Panasonic ES2067 User manual

© Panasonic Electric Works Co., Ltd. 2008.
All rights reserved. Unauthorized copying and distri-
bution is a violation of law.
Order Number PCD0810X38CE
Epilator
Model No. ES2067
Europe
Oceania
TABLE OF CONTENTS
PAGE PAGE
1 Warning -------------------------------------------------------------- 2
2 Specifications ----------------------------------------------------- 2
3 Troubleshooting Guide ----------------------------------------- 3
4 Disassembly and Assembly Instructions ---------------- 5
5 Schematic Diagram ---------------------------------------------- 8
6 Exploded View and Replacement Parts List ------------ 9

2
1Warning
Caution:
• Pb free solder has a higher melting point that standard solder; Typicall the melting point is 50 - 70°F (30 - 40°C) higher. Please
use a soldering iron with temperature control and adjust it to 750 ± 20°F (400 ± 10°C). In case of using high temperature solder-
ing iron, please be careful not to heat too long.
• Pb free solder will tend to splash when heated too high (about 1100°F / 600°C).
2 Specifications

3
3 Troubleshooting Guide

4

5
4 Disassembly and Assembly Instructions
Follow the procedure below to disassemble the main unit.
4.1. Disassembly Instructions
[MAIN UNIT]
Follow the procedure below to disassemble the main body.
1. Remove the cap and the epilation head.
Loosen two screws on top and take out the mounting
base B.
2. Remove the gear. Remove the head release button with
pushing the buttons.
3. Loosen two screws where tightening the mounting base
A.
Insert the motor remove jig into the connecting area of
adaptor and push up the motor block.
Take out the motor assembly.

6
4. Unsolder the three locations, battery terminals, motor
lead wires and plug chassis.
NOTE:
If the motor lead wires are attached the opposite pole,
the rotation speed will be decrease and the life of
motor will become short.
5. Lift up the plug chassis.
6. Remove the epilation head frame.
7. Loosen seven screws where tightening the gear case
retaining plate.
8. Take out the disc.
NOTE:
Make sure not to loose the springs and click plate.

7
4.2. Assembly Instructions
[MAIN UNIT]
For assembly, reverse the order of disassembly.
1. Confirm the colors of each lead wire when soldering with
motor.
2. Press fit the lead wires into housing neatly.
3. Put fuse onto the motor and fixed it with the motor cush-
ion.
4. Press fit the plug chassis into the motor base block until
clicking between the hook of plug chassis and the hole of
motor base. Attach the O-rings.
5. Set the discs with care of their directions. And put the
click plate properly.

8
5 Schematic Diagram

Model No. : ES2067 Exploded View

Model No. : ES2067 Parts List
Safety
Ref.
No. Part No. Part Name & Description Q'ty Remarks
1 WES2067G3137 EPILATION HEAD FRAME FOR LEGS/ARMS 1 <BG>
2 WES2045L9008 TAPPING SCREW 9 (K2-6), <BG>
3 WES2067L0207 GEAR CASE RETAINING PLATE 1 <BG>
4 WES2067L1267 EPILATION HEAD FOR LEGS/ARMS 1 <BG>
5 WES2067L0197 FLOAT SPRING 3 <BG>
6 WES2067W4937 GEAR CASE FOR LEGS/ARMS 1 <BG>
7 WES2067W3387 MOUNTING BASE B 1 <BG>
8 WES2067W3277 HEAD RELEASE BUTTON W/SPRING 1 <BG>
9 WES2067L1297 GEAR 1 <BG>
10 WES701S9706 SCREW 2 (K2-12), <BG>
11 WES8016L0967 SCREW O-RING 3 <BG>
12 WES2047S9707 SCREW 1 (K2-8), <BG>
13 WES2047L4207 MOUNTING BASE A 1 <BG>
14 WES2067L0997 HOUSING O-RING 1 <BG>
15 WES2067L1007 MOTOR ASSEMBLY 1 <BG>
16 WES8176L2509 RECHARGEABLE BATTERY 1 (Li-ion TYPE), <BG>
17 WES2067L2107 MODULE 1 <BG>
18 WES2067L2157 PLUG CHASSIS 1 <BG>
19 WES2047L0327 O-RING A 2 (2PCS/PK), <BG>
20 WES2067W3050 HOUSING 1 (EUROPE), <BG>
20 WES2067W3051 HOUSING 1 (OCEANIA), <BG>
21 WES2067X7157 PROTECTION CAP 1 <BG>
22 WES2067W3127 EPILATION HEAD FRAME WITH FOAM KEEPER FO
R UNDERARMS/BIKINI-LINE 1<BG>
23 WES2067W1077 EPILATION HEAD FOR UNDERARMS/BIKINI-LINE 1 <BG>
24 WES2067X3558 BIKINI COMB 1 <BG>
25 WES2067W4037 FOIL FRAME 1 <BG>
26 WES9753Y OUTER FOIL 1
27 WES9752Y INNER BLADE 1
28 WES2067W0787 SHAVER HEAD 1 <BG>, <BG>
29 WES2067W7664 POWER ADAPTOR 1 (C-2 PLUG), <BG>
29 WES2067W7666 POWER ADAPTOR 1 (O PLUG), <BG>
30 WES2067X7187 STAND 1 <BG>
31 WES2047H6767 CLEANING BRUSH 1 <BG>
32 WES2067W7008 SOFT CASE 1 <BG>
- WES2067W8000 INDIVIDUAL PACKAGE 1 (EUROPE), <BG>
- WES2067W8001 INDIVIDUAL PACKAGE 1 (OCEANIA), <BG>
- WES2067W8208 FLOWER LABEL 1 <BG>
- WES2067W8100 OPERATING INSTRUCTIONS 1 (EUROPE), <BG>
- WES2067W8101 OPERATING INSTRUCTIONS 1 (OCEANIA), <BG>
