Panasonic SC-DT100 User manual

DVD System
GN GCSEB EEE
Operating Instructions
Model No. SC-DT300
GCT
Model No. SC-DT100
SC- SV1
SC- SV1
SC- SV1
The illustrations show SC-DT300.
[DT300] [DT100]
AUDIO
/
VIDEO
[DT300]: indicates features applicable to SC-DT300 only.
[DT100]: SC-DT100 only.
RQT6387-B
Region number supported by
this player
Region numbers are allocated to DVD players
and DVD-Video according to where they are
sold.
≥The region number of this player is “2”.
≥The player will play DVD-Video marked with
labels containing “2” or “ALL”.
Example:
≥The region number of this player is “3”.
≥The player will play DVD-Video marked with
labels containing “3” or “ALL”.
Example:
≥The region number of this player is “4”.
≥The player will play DVD-Video marked with
labels containing “4” or “ALL”.
Example:
≥The region number of this player is “5”.
≥The player will play DVD-Video marked with
labels containing “5” or “ALL”.
Example:
For the United Kingdom and
Continental Europe
For Asia
For Australia and N.Z.
For Russia
2ALL 35
2
3ALL 36
2
4ALL 46
2
5ALL 56
2
Note:
“EB” on the packaging indicates the United Kingdom.
Before connecting, operating or adjusting this product,
please read these instructions completely.
Please keep this manual for future reference.

Getting started
RQT6387
2
VAROITUS!
LAITTEEN KÄYTTÄMINEN MUULLA KUIN TÄSSÄKÄYT-
TÖOHJEESSA MAINITULLA TAVALLA SAATTAA ALTISTAA
KÄYTTÄJÄN TURVALLISUUSLUOKAN 1 YLITTÄVÄLLE
NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE.
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. RE-
FER SERVICING TO QUALIFIED PERSONNEL. VAROITUS:
TULIPALO-, SÄHKÖISKUVAARAN TAI TUOTETTA KOHTAAVAN
MUUN VAHINGON VÄHENTÄMISEKSI EI LAITETTA SAA AL-
TISTAA SATEELLE, KOSTEUDELLE, VESIPISAROILLE TAI
ROISKEELLE, EIKÄNESTETTÄSISÄLTÄVIÄESINEITÄ, KUTEN
ESIMERKIKSI MALJAKOITA, SAA ASETTAA LAITTEEN PÄÄLLE.
VAROITUS!
≥ÄLÄASENNA TAI LAITA TÄTÄLAITETTA KABINET-
TITYYPPISEEN KIRJAKAAPPIIN TAI MUUHUN SULJETTUUN
TILAAN, JOTTA TUULETUS ONNISTUISI. VARMISTA, ETTÄ
VERHO TAI MIKÄÄN MUU MATERIAALI EI HUONONNA TUULE-
TUSTA, JOTTA VÄLTETTÄISIIN YLIKUUMENEMISESTA
JOHTUVA SÄHKÖISKU- TAI TULIPALOVAARA.
≥ÄLÄPEITÄLAITTEEN TUULETUSAUKKOJA SANOMALEH-
DELLÄ, PÖYTÄLIINALLA, VERHOLLA TAI MUULLA VAS-
TAAVALLA ESINEELLÄ.
≥ÄLÄASETA PALAVAA KYNTTILÄÄ TAI MUUTA AVOTULEN
LÄHDETTÄLAITTEEN PÄÄLLE.
≥HÄVITÄPARISTOT LUONTOA VAHINGOITTAMATTOMALLA
TAVALLA.
SUOMI
TÄMÄ LAITE ON TARKOITETTU KÄYTETTÄVÄKSI LEUDOSSA IL-
MASTOSSA.
DETTE APPARATET ER BEREGNET TIL BRUK UNDER MODER-
ATE KLIMAFORHOLD.
ADVARSEL!
≥APPARATET MÅIKKE PLASSERES I EN BOKHYLLE, ET IN-
NEBYGGET KABINETT ELLER ET ANNET LUKKET STED
HVOR VENTILASJONSFORHOLDENE ER UTILSTREKKELIGE.
SØRG FOR AT GARDINER ELLER LIGNENDE IKKE FORVER-
RER VENTILASJONSFORHOLDENE, SÅRISIKO FOR ELEK-
TRISK SJOKK ELLER BRANN FORÅRSAKET AV OVERHETING
UNNGÅS.
≥APPARATETS VENTILASJONSÅPNINGER MÅIKKE DEKKES
TIL MED AVISER, BORDDUKER , GARDINER OG LIGNENDE.
≥PLASSER IKKE ÅPEN ILD, SLIK SOM LEVENDE LYS, OPPÅ
APPARATET.
≥BRUKTE BATTERIER MÅKASSERES UTEN FARE FOR MIL-
JØET.
ADVARSEL:
FOR ÅREDUSERE FAREN FOR BRANN, ELEKTRISK STØT
ELLER SKADER PÅPRODUKTET, MÅDETTE APPARATET IKKE
UTSETTES FOR REGN, FUKTIGHET, VANNDRÅPER ELLER
VANNSPRUT. DET MÅHELLER IKKE PLASSERES GJENSTAND-
ER FYLT MED VANN, SLIK SOM BLOMSTERVASER, OPPÅAP-
PARATET.
ADVARSEL!
DETTE PRODUKTET ANVENDER EN LASER.
BETJENING AV KONTROLLER, JUSTERINGER ELLER ANDRE
INNGREP ENN DE SOM ER BESKREVENT I DENNE BRUKSAN-
VISNING, KAN FØRE TIL FARLIG BESTRÅLING.
DEKSLER MÅIKKE ÅPNES, OG FORSØK ALDRI ÅREPARERE
APPARATET PÅEGENHÅND. ALT SERVICE OG REPARASJON-
SARBEID MÅUTFØRES AV KVALIFISERT PERSONELL.
NORSK
RQLS0233
-
-
-
-
-
-
-
-
-
-
VISIBLE AND INVISIBLE LASER RADIATIONWHEN OPEN.
AVOID DIRECT EXPOSURETO BEAM.
DANGER
(FDA 21 CFR)
(IEC60825-1)
VISIBLE AND INVISIBLE LASER RADIATIONWHEN OPEN.
AVOID EXPOSURETO BEAM.
CAUTION
RAYONNEMENT LASERVISIBLE ET INVISIBLE EN CAS D’OUVERTURE.
EXPOSITION DANGEREUSE AU FAISCEAU.
ATTENTION
SYNLIG OG USYNLIG LASERSTRÅLINGVED ÅBNING.
UNDGÅUDSÆTTELSE FOR STRÅLING.
ADVARSEL
AVATTAESSA OLET ALTTIINA NÄKYVÄÄ JA NÄKYMÄTÖN
LASERSÄTEILYLLE. ÄLÄKATSO SÄTEESEEN.
VARO!
SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA DEL
ÄR ÖPPNAD.BETRAKTA EJ STRÅLEN.
VARNING
SYNLIG OG USYNLIG LASERSTRÅLING NÅR DEKSEL ÅPNES.
UNNGÅEKSPONERING FOR STRÅLEN.
ADVARSEL
SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG,WENN ABDECKUNG
GEÖFFNET. NICHT DEM STRAHL AUSSETZEN.
VORSICHT
(Inside of product)
(Tuotteen sisällä)
(Produktets innside)
LUOKAN 1 LASERLAITE
KLASS 1 LASER APPARAT
CLASS 1
LASER PRODUCT
(Back of product)
THIS UNIT IS INTENDED FOR USE IN TROPICAL CLIMATES.
THIS UNIT IS INTENDED FOR USE IN MODERATE CLIMATES.
[For\Southeast\Asia]
[For\others]
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PROD-
UCT DAMAGE, DO NOT EXPOSE THIS APPARATUS TO RAIN,
MOISTURE, DRIPPING OR SPLASHING AND THAT NO OBJECTS
FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED
ON THE APPARATUS.
CAUTION!
≥DO NOT INSTALL, OR PLACE THIS UNIT, IN A BOOKCASE,
BUILT-IN CABINET OR IN ANOTHER CONFINED SPACE. EN-
SURE THE UNIT IS WELL VENTILATED. TO PREVENT RISK OF
ELECTRIC SHOCK OR FIRE HAZARD DUE TO OVERHEATING,
ENSURE THAT CURTAINS AND ANY OTHER MATERIALS DO
NOT OBSTRUCT THE VENTILATION VENTS.
≥DO NOT OBSTRUCT THE UNIT’S VENTILATION OPENINGS
WITH NEWSPAPERS, TABLECLOTHS, CURTAINS, AND SIMI-
LAR ITEMS.
≥DO NOT PLACE SOURCES OF NAKED FLAMES, SUCH AS
LIGHTED CANDLES, ON THE UNIT.
≥DISPOSE OF BATTERIES IN AN ENVIRONMENTALLY FRIEND-
LY MANNER.
This product may receive radio interference caused by mo-
bile telephones during use. If such interference is apparent,
please increase separation between the product and the mo-
bile telephone.
Dear customer
Thank you for purchasing this product.
For optimum performance and safety, please read these instructions
carefully.
These operating instructions are applicable to models
SC-DT300 and SC-DT100.
Unless otherwise indicated, illustrations in these operating
instructions are of SC-DT300.
Marking sign is located on bottom of the unit.
AV control receiver (SA-DT300/SA-DT100)
SC-DT300
SL-DT300
SA-DT300
SB-DT300
SB-AFC301
SB-AFC301
SB-W300
System
DVD/CD player
AV control receiver
Front speakers
Center speaker
Surround speakers
Subwoofer
SC-DT100
SL-DT100
SA-DT100
SB-DT100
SB-AFC301
SB-AFC301
SB-W300

