Panasonic HX-WA10D User manual

Operating Instructions
Dual Camera
Model No.HX-WA10
Before use, please read these instructions completely.
Model number suffix “EB” denotes UK model.
EB Web Site: http://www.panasonic-europe.com
VQT3P45
1AG6P1P6322--(S)

2VQT3P45
Information for Your Safety
Dear Customer,
We would like to take this
opportunity to thank you for
purchasing this Panasonic Dual
Camera. Please read these
Operating Instructions carefully and
keep them handy for future
reference. Please note that the
actual controls and components,
menu items, etc. of your Dual
Camera may look somewhat
different from those shown in the
illustrations in these Operating
Instructions.
WARNING:
TO REDUCE THE RISK OF
FIRE, ELECTRIC SHOCK OR
PRODUCT DAMAGE,
iDO NOT EXPOSE
ACCESSORIES (AC
ADAPTOR, USB CABLE,
BATTERY PACK, SD
MEMORY CARD AND ETC.)
TO RAIN, MOISTURE,
DRIPPING OR SPLASHING
AND THAT NO OBJECTS
FILLED WITH LIQUIDS,
SUCH AS VASES, SHALL
BE PLACED ON THEM.
iUSE ONLY THE
RECOMMENDED
ACCESSORIES.
iDO NOT REMOVE THE
COVER (OR BACK); THERE
ARE NO USER
SERVICEABLE PARTS
INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
CAUTION!
iDO NOT INSTALL OR
PLACE THIS UNIT IN A
BOOKCASE, BUILT-IN
CABINET OR IN ANOTHER
CONFINED SPACE.
ENSURE THE UNIT IS
WELL VENTILATED. TO
PREVENT RISK OF
ELECTRIC SHOCK OR
FIRE HAZARD DUE TO
OVERHEATING, ENSURE
THAT CURTAINS AND ANY
OTHER MATERIALS DO
NOT OBSTRUCT THE
VENTILATION VENTS.
iDO NOT OBSTRUCT THE
UNIT’S VENTILATION
OPENINGS WITH
NEWSPAPERS,
TABLECLOTHS,
CURTAINS, AND SIMILAR
ITEMS.
iDO NOT PLACE SOURCES
OF NAKED FLAMES, SUCH
AS LIGHTED CANDLES,
ON THE UNIT.
iDISPOSE OF BATTERIES
IN AN ENVIRONMENTALLY
FRIENDLY MANNER.
THE SOCKET OUTLET SHALL
BE INSTALLED NEAR THE
EQUIPMENT AND SHALL BE
EASILY ACCESSIBLE.

VQT3P45 3
kConcerning the battery
kEMC Electric and magnetic
compatibility
This symbol (CE) is located on the
rating plate.
kProduct identification marking
kInformation for Users on
Collection and Disposal of Old
Equipment and used Batteries
For proper treatment, recovery and
recycling of old products and used
batteries, please take them to
applicable collection points, in
accordance with your national
legislation and the Directives 2002/
96/EC and 2006/66/EC.
By disposing of these products and
batteries correctly, you will help to
save valuable resources and
prevent any potential negative
effects on human health and the
environment which could otherwise
arise from inappropriate waste
handling.
For more information about
collection and recycling of old
products and batteries, please
contact your local municipality, your
waste disposal service or the point
of sale where you purchased the
items.
Penalties may be applicable for
incorrect disposal of this waste, in
accordance with national legislation.
Warning
Risk of fire, explosion and
burns. Do not disassemble, heat
above 60 oCor incinerate.
CAUTION
Danger of explosion if battery is
incorrectly replaced. Replace
only with the same or equivalent
type recommended by the
manufacturer.
Dispose of used batteries
according to the manufacturer’s
instructions.
Product Location
Dual Camera Battery holder
These symbols on
the products,
packaging, and/or
accompanying
documents mean
that used electrical
and electronic
products and
batteries should not
be mixed with
general household
waste.

