Panasonic SU-HTB550PH User manual

© Panasonic Corporation 2012. All rights reserved.
Unauthorized copying and distribution is a violation of
law.
PSG1204036AE
Home Theater Audio System
Model No. SU-HTB550PH
SB-HTB550P
SB-HWA520PH
SC-HTB550PH
Product Color: (K)...Black Type
TABLE OF CONTENTS
PAGE PAGE
1 Safety Precautions----------------------------------------------- 3
1.1. General Guidelines---------------------------------------- 3
1.2. Before Repair and Adjustment ------------------------- 4
1.3. Protection Circuitry ---------------------------------------- 4
1.4. Caution For Fuse Replacement------------------------ 4
1.5. Caution For SMPS Module------------------------------ 4
1.6. Safety Part Information----------------------------------- 5
1.7. Safety Installation Instructions -------------------------6
2Warning--------------------------------------------------------------7
2.1. Prevention of Electro Static Discharge (ESD)
to Electrostatically Sensitive (ES) Devices ----------7
2.2. Service caution based on Legal restrictions --------8
3 Service Navigation -----------------------------------------------9
3.1. Service Information ----------------------------------------9
Note: Please use this manual together with service manual
Model No.[SC-HTB550PCK, Order No.PSG1202001CE].

2
3.2. Notes -------------------------------------------------------- 10
3.3. Different Points ------------------------------------------- 11
4 Specifications ---------------------------------------------------- 14
5 Block Diagram --------------------------------------------------- 15
5.1. Main Unit (SU-HTB550) -------------------------------- 15
5.2. Active Subwoofer (SB-HWA520)--------------------- 19
6 Schematic Diagram--------------------------------------------- 20
6.1. Main Unit (SU-HTB550) -------------------------------- 20
6.2. Active Subwoofer (SB-HWA520)--------------------- 26
7 Printed Circuit Board ------------------------------------------ 29
7.1. Main Unit (SU-HTB550) ------------------------------- 29
7.2. Active Subwoofer (SB-HWA520)--------------------- 33
8 Exploded View and Replacement Parts List ----------- 34
8.1. Exploded View and Mechanical replacement
Parts List --------------------------------------------------- 34
8.2. Electrical Replacement Parts List-------------------- 41

3
1 Safety Precautions
1.1. General Guidelines
1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or
damaged by the short circuit.
2. After servicing, ensure that all the protective devices such as insulation barriers, insulation papers shields are properly
installed.
3. After servicing, check for leakage current checks to prevent from being exposed to shock hazards.
1.1.1. Leakage Current Cold Check
1. Unplug the AC cord and connect a jumper between the two prongs on the plug.
2. Using an ohmmeter measure the resistance value, between the jumpered AC plug and each exposed metallic cabinet part on
the equipment such as screwheads, connectors, control shafts, etc. When the exposed metallic part has a return path to the
chassis, the reading should be between 1MΩand 5.2Ω. When the exposed metal does not have a return path to the chassis,
the reading must be
1.1.2. Leakage Current Hot Check
1. Plug the AC cord directly into the AC outlet. Do not use an isolation transformer for this check.
2. Connect a 1.5kΩ, 10 watts resistor, in parallel with a 0.15μF capacitors, between each exposed metallic part on the set and a
good earth ground such as a water pipe, as shown in Figure 1.
3. Use an AC voltmeter, with 1000 ohms/volt or more sensitivity, to measure the potential across the resistor.
4. Check each exposed metallic part, and measure the voltage at each point.
5. Reverse the AC plug in the AC outlet and repeat each of the above measurements.
6. The potential at any point should not exceed 0.75 volts RMS. A leakage current tester (Simpson Model 229 or equivalent)
may be used to make the hot checks, leakage current must not exceed 1/2 milliamp. should the measurement is outside of
the limits specified, there is a possibility of a shock hazard, and the equipment should be repaired and re-checked before it is
returned to the customer.

4
1.2. Before Repair and Adjustment
Main Unit (SU-HTB550)
Disconnect AC power, discharge unit AC Capacitors as such C5700, C5701, C5702, C5703 and C5705 through a 10W, 1W resistor
to ground.
Caution : DO NOT SHORT-CIRCUIT DIRECTLY (with a screwdriver blade, for instance), as this may destroy solid state devices.
After repairs are completed, restore power gradually using a variac, to avoid overcurrent.
• Current consumption AC 110 V to 240 V, 50/60 Hz in Power On, No signal, Volume minimum, SEL: HDMI/OPT mode should be
~180 mA.
Active Subwoofer (SB-HWA520)
Caution : DO NOT SHORT-CIRCUIT DIRECTLY (with a screwdriver blade, for instance), as this may destroy solid state devices.
After repairs are completed, restore power gradually using a variac, to avoid overcurrent.
• Current consumption at AC 110 V to 240 V, 50/60 Hz in Power On link, Volume minimum, SEL: DVD mode should be ~220 mA.
1.3. Protection Circuitry
The protection circuitry may have operated if either of the following conditions are noticed:
• No sound is heard when the power is turned on.
• Sound stops during a performance.
The function of this circuitry is to prevent circuitry damage if, for example, the positive and negative speaker connection wires are
"shorted", or if speaker systems with an impedance less than the indicated rated impedance of the amplifier are used.
If this occurs, follow the procedure outlines below:
1. Turn off the power.
2. Determine the cause of the problem and correct it.
3. Turn on the power once again after one minute.
Note:
When the protection circuitry functions, the unit will not operate unless the power is first turned off and then on again.
1.4. Caution For Fuse Replacement
1.4.1. SU-HTB550
1.5. Caution For SMPS Module
Caution:
Active Subwoofer (SB-HWA520) uses SMPS Module to supply the voltage & power required for the circuitries. It is
replaced as an assembly, do not attempt to replace or repair by individual components.