3
Getting started
RQT6387
Accessories
Please check and identify the supplied accesso-
ries. Use numbers indicated in parentheses
when asking for replacement parts.
∏1 Remote control
[DT300] (N2QAJB000049)
[DT100] (For The United Kingdom and
Continental Europe: N2QAJB000048)
(For others: N2QAJB000058)
∏2 Batteries
for remote control
∏1 AC mains lead
[For\the\United\Kingdom] [For\Australia\and\N.Z.]
(RJA0053-3X) (RJA0035-2X)
[For\others]
(RJA0019-2X)
∏1 AM loop antenna
(REK0063)
∏1 FM indoor antenna
(RSA0007)
∏1 Video cable
(RJL1P019B15)
∏2 Speaker cables [DT300]
(REX1129)
∏1 Sheet of speaker feet (small)
(25 feet)
∏1 Sheet of speaker feet (large)
(10 feet)
∏4 Spikes [DT300]
(RGG0210-S)
∏1 Sheet of speaker pads [DT300]
(8 pads)
∏1 Cleaning cloth
for main unit
(RFE0088-1)
∏1 Sheet of speaker-cord stickers
(RQCA0950)
[For\the\United\Kingdom\onl ]
∏1 Antenna plug adaptor
(SJP9009)
[For\the\United\Kingdom,\Continental\Europe\and\Russia\
∏1 RCAJ adaptor
(VFA0151-2)
Note
The included AC mains lead is for use with this unit only. Do not
use it with other equipment.
Table of contents
Getting started
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Caution for AC Mains Lead . . . . . . . . . . . . . . . . . 14
Disc information . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Disc handling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Simple setup
STEP 1 Locating. . . . . . . . . . . . . . . . . . . . . . . . . . 6
STEP 2 Connecting the speakers [DT100] . . . . . . 7
Connecting the speakers [DT300] . . . . . . 8
STEP 3 Television and flat cable . . . . . . . . . . . 10
STEP 4 Antennas and AC mains lead . . . . . . . 10
STEP 5 The remote control . . . . . . . . . . . . . . . . 11
STEP 6 Selecting TV screen type . . . . . . . . . . . 11
Control reference guide . . . . . . . . . . . . . . . . . . . . 12
Disc operations
Discs—Basic play. . . . . . . . . . . . . . . . . . . . . . . . . 13
Playing MP3/Resume function . . . . . . . . . . . . . . . . . . . . . . . . 14
Skipping chapters or tracks . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Fast forward and rewind—SEARCH. . . . . . . . . . . . . . . . . . . . 15
Slow-motion play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Frame-by-frame viewing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Starting play from a selected title or track . . . . . . . . . . . . . . . . 15
Selecting groups to play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Selecting still pictures—Page Skip . . . . . . . . . . . . . . . . . . . . . 15
Discs—Convenient functions . . . . . . . . . . . . . . . 16
A-B repeat play/Repeat play . . . . . . . . . . . . . . . . . . . . . . . . . . 16
To enjoy even higher quality sound—AUDIO ONLY. . . . . . . . 16
All group play/Program play/Random play . . . . . . . . . . . . . . . 17
Changing soundtracks, subtitle languages
and angles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Using Graphical User Interface (GUI) screens . . 19
Common procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Disc information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Unit information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Shuttle screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Radio operations
The radio: manual tuning . . . . . . . . . . . . . . . . . . . 22
The radio: preset tuning . . . . . . . . . . . . . . . . . . . . 23
Sound quality/sound field operations
Sound field. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
DOLBY DIGITAL and DTS/DOLBY PRO LOGIC. . . . . . . . . . . 25
SUPER SURROUND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
CENTER FOCUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Changing sound field and quality . . . . . . . . . . . . . . . . . . . . . . 26
Adjusting the bass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Turning the subwoofer off . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Other functions
Convenient functions . . . . . . . . . . . . . . . . . . . . . . 27
Muting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Turning off the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Timer functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Using headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Changing settings. . . . . . . . . . . . . . . . . . . . . . . . . 28
Language code list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Common procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Entering a password (Ratings) . . . . . . . . . . . . . . . . . . . . . . . . 29
Changing the delay time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Using the remote control with other equipment . . 30
Listening to an external source/
Recording to other equipment . . . . . . . . . . . . . 31
Optional antenna connections. . . . . . . . . . . . . . . 32
Reference
Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . 33
Glossary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Troubleshooting guide . . . . . . . . . . . . . . . . . . . . . 34
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Specifications . . . . . . . . . . . . . . . . . . . . Back cover

