Panasonic Lumix DMC-FH25 Installation and service instructions

Basic Owner’s Manual
Digital Camera
Model No. DMC-FH25
DMC-FH5
DMC-FH2
Before connecting, operating or adjusting this product,
please read the instructions completely.
More detailed instructions on the
operation of this camera are
contained in “Owner’s Manual for
advanced features (PDF format)” in the supplied
CD-ROM. Install it on your PC to read it.
until
2010/12/31
VQT3D30
PC
For Canadian assistance, please call: 1-800-99-LUMIX (1-800-995-8649) or
send e-mail to: [email protected]
DMC-FH25&FH5&FH2P-VQT3D30_eng.book 1 ページ ２０１０年１２月２日 木曜日 午後８時３８分

VQT3D30 (ENG)
2
Dear Customer,
Thank you for choosing Panasonic!
You have purchased one of the most sophisticated and reliable products on
the market today. Used properly, we’re sure it will bring you and your family
years of enjoyment. Please take time to fill in the information on the below.
The serial number is on the tag located on the underside of your Camera. Be
sure to retain this manual as your convenient Camera information source.
Please note that the actual controls and components, menu items, etc. of
your Digital Camera may look somewhat different from those shown in the
illustrations in this Owner’s Manual.
Carefully observe copyright laws.
•Recording of pre-recorded tapes or discs or other published or broadcast
material for purposes other than your own private use may infringe copyright
laws. Even for the purpose of private use, recording of certain material may be
restricted.
A lithium ion battery that is recyclable powers the product
you have purchased. Please call 1-800-8-BATTERY for
information on how to recycle this battery.
Model No.
Serial No.
DMC-FH25&FH5&FH2P-VQT3D30_eng.book 2 ページ ２０１０年１２月２日 木曜日 午後８時３８分

3
(ENG) VQT3D30
Information for Your Safety
∫Product identification marking
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT
DAMAGE,
•DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING
OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH
AS VASES, SHALL BE PLACED ON THE APPARATUS.
•USE ONLY THE RECOMMENDED ACCESSORIES.
•DO NOT REMOVE THE COVER (OR BACK); THERE ARE NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
THE SOCKET OUTLET SHALL BE INSTALLED NEAR THE
EQUIPMENT AND SHALL BE EASILY ACCESSIBLE.
Product Location
Digital camera Bottom
Battery charger Bottom
This Class B digital apparatus complies with Canadian ICES-003.
DMC-FH25&FH5&FH2P-VQT3D30_eng.book 3 ページ ２０１０年１２月２日 木曜日 午後８時３８分

VQT3D30 (ENG)
4
∫About the battery pack
•Do not heat or expose to flame.
•Do not leave the battery(ies) in an automobile exposed to direct sunlight for a
long period of time with doors and windows closed.
∫About the battery charger
CAUTION
Battery pack (Lithium ion battery pack)
•Use the specified unit to recharge the battery pack.
•Do not use the battery pack with equipment other than the specified unit.
•Do not get dirt, sand, liquids, or other foreign matter on the terminals.
•Do not touch the plug terminals (iand j) with metal objects.
•Do not disassemble, remodel, heat or throw into fire.
If any electrolyte should come into contact with your hands or clothes,
wash it off thoroughly with water.
If any electrolyte should come into contact with your eyes, never rub the
eyes. Rinse eyes thoroughly with water, and then consult a doctor.
CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose
of used batteries according to the manufacturer’s instructions.
Warning
Risk of fire, explosion and burns. Do not disassemble, heat above 60 xC
(140 oF) or incinerate.
CAUTION!
DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILT-IN
CABINET OR IN ANOTHER CONFINED SPACE. ENSURE THE UNIT
IS WELL VENTILATED. TO PREVENT RISK OF ELECTRIC SHOCK
OR FIRE HAZARD DUE TO OVERHEATING, ENSURE THAT
CURTAINS AND ANY OTHER MATERIALS DO NOT OBSTRUCT THE
VENTILATION VENTS.
DMC-FH25&FH5&FH2P-VQT3D30_eng.book 4 ページ ２０１０年１２月２日 木曜日 午後８時３８分

