Panasonic SDR-H80P User manual

©Panasonic Corporation 2008. Unauthorized
copying and distribution is a violation of law.
Model No.SDR-H80P
SDR-H80PC
SDR-H80EG
SDR-H80EE
SDR-H80EB
SDR-H80EP
SDR-H80EF
SDR-H80EC
SDR-H80GC
SDR-H80GN
SDR-H80GJ
SDR-H80GK
SDR-H80PU
SDR-H80PR
SDR-H81EE
SDR-H81EB
SDR-H90P
SDR-H90PC
SDR-H90EG
SDR-H90EE
SDR-H90EB
SDR-H90EP
SDR-H90EF
SDR-H90EC
SDR-H90GC
SDR-H90GN
SDR-H90GJ
SDR-H90GK
SDR-H90PU
SD Card / Hard Disk Video Camera
ORDER NO.VM0812042CE
B27

VOL.2
Colours
1 Safety Precaution 4
1.1. General Guidelines 4
2 Warning 5
2.1. Prevention of Electrostatic Discharge (ESD) to
Electrostatic Sensitive (ES) Devices 5
2.2. Service caution based on legal restrictions 6
2.3. Caution for AC Cord (For EB/GC) 7
3 Specifications 8
4 Service Mode 9
4.1. Service Menu 9
4.2. About Default Setting 15
5 Service Fixture & Tools 16
5.1. Service Tools and Equipment 16
6 Measurements and Adjustments 17
6.1. Service Positions 17
6.2. Location for Connectors of the Main P.C.B. and Sub
P.C.B. 19
6.3. Location for CSP IC 痴of the Main P.C.B. and Sub P.C.B.
21
6.4. Temperature Profile for Heat Resistance of CSP IC 23
7 Block Diagrams 25
7.1. POWER SUPPLY BLOCK DIAGRAM 25
7.2. CAMERA DRIVE BLOCK DIAGRAM 26
7.3. LENS DRIVE BLOCK DIAGRAM 27
7.4. SYSTEM CONTROL BLOCK DIAGRAM 28
7.5. AUDIO/VIDEO BLOCK DIAGRAM 29
7.6. MONITOR BLOCK DIAGRAM 30
8 Schematic Diagrams 31
8.1. MAIN (MAIN CONNECTION (1/4)) SCHEMATIC
DIAGRAM 31
8.2. MAIN (MAIN CONNECTION (2/4)) SCHEMATIC
DIAGRAM 32
8.3. MAIN (MAIN CONNECTION (3/4)) SCHEMATIC
DIAGRAM 33
8.4. MAIN (MAIN CONNECTION (4/4)) SCHEMATIC
DIAGRAM 34
8.5. MAIN (MEMORY) SCHEMATIC DIAGRAM 35
8.6. MAIN (TG/AFE) SCHEMATIC DIAGRAM 36
8.7. MAIN (RESIZE) SCHEMATIC DIAGRAM 37
8.8. MAIN (KAO) SCHEMATIC DIAGRAM 38
8.9. MAIN (LENS DRIVE (1/4)) SCHEMATIC DIAGRAM 39
8.10. MAIN (LENS DRIVE (2/4)) SCHEMATIC DIAGRAM 40
(K)........Black Type (except DMR-H80GK)
(S)........Silver Type (except DMR-H80EF, H81, H90)
(A)........Blue Type (except DMR-H80EF/EE, H81, H90)
(R)........Red Type (except DMR-H80EE, H81, H90)
8.11. MAIN (LENS DRIVE (3/4)) SCHEMATIC DIAGRAM 41
8.12. MAIN (LENS DRIVE (4/4)) SCHEMATIC DIAGRAM 42
8.13. MAIN (VIDEO (1/4)) SCHEMATIC DIAGRAM 43
8.14. MAIN (VIDEO (2/4)) SCHEMATIC DIAGRAM 44
8.15. MAIN (VIDEO (3/4)) SCHEMATIC DIAGRAM 45
8.16. MAIN (VIDEO (4/4)) SCHEMATIC DIAGRAM 46
8.17. MAIN (USB HOST) SCHEMATIC DIAGRAM 47
8.18. MAIN (AVIO) SCHEMATIC DIAGRAM 48
8.19. MAIN (LCD) SCHEMATIC DIAGRAM 49
8.20. MAIN (SUB-POWER) SCHEMATIC DIAGRAM 50
8.21. MAIN (MIC) SCHEMATIC DIAGRAM 51
8.22. SUB (SUB CONNECTION (1/4)) SCHEMATIC DIAGRAM
52
8.23. SUB (SUB CONNECTION (2/4)) SCHEMATIC DIAGRAM
53
8.24. SUB (SUB CONNECTION (3/4)) SCHEMATIC DIAGRAM
54
8.25. SUB (SUB CONNECTION (4/4)) SCHEMATIC DIAGRAM
55
8.26. SUB (SYSCON (1/4)) SCHEMATIC DIAGRAM 56
8.27. SUB (SYSCON (2/4)) SCHEMATIC DIAGRAM 57
8.28. SUB (SYSCON (3/4)) SCHEMATIC DIAGRAM 58
8.29. SUB (SYSCON (4/4)) SCHEMATIC DIAGRAM 59
8.30. SUB (HDD G-SENSOR) SCHEMATIC DIAGRAM 62
8.31. SUB (SUB SYSCON) SCHEMATIC DIAGRAM 63
8.32. SUB (POWER (1/4)) SCHEMATIC DIAGRAM 64
8.33. SUB (POWER (2/4)) SCHEMATIC DIAGRAM 65
8.34. SUB (POWER (3/4)) SCHEMATIC DIAGRAM 66
8.35. SUB (POWER (4/4)) SCHEMATIC DIAGRAM 67
8.36. SUB (LIGHT) SCHEMATIC DIAGRAM 68
9 Printed Circuit Board 69
9.1. MAIN P.C.B. (COMPONENT SIDE) 69
9.2. MAIN P.C.B. (FOIL SIDE) 70
9.3. MAIN P.C.B. ADDRESS INFORMATION 71
9.4. SUB P.C.B. (COMPONENT SIDE) 72
9.5. SUB P.C.B. (FOIL SIDE) 73
9.6. SUB P.C.B. ADDRESS INFORMATION 74
10 Appendix Information of Schematic Diagram 75
10.1. Checking Point Table of the CSP IC 75
10.2. Waveform Table of the CSP IC 92
10.3. Abbreviations 98
11 Parts and Exploded Views 103
CONTENTS
Page Page
2
SDR-H80P