Getting started
RQT6387
4
Caution for AC Mains Lead
(For United Kingdom)
(“EB”area code model only)
For your safety, please read the following text
carefully.
This appliance is supplied with a moulded three pin
mains plug for your safety and convenience.
A 5-ampere fuse is fitted in this plug.
Should the fuse need to be replaced please ensure
that the replacement fuse has a rating of 5-ampere
and that it is approved by ASTA or BSI to BS1362.
Check for the ASTA mark Ïor the BSI mark Ìon
the body of the fuse.
If the plug contains a removable fuse cover you must
ensure that it is refitted when the fuse is replaced.
If you lose the fuse cover the plug must not be used
until a replacement cover is obtained.
A replacement fuse cover can be purchased from
your local dealer.
If a new plug is to be fitted please observe the wiring
code as stated below.
If in any doubt please consult a qualified electrician.
IMPORTANT
The wires in this mains lead are coloured in accor-
dance with the following code:
Blue: Neutral, Brown: Live.
As these colours may not correspond with the col-
oured markings identifying the terminals in your plug,
proceed as follows:
The wire which is coloured Blue must be connected to
the terminal which is marked with the letter N or col-
oured Black or Blue.
The wire which is coloured Brown must be connected
to the terminal which is marked with the letter L or col-
oured Brown or Red.
WARNING: DO NOT CONNECT EITHER WIRE TO
THE EARTH TERMINAL WHICH IS MARKED WITH
THE LETTER E, BY THE EARTH SYMBOL ÓOR
COLOURED GREEN OR GREEN/YELLOW.
THIS PLUG IS NOT WATERPROOF—KEEP DRY.
Before use
Remove the connector cover.
How to replace the fuse
The location of the fuse differ according to the type of
AC mains plug (figures A and B). Confirm the AC
mains plug fitted and follow the instructions below.
Illustrations may differ from actual AC mains plug.
1. Open the fuse cover with a screwdriver.
2. Replace the fuse and close or attach the fuse
cover.
Fuse cover
Figure A
Figure B
Fuse
(5 ampere)
Fuse
(5 ampere)
Figure A
Figure B
CAUTION!
IF THE FITTED MOULDED PLUG IS UNSUIT-
ABLE FOR THE SOCKET OUTLET IN YOUR
HOME THEN THE FUSE SHOULD BE RE-
MOVED AND THE PLUG CUT OFF AND DIS-
POSED OF SAFELY.
THERE IS A DANGER OF SEVERE ELECTRI-
CAL SHOCK IF THE CUT OFF PLUG IS IN-
SERTED INTO ANY 13-AMPERE SOCKET.

5
Getting started
RQT6387
Disc information
∫Discs that can be played
Disc handling
Do not use irregularly shaped discs, such as heart-shaped.
(These can damage the unit.)
∫How to hold a disc
Do not touch the recorded surface.
∫If the surface is dirty
Wipe it with a damp cloth and then wipe dry.
∫If the disc is brought from a cold to a warm
environment, moisture may form on the disc
Wipe with a soft, dry, lint-free cloth before using the disc.
∫Handling precautions
≥Do not write on the label side with a ball-point pen or other writing
instrument.
≥Do not use record cleaning sprays, benzine, thinner, static electric-
ity prevention liquids or any other solvent.
≥Do not attach labels or stickers to discs. (Do not use discs with
exposed adhesive from tape or left over peeled-off stickers.)
≥Do not use scratch-proof protectors or covers.
≥Do not use discs printed with label printers available on the market.
∫Do not place or store discs in the following
places
≥Locations exposed to direct sunlight
≥Humid or dusty locations
≥Locations directly exposed to a heat vent or heating appliance
∫Discs that cannot be played
DVD-Audio([DT100]), DVD-ROM, DVD-RAM, CD-ROM, CDV, CD-G,
iRW, DVD-RW, CVD, SVCD, SACD, Divx Video Discs and Photo
CD.
∫Playing DVDs and Video CDs
The producer of these discs can control how they are played so you
may not always be able to control play as described in these operat-
ing instructions. Read the disc’s instructions carefully.
∫Video systems
This unit can play both the PAL and NTSC video systems. To view
PAL or NTSC, however, your television must match the system used
on the disc.
PAL discs cannot be correctly viewed on an NTSC television. NTSC
can be correctly viewed on a PAL television by converting the video
signal to PAL 60 (➡page 28, Video—NTSC Disc Output).
∫CD-R and CD-RW discs
This unit can play CD-DA (digital audio) and video CD format audio
CD-R and CD-RW that have been finalized (a process that enables
CD-R/CD-RW players to play audio CD-R and CD-RW) upon com-
pletion of recording.
It may not be able to play some CD-R or CD-RW due to the condition
of the recording.
∫DVD-R discs
Panasonic DVD-R recorded and finalized on a Panasonic DVD video
recorder are played as DVD-Video on this unit.
It may not be possible to play these discs in all cases due to the type
of disc or condition of the recording.
LogoDisc type
[DT300]
DVD-Audio
DVD-Video
DVD-R
Audio CD
Video CD
Indication used in
instructions
[DVD-A]
[DVD-V]
[CD]
(Including CD-R/RW
and discs recorded
with MP3)
[VCD]

Simple setup
RQT6387
6
120˚
30
˚
30
˚
2
4
6
5
<
;
1
<
PWRÍ/ISELECT
VOLUME
DOWNUP
PLAY/REC
1
3
Simple setup
STEP1 Locating [DT300] ]DT100]
If irregular coloring occurs on your television
These speakers are designed to be used close to a television, but
the picture may be affected with some televisions and setup com-
binations.
If this occurs, turn the television off for about 30 minutes.
The television’s demagnetizing function should correct the
problem. If it persists, move the speakers further away from the
television.
Use only supplied speakers
Using other speakers can damage the unit and sound quality will be negatively affected.
Set the speakers up on an even surface to prevent them from falling. Take proper precautions to prevent the speakers from falling if you
cannot set them up on an even surface.
Place the front, center, and surround speakers at approximately the same distance from the seating position. The angles in the diagram are
approximate.
Front speakers (1Left 2Right)
[DT300] SB-DT300 [DT100] SB-DT100
≥Place it at least 15 cm away from wall surfaces to avoid
distortion and unwanted acoustical effects.
≥The left and right speakers are the same.
Surround speakers (3Left 4Right) SB-AFC301
Place either side of the seating position, or slightly to the
rear, about 1 meter higher than ear level.
≥The left and right speakers are the same.
Center speaker (5) SB-AFC301
≥You can also put this speaker directly under the
television.
≥Do not place the center speaker on the main unit
as sound quality will be affected.
≥Vibration caused by the center speaker can dis-
rupt the picture if it is placed directly on the tele-
vision. Put the center speaker on a rack or shelf.
Subwoofer (6) SB-W300
Place near the television, on the floor or a sturdy shelf so
that it won’t cause vibration.
Main unit
Keep your speakers
at least 10 mm away
from the system for
proper ventilation.
≥After you have completed setup and connection, wind the ex-
cess cord and keep together with string.
≥The front speaker nets can be removed.
Notes on speaker use
≥You can damage your speakers and shorten their useful life if
you play sound at high levels over extended periods.
≥Reduce the volume in the following cases to avoid damage.
–When playing distorted sound.
–When the speakers are receiving howling from a microphone
or record player, noise from FM broadcasts, or continuous sig-
nals from an oscillator, test disc, or electronic instrument.
–When adjusting the sound quality.
–When turning the unit on or off.
Caution
≥Use the speakers only with the recommended system.
Failure to do so may lead to damage to the amplifier
and/or the speakers, and may result in the risk of fire.
Consult a qualified service person if damage has oc-
curred or if you experience a sudden change in per-
formance.
≥Do not attempt to attach these speakers to walls using
methods other than those described in this manual.
Stacking
AV control receiver
DVD/CD Player