4VQT3P45
[Information on Disposal in other
Countries outside the European
Union]
These symbols are only valid in the
European Union. If you wish to
discard these items, please contact
your local authorities or dealer and
ask for the correct method of
disposal.
kSales and Support Information
Customer Care Centre
iFor customers within the UK:
0844 844 3852
iFor customers within Ireland: 01
289 8333
iVisit our website for product
information
www.panasonic.co.uk.
iE-mail:
customer.car[email protected].uk
Technical Support for AV Software
iFor customers within the UK:
0844 844 3869
iFor customers within Ireland: 01
289 8333
Direct Sales at Panasonic UK
iFor customers: 0844 844 3856
iOrder accessory and
consumable items for your
product with ease and confidence
by phoning our Customer Care
Centre Monday–Thursday 9.00
a.m.–5.30 p.m., Friday 9.30 a.m.–
5.30 p.m. (Excluding public
holidays)
iOr go on line through our Internet
Accessory ordering application at
www.pas-europe.com.
iMost major credit and debit cards
accepted.
iAll enquiries transactions and
distribution facilities are provided
directly by Panasonic UK.
iIt couldn’t be simpler!
iAlso available through our
Internet is direct shopping for a
wide range of finished products,
take a browse on our website for
further details.
For business
users in the
European Union
If you wish to
discard electrical
and electronic
equipment, please
contact your dealer
or supplier for
further information.
Note for the
battery symbol
(bottom two
symbol
examples):
This symbol might
be used in
combination with a
chemical symbol. In
this case it
complies with the
requirement set by
the Directive for the
chemical involved.
Cd

VQT3P45 5
IMPORTANT! PLEASE READ
kAbout handling the camera
iOpening and closing the battery cover or terminal cover in a sandy or
dusty environment may cause water to get inside the camera and
result in malfunction, so be especially careful in these environments.
iDo not touch the lens or terminals with dirty hands.
iDo not open or close the battery cover or terminal cover near or in
water, or with wet hands.
iIf there is moisture inside the battery cover or terminal cover, wipe it
completely dry, and use the supplied brush to remove any foreign
matter.
iIf there is water on the surface of the camera, use a soft dry cloth to wipe it
completely dry before opening the camera.
iAvoid dropping or hitting the camera, or subjecting it to strong
vibrations or shocks. Do not apply strong pressure to it.
hThe camera may malfunction or lose the ability to record images,
or the LCD monitor and/or exterior case may be damaged.
hThe waterproof capability may deteriorate.
iDo not sit with the camera in a pants pocket, or force it into a full briefcase
or bag.
iBe careful of accessories etc. dangling from the strap, which may press
against the LCD monitor and break it.
kCondensation (when the lens is cloudy)
iChanges in temperature or humidity may cause water to form on the
camera surfaces (condensation). Recorded images may appear
washed out. Some possible causes to be aware of are the following.
hUsing the camera in the water immediately after moving from a very
warm waterside setting, for example.
hMoving from cold surroundings, such as a ski slope, to warm
surroundings.
hOpening the battery cover or terminal cover in a humid environment.
iIf condensation has formed, try the following countermeasures.
hTurn off the camera and leave it with the battery door open it in a
location with a stable ambient temperature for about 2 hours. The
cloudiness will dissipate naturally when the camera adjusts to the
ambient temperature.
hIf cloudiness persists, open the battery cover and terminal cover in a
location away from heat and humidity, and leave the camera for
about 2 hours. (Do not open and close the covers near the
waterside.)