5
(ENG) VQT3D30
∫Cautions for Use
•Do not use any other AV cables except the supplied one.
•Do not use any other USB connection cables except the supplied one.
Keep this unit as far away as possible from electromagnetic equipment
(such as microwave ovens, TVs, video games etc.).
•If you use this unit on top of or near a TV, the pictures and/or sound on this unit
may be disrupted by electromagnetic wave radiation.
•Do not use this unit near cell phones because doing so may result in noise
adversely affecting the pictures and/or sound.
•Recorded data may be damaged, or pictures may be distorted, by strong
magnetic fields created by speakers or large motors.
•Electromagnetic wave radiation generated by microprocessors may adversely
affect this unit, disturbing the pictures and/or sound.
•If this unit is adversely affected by electromagnetic equipment and stops
functioning properly, turn this unit off and remove the battery or disconnect AC
adaptor (DMW-AC5PP; optional). Then reinsert the battery or reconnect AC
adaptor and turn this unit on.
Do not use this unit near radio transmitters or high-voltage lines.
•If you record near radio transmitters or high-voltage lines, the recorded pictures
and/or sound may be adversely affected.
Battery charger
This battery charger operates on AC between 110 V and 240 V.
But
•In the U.S.A. and Canada, the battery charger must be connected to a 120 V
AC power supply only.
•When connecting to an AC supply outside of the U.S.A. or Canada, use a
plug adaptor to suit the AC outlet configuration.
DMC-FH25&FH5&FH2P-VQT3D30_eng.book 5 ページ ２０１０年１２月２日 木曜日 午後８時３８分

VQT3D30 (ENG)
6
-If you see this symbol-
Information on Disposal in other Countries outside
the European Union
This symbol is only valid in the European Union.
If you wish to discard this product, please contact your
local authorities or dealer and ask for the correct
method of disposal.
DMC-FH25&FH5&FH2P-VQT3D30_eng.book 6 ページ ２０１０年１２月２日 木曜日 午後８時３８分

7
(ENG) VQT3D30
Contents
Information for Your Safety ........................................................................... 3
Standard Accessories ................................................................................... 8
Names of the Components ........................................................................... 9
Charging the Battery ................................................................................... 12
• Charging ............................................................................................... 12
• Approximate operating time and number of recordable pictures .......... 14
About the Built-in Memory/the Card ............................................................ 15
Inserting and Removing the Card (optional)/the Battery ............................. 16
Setting Date/Time (Clock Set)..................................................................... 18
• Changing the Clock Setting .................................................................. 18
Selecting the [Rec] Mode............................................................................ 19
Taking pictures using the automatic function
(ñ: Intelligent Auto Mode) ......................................................................... 20
• Scene Detection.................................................................................... 21
Motion Picture Mode ................................................................................... 22
Playing Back Pictures ([Normal Play]) ........................................................ 23
Deleting Pictures ......................................................................................... 23
Setting the Menu ......................................................................................... 24
Reading the Owner’s Manual (PDF format) ................................................ 25
Specifications.............................................................................................. 27
Digital Camera Accessory System.............................................................. 31
∫About illustrations in this owner’s manual
The procedure is described for (DMC-FH25) as an example.
DMC-FH25&FH5&FH2P-VQT3D30_eng.book 7 ページ ２０１０年１２月２日 木曜日 午後８時３８分

VQT3D30 (ENG)
8
Standard Accessories
Check that all the accessories are supplied before using the camera.
Product numbers correct as of January 2011. These may be subject to change.
1 Battery Pack¢
(Indicated as battery pack or
battery in the text)
Charge the battery before use.
2 Battery Charger
(Indicated as battery charger or
charger in the text)
3 USB Connection Cable
4AVCable
5 CD-ROM
•Software:
Use it to install the software to your
PC.
•Owner’s Manual
6 Hand Strap
¢When purchasing a spare battery,
please purchase an optional battery
(DMW-BCK7PP).
•SD Memory Card, SDHC Memory Card
and SDXC Memory Card are indicated
as card in the text.
•The card is optional.
You can record or play back pictures
on the built-in memory when you are
not using a card.
•For information about optional
accessories, refer to the “Digital
Camera Accessory System”.
•If any accessories are lost, customers in Canada should contact
1 800 99-LUMIX (1-800-995-8649) for further information about obtaining
replacement parts.
VFC4297VFF0726
3
12
4
56
NCA-YN101G DE-A91B
(DMC-FH25)
K1HY08YY0019
(DMC-FH5)
(DMC-FH2)
K1HY08YY0015
(DMC-FH25)
K1HY08YY0020
(DMC-FH5)
(DMC-FH2)
K1HY08YY0016
DMC-FH25&FH5&FH2P-VQT3D30_eng.book 8 ページ ２０１０年１２月１１日 土曜日 午後４時１３分