5
1.6. Safety Part Information
Safety Parts List:
There are special components used in this equipment which are important for safety.
These parts are marked by in the Schematic Diagrams & Replacement Parts List. It is essential that these critical parts should
be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards. Do not modify the original design without
permission of manufacturer.
1.6.1. Main Unit (SU-HTB550)
1.6.2. Front Speaker (SB-HTB550)
1.6.3. Active Subwoofer (SB-HWA520)
1.6.4. System (SC-HTB550)
Safety Ref. No. Part No. Part Name & Description Remarks
11 RGR0423B-G REAR PANEL
27 RMZ1264 SMPS INSULATOR BOTTOM
28 RFKKUHTB350P TOP PANEL ASS’Y
PCB7 REP4737NA SMPS P.C.B.
DZ5701 ERZV10V511CS ZNR
L5702 ELF19H820E LINE FILTER
L5703 ELF19H010A LINE FILTER
T5701 ETS35BL166AD MAIN TRANSFORMER
PC5720 B3PBA0000503 PHOTO COUPLER
PC5760 B3PBA0000503 PHOTO COUPLER
F1 K5G312Y00007 FUSE PROTECTOR
TH5702 D4CAA5R10001 THERMISTOR
P5701 K2AA2B000011 AC INLET
R5700 ERJ8GEYJ105V 1M 1/4W
R5701 ERJ8GEYJ105V 1M 1/4W
R5710 ERJ8GEYJ105V 1M 1/4W
C5700 F1BAF471A013 470pF
C5701 F0CAF104A105 0.1uF
C5702 F0CAF104A105 0.1uF
C5703 F0CAF104A105 0.1uF
C5705 F1BAF471A013 470pF
Safety Ref. No. Part No. Part Name & Description Remarks
3 RYQ0955-K REAR CABINET ASSY
Safety Ref. No. Part No. Part Name & Description Remarks
66 RGN3230-K SPEC LABEL
70 REEX1265-J 2P WIRE (SMPS MODULE - AC INLET)
PCB14 REP4806BD AC INLET P.C.B. (RTL)
PCB15 N0AE3ZJ00001 SMPS MODULE P.C.B.
PCB16 REP4814A DIGITAL RECEIVER MODULE P.C.B.
P5701 K2AAYA000001 AC INLET
Safety Ref. No. Part No. Part Name & Description Remarks
A1 N2QAYC000064 REMOTE CONTROL
A2 K2CJ2DA00008 AC CORD
A3 RQT9668-1M O/I BOOK (Sp/Pr)

6
1.7. Safety Installation Instructions

7
2Warning
2.1. Prevention of Electro Static Discharge (ESD) to Electrostatically Sensi-
tive (ES) Devices
Some semiconductor (solid state) devices can be damaged easily by electricity. Such components commonly are called Electrostat-
ically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semicon-
ductor “chip” components. The following techniques should be used to help reduce the incidence of component damage caused by
electro static discharge (ESD).
1. Immediately before handling any semiconductor component or semiconductor-equiped assembly, drain off any ESD on your
body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap,
which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equiped with ES devices, place the assembly on a conductive surface such as alumin-
ium foil, to prevent electrostatic charge build up or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an anti-static solder remover device. Some solder removal devices not classified as “anti-static (ESD protected)” can
generate electrical charge to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most
replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminium foil or compara-
ble conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material
to the chassis or circuit assembly into which the device will be installed.
Caution
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize body motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the brush-
ing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD) sufficient
to damage an ES device).

8
2.2. Service caution based on Legal restrictions
2.2.1. General description about Lead Free Solder (PbF)
The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this
equipment in considering the globally environmental conservation.
The normal solder is the alloy of tin (Sn) and lead (Pb). On the other hand, the lead free solder is the alloy mainly consists of tin
(Sn), silver (Ag) and Copper (Cu), and the melting point of the lead free solder is higher approx.30 degrees C (86°F) more than that
of the normal solder.
Definition of PCB Lead Free Solder being used
Service caution for repair work using Lead Free Solder (PbF)
• The lead free solder has to be used when repairing the equipment for which the lead free solder is used.
(Definition: The letter of “PbF” is printed on the PCB using the lead free solder.)
• To put lead free solder, it should be well molten and mixed with the original lead free solder.
• Remove the remaining lead free solder on the PCB cleanly for soldering of the new IC.
• Since the melting point of the lead free solder is higher than that of the normal lead solder, it takes the longer time to melt the
lead free solder.
• Use the soldering iron (more than 70W) equipped with the temperature control after setting the temperature at 350±30 degrees
C (662±86°F).
Recommended Lead Free Solder (Service Parts Route.)
• The following 3 types of lead free solder are available through the service parts route.
RFKZ03D01K-----------(0.3mm 100g Reel)
RFKZ06D01K-----------(0.6mm 100g Reel)
RFKZ10D01K-----------(1.0mm 100g Reel)
Note
* Ingredient: Tin (Sn), 96.5%, Silver (Ag) 3.0%, Copper (Cu) 0.5%, Cobalt (Co) / Germanium (Ge) 0.1 to 0.3%
The letter of “PbF” is printed either foil side or components side on the PCB using the lead free solder.
(See right figure)

9
3 Service Navigation
3.1. Service Information
This service manual contains technical information which will allow service personnel’s to understand and service this model.
Please place orders using the parts list and not the drawing reference numbers.
If the circuit is changed or modified, this information will be followed by supplement service manual to be filed with original service
manual.
•Microprocessor :
The following components are supplied as an assembled part.
• Microprocessor IC, IC2301 (RFKWMHTB550P).
•SMPS Module :
Active Subwoofer (SB-HWA520) uses SMPS Module to supply the voltage & power required for the circuitries. It is
replaced as an assembly, do not attempt to replace or repair by individual components.
•Bluetooth Module :
Bluetooth feature is not applicable in this model.

10
3.2. Notes
This service manual contains technical information which will allow service personnel’s to understand and service this model.
Please place orders using the parts list and not the drawing reference numbers.
If the circuit is changed or modified, this information will be followed by supplement service manual to be filed with original service
manual.
1) This service manual does not contains the following information
This simplified service manual is base on SC-HTB550PCK. Please refer to the original service manual, SC-HTB550PCK (Order No.
PSG1202001CE) for the below mention contents.
- Location of Controls and Components
- Operating Instructions
- Self Diagnostic and Doctor Mode Setting
- Disassembly and Assembly Instructions
- Service Position
- Voltage Measurement & Waveform Chart
- Overall Simplified Block
- Block Diagram
- Wiring Connection Diagram
- Schematic Diagram
- Printed Circuit Board
- Illustration of IC’s, Transistors and Diodes
- Terminal Function of IC’s
2) This service manual contains include the following information
- Safety Precautions
- Warning
- Service Navigation
- Specifications
- Block Diagram
- Schematic Diagram
- Printed Circuit Board
- Exploded View and Replacement Parts List