6VQT3P45
kBe sure to take some test pictures beforehand
Before those important events, be sure to take some trial pictures to confirm
that the images and audio are being properly recorded.
kIndemnity about recorded content
Panasonic does not accept any responsibility for damages directly or
indirectly due to any type of problems that result in loss of recording or edited
content, and does not guarantee any content if recording or editing does not
work properly. Likewise, the above also applies in a case where any type of
repair is made to the unit (including any other non-built-in memory/HDD
related component).
kBe aware of copyrights
Under copyright law, your video and audio recordings cannot be used without
permission of the owner except for your personal use.
Note that photography may be restricted even if the purpose is for your
personal use only.
kPlease also read the “CAUTIONS FOR USE” (page 184).
kHandling of built-in memory
This unit is equipped with a 80 MB (approx.) built-in memory. When using this
component, pay attention to the following points.
iThe status indicator (page 29) illuminates while the SD card or built-in
memory is being accessed (reading, recording, playback, deleting etc.). Do
not perform the following operations when the lamp illuminates. It may
damage the built-in memory or cause a malfunction in the unit.
hTurn the unit off (remove the battery)
hEject the SD card from the camera
hInsert or remove the USB cable
hExpose the unit to vibrations or shock
iFor disposing of or transferring this unit, please see page 185.
Back up data periodically.
The built-in memory is temporary storage. In order to avoid erasing data
due to static electricity, electromagnetic waves, breakage, and failures,
back up the data to a computer or DVD disc. (page 139)

VQT3P45 7
kConcerning this unit’s recording method and compatibility
<Video compatibility>
iThis camera is an MP4 standard (MPEG-4AVC/H.264 format) digital movie
camera that records high-definition HDTV video.
The AVCHD and MPEG2 video formats are different and are therefore not
compatible.
iThis camera may degrade or be unable to play back videos recorded or
created with other products, and other products may degrade or not be
able to play back videos recorded with this camera, even if the products
support the MP4 format.
<Photo compatibility>
iThis unit is compliant with the unified standard DCF (Design rule for
Camera File system) established by JEITA (Japan Electronics and
Information Technology Industries Association) and with Exif
(Exchangeable Image File Format). Files which do not comply with the
DCF standard cannot be played back.
iThe file format of images supported by this unit is JPEG. (Not all JPEG
format files will be played back.)
iThis unit may degrade or not play back images recorded or created on
other products, and other products may degrade or not play back images
recorded on this unit.
kAbout the battery pack
iNever place the battery pack within the reach of infants. In the event that
the battery pack is swallowed, consult a doctor immediately.
kAbout the photos and illustrations in this manual
iThe product images, illustrations, menu displays etc. in this manual may
differ slightly from the actual product.
kFor the purposes of these operating instructions
iSD Memory Card, SDHC Memory Card and SDXC Memory Card are
referred to as the “SD card”.
iPages for reference are indicated by parentheses, for example: (page 00).

8VQT3P45
IMPORTANT: ABOUT THE
WATERPROOF PERFORMANCE OF
THE CAMERA
iThis camera is qualified JIS protection grade 8 (JIS IPX8) for waterproof
performance. It is waterproof up to a depth of 3 meters for at least 60
minutes.*
iThe supplied accessories are not waterproof (excluding handstrap).
* This means that the camera can be used underwater for a specified time in
a specified pressure in accordance with the handling method established by
Panasonic. It does not guarantee against destruction or malfunction, or
guarantee waterproofing, in all conditions.
Observe the following precautions and avoid using under water pressure
exceeding the guaranteed performance, or in an environment with excessive
dust or sand.
The waterproof capability is not guaranteed if the camera is subjected to an
impact as a result of being hit or dropped, etc.
If an impact to the camera occurs, consult with the store where it was
purchased or a service centre, and have it inspected (subject to a fee) to
verify that the waterproof capability has not been compromised.
Any damage due to water leakage that was caused by customer misuse or
mishandling is not covered by the warranty.
kHandling of the camera
iDo not leave the camera for a long period of time in places where the
temperature is very low (ski resort etc.) or very high (above 35 °C),
especially in strong sunlight, in a car sitting outside, close to a heater, on
the beach, etc. (The waterproof capability may be degraded.)
iThe inside of the camera is not waterproof. Do not open or close the
battery cover or terminal cover when you are close to the sea, a lake or a
river, or with wet hands.
iThe waterproof function of the camera applies only to sea water and fresh
water.
iOperation may not be possible, or the audio volume may be low, if snow or
water freezes on the zoom switch, speaker or microphone in cold
environments such as at a ski resort.