9
(ENG) VQT3D30
Names of the Components
1Flash
2Lens
3 Self-timer indicator
AF Assist Lamp
4 LCD monitor
5 [MENU/SET] button
6 [DISP.] button
7 [Q.MENU]/Delete/Cancel button
8 [MODE] button
9 [Rec]/[Playback] selector switch
1 2 3
(DMC-FH25)
1 23
(DMC-FH5) (DMC-FH2)
4109
57
8
6
DMC-FH25&FH5&FH2P-VQT3D30_eng.book 9 ページ ２０１０年１２月２日 木曜日 午後８時３８分

VQT3D30 (ENG)
10
10 Cursor buttons
A: 3/Exposure compensation
B: 4/Macro Mode
AF Tracking
C: 2/Self-timer
D: 1/Flash setting
11 Strap eyelet
•Be sure to attach the strap when
using the camera to ensure that
you will not drop it.
12 Lens barrel
13 [AV OUT/DIGITAL] socket
In this owner’s manual, the cursor buttons are described as shown in the
figure below or described with 3/4/2/1.
e.g.: When you press the 4(down) button
or Press 4
12
1
3
11
DMC-FH25&FH5&FH2P-VQT3D30_eng.book 10 ページ ２０１０年１２月２日 木曜日 午後８時３８分

11
(ENG) VQT3D30
14 Camera ON/OFF switch
15 Zoom lever
16 Speaker
•Do not cover the speaker with
your fingers.
17 Microphone
18 Shutter button
19 (DMC-FH25)
[E.ZOOM] button
20 Tripod receptacle
21 Card/Battery door
23 (DMC-FH5) (DMC-FH2)
Release lever
22 DC coupler cover
•When using an AC adaptor,
ensure that the Panasonic DC
coupler (DMW-DCC10; optional)
and AC adaptor (DMW-AC5PP;
optional) are used.
•Always use a genuine Panasonic
AC adaptor (DMW-AC5PP;
optional).
•It is recommended to use a fully
charged battery or AC adaptor
(DMW-AC5PP; optional) and DC
coupler (DMW-DCC10; optional)
when recording motion pictures.
•If while recording motion pictures
using the AC adaptor and the
power supply is cut off due to a
power outage or if the AC adaptor
is disconnected etc., the motion
picture being recorded will not be
recorded.
15
16 17 18 19
14
(DMC-FH25)
14 15
17 18
(DMC-FH5) (DMC-FH2)
ヮユヮヰンヺチヤモンュチバ
ャモヵヵユンヺ
21
22
20
ヮユヮヰンヺチヤモンュチバチャモヵヵユンヺ
ヰヱユワ ロヰヤレ
21
2322
20
16
VQT3D30~Body1_eng.fm 11 ページ ２０１０年１２月１１日 土曜日 午後６時２０分

VQT3D30 (ENG)
12
Charging the Battery
∫About batteries that you can use with this unit
Supplied battery or dedicated optional batteries (DMW-BCK7PP) can be
used with this unit.
•Use the dedicated charger and battery.
•The battery is not charged when the camera is shipped. Charge the battery
before use.
•Charge the battery with the charger indoors.
It has been found that counterfeit battery packs which look very similar
to the genuine product are made available to purchase in some markets.
Some of these battery packs are not adequately protected with internal
protection to meet the requirements of appropriate safety standards.
There is a possibility that these battery packs may lead to fire or
explosion. Please be advised that we are not liable for any accident or
failure occurring as a result of use of a counterfeit battery pack. To
ensure that safe products are used we would recommend that a genuine
Panasonic battery pack is used.
Charging
Attach the battery paying
attention to the direction of the
battery.
Connect the charger to the
electrical outlet.
•Disconnect the charger from the
electrical socket and detach the battery
after charging is completed.
DMC-FH25&FH5&FH2P-VQT3D30_eng.book 12 ページ ２０１０年１２月２日 木曜日 午後８時３８分