11
3.3. Different Points
3.3.1. Main Unit (SU-HTB550)
Ref. No. Parts No. Parts name & Description Remarks
SU-HTB550PCK SU-HTB550PHK
11 RGR0423B-B2 RGR0423B-G REAR PANEL
12 RYP1694-K RYP1694D-K FRONT PANEL ASSY
13 RGU2775-K RGU2775-K1 VOLUME BUTTON
C2101 F1G1H101A565 _ 100pF 50V
C2102 F1G1H101A565 _ 100pF 50V
C2105 F1G0J105A031 _ 1uF 6.3V
C2106 F1G0J105A031 _ 1uF 6.3V
C2107 F1J1A106A043 _ 10uF 10V
C2108 F1J1A106A043 _ 10uF 10V
C2109 F1J1A106A043 _ 10uF 10V
C2110 F1J1A106A043 _ 10uF 10V
C2111 F1G1H101A565 _ 100pF 50V
C2112 F1G1H101A565 _ 100pF 50V
C2113 F1G1A1040006 _ 0.1uF 10V
C2114 F1J1A106A043 _ 10uF 10V
C2115 F1G1A1040006 _ 0.1uF 10V
C2116 F1J1A106A043 _ 10uF 10V
C2117 F1G1A1040006 _ 0.1uF 10V
C2118 F1J1A106A043 _ 10uF 10V
C2119 EEEHB0J101UR _ 100uF 6.3V
C2120 F1G1A1040006 _ 0.1uF 10V
C5700 F1BAF1020020 F1BAF471A013 470pF
C5705 F1BAF1020020 F1BAF471A013 470pF
C5712 F2B2D1810007 F2A2G1810002 180uF 400V
CN2111 K1MY12AA0021 _ 12P CONNECTOR
D6008 B3AEA0000166 _ DIODE
DZ5701 ERZVA5Z471 ERZV10V511CS ZNR
IC2101 C0ABBA000159 _ IC
IC2102 C0FBAK000026 _ IC
IC2103 C0JBAR000396 _ IC
IC5701 C0DABYY00035 C0DAAYY00064 IC
K100 D0GBR00JA008 _ 0 1/10W
K101 - D0GBR00JA008 0 1/10W
K111 D0GAR00J0008 _ 0 1/16W
K113 _ D0GAR00J0008 0 1/16W
K211 D0GAR00J0008 _ 0 1/16W
K213 _ D0GAR00J0008 0 1/16W
K5722 ERJ3GEY0R00V _ 0 1/10W
K5724 _ ERJ3GEY0R00V 0 1/10W
L2805 G1C330MA0291 G1C330M00028 INDUCTOR
L5702 _ ELF19H820E LINE FILTER
LB2101 J0JYB0000013 _ INDUCTOR
LB2102 J0JYB0000013 _ INDUCTOR
LB2103 J0JBC0000014 _ INDUCTOR
LB2104 J0JBC0000014 _ INDUCTOR
LB2105 J0JBC0000014 _ INDUCTOR
LB2106 J0JHC0000078 _ INDUCTOR
P5701 K2AB2B000007 K2AA2B000011 AC INLET
PCB1 REP4735E REP4735D MAIN P.C.B. (RTL)
PCB3 REP4792AA REP4792BA PANEL P.C.B. (RTL)
PCB4 REP4792AB REP4792BB BUTTON P.C.B. (RTL)
PCB5 REP4792AC REP4792BC POWER BUTTON P.C.B. (RTL)
PCB6 REP4792AD REP4792BD WIRELESS ADAPTER P.C.B. (RTL)
PCB7 REP4737LA REP4737NA SMPS P.C.B. (RTL)
PCB8 REP4777A REP4813A DIGITAL TRANSMITTER MODULE
P. C . B .
PCB9 REP4805A - BLUETOOTH MODULE P.C.B.
R2101 ERJ2GEJ104X _ 100K 1/16W
R2103 ERJ2GEJ223X _ 22K 1/16W
R2104 ERJ2GEJ223X _ 22K 1/16W
R2105 ERJ2GEJ223X _ 22K 1/16W

12
3.3.2. Active Subwoofer (SB-HWA520)
3.3.3. System (SC-HTB550)
R2106 ERJ2GEJ223X _ 22K 1/16W
R2107 ERJ2GEJ154X _ 150K 1/16W
R2108 ERJ2GEJ154X _ 150K 1/16W
R2109 ERJ2GEJ154X _ 150K 1/16W
R2110 ERJ2GEJ154X _ 150K 1/16W
R2111 ERJ2GEJ472X _ 4.7K 1/16W
R2112 ERJ2GEJ472X _ 4.7K 1/16W
R2113 ERJ2GEJ101X _ 100 1/16W
R2114 ERJ2GEJ101X _ 100 1/16W
R2115 ERJ2GEJ473X _ 47K 1/16W
R2116 ERJ2GEJ473X _ 47K 1/16W
R2117 ERJ2GEJ100X _ 10 1/16W
R2118 ERJ2GEJ330X _ 33 1/16W
R2119 _ D0GAR00J0008 0 1/16W
R2121 ERJ2GEJ330X _ 33 1/16W
R2124 ERJ2GEJ330X _ 33 1/16W
R2125 ERJ2GEJ330X _ 33 1/16W
R2126 ERJ2GEJ102X _ 1K 1/16W
R2127 ERJ2GEJ102X _ 1K 1/16W
R2128 ERJ2GEJ102X _ 1K 1/16W
R2227 ERJ2GEJ101X _ 100 1/16W
R2228 ERJ2GEJ101X _ 100 1/16W
R2229 ERJ2GEJ472X _ 4.7K 1/16W
R2281 ERJ2GEJ104X ERJ2GEJ473X 47K 1/16W
R2338 ERJ2GEJ101X _ 100 1/16W
R2343 ERJ2GEJ101X _ 100 1/16W
R5700 ERJ8GEYJ155V ERJ8GEYJ105V 1M 1/4W
R5701 ERJ8GEYJ155V ERJ8GEYJ105V 1M 1/4W
R5702 ERJ1TYJ333U ERJ1TYJ104U 100K 1W
R5703 ERJ1TYJ333U ERJ1TYJ104U 100K 1W
R5710 ERJ8GEYJ155V ERJ8GEYJ105V 1M 1/4W
R5727 ERX2SZJR15P ERX2SZJR18P 0.18 2W
R5761 _ ERJ3GEYJ824V 820K 1/10W
R5802 ERJ3RBD153V ERJ3RBD332V 3.3K 1/16W
R5817 ERJ3RBD562V ERJ3RBD222V 2.2K 1/16W
R5818 ERJ3GEYJ391V ERJ3RBD222V 2.2K 1/16W
R5819 ERJ6GEYJ122V ERJ3GEYJ151V 150 1/10W
R6016 D0GB152JA008 _ 1.5K 1/10W
T5701 ETS35BC2ZGAD ETS35BL166AD MAIN TRANSFORMER
TH5702 D4CAA2R20001 D4CAA5R10001 THERMISTOR
Ref. No. Parts No. Parts name & Description Remarks
SU-HTB550PCK SU-HTB550PHK
Ref. No. Parts No. Parts name & Description Remarks
SU-HWA550PCK SB-HWA520PH1
66 RGN3177-K RGN3230-K SPEC LABEL
67 RFKHBHWA550P RFKHBHWA550E SPEAKER CABINET ASS’Y
70 REE1607-J REEX1265-J 2P WIRE (SMPS MODULE - AC INLET)
P5701 K2ABYA000001 K2AAYA000001 AC INLET
PCB11 REP4806AA REP4806BA D-AMP P.C.B. (RTL)
PCB12 REP4806AB REP4806BB LED P.C.B. (RTL)
PCB13 REP4806AC REP4806BC POWER BUTTON P.C.B. (RTL)
PCB14 REP4806AD REP4806BD AC INLET P.C.B. (RTL)
PCB15 N0AB3ZJ00001 N0AE3ZJ00001 SMPS P.C.B.
PCB16 REP4778A REP4814A DIGITAL RECEIVER MODULE P.C.B.
Ref. No. Parts No. Parts name & Description Remarks
SC-HTB550PCK SC-HTB550PHK
A1 N2QAYC000063 N2QAYC000064 REMOTE CONTROL
A2 K2CB2YY00059 K2CJ2DA00008 AC CORD
A3 RQT9661-C RQT9668-1M O/I BOOK (Sp/Pr)
P1 RPG9860 RPG9866 PACKING CASE
P3 RPFX1010 RPF0610 MIRAMAT BAG (SU-HTB)