11.1. Replacement Parts List 103
3
SDR-H80P

1 Safety Precaution
1.1. General Guidelines
1. IMPORTANT SAFETY NOTICE
There are special components used in this equipment which are important for safety. These parts are marked by in the
Schematic Diagrams, Circuit Board Layout, Exploded Views and Replacement Parts List. It is essential that these critical parts
should be replaced with manufacturer’s specified parts to prevent X-RADIATION, shock fire, or other hazards. Do not modify
the original design without permission of manufacturer.
2. An Isolation Transformer should always be used during the servicing of AC Adaptor whose chassis is not isolated from the AC
power line. Use a transformer of adequate power rating as this protects the technician from accidents resulting in personal injury
from electrical shocks. It will also protect AC Adaptor from being damaged by accidental shorting that may occur during
servicing.
3. When servicing, observe the original lead dress. It a short circuit is found, replace all parts which have been overheated or
damaged by the short circuit.
4. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly
installed.
5. After servicing, make the following leakage current checks to prevent the customer from being exposed to shock hazards.
4
SDR-H80P

2 Warning
2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatic Sensitive
(ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called
Electrostatic Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and
semiconductor “chip” components. The following techniques should be used to help reduce the incidence of component damage
caused by electrostatic discharge (ESD).
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your
body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap,
which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as
aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an antistatic solder removal device. Some solder removal devices not classified as “antistatic (ESD protected)” can
generate electrical charge sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most
replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or comparable
conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material
to the chassis or circuit assembly into which the device will be installed.
CAUTION:
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the
brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD)
sufficient to damage an ES device).
5
SDR-H80P

2.2. Service caution based on legal restrictions
2.2.1. General description about Lead Free Solder (PbF)
The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this
equipment in considering the globally environmental conservation.
The normal solder is the alloy of tin (Sn) and lead (Pb). On the other hand, the lead free solder is the alloy mainly consists of tin
(Sn), silver (Ag) and Copper (Cu), and the melting point of the lead free solder is higher approx.30 degrees C (86°F) more than that
of the normal solder.
Definition of PCB Lead Free Solder being used
The letter of “PbF” is printed either foil side or components side on the PCB using the lead free solder.
(See right figure)
Service caution for repair work using Lead Free Solder (PbF)
· The lead free solder has to be used when repairing the equipment for which the lead free solder is used.
(Definition: The letter of “PbF” is printed on the PCB using the lead free solder.)
· To put lead free solder, it should be well molten and mixed with the original lead free solder.
· Remove the remaining lead free solder on the PCB cleanly for soldering of the new IC.
· Since the melting point of the lead free solder is higher than that of the normal lead solder, it takes the longer time to melt
the lead free solder.
· Use the soldering iron (more than 70W) equipped with the temperature control after setting the temperature at 350±30
degrees C (662±86°F).
Recommended Lead Free Solder (Service Parts Route.)
· The following 3 types of lead free solder are available through the service parts route.
RFKZ03D01KS-----------(0.3mm 100g Reel)
RFKZ06D01KS-----------(0.6mm 100g Reel)
RFKZ10D01KS-----------(1.0mm 100g Reel)
Note
* Ingredient: tin (Sn), 96.5%, silver (Ag) 3.0%, Copper (Cu) 0.5%, Cobalt (Co) / Germanium (Ge) 0.1 to 0.3%
6
SDR-H80P