13
(ENG) VQT3D30
∫About the [CHARGE] indicator
The [CHARGE] indicator turns on:
The [CHARGE] indicator Ais turned on during charging.
The [CHARGE] indicator turns off:
The [CHARGE] indicator Awill turn off once the charging has completed without
any problem.
•When the [CHARGE] indicator flashes
–The battery temperature is too high or too low. It is recommended to charge
the battery again in an ambient temperature of between 10 oC to 30 oC (50 oF
to 86 oF).
–The terminals of the charger or the battery are dirty. In this case, wipe them
with a dry cloth.
∫Charging time
Supplied battery Optional battery
Charging time Approx. 115 min Approx. 120 min
DMC-FH25&FH5&FH2P-VQT3D30_eng.book 13 ページ ２０１０年１２月２日 木曜日 午後８時３８分

VQT3D30 (ENG)
14
(DMC-FH25)
(DMC-FH5)
(DMC-FH2)
Recording conditions by CIPA standard:
•CIPA is an abbreviation of [Camera & Imaging Products Association].
•Normal Picture Mode
•Temperature: 23 oC (73.4 oF)/Humidity: 50%RH when LCD monitor is on.
•Using a Panasonic SD Memory Card (32 MB).
•Starting recording 30 seconds after the camera is turned on. (When the Optical
Image Stabilizer function is set to [ON].)
•Recording once every 30 seconds with full flash every second recording.
•Rotating the zoom lever from Tele to Wide or vice versa in every recording.
•Turning the camera off every 10 recordings and leaving it until the temperature
of the battery decreases.
Approximate operating time and number of recordable pictures
Supplied battery Optional battery
Capacity of the battery 660 mAh 680 mAh
Number of recordable
pictures Approx. 250 pictures Approx. 255 pictures
Recording time Approx. 125 min Approx. 127 min
Supplied battery Optional battery
Capacity of the battery 660 mAh 680 mAh
Number of recordable
pictures Approx. 260 pictures Approx. 265 pictures
Recording time Approx. 130 min Approx. 132 min
Supplied battery Optional battery
Capacity of the battery 660 mAh 680 mAh
Number of recordable
pictures Approx. 270 pictures Approx. 275 pictures
Recording time Approx. 135 min Approx. 137 min
Supplied battery Optional battery
Playback time Approx. 200 min Approx. 205 min
DMC-FH25&FH5&FH2P-VQT3D30_eng.book 14 ページ ２０１０年１２月１１日 土曜日 午後４時１３分

15
(ENG) VQT3D30
About the Built-in Memory/the Card
•Memory size: Approx. 70 MB
•The access time for the built-in memory may be longer than the access time for
a card.
The following cards, which conform to the SD video standard, can be used with
this unit.
(These cards are indicated as card in the text.)
¢SD Speed Class is the speed standard regarding continuous writing. Check
via the label on the card, etc.
•Please check the website for updated information:
http://panasonic.jp/support/global/cs/dsc/
(This Site is English only.)
Note
•Keep the Memory Card out of reach of children to prevent swallowing.
Built-in Memory
Card
Type of card which
can be used with
this unit
Remarks
SD Memory Card
(8 MB to 2 GB)
•Use a card with SD Speed Class¢with “Class 6” or
higher when recording motion pictures.
•SDHC Memory Card can be used with SDHC Memory
Card or SDXC Memory Card compatible equipment.
•SDXC Memory Card can only be used with SDXC
Memory Card compatible equipment.
•Check that the PC and other equipment are compatible
when using the SDXC Memory Cards.
http://panasonic.net/avc/sdcard/information/
SDXC.html
•Only the cards with capacity listed left can be used.
SDHC Memory Card
(4 GB to 32 GB)
SDXC Memory Card
(48 GB, 64 GB)
e.g.:
DMC-FH25&FH5&FH2P-VQT3D30_eng.book 15 ページ ２０１０年１２月１１日 土曜日 午後４時１３分