13
P5 RPFX1044GN RPF0588 MIRAMAT BAG (SB-HWA)
Ref. No. Parts No. Parts name & Description Remarks
SC-HTB550PCK SC-HTB550PHK

14
4 Specifications
QAmplifier Section
RMS Output Power
10% total harmonic distortion
Subwoofer ch 120 W per channel (100 Hz, 8 Ω)
Front ch (L, R ch) 60 W per channel (1 kHz, 6 Ω)
Total RMS Dolby Digital mode
power
240 W
QWireless section
Wireless module
Frequency Range 2.4 GHz to 2.4835 GHz
Number of channels 3
QTerminal Section
HDAVI Control This unit supports “HDAVI Control
5” function.
HDMI AV input (BD/DVD, AUX1) 2
Input connector Type A (19 pin)
HDMI AV output (TV (ARC)) 1
Output connector Type A (19 pin)
Digital audio input
Optical digital input (TV, AUX2) 2
Sampling frequency 32 kHz, 44.1 kHz, 48 kHz
88.2 kHz, 96 kHz (only LPCM)
Audio format LPCM, Dolby Digital, DTS
QSpeaker Section
Front speakers
2 way, 2 speaker system (Bass reflex type)
Speaker unit(s) Impedance 6 Ω
Woofer 6.5 cm cone type x 1
Tweeter 2.5 cm semi-dome type x 1
Frequency range 100 Hz to 30 kHz (-16 dB)
150 Hz to 25 kHz (-10 dB)
Active subwoofer
1 way, 1 speaker system (Bass reflex type)
Woofer 16 cm cone type x 1
Frequency range 30 Hz to 180 Hz (-16 dB)
35 Hz to 160 Hz (-10 dB)
QGeneral
Power consumption Main Unit: 33 W
Active subwoofer: 23 W
In standby condition Main Unit: Approx. 0.2 W
Active subwoofer: Approx. 0.2 W
Power supply AC 110 V to 240 V, 50/60 Hz
Dimensions (W x H x D)
Main Unit
Cabinet dimension 310 mm x 44 mm x 195 mm
Maximum outer dimension 310 mm x 45 mm x 202 mm
Active subwoofer 180 mm x 408 mm x 306 mm
Mass
Main Unit Approx. 1.1 kg
Active subwoofer Approx. 5.2 kg
Operating temperature range 0°C to +40°C
Operating humidity range 20% to 80 % RH
(no condensation)
QSpeaker general
Horizontal placement using the stands
Dimensions (W x H x D) 956 mm x 102 mm x 74 mm
Mass 1.61 kg
Horizontal placement using the speaker feet and the support legs
Dimensions (W x H x D) 956 mm x 78 mm x 55 mm
Mass 1.57 kg
Horizontal placement (for wall mount)
Dimensions (W x H x D) 956 mm x 75 mm x 35 mm
Mass 1.54 kg
Vertical placement using the speaker bases
Dimensions (W x H x D) 148 mm x 528 mm x 145 mm
Mass 0.88 kg
Vertical placement (for wall mount)
Dimensions (W x H x D) 75 mm x 478 mm x 35 mm
Mass 0.77 kg
• Specifications are subject to change without notice. Weight and
dimensions are approximate.
• Total harmonic distortion is measured by the digital spectrum ana-
lyzer.
QSystem: SC-HTB550PHK MAIN UNIT : SU-HTB550PHK
FRONT SPEAKERS : SB-HTB550P-K
ACTIVE SUBWOOFER : SB-HWA520PH1