Simple setup
7
RQT6387
FRONTHF/LFSURROUND CENTER
SUB
WOOFER
6
SUB
WOOFE
R
5
CENTER
4
SURROUND
Rch
3
3
4
5
61
L
2
RLR
SURROUND
Lch
2
FRONT
Rch
1
FRONT
Lch
SUBWOOFER
CENTER
SURROUND(R)
FRONT(R)
FRONT(L)
SURROUND(L)
Connecting the speakers [DT100]
STEP2
1 Attach the stickers to the speaker cords.
Attach the speaker-cord stickers to make connection easier.
FRONT L, R
e.g.) FRONT L
2 Connecting
Match the labels on the speaker stickers with the labels on the terminals.
3 Attach the speaker feet.
≥Attach the speaker feet to the bases of the speakers to help stop them from moving due to vibration.
≥You can set the speakers up at an angle by attaching two large speaker feet to the front of each speaker.
5
CENTER
6
SUB
WOOFER
1
FRONT
L ch
To face up
Base
AV control receiver
To disconnect
Press on the hook and pull.
Hook
SURROUND, CENTER
e.g.) CENTER
SUBWOOFER
speaker-cord stickers
Insert with the hook
down, until it clicks
into place.
Sheet of
speaker feet
(small )
Sheet of
speaker feet
(small )
Sheet of
speaker feet
(large) To attach center and surround speakers to a wall or
speaker stands (➡page 9)

Simple setup
RQT6387
8
2 Connecting
Match the labels on the speaker stickers with the labels on the terminals.
FRONT
1
2
3
4
5
6
L
R
L
R
HF
LF
HF
LF
HF
LF
FRONTHF/LFSURROUND CENTER
SUB
WOOFER
2
FRONT
Rch
FRONT
LF Rch
FRONT
HFRch
1
FRONT
L ch
FRONT
HF Lch
FRONT
LFLch
1 Attach the stickers to the speaker cords.
Attach the speaker-cord stickers to make connection easier.
FRONT L, R
e.g.) FRONT L
Simple setup
Connecting the speakers [DT300]
STEP2
To disconnect
Press on the hook and pull.
Insert with the hook
down, until it clicks
into place.
SURROUND, CENTER, SUBWOOFER AV control receiver
SURROUND, CENTER
e.g.) CENTER
SUBWOOFER
speaker-cord stickers
2
3
41
L
5
R
L
R
6
FRONTHF/LFSURROUNDCENTER
SUB
WOOFER
21
6
SUB
WOOFE
R
5
CENTER
4
SURROUND
Rch
3
SURROUND
Lch
SUBWOOFER
CENTER
SURROUND(R)
SURROUND(L)
Hook
Push the lever in the di-
rection indicated by the
allow, insert the wire,
then release the lever.
Copper
Silver
Copper
Silver
To prevent damage to circuitry, never short-circuit pos-
itive (r) and negative (s) speaker wires.
AV control receiver
HF: High Frequency
LF: Low Frequency
Right Left
These front speakers are bi-wired for high quality sound reproduction.
Copper: r
Silver: s
Hook
5
CENTER
6
SUB
WOOFER
1
FRONT
Lch
FRONT
HFLch
FRONT
LF Lch

Simple setup
9
RQT6387
[DT300] ]DT100]
Attaching to a wall
Center and surround speakers can be attached to a wall.
Set the speaker onto screw and slide through bracket to lock into
position.
Note
The wall or pillar on which the speakers are to be attached should
be capable of supporting 10 kgper screw.
Attaching to speaker stands
Ensure the following conditions are met when you purchase your
speaker stands.
≥Observe the diameter and length of the screws and the distance
between screws as shown in the diagram.
≥The stands must be able to support over 10 kg.
≥The stands must be stable even if the speakers are in a high
position.
3 Attach the spikes and speaker feet to the bases of the front speakers.
These help stop the speakers from moving due to vibration and also change their angle.
To protect surfaces from scratching
1. Adhere two pads together. 2. Place the pads under the spikes.
≥If you put the speakers in a position where it is not appropriate to attach the spikes, attach speaker feet in ther place.
≥Use speaker feet for the remaining speakers.
≥You can set the surround and center speakers up at an angle by attaching two large speaker feet to the front.
≥Remove the seals from the adhesive surfaces of the spikes and
speaker feet.
≥Be sure to attach the spikes to the front of the speaker's base.
To face up
Speaker net
Sheet of
speaker feet
(small )
Spikes
Pads
Adhesive
surface
30–35 mm
7.5–9.5 mm
7–9 mm
Speaker feet
Speaker feet
Screw
(not included)
Attach the stands
with these holes.
5 mm,
pitch 0.8 mm
Plate thickness
plus 7 to 10 mm
Speaker stand
(not included)
60 mm
Base
Sheet of
speaker feet
(small )
Sheet of
speaker feet
(small)
Sheet of
speaker feet
(large)

Simple setup
RQT6387
10
AC IN
1
3
1
2
Adhesive tape
FM indoor antenna
Fix the other end of the antenna
where reception is best. AM loop antenna
Stand the antenna up on its base.
Keep loose antenna cord away from other wires and cords.
To household
mains socket
AC mains lead (included)
Insertion of connector
Even when the connector is perfectly
inserted, depending on the type of inlet
used, the front part of the connector
may jut out as shown in the drawing.
However there is no problem using the unit.
Conserving power
The unit consumes power (approx. 0.7 W) even when it is turned off
with [Í]. To save power when the unit is not to be used for a long time,
unplug it from the household mains socket. Remember to reset the ra-
dio stations and any other memory items before using the unit again.
For your reference
Information you enter into the unit’s memory remains intact for up to
a week after the AC mains lead is disconnected.
[For\the\United\Kingdom\onl ]
BE SURE TO READ THE CAUTION FOR THE AC MAINS
LEAD ON PAGE 4 BEFORE CONNECTION.
Television and flat cable [DT300] ]DT100]
STEP3
Connect directly to your television.
Do not connect the unit through a video cassette recorder, because the picture may not be played correctly due to the copy guard.
Antennas and AC mains lead [DT300] ]DT100]
STEP4
S-VIDEO OUT terminal
The S-video terminal achieves a more vivid picture than the VIDEO
OUT terminal by separating the chrominance (C) and luminance(Y)
signals. (Actual results depend on the television.)
Appliance inletConnector
Approx. 6 mm
[For\the\United\Kingdom,\Continental\Eupope\and\Russia]
Use the RCAJ adaptor (included) if your television
has a 21-pin SCART terminal. You do not have to
connect anything to the AUDIO terminals.
VIDEO
OUT
Video terminal
Video cable
(included) To your
television
Audio terminals
RCAJ adaptor
VIDEO
OUT
S-VIDEO
OUT
1
1
2
VIDEO
IN
To connect
cable To unplug cable
Noise filter
≥Leave the noise filter attached.
Simple setup
Video
cable
(included)

