
audio input of both left and right channels. Auto gain level control can
be turned on and off, and the input mic level (–50 dB/–60 dB) can be
selected from the menu.
Three 16:9 Wide Modes, Including the New Squeeze Mode
The AG-DVX100A has three modes
for shooting 16:9 wide images. Use
the optional 16:9 conversion lens
(AG-LA7200G, sold separately) to
take full advantage of the higher
image quality made possible by
using all of the CCD pixels. With the
standard lens*, you can record in
letterbox mode or the newly added
squeeze mode. This gives you extra
flexibility when using the AG-
DVX100A together with equipment
from other manufacturers.
*Vertical resolution with the standard lens is slightly lower than with the 16:9 conversion lens. However,
when recording in progressive mode rather than interlace mode, the difference is barely perceptible.
Large Electronic Viewfinder
The large viewfinder is easy to see
through, even with your eye at a slight
distance, and it tilts upward
100° for easy low-angle
shots. The AG-DVX100A
also adds a B/W display
mode*, detail (PEAKING)
function, and image adjustment
menu.
*With the same high resolution as the color display
3.5" Color LCD Monitor
The large 3.5" color LCD monitor rotates 270°. This improves shooting
flexibility by making it easier to monitor high-angle shots or self
recordings. The display is bright, too, for easy viewing when monitoring
images or selecting the menu settings. The AG-DVX100A also
introduces a new detail (PEAKING) function that helps assure a sharp,
easy-to-see display.
Built-In SMPTE Time Code Generator/Reader
The AG-DVX100A records an SMPTE-compliant VTC onto the sub-code
area of the tape. Select from DF/NDF and Free Run/Rec Run modes, and
use preset or regen. User bits (UB) are also provided, letting you record
your choice of date, time, TC value, frame rate, or user data.
External Backup with the IEEE 1394 Synchro Lock Function
The AG-DVX100A comes equipped with an IEEE 1394-compliant 4-pin
DV terminal that makes it easy to upload data to a PC and dub onto a
DV recorder. This terminal also features a new synchro lock function
that allows the AG-DVX100A to remotely start and stop an external DV
device connected to it via a DV cable. Three recording modes help
protect against mistakes: record only onto the external recorder, record
onto both the AG-DVX100A and the external recorder, begin external
recording when the AG-DVX100A tape ends.
Interval Recording and One-Shot Recording
The AG-DVX100A's interval recording works much like a time-lapse
VTR and offers exceptionally high quality. Use it to observe the growth
of a plant, monitor progress at a construction site, or for a frame-by-
frame recording effect. Recording times can be set from 0.5 to 2
seconds, at intervals from 15 seconds to 10 minutes. There's also a
One-Shot mode — for animation film making — that records for the set
number of seconds each time the Start/Stop button is pressed.
Recessed Trigger and Zoom Control on Upper Handle Grip
In addition to the lens grip, the
upper part of the handle grip
contains both the Rec Start/Stop
button and a lens zoom control.
This design assures easy shooting
even at low angles or when using a
tripod. The zoom speed can be set
to any of three speed levels or off.
DV Cable (4P-4P)AG-DVX100A Camera-Recorder DV Recorder BT-LS1400 14" SD LSD Monitor


Digital A/V and Remote A/V
16:9 Conversion Lens
Letter Box mode
Squeeze mode
CCD image Recording image
CCD image Recording image
CCD image Recording image

Gain, Iris, Shutter Speed, ND Filter
•Gain: Increases gain up to 18 dB. The selector has three positions: L is
fixed at 0 dB; M and H can be set to 0, +3, +6, +9, or +12 dB.
+18dB can also be quickly accessed by the use of
USER 1, 2 or 3 switch.
•Iris: Allows smooth, gradual manual or auto iris adjustment. The iris
dial allows adjustment even when in Auto mode. Either backlight
compensation or spotlight compensation can be added to the auto
iris adjustment.
•Shutter: Maximum shutter speed is 1/2,000 sec. When a computer
display is being recorded, a synchro scan function matches the shutter
speed to the monitor to help eliminate the moving bar.
•ND filter: Two ND filters (1/8 ND, 1/64 ND) are built-in and
easily accessible.
Support Functions for Greater Convenience
•End search: Automatically searches for the last recorded portion of the
tape. Convenient when preparing to start the next recording.
•Mode check: Displays a list of the camera settings on the viewfinder
and monitor. Makes it easy to check settings before recording.
•2-Pattern zebra: Displays an overexposure warning on the viewfinder
and monitor. Select any two levels from among 80%, 85%, 90%,
95%, 100% and 105%.
•Rec check: Plays back the last portion of a recorded passage
for easy checking.
•Index: Enables marking while recording. Convenient for searching
after recording.
•Tally lamps: Provided on the unit’s front and rear menu switchable.
•Audio dubbing: Allows voice-over recording on a recorded tape via
an external mic.
•Line recording: Lets you record a video signal input from
an external source.
•Unlike consumer DV camcorders, the audio is locked to the video
with a PLL circuit.
•Reversible eye cup for left and right eyed shooters.
•Built-in SMPTE color bars useful for setup.