VQT3P45 9
MAINTENANCE AND
WATERPROOF PERFORMANCE
kBefore using the camera in water, please check the following
jCheck that there is no foreign matter adhering to the inside of any of
the covers.
hIf lint, hair, sand or the like is present, water may leak into the camera
in seconds and damage it.
hIf any liquid is adhering to the camera, wipe it off with a soft dry cloth.
Liquid on the camera may leak inside and damage the camera.
hIf there is any foreign matter adhering to the
camera, use the supplied brush to remove it.
hTake particular care to remove all traces of
foreign matter from the sides and corners of
the rubber seals, where minute particles of
sand or dust may adhere.
hUse the brush end with the short (hard) bristles to remove larger
foreign matter or damp sand from the camera.
kCare of the brush
iBefore using the brush, check that there is no foreign matter adhering to it.
iAfter using the brush, shake off any foreign matter and keep it where it will
stay clean.
Do not open or close any of the covers in sandy or dusty environments,
near the waterside, or with wet hands. Sand or dust adhering to the
camera can result in water getting inside.
Brush (supplied)
Terminal cover
Battery cover
Battery cover
Terminal cover

10 VQT3P45
kTo prevent water leaking into the camera, please observe the
following precautions before using it.
kCheck that there is sufficient battery power and card memory
remaining.
kDo not open or close the battery cover or terminal cover in places
with sand and dust, or with wet hands.
kAt the time of purchase, the battery cover lock is in the locked
position. When opening the battery cover, first release the lock.
1 Check that there is no foreign matter on the inner side of the battery
cover or terminal cover (where the rubber seal 1contacts the
camera body 2).
hIf the rubber seal inside the battery cover or terminal cover is cracked
or deformed, consult the store where the camera was purchased or a
nearby service centre.
Battery cover lock
Red part
(coloured label)
Terminal cover lock
1
1
2
2
Terminal cover
Battery cover
Hair, lint
Liquid
Crack,
deformation
Sand, dust

VQT3P45 11
2 If there is foreign matter adhering to the camera, use the supplied
brush to remove it.
hIf there is any foreign matter, such as lint, hair,
sand, etc., on the parts indicated by the text
balloons in the illustration, water will leak
inside within seconds and may damage the
camera.
kExample of foreign matter inside the battery cover
kExample of foreign matter inside the terminal cover
Brush (supplied)
Rubber seal
Where the rubber seal
contacts the camera
body
Rubber seal Where the rubber seal
contacts the camera body

12 VQT3P45
iIf there is liquid on the surface, wipe it off with a soft dry cloth.
iThe integrity of the rubber seals decreases after about 1 year. It is strongly
recommended that you have the seals replaced (subject to a fee) at least
once a year at the store where the camera was purchased or at nearby
service centre.
3 1With the battery cover lock released, press the battery cover to
close it.
hTo prevent water seeping into the camera, make sure that foreign
matter such as liquids, sand, hair or dust is trapped between the
cover and the camera body.
2Push the battery cover lock to the left to lock it.
hThe coloured label is visible when the battery cover lock is not
completely closed. Be sure to close the lock completely so that the
coloured label is not visible.
3Close the terminal cover firmly until you hear it “click” shut and
the red part of the terminal cover lock is no longer visible.
hIf the camera is used without the covers securely closed, they may
open on their own.
1
3
2
Terminal cover lock
Battery cover lock