Simple setup
11
RQT6387
The remote control [DT300] ]DT100]
STEP5
1
2
3
∫Batteries
Do not;
≥mix old and new batteries.
≥use different types at the same time.
≥heat or expose to flame.
≥take apart or short circuit.
≥attempt to recharge alkaline or manganese batteries.
≥use batteries if the covering has been peeled off.
Mishandling of batteries can cause electrolyte leakage which can
damage items the fluid contacts and may cause a fire.
Remove if the remote control is not going to be used for a long period
of time. Store in a cool, dark place. ≥Insert so the poles (iand j) match those in the remote control.
≥Do not use rechargeable type batteries.
∫Use
Aim at the sensor, avoiding obstacles, at a maximum range of 7 m
directly in front of the unit.
4Press [SETUP] to show the menus.
5 Press [2, 1] to select the “Video”tab.
6Press [3, 4] to select “TV Aspect”
and press [ENTER].
7Press [3, 4] to select the item and
press [ENTER].
≥4:3 Pan&Scan (Factory preset)
Select if you have a regular
television and to view 16:9 software
in the pan and scan style.
≥4:3 Letterbox
Select if you have a regular
television and to view 16:9 software
in the letterbox style.
≥16:9
Select if you have a widescreen (16:9) television.
Use the television’s screen modes to change the way the
picture is shown.
8Press [SETUP] to end the settings.
To return to the previous screen
Press [RETURN].
SLOW/SEARCH
MENUTOP MENU
CH
SELECT
TEST
ENTER
SET
OSD
TIMER
RDS
PLAY MODE
DISPLAY
SETUP AUDIO ANGLE
SUBTITLE
RETURN
GROUP
X
TUNER/BAND
TV FM MODE
W
123
456
21·3
5·6·7
4·8
DVD/CD
AUDIO ONLY
PAGE
VCR TV/AV
SKIP
RETURN
Change the setting to suit your television.
The menu language is set to English, but you can change it
(➡page 28, Display—Menu Language). English is used in
the examples.
Preparation
Turn on the television and select the appropriate video input on the
television to suit the connections for the unit.
1 Press either [DVD/CD] or [TUNER/BAND]
to set the remote control to operate this
unit.
2 Press [ Í ] to turn on the unit.
3 Press [DVD/CD] to select “DVD” .
Disc
SELECT
Audio
Subtitle
Menus
Ratings
English
English
Automatic
Level 8
SETUP
Selecting TV screen type [DT300] ]DT100]
STEP6
R6, AA, UM-3
16:9 software prohibited from being shown in the pan
and scan style will appear in the letterbox style de-
spite the setting here.

Getting started
RQT6387
12
Control reference guide
Remote control
1TV button [TV] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
2Standby/on button [Í] . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3Skip, Channel select, VCR, TV/AV buttons
[:, 9, X X
X X
X, WW
WW
W, VCR, TV/AV] . . . . . . . . . . . . . . . 15, 22, 30
4Stop buttons [∫] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5Top menu button [TOP MENU] . . . . . . . . . . . . . . . . . . . . . . 14
6Cursor buttons [3, 4, 2, 1]/
Enter, SET button [ENTER, SET] . . . . . . . . . . . . . . . . . 11, 23
[DT300] These buttons have the following functions.
[3]:[AUDIO ONLY] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
[2]:[GROUP] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
[1]:[PAGE] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
7GUI display button [OSD] . . . . . . . . . . . . . . . . . . . . . . . . . . 19
8Setting button [SETUP] . . . . . . . . . . . . . . . . . . . . . . . . . . . 011
9[For\the\United\Kingdom,\Continental\Europe\and\Russia]
RDS, Timer button [RDS, TIMER] . . . . . . . . . . . . . . . . . 22, 27
[For\Southeast\Asia,\Australia\and\N.Z.]
Timer button [TIMER] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
:Play mode button [PLAY MODE] . . . . . . . . . . . . . . . . . . . . 17
;FL display button [DISPLAY] . . . . . . . . . . . . . . . . . . . . . . . 27
<A-B Repeat button [A-B REPEAT] . . . . . . . . . . . . . . . . . . . 16
=Repeat button [REPEAT] . . . . . . . . . . . . . . . . . . . . . . . . . . 16
>Position memory, Center focus button
[POSITION MEMORY, CENTER FOCUS] . . . . . . . . . . 14, 26
?Subwoofer level, Down mix button
[SUBWOOFER LEVEL, D.MIX] . . . . . . . . . . . . . . . . . . . 25, 26
@Shift button [SHIFT]
AMuting, Super surround button
[MUTING, SUPER SURROUND] . . . . . . . . . . . . . . . . . . 26, 27
BTuner/Band, FM mode button
[TUNER/BAND, FM MODE] . . . . . . . . . . . . . . . . . . . . . . 11, 22
CDVD/CD button [DVD/CD] . . . . . . . . . . . . . . . . . . . . . . . . . . 11
DSlow/Search buttons [6, 5, SLOW/SEARCH] . . . . . . 15
EPlay button [1] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
FPause button [;] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
G Menu button [ MENU ] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
HReturn, Angle button [RETURN, ANGLE] . . . . . . . . . . 11, 18
IAudio button [AUDIO] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
JSubtitle button [SUBTITLE] . . . . . . . . . . . . . . . . . . . . . . . . 18
KNumbered buttons [1–9, 0, S10/-/--] . . . . . . . . . . . . . . . . . 14
LCancel button [CANCEL] . . . . . . . . . . . . . . . . . . . . . . . . . . 17
MSound field control, Test button [SFC, TEST] . . . . . . 25, 26
NDolby Pro Logic, Speaker channel select button
[ÎPL, CH SELECT] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
OVolume, TV Volume buttons [ss
ss
s, rr
rr
r,TV VOLUME] . . . . 13, 30
Main unit
Buttons 4, E and F function the same as the controls on the re-
mote control.
Standby/on switch [Í/I]
Press to switch the unit from on to standby mode or vice versa.
In standby mode, the unit is still consuming a small amount of
power.
Standby/on indicator
When the unit is connected to the AC mains supply, this indicator
lights red in standby mode and lights green when the unit is
turned on.
QSelect button [SELECT] . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
RRemote control signal sensor
SVolume control [VOLUME, DOWN, UP] . . . . . . . . . . . . . . . 13
THeadphone jack [Ë] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
UWake timer indicator [WAKE] . . . . . . . . . . . . . . . . . . . . . . . 27
VDisc tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
WOpen/close button [<] . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
To operate functions labeled in orange, press [SHIFT] and
the corresponding button at the same time.
SLOW/SEARCH
MENUTOP MENU
ENTER
SET
OSD
TIMER
RDS
PLAY MODE
DISPLAY
A-B REPEAT
REPEAT
SFC
PL
CH SELECTD.MIXCENTER FOCUS TEST
SUBWOOFER
LEVEL
POSITION
MEMORY
SHIFT MUTING
TV VOLUME
SUPER
SURROUND
CANCEL
SETUP AUDIO ANGLE
SUBTITLE
RETURN
GROUP
X
TUNER/BAND
TV
VCR TV/AV
FM MODE
W
123
456
78
0
S10/-/--
9
DVD/CD
SKIP
AUDIO ONLY
PAGE
1
2
3
4
5
6
7
9
:
;
<
=
>
@
A
D
E
F
G
H
J
K
L
M
N
O
8
?
I
C
B
Í/I SELECT
VOLUME
DOWN UP
<;1
WAKE
Q
S
RTU
EF4W
V