AG-MC100G XLR microphone
CGR-D16A/1B Battery Pack (1.6 Ah)
CGP-D28A/1B Battery Pack (2.8 Ah)
CGA-D54SE/1BBattery Pack (5.4 Ah)
AG-LA7200G
16:9 conversion lens
AG-LW7208G
Wide conversion lens
AG-LW7208G AG-LA7200G
AG-DVX100A Bundled Standard Accessories Optional Accessories
Switches and connectors are arranged to allow easy use of the AG-DVX100A's many functions,
and a host of bundled accessories and available options prepare it for action just about anywhere.
Top view (handle and grip) Sub-panel (with LCD monitor opened)
Side view (with LCD monitor closed)
CGR-D16A/1B
CGP-D28A/1B
CGA-D54SE/1B
Shoulder
strap
Eye cup
Lens hood
Wireless remote
control unit
AC adapter
Master Series tape
Microphone
holder
BatteryDC CableAC cable

AG-B15 AC adapter kit
QR-DVX AntonBauer battery adapter
AG-HT100G Hard carry case
AG-SC100G Soft carry case
IEEE1394 Interface cable
Front view (with lens hood removed) Rear view (with terminal cover removed)
Side view (with terminal cover removed)
AY-DVM63PQ
Professional Series Tape
AY-DVM63MQ
Master Series Tape
*Please do not use 80 minutes miniDV
cassette tapes
AY-DVMCL
Cleaning tape
BT-LS1400 14" SD LCD Monitor