15
5 Block Diagram
5.1. Main Unit (SU-HTB550)
5.1.1. SYSTEM CONTROL BLOCK DIAGRAM
SC-HTB550PH(SU-HTB550PH) SYSTEM CONTROL BLOCK DIAGRAM
84
CN6001CN2204
6 SCL
5 SDA
MICROPROCESSOR
RFKWMHTB550P
IC2301
EEPROM
C3EBEY000042
X2301
IC2303
LED DATA 78 LED DATA
75
CN6001CN2204
LED CLK 79 LED CLK
66
CN6001CN2204
LED LCK 80
LED DRIVER
C0JBAQ000073
IC6001
IDROM/BKROM SCL 20
IDROM/BKROM SDA 19
XIN 13
XOUT 11
X2302
XCIN 8
XCOUT 9
LED LCK
LED DATA
LED CLK
LED LCK
93
CN6001CN2204
LED OE 83 LED OELED OE
KEY2 89 KEY2
SELECTOR
S6004
VOLUME+
S6003
VOLUME-
S6002
KEY1 90 KEY1
KEY1
REMOTE 3 REMOTE REMOTE
39
CN6001CN2204
3.3V
5V
REMOTE
CONTROL SENSOR
Z6001
DAP SCL46
DAP SCL
DAP SCL
W SCL
W SCL
W SSB63
W SSB
W SSB
W SDO99
W SDO
W SDO
PCONT
PCONT
ECO PCONT
ECO PCONT
SD OUT
SD OUT
DAP RESET24
DAP RESET
DAP RESET
RX0 HPD54
RX0 HPD
RX0 HPD
HDMI SCL34
HDMI SCL
HDMI SCL
RX1 HPD53
RX1 HPD
RX1 HPD
RX0 WRT SEL47
RX0 WRT SEL
RX0 WRT SEL
RX RESET37
RX RST
RX RST
TX RESET36
TX RST
TX RST
STBY H52
STBY H
STBY H
RX1 WRT SEL50
RX1 WRT SEL
RX1 WRT SEL
DAP MUTE23
DAP MUTE
DAP MUTE
RESET CODEC
RESET CODEC
MOSI DSP
MOSI DSP
RESET DSP
RESET DSP
SD84
SD
DC DET86
DATA2
CLK3
LCK4
OE17
DC DET
DC DET
W INT87
W INT
W INT
W SDI98
W SDI
W SDI
W DET64
W DET
W DET
ECO LVL91
ECO LEVEL
ECO LEVEL
RX INT42
RX INT
RX INT
TX INT41
TX INT
TX INT
TX HPD66
TX HPD
TX HPD
VSYNC COUNT4
VSYNC
VSYNC
RX0 5V DET56
RX0 5V
RX0 5V
RX1 5V DET55
5V DET65
RX1 5V
RX1 5V
S DET93
S DET
PCONT88
MUTE ALL22
RESET CODEC67
CS CODEC
CS CODEC
CS CODEC58
CLK DSP77
MOSI DSP75
CS DSP
CS DSP
CS DSP68
RESET DSP70
MISO DSP/SDOUT76
S DET
AC SYNC18
SYNC
SYNC
DC DET
DC DET
SD
MISO DSP
MISO DSP
INTREQ DSP71
INTREQ DSP
INTREQ DSP
INTREQ CODEC73
INTREQ CODEC
INTREQ CODEC
DAP SDA45
DAP SDA
DAP SDA
RX0/1 EDID SCL48
RX01 EDID CK
RX01 EDID CK
RX0/1 EDID SDA49
RX01 EDID DT
RX01 EDID DT
CEC I/O15
CEC IO
CEC IO
HDMI SDA33
HDMI SDA
HDMI SDA
CLK DSP
CLK DSP
BUSY DSP69
BUSY DSP
BUSY DSP
MUTEOUT
MUTEOUT
VALID21
VALID
VALID
Q0 5
Q5 10
D6001
Q6 11
D6007
D6005
Q7 12
Q8 13
D6004
Q10 15
D6003
Q11 16
D6002
D6006
HDMI MUTE DIS25
HDMI MUTE DET5
ECO PCONT61
HDMI PCONT
HDMI PCONT
HDMI PCONT40
SD OUT74
OTW85
OTW
OTW
PANEL P.C.B.
BUTTON P.C.B.
POWER BUTTON P.C.B.
MAIN P.C.B.
FROM/TO
HDMI
FROM/TO
AUDIO
FROM/TO
POWER SUPPLY
KEY1
33
JW6003JW6002
KEY2
22
JW6003JW6002
48
CN6001CN2204
57
CN6001CN2204
POWER
S6001
KEY1
21
JW6004CN2206
MUTING
CIRCUIT
QR2303,QR2304
D2307
QR2305,QR2306
W SCL
100
D2308

16
5.1.2. AUDIO BLOCK DIAGRAM
SC-HTB550PH(SU-HTB550PH) AUDIO BLOCK DIAGRAM
DIGITAL
TRANSMITTER
CIRCUIT
DIGITAL AUDIO INTERFACE RECEIVER
C1AB00003174
IC2401
DIGITAL SOUND PROCESSOR
C2HBCY000102
IC2001
16M SDRAM
C3ABMY000029
IC2003
DAO DATA2 48
ARC
RXP2
JK5251
OUTPUT32
RXP612
RST9
AD0/CS14
GPO119
DAI SCLK DAI SCLK129
DAI LRCK DAI LRCLK130
DAI DAT2 DAI DATA224
DAI DAT3 DAI DATA323
DAI DAT0 DAI DATA027
SPDIF RXP410
DAI DAT1 DAI DATA126
DAI LRCLK2
32
DAI SCLK2
33
XTAL OUT
16
OLRCK
DAI DATA4
34
28
MISO DSP SDA/CDOUT
17
SCP1 CLK
126
SCL/CCLK
16
OMCK
25
SCP1 MOSI
123124
AD1/CDIN
15
OSCLK
27
SDOUT
26
DAO MCLK
40
RMCK
24
GPO0
20
2CH
MULTIPLEXER
C0JBAR000396
IC2002
CH11
CH0
COM
3
4
A
6
A0 ~ A10
TC - 5
DQ0 ~ DQ15
TC - 6
X2001
XTI17
XTO18
DAO DATA0 51 DSP SD1
DAO SCLK1 52 DSP SCLK
DAO LRCLK1 54 DSP LRCLK
DAO DATA1 49
DC DET
SD
OTW
DAP SCL
DAP RESET
DAP MUTE
MCLK HDMI
MCLK HDMI
ARC
SPDIF
DAI DAT0
DAI DAT1
DAI DAT2
DAI DAT3
DAI SCLK
DAI LRCK
CS DSP SCP1 CS6
RESET DSP RESET
SCP1 REQ4
INTREQ DSP
MOSI DSP
MOSI DSP
CS DSP
RESET DSP
121
MISO DSP
INTREQ DSP
BUSY DSP SCP1 BSY
128
MISO DSP
RESET CODEC
RESET CODEC
CS CODEC
CS CODEC
INTREQ CODEC
INTREQ CODEC
BUSY DSP
CLK DSP
CLK DSP
DAP SDA
DSP SD1
2813
CN5200CN2201
DSP SD2 DSP SD2
2714
CN5200CN2201
DSP SD3 DSP SD3
2615
CN5200CN2201
DSP LRCLK
DSP SCLK
329
CN5200CN2201
3011
CN5200CN2201
OPT1 INOPT1 IN
39 2
CN2201 CN5200
DAP SDA
2417
CN5200CN2201
DAP SCL
2318
CN5200CN2201
DAP RESET
1922
CN5200CN2201
DAP MUTE
DAP SDA
VALID
VALID
2021
CN5200CN2201
VALID
DAP SCL
DAP RESET
DAP MUTE
1823
CN5200CN2201
DC DETDC DET
1229
CN5200CN2201
ECO LEVEL
ECO LEVELECO LEVEL
833
CN5200CN2201
SD
SDI
SCL
SSB
WCLK
BCLK
ADAT0
AGND
INT
SDO
SD
932
CN5200CN2201
PWM A
PWM B
PWM C
PWM D
RST AB(L)
RST CD(L)
DIGITAL
AMPLIFIER
C1AB00003217
IC5300
+
-
+
-
5 SD(L)
OTWOTW
1031
CN5200CN2201
2 OTW(L)
6
8
16
18
7
17
OUT A 39
BST A 43
OUT B 36
BST B 34
OUT D 28
BST D 24
OUT C 31
BST C 33
3
P5100
4
P5100
1
P5100
2
P5100
SB-HWA520PH
D2002
D2001
315
CN3001
5
CN3000CN2205
711
CN3001
9
CN3000CN2205
513
CN3001
7
CN3000CN2205
W SDI
ADAT0
LRCLK
BCLK
99
CN3001
11
CN3000CN2205
SCL
117
CN3001
12
CN3000CN2205
108
CN3001
13
CN3000CN2205
SDO
SDI
W SDO
W SCL
810
CN3001
10
CN3000CN2205
SSB
W INT
126
CN3001
14
CN3000CN2205
INT
W DET
171
CN3001
16
CN3000
12
-
11
-
10
-
9
-
7
-
5
-
16
-
14
-
13
-
CN2205
WM DET
DAP SDA
VALID
DAP SCL
DAP RESET
DAP MUTE
DC DET
ECO LEVEL
SD
OTW
W SCL
W SDO
W SDI
W SSB
W INT
W DET
W SSB
Q5802,Q5803
Q5804,Q5805
DC DETECT
CIRCUIT
PVCC
FROM HDMI
FROM HDMI
FROM/TO
SYSTEM CONTROL
FROM/TO
SYSTEM CONTROL
FROM/TO
SYSTEM CONTROL
FROM/TO
SYSTEM CONTROL
DIGITAL TRANSMITTER MODULE P.C.B.
TV
(OPT1)
DIGITAL
AUDIO IN
RXP0
JK5252
OUTPUT34
OPT2 IN
OPT2 IN
37 4
CN2201 CN5200
AUX2
(OPT2)
MAIN P.C.B.
SPEAKERS
LEFT
RIGHT
FREQUENCY
DIGITAL AUDIO
PWM PROCESSOR
C1AB00003852
IC5301
OR GATE
C0JBAE000302
IC5205
B2
A1
Y4
PWM FL+
PWM4A 48
PWM FL-
PWM4B 47
PWM3A 46
SDIN1
23
SDIN2
24
SDIN3
25
D5301
D5803
D5401
LRCLK
21
BCK
22
SDA
29
SCL
28
RST
12
SMUTE
11
VALID
39
PWM FR+
PWM3B 45 PWM FR-
MONI3 15
ERRIN 38
DUAL
INVERTER
C0JBAB000837
IC5204
1A11Y 6
: HDMI/OPTICAL AUDIO INPUT SIGNAL LINE : AUDIO OUTPUT SIGNAL LINE
DAMP P.C.B.
DAMP P.C.B.
D5804
X5302
XIN 7
XOUT 8
WIRELESS ADAPTER P.C.B.