VQT3P45 13
HINT
iIf there is any foreign matter on the camera, use the supplied brush to
remove it.
iIf the camera is used in the following environments, foreign matter such as
sand or dust may inadvertently get caught in the gap between the battery
cover or terminal cover and the body.
hIn the sea or in waters in which sand is suspended.
hIn places with a lot of sand or dust, such as at the beach or in a
sandbox.
kUsing the camera underwater
iUse the camera underwater at a depth of up to 3 meters, water
temperature from 0 °C to 35 °C, and for not longer than 60 minutes
continuously. Before using the camera in water again, make sure that it has
been sufficiently dried.
iIf there is water or dirt on the camera, wipe it dry with a soft dry cloth and
leave it to dry in a well ventilated spot before using again.
iDo not open and close the battery cover or terminal cover while
underwater.
iDo not subject the camera to shock underwater. (The waterproof
performance may become impaired, and water may seep into the camera.)
iDo not dive into the water holding the camera. Do not use the camera in a
location where it might be impacted by forceful splashing, such as in a
strong current or a waterfall. (Strong water pressure may cause the
camera to malfunction.)
iThe camera will sink in water. Take care not to drop the camera and lose it
underwater, for example by making sure the hand strap is secured or by
some other measure.
iDo not use the camera in water warmer than 35 °C (in the bath or spa).
iIf the camera is splashed with detergent, soap, hot water, bath salts,
tanning oil, sun screen, chemicals, etc., wipe it off immediately.
iThe card and battery are not waterproof. Do not handle them with wet
hands. Also, do not insert a wet card or battery in the camera.

14 VQT3P45
kCauses of water leak
iIf the camera is used in any of the following conditions, a gap may appear
between the camera body and the battery cover or terminal cover, resulting
in water seeping in and causing the camera malfunction.
hWhen there is foreign matter, such as lint, hair, sand, etc., between the
battery cover or terminal cover and the camera body.
hWhen the rubber seal has deteriorated.
hWhen the lock on the battery cover and/or terminal cover is not closed.
kCare of the camera after using underwater
1 With the battery cover and
terminal cover closed, rinse
the camera with water; or, if it
was used in the sea, soak it in
a shallow container filled with
fresh water for about 10
minutes.
hLeaving the camera with
foreign objects or saline
matter on it may cause
damage, discolouration,
corrosion, unusual odor, or
deterioration.
The camera must be cleaned after it has been used underwater.
iRinse the camera in water, and do not open the battery cover or
terminal cover until all sand and dust have been removed.
iDo not soak the camera in water for more than 60 minutes.
Battery cove
r
Water can leak
inside through the
gap
Ter mi n al
cover
Rubber seal
Where the
rubber seal
contacts the
camera body
Rubber seal Where the rubber seal contacts the camera body

VQT3P45 15
2 Wipe off the water, place the camera on a dry cloth and leave it to dry
for a while in a well-ventilated shaded spot.
3 Check that there is no water on
the camera, and open the
battery cover and terminal
cover.
hMoisture may easily
accumulate in the grooves
inside the covers, so take care
that no water gets inside.
4 Wipe off any water or sand
inside the battery cover and
terminal cover with the
supplied brush or a soft dry cloth.
iAfter the camera has been used underwater or soaked in fresh water,
moisture may collect in the grooves around the card/battery compartment
and connection terminals. In addition, water droplets may adhere to the
card or battery if the battery cover is opened without sufficiently drying the
camera. Be sure to wipe off the water with a soft dry cloth in such cases.
iDo not open or close the battery cover or terminal cover with water
droplets still on the camera. The water droplets may seep into the camera,
causing condensation and malfunction.
<Wiping moisture from the camera>
iIf there is moisture inside the battery cover, wipe every crevice completely
clear of moisture.
*This moisture is not due to exposure to water.
Moisture
here

16 VQT3P45
kAbout the water draining design
This camera is designed so that water that entered the gaps around the zoom
switch etc. drains out. For this reason, bubbles may appear when the camera
is immersed in water, but this is not a malfunction.
<Draining water from the camera>
iDrainage holes are found at two points on the bottom of the camera. Hold
the camera vertically, as shown, to drain off the water.
When draining, attach the hand strap to the camera and secure the hand
strap to your wrist to prevent the camera from dropping.
HINT
iUse a soft dry cloth to wipe water and dirt from the camera.
iAfter use at the seaside or underwater, make sure that the battery cover
and terminal cover are securely closed, and soak the camera in a shallow
container filled with fresh water for about 10 minutes.
iIf the zoom switch does not operate smoothly, it may be due to the
adhesion of foreign matter. Using the camera in this condition may cause a
malfunction such as locking up, so wash off any foreign objects by soaking
the camera in fresh water and rinsing it. After cleaning, check that the
zoom switch operates smoothly.
iAfter soaking or washing the camera, wipe the water from it with a soft dry
cloth and dry it in a well ventilated shaded spot.
iAfter soaking the camera in water, place it on a dry cloth and leave it to dry
for a while, and check to make sure that the water has drained from it.
iDo not use hot air from a hairdryer or the like to dry the camera. The
waterproof capability will deteriorate due to deformation.
iDo not use chemicals such as benzine, paint thinner, alcohol or cleanser;
do not use soap or detergents.
Drainage
holes