[GENERAL]
Supply Voltage: DC 7.2/7.9 V
Power Consumption: 6.8 W (when viewfinder is used)
7.8 W (when LCD monitor is used)
9.2 W (max.)
Operating Temperature: 32°F to +104°F (0°C to +40°C)
Operating Humidity: 10% to 85% (no condensation)
Weight: 3.660 lb (1.69 kg)
4.189 lb (1.90kg) with battery and cassette
Dimensions (WxHxD): 5-1/2" x 6-5/16" x 14-3/8" (139 x 160 x 364 mm)
[CAMERA]
Pick-up Device: 1/3-inch interline transfer type CCD x 3
(progressive modes supported)
Picture Elements: Total: 410,000 pixels
Effective: 380,000 pixels (horizontal pixel shift system)
Lens: Leica DICOMAR lens with optical image stabilizer,
motorized/manual mode switching, 10x zoom
F 1.6 (f = 4.5 to 45 mm) (35 mm equivalent: 32.5 to 325 mm)
Filter Diameter: 72 mm
Optical Color Separation: Prism system
Optical Filter: ND Filters, 1/8ND, 1/64ND
Shooting Mode: 60i (525i) interlaced fields
Progressive mode (30P, 24P or 24P advance)
Gain Selection: 60i mode: 0, +3, +6, +9, +12, +18 dB
30P, 24P, 24P (ADV) mode: 0,+3,+6,+9,+12 dB
(0dB fixed, when slow shutter mode )
Preset Shutter Speeds: 60i mode: 1/60 (OFF), 1/100, 1/120, 1/250, 1/500,
1/1000, 1/2000 sec.
30P mode: 1/30, 1/50 (OFF), 1/60, 1/120, 1/250,
1/500,1/1000 sec.
24P, 24P (ADV) mode: 1/24, 1/50 (OFF), 1/60, 1/120, 1/250,
1/500, 1/1000 Sec.
Synchro Scan Shutter Speeds: 60i mode: 1/60.3 to 1/250.0 sec.
30P mode: 1/30.1 to 1/250.0 sec.
24P, 24P (ADV) mode: 1/24.1 to 1/250.0 sec.
Slow Shutter Speeds: 60i mode: 1/4, 1/8, 1/15, 1/30 sec.
30P mode: 1/4, 1/8, 1/15 sec.
24P, 24P (ADV) mode: 1/6, 1/12 sec.
Sensitivity: F11.0 at 2000 lux
Minimum luminance: 3 lux (F 1.6, 18 dB gain, 50 IRE video output)
[VTR]
Tape Used: 6.35 mm wide metal tape (mini DV cassette)
Recorded Audio Signals: PCM digital recording
16 bits: 48 kHz/2 channels, 12 bits: 32 kHz/4 channels
Recording Tracks: Digital video, audio signals: helical track
Time code: helical track (sub-code area)
Tape Speed: SP mode: 18.812 mm/sec., LP mode: 12.555 mm/sec.
Recording Time: SP mode: 60 minutes,
LP mode: 90 minutes (when AY-DVM63 is used)
FF/Rew Time: Approx. 85 sec. (when AY-DVM60 is used)
[VIDEO]
Sampling Frequencies: Y: 13.5 MHz, PB/PR: 3.375 MHz
Quantizing: 8 bits
Video Compression System: DCT + variable length code
Error Correction: Reed-Solomon product code
[AUDIO]
Sampling Frequency: 48 kHz/32 kHz
Quantizing: 16 bits/12 bits
Frequency Characteristics: 20 Hz to 20 kHz
Wow & Flutter: Below measurable limits
[CONNECTORS]
VIDEO IN/OUT: RCA x 1, analog composite input/output, 1.0 Vp-p, 75Ω
(input/output automatically switched)
S-VIDEO IN/OUT: DIN 4pin x 1, Y/C separate signal input/output,
Y: 1.0 Vp-p, C: 0.286 Vp-p, 75Ω
(input/output automatically switched)
AUDIO IN/OUT: RCA x 2 (CH1, CH2)
Input: 316 mV, high impedance
Output: 316 mV, 600Ω
(input/output automatically switched)
DV: 4-pin, digital input/output, IEEE 1394 standard
MIC/LINE INPUT: XLR (3 pins) x 2 (CH1, CH2)
LINE/MIC switching, high impedance
LINE: 0 dBu, MIC: –50 dBu/–60 dBu (menu selection)
DC INPUT: 7.9 V
PHONES: Stereo (3.5 mm diameter)
CAM REMOTE: Mini jack (2.5 mm diameter)
[EQUIPMENTS]
LCD Monitor: 3.5-inch LCD color monitor, 200,000 pixels
Viewfinder: 0.44-inch LCD color viewfinder, 180,000 pixels
Internal Microphone: Stereo microphone
Internal Speaker: 20mm round shape, volume – or +
[AC ADAPTER]
Power Source: 110/120/220/240 V AC, 50/60 Hz
Power Consumption: 18 W
Weight: 0.35 Ib (0.16 kg)
Dimensions (WxHxD): 2-13/16" x 1-13/16" x 4-5/8" (70 x 44.5 x 116 mm)
*The specifications given above were measured by playing back tapes
recorded by the AG-DVX100A on standard VTRs.
Weight and dimensions shown are approximate.
Specifications are subject to change without notice.
AG-DVX100A Specifications
SP-DVX100AP1 25K311ZM-1 Printed in Japan
Matsushita Electric Industrial Co., Ltd.
Systems Business Group
2-15 Matsuba-cho, Kadoma, Osaka, 571-8503 Japan
Tel. [phone] Fax. [phone]
www.panasonic.co.jp/bsd
Panasonic Systems Sales Taiwan Co.,Ltd.
5F, 2 Sec. 5 Hsin I Road Taipei, Taiwan, R.O.C
Tel. [phone] Fax. [phone]
DaeHeung Multimedia Communication Corp.
5th Fl, DaeHeung Bldg., 264, DangsanDong-3-GA,
YoungdungpoGu, Seoul, Korea
Tel. [phone] Fax. [phone]
Broadcast and Communication Company of Asia, Inc.
R-1902A Tektite Tower II Exchange Road Ortigas Center Posig
City, Philippines
Tel. [phone] Fax. [phone]
Panasonic de Mexico, S.A. de C.V.
Tel. [phone] Fax. [phone]
Panasonic Latin America S.A.
( Caribe,Centro America, Venezuela, Colombia, Ecuador, Bolivia,
Uruguay, Paraguay, Chile
)
Tel. [phone] Fax. [phone]
Panasonic del Peru S.A.
Tel. [phone] Fax. [phone]
Panasonic do Brasil Ltda
Tel. [phone] Fax. [phone]
PANASONIC BROADCAST & TELEVISION SYSTEMS COMPANY
DIVISION OF MATSUSHITA ELECTRIC CORPORATION OF AMERICA
www.panasonic.com/broadcast
Executive Office: One Panasonic Way 4E-7, Secaucus, NJ 07094
[phone]
EASTERN ZONE: One Panasonic Way 4E-7, Secaucus, NJ 07094
[phone]
Central Region: 1707 N Randall Road E1-C-1, Elgin, IL 60123 [phone]
WESTERN ZONE: 3330 Cahuenga Blvd W., Los Angeles, CA 90068
[phone]
Government Marketing Department:
52 West Gude Drive, Rockville, MD 20850 [phone]
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga, Ontario L4W 2T3 [phone]
www.panasonic.ca e-mail: [email protected]
Panasonic Sales Company
(Division of Matsushita Electric of Puerto Rico Inc.)
San Gabriel Industrial Park, 65th Infantry Ave., Km. 9.5, Carolina,
Puerto Rico 00630 [phone]