VQT3D30 (ENG)
16
Inserting and Removing the Card
(optional)/the Battery
•Check that this unit is turned off.
•We recommend using a Panasonic card.
(DMC-FH25)
Slide the card/battery door to
open it.
•Always use genuine Panasonic
batteries (NCA-YN101G; supplied or
DMW-BCK7PP; optional).
•If you use other batteries, we cannot
guarantee the quality of this product.
Battery: Being careful about the
battery orientation, insert all the
way until you hear a locking
sound and then check that it is
locked by lever A.
Pull the lever Ain the direction of
the arrow to remove the battery.
Card: Push it securely all the way
until you hear a “click” while
being careful about the direction in which you insert it.
To remove the card, push the card until it clicks, then pull
the card out upright.
B: Do not touch the connection terminals of the card.
1:Close the card/battery door.
2:Firmly slide the card/battery
door to the end until you hear a
locking sound.
ヮユヮヰンヺチヤモンュチバ
ャモヵヵユンヺ
ヵ
ユンヺ ヤモンュ
DMC-FH25&FH5&FH2P-VQT3D30_eng.book 16 ページ ２０１０年１２月１１日 土曜日 午後４時１３分

17
(ENG) VQT3D30
(DMC-FH5) (DMC-FH2)
Slide the release lever in the
direction of the arrow and open
the card/battery door.
•Always use genuine Panasonic
batteries (NCA-YN101G; supplied or
DMW-BCK7PP; optional).
•If you use other batteries, we cannot
guarantee the quality of this product.
Battery: Being careful about the
battery orientation, insert all the
way until you hear a locking
sound and then check that it is
locked by lever A.
Pull the lever Ain the direction of
the arrow to remove the battery.
Card: Push it securely all the way
until you hear a “click” while
being careful about the direction in which you insert it.
To remove the card, push the card until it clicks, then pull
the card out upright.
B: Do not touch the connection terminals of the card.
1:Close the card/battery door.
2:Slide the release lever in the
direction of the arrow.
ヮ
ユヮヰンヺチヤモンュチバチャモヵヵユンヺ
ヰヱユワ ロヰヤレ
ヵヵユンヺ ヤモンュ
ヮヰンヺチヤモンュチバチャモヵヵユンヺ
ヰヱユワ ロヰヤレ
DMC-FH25&FH5&FH2P-VQT3D30_eng.book 17 ページ ２０１０年１２月１１日 土曜日 午後４時１３分

VQT3D30 (ENG)
18
Setting Date/Time (Clock Set)
•The clock is not set when the camera is shipped.
Slide the [Rec]/[Playback]
selector switch to [!] and then
turn the camera on.
Press [MENU/SET].
Press 2/1to select the items (year,
month, day, hour, minute, display
sequence or time display format),
and press 3/4to set.
•You can cancel without setting the clock by pressing [ ].
Press [MENU/SET] to set.
Press [MENU/SET].
Select [Clock Set] in the [Rec] or [Setup] menu, and press [MENU/SET].
•It can be changed in steps 3 and 4 to set the clock.
Changing the Clock Setting
DMC-FH25&FH5&FH2P-VQT3D30_eng.book 18 ページ ２０１０年１２月１１日 土曜日 午後４時１３分

19
(ENG) VQT3D30
Selecting the [Rec] Mode
∫List of [Rec] Modes
Slide the [Rec]/[Playback]
selector switch to [!].
Press [MODE].
Press 3/4/2/1to select the
mode.
Press [MENU/SET].
¦Intelligent Auto Mode
The subjects are recorded using settings automatically selected by the camera.
!Normal Picture Mode
The subjects are recorded using your own settings.
My Scene Mode
Pictures are taken using previously registered recording scenes.
ÛScene Mode
This allows you to take pictures that match the scene being recorded.
$Motion Picture Mode
This mode allows you to record motion pictures with audio.
DMC-FH25&FH5&FH2P-VQT3D30_eng.book 19 ページ ２０１０年１２月１１日 土曜日 午後４時１３分

VQT3D30 (ENG)
20
[Rec] Mode: ñ
Taking pictures using the automatic
function (ñ: Intelligent Auto Mode)
The camera will set the most appropriate settings to match the subject and the
recording conditions so we recommend this mode for beginners or those who
want to leave the settings to the camera and take pictures easily.
Slide the [Rec]/[Playback]
selector switch to [!], and
then press [MODE].
Press 3/4/2/1to select [Intelligent Auto], and then
press [MENU/SET].
Press the shutter button halfway to
focus.
•The focus indication 1(green) lights when
the subject is focused.
•The AF area 2is displayed around the
subject’s face by the Face Detection function.
In other cases, it is displayed at the point on
the subject which is in focus.
Press the shutter button fully (push
it in further), and take the picture.
1
2
DMC-FH25&FH5&FH2P-VQT3D30_eng.book 20 ページ ２０１０年１２月１１日 土曜日 午後４時１３分