17
5.1.3. POWER SUPPLY (1/2) BLOCK DIAGRAM
SC-HTB550PH(SU-HTB550PH) POWER SUPPLY (1/2) BLOCK DIAGRAM
TO POWER SUPPLY
BLOCK (2/2)
1
3
2
ECO CONT
64
CN2202CN1
ECO CONT
SD OUT
73
CN2202CN1
SD OUT
D2321
IC2503
5VIN
1 VCONT
+5V VOLTAGE
REGULATOR
C0CBCDD00004
VOUT 4 +5V
5V
+5V
REG8V
HDMI 1.8V
1.8V
DC DET
DC DET
HDMI 3.3V
3.3V
BK 3.3V
3.3V
S DET
ECO PCONT
HDMI PCONT
ECO PCONT
SD OUT
SD OUT
PCONT
HDMI PCONT
D5801D5805D5802
D5823
Q5801
DC DETECT
QR2301
SYNC
QR2804
SWITCH
DC20V REG12V
1VIN
+12V VOLTAGE
REGULATOR
C0DBAYH00005
IC5801
VOUT 2
ADJ 4
ON/OFF 5
DC20V REG8V
1VIN
5 ON/OFF
+8V VOLTAGE
REGULATOR
C0DBAYH00005
IC2801
VOUT 2
ADJ 4
HDMI 1.8V
VOUT 2
ADJ 4
REG8V 1VIN
+1.8V VOLTAGE
REGULATOR
C0DBAYH00005
IC2805
HDMI 3.3V
VOUT 2
ADJ 4
REG8V
QR2302
SYNC
CONTROL
QR2801
SWITCH
D2304
1VIN
+3.3V VOLTAGE
REGULATOR
C0DBAYH00005
IC2806
REG12V
12V
PVCC
PVCC
REG3.3V
3.3V
S DET
S DET
3011
CN2201CN5200
REG12V
REG12V
3,4,536,37,38
CN2201CN5200
DC20VDC20V
11
CN5900JW1
PVCCPVCC
3,43,4
CN5900JW1
DC20VDC20V
1,28,9
CN2202CN1
BK5V
BK5V
BK 3.3V
3VIN
5CE
+3.3V VOLTAGE
REGULATOR
C0DBEYY00146
IC2802
VOUT 1
ADJ 4
BK5VBK5V
55
CN2202CN1
DC DETDC DET
82
CN2202CN1
SYNC
SYNC
SYNCSYNC
91
CN2202CN1
PCONT DAMP
PCONT DAMP
2516
CN2201CN5200
REG3.3V
REG3.3V
34,356,7
CN2201CN5200
SMPS P.C.B.
MAIN P.C.B.
DAMP P.C.B.
FROM/TO
SYSTEM CONTROL
FROM/TO
SYSTEM CONTROL
FROM
SYSTEM CONTROL
IC5701
SHUNT
REGULATOR
C0DABYY00011
IC5801
MAIN
TRANSFORMER
T5701
Q5863
FEEDBACK
CIRCUIT
SWITCHING
REGULATOR
C0DAAYY00064
VOLTAGE
DETECTOR
C0EBY0000867
IC5822
P5701
F1
DZ5701
4
5
1
2
10
14
9
11
15
12
6
7
8
L5703
TH5702 D5701
3
2
4
1
D5712
D5704
D5705
D5807
D5710
D5802
D5803
D5721
D5706
D5702
Q5760,Q5761
QR5762, D5760
Q5720
VOLTAGE
REGULATOR
FEEDBACK
CIRCUIT
4
3
1
2
PC5760
FEEDBACK
4
3
1
2
PC5720
FEEDBACK
VCC 3
BD 6
FB 5
S2
D1
QR5862
DC DETECT
QR5824
SWITCH
QR5823
SWITCH
Q5864
SWITCH
AC INLET
VDD2OUT 1
REG12V
REG3.3V
S DET
SECONDARYPRIMARY
L5702
3
2
4
1

18
5.1.4. POWER SUPPLY (2/2) BLOCK DIAGRAM
SC-HTB550PH(SU-HTB550PH) POWER SUPPLY (2/2) BLOCK DIAGRAM
TO POWER SUPPLY
BLOCK (1/2)
1
2
3
D2903
IC2902
1IN
2 ON/OFF
+1.8V VOLTAGE
REGULATOR
C0CBCAG00015
OUT 3 REG1.8V
1.8V
REG1.8V
REG3.3V
3.3V
REG5V
5V
REG3.3V
REG3.3V
D2326
REG3.3V
VOUT 2
ADJ 4
REG12V 1VIN
+3.3V VOLTAGE
REGULATOR
C0DBAYH00005
IC2803
REG5V
VOUT 2
ADJ 4
REG12V 1VIN
+5V VOLTAGE
REGULATOR
C0DBAYH00005
IC2804
QR2312
DC DETECT
D2325
D2322
D2323
D2324
5V 5VRF+5V
5V
13,144,5
CN3001CN2205
1717
-CN3000
MAIN P.C.B.
VREF(3.3V) VREF(3.3V)
VREF(3.3V)
3.3V
REG5V REG5V
5V
210
CN6001CN2204
REG5V
111
CN6001CN2204
PANEL P.C.B.
REG12V
S DET
REG3.3V
DIGITAL TRANSMITTER MODULE P.C.B.WIRELESS ADAPTER P.C.B.