13
RQT6387
Disc operations
∫
;
SELECT
SLOW/SEARCH
MENUTOP MENU
ENTER
SET
OSD
TIMER
RDS
PLAY MODE
DISPLAY
A-B REPEAT
REPEAT
SFC
PL
CH SELECTD.MIXCENTER FOCUS TEST
SUBWOOFER
LEVEL
POSITION
MEMORY
SHIFT MUTING
SUPER
SURROUND
CANCEL
SETUP AUDIO ANGLE
SUBTITLE
RETURN
GROUP
X
TUNER/BAND
TV
VCR TV/AV
FM MODE
W
123
456
78
0
S10/-/--
9
DVD/CD
SKIP
AUDIO ONLY
PAGE
Í/I SELECT
VOLUME
DOWN UP
WAKE
1·3
6
2
4
7
<;1
TV VOLUME
7
5
Discs—Basic play
[DVD-A] [DVD-V] [CD] [VCD]
Preparation
Turn on the television and select the appropriate video input on the
television to suit the connections for the unit.
1 Press either [DVD/CD] or [TUNER/
BAND] to set the remote control to op-
erate this unit.
2 Press [ Í ] to turn on the unit.
3Press [DVD/CD] to select “DVD”as
the source.
≥Main unit: Press [SELECT].
Each time you press the button:
DVD>TV<AUX>>VCR<EXT>>FM>AM
^--------------------------------------------------------------------}
4Press [<] to open the disc tray.
5Place the disc on the disc tray.
Press again to close and start play.
6If play doesn’t start after step 5
Press [1] (PLAY).
7Adjust the volume.
∫When “D.MIX”is flashing (➡page 25)
∫To stop play
Press [∫] (➡page 14, Resume function).
∫To pause play
Press [;] during play.
Press [1] (PLAY) to restart play.
Note
≥If “$”appears on the television
The operation is prohibited by the unit or disc.
≥The disc continues to rotate while the menu is displayed even after
you finish playing an item. Press [∫] when you finish to preserve
the unit’s motor and your television screen.
≥Volume may be lower when playing DVDs than when playing other
discs or during television broadcasts.
If you turn the volume up, be sure to reduce the volume again be-
fore playing other sources so that a sudden increase in output does
not occur.
Label must face upward.
(With double-sided discs,
load so the label for the side
you want to play is facing
up.)

RQT6387
14
Disc operations
1
∫
POSITION
MEMORY
SHIFT
SLOW/
SEARCH
6, 5
SKIP
:, 9
;
3, 4, 2, 1
GROUP
PAGE
ENTER
SLOW/SEARCH
MENUTOP MENU
ENTER
SET
OSD
TIMER
RDS
PLAY MODE
DISPLAY
A-B REPEAT
REPEAT
SFC
PL
CH SELECTD.MIXCENTER FOCUS TEST
SUBWOOFER
LEVEL
POSITION
MEMORY
SHIFT MUTING
SUPER
SURROUND
CANCEL
SETUP AUDIO ANGLE
SUBTITLE
RETURN
GROUP
X
TUNER/BAND
TV
VCR TV/AV
FM MODE
W
123
456
78
0
S10/-/--
9
DVD/CD
SKIP
AUDIO ONLY
PAGE
TV VOLUME
CANCEL
RETURN
MENU
TOP MENU
Discs—Basic play
Resume function
[DVD-A] [DVD-V] [CD] [VCD]
(When the elapsed play time is displayed)
“RESUME” lights on the display when the unit has recorded the posi-
tion at which you stopped play.
Press [1] (PLAY) to start play from that position.
(When playing DVD-Video ➡Chapter Review below)
≥The position is cleared when you:
— Turn the unit off.
— Open the disc tray or select another source.
≥Press [∫] to clear the position.
Position Memory function [DVD-V] [CD] [VCD]
During play
Press [POSITION MEMORY] to memorize a
position.
This position is saved if you turn the unit off or change the source.
When you turn the unit on or reselect “DVD”, “RESUME” lights on
the display.
Press [1] (PLAY) to start play from the memorized position.
The position is cleared.
(When playing DVD-Video ➡Chapter Review below)
≥The position is cleared when you open the disc tray.
Chapter Review [DVD-V]
One of these messages appears immediately after you press [1]
(PLAY).
Press [1] (PLAY) while the message is displayed and the beginning
portions of each chapter up to the current one are played.
Full play resumes from the point where you pressed [∫] or [POSI-
TION MEMORY].(This feature works only within a title.)
If you do not press [1] (PLAY), the message disappears and play
starts from where you pressed [∫] or [POSITION MEMORY].
Numbered
buttons
Position memorized
Press PLAY to Preview Chapters
Press PLAY to Chapter Review
Playing MP3
[CD]
Discs recorded using MP3 differ to CDs in the following ways.
≥Structure of the disc (example)
≥Starting play from a selected chapter
Press the numbered buttons and press [ENTER].
Example: Chapter 23: [2] ➡[3] ➡[ENTER]
(Pressing [S10/-/--] is unnecessary.)
≥Repeat play
You can use chapter repeat or title repeat (➡page 16).
≥Program play, random play
You cannot use program play or random play.
Note
≥If you play an MP3 track that includes still picture data, it will take
some time before the music itself starts playing and the elapsed
time will not be displayed during this time. Even after the track
starts, the correct play time will not be displayed.
≥This unit is not compatible with ID3 tags.
Refer to the glossary on page 33 for more information about MP3.
When a menu appears on the television
[DVD-A] [DVD-V] [VCD]
Press the numbered buttons to select an
item.
To select a 2-digit number
Example: To select item 23, press [S10/-/--] ➡[2] ➡[3].
≥When playing DVDs, you can also use [3, 4, 2, 1] to select
items. Press [ENTER] to confirm your selection.
Play of the selected item now begins.
Other buttons used to operate menus
Read the disc’s instructions for further details about operation.
[9]: Shows the next menu.
[:]: Shows the previous menu.
[RETURN]: Shows the menu screen. [VCD]
[TOP MENU]: Shows the first menu screen. [DVD-A] [DVD-V]
[MENU]: Shows the menu screen. [DVD-V]
1 2 3 4 5 6 7 8 9
Title
(Folder) Title
Chapter (File)

15
RQT6387
Disc operations
Skipping chapters or tracks
[DVD-A] [DVD-V] [CD] [VCD]
During play or while paused
Press [:] or [9].
≥Each press increases the number of skips.
Fast forward and rewind—SEARCH
[DVD-A] [DVD-V] [CD] [VCD]
During play
Press [6] or [5].
≥Audio will be heard during search for most discs. You can turn this
audio off if you want to (➡page 28, Audio—Audio during Search).
Slow-motion play
[DVD-A] [DVD-V] [VCD]
While paused
Press [6] or [5].
Frame-by-frame viewing
[DVD-A] [DVD-V] [VCD]
While paused
Press [2] or [1].
The frame changes each time you press the button.
≥The frames change in succession if you press and hold the button.
≥Pressing [;] also activates forward frame-by-frame.
Selecting groups to play
[DT300]
[DVD-A]
The tracks on DVD-Audio are divided into groups. How these groups
are played differs with the disc so read the instructions that came
with the disc for further details.
1Press [SHIFT] ii
ii
i[2, GROUP].
2Press the numbered buttons to select
the group and press [ENTER].
3Press the numbered buttons to select
the track number and press [ENTER].
The selected group and track begin to play.
Playing all the groups in succession (➡page 17, All group play)
Playing bonus groups
Some discs contain bonus groups. To enjoy these groups you may
have to enter a password. Refer to the disc’s jacket.
1. Press [2, GROUP] to select the bonus group and press [ENTER].
2. Enter the 4-digit password with the numbered buttons and press
[ENTER].
≥If you enter the wrong password, you can erase a digit by press-
ing [CANCEL].
3. Press the numbered buttons to select a track and press [ENTER].
≥The bonus group can be played as many times as you like after the
password has been entered until the disc is removed from the unit.
Selecting still pictures—Page Skip
[DT300]
[DVD-A]
During play
Press [SHIFT] ii
ii
i[1, PAGE].
The page changes each time you press [SHIFT] ii
ii
i[1, PAGE ].
PAGE 1
T
1
G
1
When playing Video CDs with playback control
Pressing buttons to perform skip, search or slow-motion may
take you to a menu screen.
Notes
≥ The speed of search and slow-motion increases up to 5 steps.
≥Press [1] (PLAY) to restart play.
≥You cannot move backwards with Video CD during frame-
by-frame and slow-motion.
≥Frame-by-frame and slow-motion only work on the moving
picture parts of DVD-Audio.
Starting play from a selected title or
track
[DVD-A] [DVD-V] [CD] [VCD]
Press the numbered buttons to select the
item.
To select a 2-digit number
Example: To select track 23, press [S10/-/--] ➡[2] ➡[3].
Play starts from the selected item.
Note
This works only when stopped with some discs.