VQT3P45 17
WHAT YOU CAN DO WITH YOUR
DIGITAL MOVIE CAMERA
Easy shooting/playback (Basic features)
Intelligent Auto Mode
... (page 56)
Just point the camera at the subject, and
it automatically ascertains the scene
and captures the images with the
optimum settings.
Shoot movies
... (page 61)
Take photos
... (page 62)
Play back videos and
photos
... (page 69)
353 000:15:53
16 M
-
S
1080-30 p
1080-30 p
000:00:09
000:00:09
000:00:09
2 M
16 M
-
S
F3.5
F3.5
1/30
1/30
F3.5
1/30
20.12.201120.12
20.12.
2011
2011
20.12.2011

18 VQT3P45
Using the convenient features (Practical
applications)
Image stabiliser... (pages 51, 84)
Subject tracking... (pages 53, 90)
Scene mode... (pages 49, 82, 180 to 182)
HINT
User guide on the Internet
When this camera is connected to an Internet-connected VIERA via an HDMI
mini cable (sold separately), you can press the VIERA’s remote control Menu
button and from the resulting menu select “User guide on the Internet” to see
easy-to-understand explanations of the camera’s operation and convenient
functions on the VIERA screen.
iApplicable to VIERA units sold from December 2010.
iTo connect the camera to the VIERA via an HDMI mini cable, please see
pages 161 to 162.

VQT3P45 19
Keeping recorded videos (Copy/dubbing)
From built-in memory to SD
card...
(page 55)
DVD recorder and video deck...
(page 164)
* It is not possible to directly insert in the card slot
an SD card recorded with this camera and play
back or dub from it.
* It is not possible to connect the camera to the
USB connector and play back or dub from it.
* Recording with HD image quality on a Blu-ray
disc recorder is not possible.
On a computer...
(pages 133 to 158)

20 VQT3P45
CONTENTS
Information for Your Safety .................................................................... 2
CHECKING THE INCLUDED ACCESSORIES .................................... 24
ABOUT THE CARD ............................................................................. 25
Media cards that can be used with this camera
(as of February 2011) ............................................................... 25
SETUP
PARTS NAMES ................................................................................... 27
CHARGING THE BATTERY PACK ..................................................... 30
About the temperature alert icon ........................................... 36
INSTALLING THE CARD ..................................................................... 37
TURNING THE CAMERA ON AND OFF ............................................. 39
Turning on the camera .................................................................. 39
Turning off the camera .................................................................. 40
Turning on the camera when it is in the sleep mode .................... 40
DATE AND TIME SETTING ................................................................. 41
Date and time backup ................................................................... 43
SWITCHING BETWEEN THE RECORDING MODE AND
PLAYBACK MODE .......................................................................... 44
MENU SCREEN .................................................................................. 45
Accessing/exiting the Menu Screen .............................................. 45
Using the Menu ............................................................................. 46
Overview of the Menu Screen ...................................................... 48
INTELLIGENT AUTO MODE ............................................................... 56
BASIC OPERATION
SHOOTING
BEFORE TAKING PICTURES ............................................................. 59
For best results ............................................................................. 59
How to use the accessories .......................................................... 60
VIDEO RECORDING ........................................................................... 61
TAKING PHOTOS ............................................................................... 62
Shoot a photo while recording a video .......................................... 64
MACRO-PHOTOGRAPHY (ZOOM) .................................................... 65
SHOOTING UNDER WATER .............................................................. 67
Capturing the best colours and audio when shooting underwater
(underwater mode) ................................................................... 67
After using in water ....................................................................... 68