19
5.2. Active Subwoofer (SB-HWA520)
5.2.1. AUDIO & POWER SUPPLY BLOCK DIAGRAM
SC-HTB550PH(SB-HWA520PH) AUDIO & POWER SUPPLY BLOCK DIAGRAM
44
CN1000-
CH2 IN RCH
I/D SET
S1000
POWER
S1001
PCONT
SWITCH
MUTING
+5V POWER
SUPPLY
SWITCH
Q1006
Q1004
Q1005
SWITCHING MODE
POWER SUPPLY
CIRCUIT
DIGITAL
RECEIVER
CIRCUIT
23.5V
16V
-16V
-23.5V
11
H1001*CN201*
PCONT
99
CN1000-
IDSET
11
CN1003CN4000*
LINK LED
33
CN1003CN4000*
5V
1212
CN1000-
DC DET
55
CN1000-
+5V
+23.5V
22
H1001*CN201*
IDSETIDSET
5V
LINK LED
MODE SW
POWER SW
41
CN1002H1004*
-23.5V
55
H1001*CN201*
DC DET
66
H1001*CN201*
L
RED
CN101*
TL10*
N
BLK
CN101*
TL20*
POWER SW
23
CN1002H1004*
MODE SW
14
CN1002H1004*
PCONT
77
CN1000-
RF MUTE
1010
CN1000-
LINK LED
CH2 R OUT
IDSET
DC DET
5V
RF PCONT
RF MUTE
LINK
88
CN1000-
+5V
PCONT
+23V
-23V
MUTE
+5V
77
H1001*CN201*
P5701
POWER AMPLIFIER
C1BA00000497
IC5200
-
+
Q1007,Q1008
SPEAKER
PROTECTION
SWITCH
OUT1 10
BOOT1 9
OUT2 14
BOOT2 15
3IN1-
22 IN2+
23 MODE
2
CN1005
1
CN1005
21
67
DUAL
OP-AMP
C0ABBB000244
IC3002
+23.5V +16V
Q2002
+16V VOLTAGE
REGULATOR
Q2010
STABILIZER
LED DRIVE SWITCH
Q1009
VOLTAGE
SUPPLY
CONTROL
-23.5V
Q2011
-16V VOLTAGE
REGULATOR
-16V
+23.5V
-23.5V
5V
+5V
+16V
-16V
+5V
Q1003
+5V POWER
SUPPLY
+5V
: AUDIO OUTPUT SIGNAL LINE
AC INLET
DAMP P.C.B.
AC INLET P.C.B.
POWER BUTTON P.C.B.
LED P.C.B.
SPEAKER
SUBWOOFER
NOTE: “ * ” REF IS FOR INDICATION ONLY
LED
FREQUENCY
SU-HTB550PH
D2000
DIGITAL RECEIVER MODULE P.C.B.
SMPS MODULE P.C.B.
SECONDARYPRIMARY