2.3. Caution for AC Cord
(For EB/GC)
2.3.1. Information for your safety
IMPORTANT
Your attention is drawn to the fact that recording of pre-
recorded tapes or discs or other published or broadcast
material may infringe copyright laws.
WARNING
To reduce the risk of fire or shock hazard, do not expose
this equipment to rain or moisture.
CAUTION
To reduce the risk of fire or shock hazard and annoying
interference, use the recommended accessories only.
FOR YOUR SAFETY
DO NOT REMOVE THE OUTER COVER
To prevent electric shock, do not remove the cover. No user
serviceable parts inside. Refer servicing to qualified service
personnel.
2.3.2. Caution for AC mains lead
For your safety, please read the following text carefully.
This appliance is supplied with a moulded three-pin mains plug
for your safety and convenience.
A 5-ampere fuse is fitted in this plug.
Should the fuse need to be replaced please ensure that the
replacement fuse has a rating of 5 amperes and it is approved
by ASTA or BSI to BS1362
Check for the ASRA mark or the BSI mark on the body of the
fuse.
If the plug contains a removable fuse cover you must ensure
that it is refitted when the fuse is replaced.
If you lose the fuse cover, the plug must not be used until a
replacement cover is obtained.
A replacement fuse cover can be purchased from your local
Panasonic Dealer.
If the fitted moulded plug is unsuitable for the socket outlet in
your home then the fuse should be removed and the plug cut
off and disposed of safety.
There is a danger of severe electrical shock if the cut off plug
is inserted into any 13-ampere socket.
If a new plug is to be fitted please observe the wiring code as
shown below.
If in any doubt, please consult a qualified electrician.
2.3.2.1. Important
The wires in this mains lead are coloured in accordance with
the following code:
Blue Neutral
Brown Live
As the colours of the wires in the mains lead of this appliance
may not correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:
The wire which is coloured BLUE must be connected to the
terminal in the plug which is marked with the letter N or
coloured BLACK.
The wire which is coloured BROWN must be connected to the
terminal in the plug which is marked with the letter L or coloured
RED.
Under no circumstances should either of these wires be
connected to the earth terminal of the three pin plug, marked
with the letter E or the Earth Symbol.
2.3.2.2. Before use
remove the Connector Cover as follows.
2.3.2.3. How to replace the Fuse
1. Remove the Fuse Cover with a screwdriver.
2. Replace the fuse and attach the Fuse cover.
7
SDR-H80P

3 Specifications
8
SDR-H80P

4 Service Mode
4.1. Service Menu
When abnormal detection contents are confirmed, do the following operation. Automatic diagnosis code will bedisplayed.
(Service Menu)
To enter the Service Menu
1. Turn the Power on and set the Mode Dial to [VIDEO RECORDING MODE].
2. Push the [OIS], [JOYSTICK CONTROL LEFT] and [iA] simultaneously for 3 seconds (with no SD Card inserted).
Note:
If a SD Card is inserted, the above operation will not work.
Fig. 1-1
Note:
Only perform items 1, 2, 3, 4, 9, 10, 14 and 15 in the Service Menu.
9
SDR-H80P

To select the Item of Service Menu
1. Press [JOYSTICK CONTROL UP/DOWN] to select item [1], [2], [3], [4], [9], [10], [14] or [15].
2. Press [JOYSTICK CONTROL RIGHT] to display [YES/NO] screen.
3. Press [JOYSTICK CONTROL UP/DOWN] to select [YES].
4. Press [JOYSTICK CONTROL CENTER] to end.
Fig. 1-2
10
SDR-H80P

Fig. 1-3
11
SDR-H80P

Fig. 1-4
12
SDR-H80P

Fig. 1-5
13
SDR-H80P

Fig. 1-6
Fig. 1-7
To exit the Service Menu
Unplug the AC Cord.
14
SDR-H80P

4.2. About Default Setting
The data of Menu, Mode, Card and EEPROM setting, etc. is set to the default condition in factory.
4.2.1. How to set the Default Setting
1. Turn the Power on and set the Mode Dial to [VIDEO RECORDING MODE].
2. When pressing [OIS], [JOYSTICK CONTROL RIGHT] and [iA] for more than 3 minutes simultaneously (with no SD Card
inserted), the items below are set to the Default Setting.
1. Menu, Mode, Adjusted Value
2. Card format
3. Reset of picture files and directory number (Set the picture record file number to 1)
4. Clear the information of Mechanism Lock
5. Set the time setting to no-setting
15
SDR-H80P

5 Service Fixture & Tools
5.1. Service Tools and Equipment
16
SDR-H80P

6 Measurements and Adjustments
6.1. Service Positions
6.1.1. List of the extension cables
Use the following extension cables when checking or adjusting individual circuit boards except module Parts (Main P.C.B. and Sub
P.C.B.).
17
SDR-H80P

6.1.2. Checking and repairing individual circuit boards except module parts (Main
P.C.B. and Sub P.C.B.)
How to use extension cables.
18
SDR-H80P

6.2.1. Main P.C.B.
6.2. Location for Connectors of the Main P.C.B. and Sub P.C.B.
19
SDR-H80P

6.2.2. Sub P.C.B.
20
SDR-H80P