RQT6387
16
Disc operations
SLOW/SEARCH
MENUTOP MENU
CH
SELECT
TEST
ENTER
SET
OSD
TIMER
RDS
PLAY MODE
DISPLAY
A-B REPEAT
REPEAT
SFC
PL
CH SELECTD.MIXCENTER FOCUS TEST
SUBWOOFER
LEVEL
POSITION
MEMORY
SHIFT MUTING
SUPER
SURROUND
CANCEL
SETUP AUDIO ANGLE
SUBTITLE
RETURN
GROUP
X
TUNER/BAND
TV FM MODE
W
123
456
78
0
S10/-/--
9
DVD/CD
AUDIO ONLY
PAGE
VCR TV/AV
SKIP
∫
1
3, 4, 2, 1
ENTER
PLAY MODE
A-B REPEAT
REPEAT
CANCEL
TV VOLUME
SLOW/
SEARCH
6, 5
AUDIO ONLY
SHIFT
Discs—Convenient functions
Repeat play
[DVD-A] [DVD-V] [CD] [VCD]
(When the elapsed play time is displayed)
During play
Press [REPEAT].
Each time you press the button:
[DVD-A]
Track --)Whole group --)OFF
^--------------------------------------------}
§During All group, Program, or Random play mode, “A” is dis-
played instead of “G”.
[DVD-V] [CD] (MP3 disc)
Chapter__)Title__)OFF
^--------------------------------------------}
[CD] [VCD]
Track>Entire disc>OFF
^-----------------------------------}
If the Video CD has playback control
1. Press [∫].
2. Press the numbered buttons to select a track to start play
(➡page 15).
3. Press [REPEAT] (➡above).
Note
You cannot use repeat play to repeat an entire DVD-Video or an
entire MP3 disc.
∫To repeat only your favorite tracks
[DVD-A] [CD] [VCD]
Start program play (➡page 17) and press [REPEAT] to select the
repeat mode.
To enjoy even higher quality sound
—AUDIO ONLY
[DT300]
[DVD-A] [DVD-V] [CD] [VCD]
You can enjoy higher quality audio by stopping the video signal.
Press [SHIFT] ii
ii
i[ 3 , AUDIO ONLY] .
≥ AUDIO ONLY is canceled if you press [SHIFT] ii
ii
i[3, AUDIO ONLY]
again or turn the unit off.
Note
≥Video signals are output while the disc is stopped and when opera-
tions such as searching are performed. The television screen can
appear unusual while video signals are not being output.
≥The television may be distorted when video signals are turned on
and off when you turn AUDIO ONLY on and off, but this is not a
malfunction.
A-B repeat play
[DVD-A] [DVD-V] [CD] [VCD]
(When the elapsed play time is displayed)
You can repeat a section between points A and B within a title or
track.
1During play
Press [A-B REPEAT] at the starting
point (A).
2Press [A-B REPEAT] at the finishing
point (B).
A-B repeat starts.
To cancel
Press [A-B REPEAT] until “ ” is displayed.
Note
≥Some subtitles recorded around point A or B may fail to appear.
≥The unit automatically determines the end of a title/track as point B
when the end of the title/track is reached.
A ✱
A B
Numbered
buttons
T G OFF
§
C T OFF
AUDIO ONLY
T A OFF
✱ ✱

17
RQT6387
Disc operations
[DVD-A] [CD] [VCD]
While stopped
Press [PLAY MODE] to select the play mode.
The mode changes as follows each time you press the button.
All group play ([DVD-A] only) Program play
Random play
After selecting the mode, follow the steps for the mode.
[DVD-A] If you select bonus groups, you will have to enter a 4-digit
password (➡page 15).
All group play
To play all the groups in succession
Press [1] (PLAY).
Random play
To play tracks randomly e.g. [DVD-A] (three groups)
1[DVD-A]
Press [ 2, 1 ] to select a group and
press [ENTER].
≥You can select more than one group.
2Press [1] (PLAY).
Play now begins in random order.
To clear a group [DVD-A]
Press [2, 1] to select the group you want to clear, then press [ENTER].
Normal play
Play modes are canceled and the program is cleared when you:
–Turn the unit off.
–Open the disc tray or select another source.
Press PLAY to start
All Group Playback
Choose a group or groups
All 1 2 3
Random Playback
0Press PLAY to start
ENTER RETURN
SELECT
All group play/Program play/Random play
Program play
To play a maximum of 24 tracks in a programmed order
e.g. [DVD-A]
1[DVD-A]
Press the numbered buttons to select
a group.
2Press the numbered buttons to select
a track.
≥Repeat steps 1and 2to program other tracks.
≥To select a track using the cursor buttons
Press [ENTER] and [3, 4] to select a group or track, then
press [ENTER] again to register the number.
All the tracks in the selected group are selected when you
select “ALL”.
3Press [1] (PLAY).
Play now begins in the programmed sequence.
When play is stopped and the program contents are shown on
the display, you can also do the following.
≥To add or change groups or tracks
Press [3, 4] to select an available item, then repeat steps 1and 2.
≥To check program contents
Press [3, 4].
≥To move to the pages before or after the one shown
Press [6, 5].
≥To clear tracks
Press [CANCEL] to clear the last track in the program.
≥To clear a track
1. Select the item you want to clear.
2. Select “Clear” with [3, 4, 2, 1] and press [ENTER].
≥To clear the whole program
Select “Clear all” with [3, 4, 2, 1] and press [ENTER].
ALL GROUP PROGRAM
RANDOM
PGM
RND
PLAY MODE
ENTER RETURN
6 ∫ 1
5
Choose a group and track,then press ENTER.
No Time
G
TotalTime
0Press PLAY to start
TPlay
Clear
Clear all
0:00
SELECT
1
CD P:00
PGM
e.g. [CD]
Track No.
Program No.
Normal play
(Original display)