20
6 Schematic Diagram
6.1. Main Unit (SU-HTB550)
6.1.1. MAIN (CPU) CIRCUIT (1/2)
A
12 3 4 5 6 7 8 9 10 11 12 13 14
1 2 3 4 5 6 7 8 9 10 11 12 13 14
C
D
B
E
G
H
F
A
SC-HTB550PH (SU-HTB550PH)
2/21/2
P1
P2
P3
B
1
40
FOR
ID PROGRAMMING
HD: MAIN (HDMI) CIRCUIT: SCHEMATIC DIAGRAM - 1 ~ 4
CP: MAIN (CPU) CIRCUIT: SCHEMATIC DIAGRAM - 5 ~ 6
DP: MAIN (DSP) CIRCUIT: SCHEMATIC DIAGRAM - 7 ~ 8
HD
HD HDMI_1.8V
HDMI_GND
DSP_SD2
DSP_SD3 DP
DP
DSP_SD1
DSP_GND
DSP_GND
DSP_GND
IC2303
C3EBEY000042
EEPROM
R2311 4.7K
C2320
0
R2308 4.7K
1
FAN_DA
OTW
DC_DET
ECO_LVL
SD
DAP_MUTE
DSP_CLIP
DSP_IRQ
DSP_MODE
DAP_PDN
DAP_RESET
VALID
DSP_MCLK
OPTICAL2_IN
G1
G2
6
7
5
9
36
37
33
32
34
29
28
30
25
24
26
21
22
17
11
12
10
15
16
13
14
19
20
18
23
27
31
35
38
8
1
3
4
2
40
39
CN2201
OPTICAL1_IN
R2346 100
R2345 100
PCONT
DZ2J033M0L
D2806
R2368
1K
REG3.3V
1K
R2367
DAP_SDA
DAP_SCL
INTREQ_CODEC
ZERO
CS_CODEC
RESET_CODEC
REG3.3V
MISO_DSP
BUSY_DSP
CS_DSP
INTREQ_DSP
CLK_DSP
RESET_DSP
MOSI_DSP
R2294 47K
R2306 4.7K
C2313
REG12V
R2318
100K
ZERO
100
R2359
DSP_MODE
CS_CODEC
ECO_PCONT
100KR2352
R2361 100
RESET_CODEC
CS_DSP
0.1
C2303
R2317 100K
C2311
0.01
C2302
6.3V1000
C2301
0.1 0.1
C2310
KEY2
220K
R2286
R2381 100K
HDMI_SDA
RX01_EDID_CK
HDMI_SCL
STBY_H
RX01_EDID_DT
R2362
100K R2372
100K
R2380 100
R2385 100
R2387
R2386 1K
1K
R2383 100
R2384 100
LED_OE
LED_CLK
LED_DATA
LED_LCK
1K
R2258
W_INT
R2378 100
R2379 100
R2388
100K
INTREQ_CODEC
INTREQ_DSP
BUSY_DSP
RESET_DSP
CEC_IO
TX_INT
RX_INT
TX_RST
RX1_WRT_SEL
RX0_5V
RX0_HPD
TX_HPD
OTW
VSYNC_M
HD
HD
HD
HD
HD
HD
HD
HD
HD
HD
HD
HD
HD
HD
HD
HD
HD
HD
RX0_WRT_SEL
RX1_HPD
MISO_DSP MOSI_DSP
R2375 100 SD_OUT
R2376
0
SD
RX1_5V
C2376
22P
R2285 100K
DC_DET
ECO_LVL
PCONT
CLK_DSP
RX_RST
R2284 100K
C2369
22P
22P
22P
C2373
R2374
100
C2371
220KR2293
R2391 100
R2395 100K
1KR2393
10KR2389
KEY1
10KR2390
B0JCME000105
D2392 6.3V100
C2304
0.1
C2391
X2302
R2309
100K
C2308
12P
C2309
33P
REMOTE
R2303 100
RX0_WRT_SEL
R2326 100
R2335 4.7K
R2325 4.7K
R2330 100
R2329 100
DSP_IRQ
R2316 100
VALID
DAP_RESET
FLASH_RXD
FLASH_TXD
R2324 100
FLASH_CE
R2296
4.7K
R2295
4.7K
FLASH_EPM
R2321 100
R2331 100
FLASH_BUSY
FLASH_SCLK
LOG_MONI
_SW
R2332 100
R2344 100
R2339 100
100
R2320
100
R2319
DAP_MUTE
DAP_MUTE R2323 680
RX01_EDID_CK
R2357 100
RX0_HPD RX1_HPD
RX1_5V RX0_5V
RX1_WRT_SEL
100K
R2365
DSP_CLIP
R2351 100
STBY_H
79
77
76
78
49
48
47
50
74 7172 6768 56 5558 57 52 5154 536566 6162 596064 6370 697375
10
879 1211
99
100
95
94
96
97
90
91
89
93
92
98
465213
81
82
80
86
87
88
84
83
85
45
19171514 16 18
43
232120 22
41
24
39
37
34
35
33
32
27
31
30
29
28
26
36
38
25
40
42
44
13
46
IC2301
RFKWMHTB550P
MICROPROCESSOR
RX01_EDID_DT
BK_3.3V GND
CEC_IO
S_DET
S_DET
R2310
100K
150K
R2307
R2312
1K
3
1
2
X2301
VSYNC_M
DP
DP
DP
DP
DP
OPT GND
(CT/SW)
(FL/FR)
(SL/SR)
OPT GND
OPT GND
REG3.3V
OTW
DGND
DGND
DGND
VALID
S_DET
SD
DC_DET
DAP_PDN
REG12V
REG12V
REG12V
FAN_DA
DSP_SD3
DSP_SD1
DSP_GND
DSP_GND
DSP_GND
DSP_GND
DSP_SD2
DSP_GND
DSP IRQ
DSP MODE
DSP_SCLK
DSP_MCLK
DAP_MUTE
DAP_RESET
DAP_SDA
DAP_SCL
DSP_LRCLK
PCONT_INV
DSP CLIP
ECO_LEVEL
REG3.3V
OPT2 IN
OPT1 IN
DP
DP
DP
DP
DP
DP
DP
DP
DP
DP
DP
DP
RX RESET
KEY2
W_SSB
W_DET
VSS
FLASH CE
ADC_PDN
[49] RX0/1_EDID_SDA
[48] RX0/1_EDID_SCL
ZERO
STBY_H
RX0_5V_DET
CS_CODEC
DSP_MODE
RX1_HPD RX0_HPD
DAP/CS2_SDA
RX1_5V_DET
VCC2
ECO_PCONT
[50] RX1_WRT_SEL
[51] DSP_CLIP
FLASH EPM
ADC_MS-SL
[46] DAP/CS2_SCL
[47] RX0_WRT_SEL RX_INT
TX_INT
HDMI PCONT
REG1 AREA
REG2 MODEL
SD
MOSI_DSP
[77] CLK_DSP
[78] LED_DATA
[76] MISO_DSP
LED_OE
[80] LED_LCK
[79] LED_CLK
CS_DSP
TX_HPD
5V DET
RESET_DSP
RESET_CODEC
BUSY_DSP
SD_OUT
INTREQ_DSP
NC
INTREQ_CODEC
OTW
W_INT
PCONT
DC_DET
[99] W_SDO
AVSS
S_DET
[97] AVCC
[98] W_SDI
FLASH BUSY
[29] FLASH TXD
[28] BT_UART_TX
HDMI_SDA
[30] FLASH RXD
XCIN XCOUT CNVSS VSS XIN XOUT RESET BYTE FAN_DA REM(PMC0)
AUX/BT
[100] W_SCL
VCC1(VDET) VSYNC COUNT HDMI_MUTE_DET NC DAP_MUTE MUTE_ALL
AC_SYNC
AC_SYNC
ROM_SCL DAP RESET VALID ROM_SDA CEC I/O
FLASH SCLK
[27] BT_UART_RX
[26] DAP_PDN
[25] HDMI_MUTE_DIS
DSP_IRQ
TX RESET
HDMI_SCL
LOG_MONI_SW
KEY1
ECO_LEVEL [95] NC
[96] VREF
V_CHECK
7
8
54
3
2
1
6
WP
VCC
SDA
SCL
A2
GND
A0
A1
RESET CNVSS
R2302 100K
R2315 150
150
R2314
R2363
W_SSB 100
W_DET 100
R2364
W_SCL
W_SDO
W_SDI R2399
R2398
R2300 100
100
100
B0ACCK000012
D2305
R2282
R2281 47K
100K
DAP_PDN
CN2302
N.C.
GND
N.C.
N.C.
+3.3V
IDROM_DT
IDROM_CK
N.C.
N.C.
N.C.
6
8
9
7
2
1
4
5
3
10
D2308
D2307 B0ACCK000012
B0ACCK000012
D2310 B0JCCD000017
D2309 B0JCCD000017
47K 47K 4.7K 4.7K
R2347 R2348 R2349 R2350
RX_INT
TX_INT
100
100
100
R2340
R2342
R2341
RX_RST
TX_RST
R2336
100
100
R2337
HDMI_SCL
HDMI_SDA
R2333
R2334
47
47
HDMI_PCONT
HDMI_PCONT
TX_HPD
R2366 100
100K
R2382
R2751
15K
R2752
15K
R2753
18K
: +B SIGNAL LINE : OPTICAL AUDIO INPUT SIGNAL LINE : AUDIO OUTPUT SIGNAL LINE
TO
DAMP
CIRCUIT
(CN5200)
IN SCHEMATIC
DIAGRAM - 9
MAIN (CPU) CIRCUIT
TO MAIN (CPU)
SECTION (2/2)
MAIN (CPU) CIRCUIT
SCHEMATIC DIAGRAM - 5