RQT6387
18
Disc operations
Subtitles
During play
Press [SUBTITLE].
The number changes each time you press the button.
≥In some cases, the subtitle language is not changed to the
selected one immediately.
≥Refer to [A] on page 20 for language abbreviations.
To clear/display the subtitles
1. Press [SUBTITLE].
2. Press [1].
3. Press [3, 4] to select “OFF” or “ON”.
Angles
During play
Press [SHIFT] ii
ii
i[ANGLE].
The number changes each time you press the button.
Changing soundtracks, subtitle languages and angles
12
[DVD-A] [DVD-V]
Some DVDs have multiple soundtracks, subtitle languages and
camera angles, and you can change these during play.
≥“–” or “––” is displayed instead of the language number in circum-
stances such as when no language is recorded on the disc.
Soundtracks
During play
Press [AUDIO].
The number changes each time you press the button.
[DVD-A] [DVD-V]
≥Play restarts from the beginning of the soundtrack when changing
DVD-Audio soundtracks that are accompanied by still pictures.
≥Even if a second soundtrack isn’t recorded on a DVD-Audio, two
soundtrack numbers will normally be shown when you press
[AUDIO]. The soundtrack currently playing is number 1.
≥You can also use this button to turn the vocals on and off on
karaoke discs. Read the disc’s instructions for details.
≥Refer to [A] and [B] on page 20 for language abbreviations and au-
dio signal type details.
≥[VCD]
Audio changes as follows each time you press [AUDIO]:
LR>L>R
^--------------}
I love you
Je t’aime
ENG
ON FRA
ON
12
192k24b 2ch
LPCM
3/2.1 ch
Digital
Î
1
1 1 ENG
Soundtrack selected
Soundtrack playing
SLOW/SEARCH
MENUTOP MENU
CH
SELECT
TEST
ENTER
SET
OSD
TIMER
RDS
PLAY MODE
DISPLAY
A-B REPEAT
REPEAT
SFC
PL
CH SELECTD.MIXCENTER FOCUS TEST
SUBWOOFER
LEVEL
POSITION
MEMORY
SHIFT MUTING
SUPER
SURROUND
CANCEL
SETUP AUDIO ANGLE
SUBTITLE
RETURN
GROUP
X
TUNER/BAND
TV FM MODE
W
123
456
78
0
S10/-/--
9
DVD/CD
AUDIO ONLY
PAGE
VCR TV/AV
SKIP
AUDIO
ANGLE
3, 4, 1
SUBTITLE
SHIFT
TV VOLUME

19
RQT6387
Disc operations
OSD RETURN
SLOW/SEARCH
MENUTOP MENU
CH
SELECT
TEST
ENTER
SET
OSD
TIMER
RDS
PLAY MODE
DISPLAY
A-B REPEAT
REPEAT
SFC
PL
CH SELECTD.MIXCENTER FOCUS TEST
SUBWOOFER
LEVEL
POSITION
MEMORY
SHIFT MUTING
SUPER
SURROUND
CANCEL
SETUP AUDIO ANGLE
SUBTITLE
RETURN
GROUP
X
TUNER/BAND
TV FM MODE
W
123
456
78
0
S10/-/--
9
DVD/CD
AUDIO ONLY
PAGE
VCR TV/AV
SKIP
3, 4, 2, 1
ENTER
TV VOLUME
Using Graphical User Interface (GUI) screens
2[Unit\information\only]
While the leftmost icon is highlighted
Press [3, 4] to select the menu.
Each time you press the button:
[>Play menu
l
l
l;:
l>Display menu
l
l
l;:
l>Audio menu
l
l
l;:
{>Video menu
3Press [2, 1] to select the item.
4Press [3, 4] to select the setting.
≥Items with “3” or “4” above and below can be changed by
[3, 4].
≥Press [ENTER] if the setting does not change after pressing
[3, 4].
≥Some items require different operations. Read the explana-
tions on the following pages.
For your reference
≥Depending on the condition of the unit (playing, stopped, etc.) and
the type of software you are playing, there are some items that you
cannot select or change.
≥When numbers are displayed (e.g. title No.), the numbered buttons
are also effective for setting. After entering the numbers, press
[ENTER] to register the setting.
To clear the menus
Press [RETURN] until the menus disappear.
∫To change the position of the menus
1. Press [2, 1] to select the rightmost menus.
2. Press [3, 4] to move the menus.
(There are 5 positions.)
Numbered
buttons
GUI screens are menus that contain information about the disc or
unit. These menus allow you to perform operations by changing this
information.
Common procedures
1Press [OSD].
Each time you press the button:
[>Disc information
l
l
l;
l>Unit information
l
l
l;
l>Shuttle screen
l
l
l;
{=Original display
≥The screens depend on disc contents.
N
OFF
I P B
r 100
j 100
2
C
21 : 46 : 50
1 ENG 3/2.1 ch
Digital
Î
ENG
ON
11
T
OFF OFF

RQT6387
20
Disc operations
Icon
Using Graphical User Interface (GUI) screens
Notes on marker
≥Only when the elapsed play time is displayed.
≥Some subtitles may fail to appear around the marker.
≥All the markers are cleared when you:
–Turn the unit off.
–Open the disc tray or select another source.
Unit information
Disc information
e.g. DVD-Video
T
2
C
21 : 46 : 50
1 ENG 3/2.1 ch
Digital
Î
ENG
ON
11
.1: Subwoofer signal
(not displayed if there is no subwoofer signal)
.0: No surround
.1: Mono surround
.2: Stereo surround (left/right)
.1: Center
.2: Front leftiFront right
.3: Front leftiFront rightiCenter
[B][B]
[B][B]
[B] Signal type/data
LPCM/PPCM/ÎDigital/DTS: Signal type
k (kHz): Sampling frequency
b (bit): Number of bits
ch (channel): Number of channels
Example:
3/2 .1ch
[A][A]
[A][A]
[A] Audio/Subtitle language
ENG: English
FRA: French
DEU: German
ITA: Italian
ESP: Spanish
NLD: Dutch
SVE: Swedish
NOR: Norwegian
DAN: Danish
POR: Portuguese
RUS: Russian
JPN: Japanese
CHI: Chinese
KOR: Korean
MAL: Malay
VIE: Vietnamese
THA: Thai
¢: Others
Icon Content
Subtitles on/off
ON()OFF
[DVD-A] [DVD-V] Angle number
[DT300]
[DVD-A] Still picture number
Selected picture is shown during
play.
[VCD] Audio mode
LR()L()R
^_ --------------J
[VCD] (with playback control only)
Menu play
Indicates whether menu
play(playback control) is on or out.
ENG
ON
1
ENG
1
ON
1
Content
[DT300]
[DVD-A] Group number
[DVD-A] [CD] [VCD] Track number
[DVD-V] Title number
[DVD-V] Chapter number
[DVD-A] [DVD-V] Time
Select a position to start play by
specifying a time with the
numbered buttons.
[DVD-A] [CD] [VCD]
Changing the time display
Press [3, 4] to show the elapsed
play time, remaining time for the
track, or remaining time for the
disc/group.
[DVD-A] [DVD-V] Soundtrack
aSoundtrack language
(See [A] at right for language
abbreviations.)
bAudio signal type
(See [B] at right for details.)
Karaoke vocal on/off
(Karaoke DVD only)
Solo: OFF or ON
Duet: OFF, V1iV2, V1 or V2
[DVD-A] [DVD-V] Subtitle language
(See [A] at right for language
abbreviations.)
T
2
C
2
1 : 46 : 50
1 ✱
Vocal
OFF
2
G
1 ENG 3/2.1 ch
Digital Î
b
a
Content
A-B repeat (➡page 16)
[ENTER] (start point) ➡[ENTER] (finish point)
To cancel: [ENTER]
Repeat play (➡page 16)
[DVD-A] [CD] [VCD]
Play mode display (➡page 17)
– – – : Normal play PGM : Program play
RND : Random play
ALL : All group play( [DVD-A] )
Icon
AB
OFF
Content
Marker
You can mark up to 5 positions to play again.
[ENTER] (The unit is now ready to accept markers.)
To mark a position:
[ENTER] (at the desired point)
To mark another position: [2, 1] ➡[ENTER]
To recall a marker: [2, 1] ➡[ENTER]
To erase a marker: [2, 1] ➡[CANCEL]
Icon
1 2 3 ✱✱
Play menu
Page
1
L R
P B C
ON
