NN-P994 NN-T994SF

3
NN-P994 NN-T994SF

1 SCHEMATIC DIAGRAM 5
1.1. APH 5
1.2. CPH 6
2 MEASUREMENTS AND ADJUSTMENTS 7
2.1. Adjustment of primary latch switch, secondary latch switch
and short switch. 7
2.2. Measurement of microwave output 7
3 PROCEDURE FOR MEASURING MICROWAVE ENERGY
LEAKAGE 8
3.1. Equipment 8
3.2. Procedure for measuring radiation leakage 8
3.3. Record keeping and notification after measurement 8
3.4. At least once a year, have the radiation monitor checked
for calibration by its manufacturer. 8
4 EXPLODED VIEW AND PARTS LIST 9
4.1. EXPLODED VIEW 9
4.2. PARTS LIST 10
4.3. ESCUTCHEON BASE ASSEMBLY 12
4.4. WIRING MATERIALS 14
4.5. PACKING AND ACCESSORIES 15
4.6. DOOR ASSEMBLY 16
5 DIGITAL PROGRAMMER CIRCUIT 17
5.1. NN-P994 APH/CPH 17
5.2. NN-T994SF APH, T984SF APH 19
5.3. NN-T964SF APH 21
5.4. H964BF/WF APH, H964BF/WF CPH, S954BF/WF APH
23
5.5. H944BF(W)/WF(W) APH, H934BF/WF APH,
H924BF(W)/WF(W) APH, S944BF(W)/WF(W) APH,
S924BF(W)/WF(W) APH, S914BF/WF APH 25
5.6. PARTS LIST 27
CONTENTS
Page Page
4
NN-P994 NN-T994SF

1 SCHEMATIC DIAGRAM
1.1. APH
5
NN-P994 NN-T994SF

1.2. CPH
6
NN-P994 NN-T994SF

2.1. Adjustment of primary latch
switch, secondary latch switch
and short switch.
1. Mount the Primary latch switch, the Secondary latch switch
and the short switch to the door hook assembly as shown in
ILL.
NOTE:
No specific individual adjustments during
installation of the Primary latch switch, Secondary
latch switch or Short switch to the door hook are
required.
2. When mounting the door hook assembly to the oven
assembly, adjust the door hook assembly by moving it in
the direction of the arrows in the illustration so that the oven
door will not have any play in it. Check for play in the door
by pulling the door assembly. Make sure that the latch keys
move smoothly after adjustment is completed. Completely
tighten the screws holding the door hook assembly to the
oven assembly.
3. Reconnect the short switch and check the continuity of the
monitor circuit and all latch switches again by following the
component test procedures.
2.2. Measurement of microwave
output
The output power of the magnetron can be determined by
performing IEC standard test procedures. However,due to the
complexity of IEC test procedures, it is recommended to test
the magnetron using the simple method outlined below.
Necessary Equipment:
*1 liter beaker *Glass thermometer
*Wrist watch or stopwatch
NOTE:
Check the line voltage under load.Low voltage will
lower the magnetron output. Take the temperature
readings and heating time as accurately as possible.
1. Fill the beaker with exactly one liter of tap water.Stir the
water using the thermometer and record the water’s
temperature. (recorded as T1).
2. Place the beaker on the center of glass tray.
Set the oven for High power and heat it for exactly one
minute.
3. Stir the water again and read the temperature of the water.
(recorded as T2).
4. The normal temperature rise at High power level for each
model is as shown in table.
TABLE (1L-1min.test)
RATED OUTPUT TEMPERATURE RISE
1200W(IEC705-88) Min. 18.5°F(10.3°C)
1300W(IEC705-88) Min. 19.8°F(11.1°C)
2 MEASUREMENTS AND ADJUSTMENTS
7
NN-P994 NN-T994SF

NOTE:
The U.S. Government standard is 5 mW/cm2while in the
customer’s home. 2mW/cm2stated here is our own
voluntary standard. (1mW/cm2for Canada)
3.1. Equipment
• • •
• Electromagnatic radiation monitor
• • •
• Glass thermometer 212°F or 100°C
• • •
• 600cc glass beaker
3.2. Procedure for measuring
radiation leakage
Note before measuring.
• • •
• Do not exceed meter full scale deflection. Leakage monitor
should initially be set to the highest scale.
• • •
• To prevent false readings the test probe should be held by
the grip portion of the handle only and moved along the
shaded area in Figure no faster than 1 inch/sec
(2.5cm/sec).
• • •
• Leakage with the outer panel removed ...... less than
5mW/cm2.
• • •
• Leakage for a fully assembled oven with door normally
closed ...... less than 2mW/cm 2(1mW/cm 2for Canada).
• • •
• Leakage for a fully assembled oven [Before the latch switch
(primary) is interrupted] while pulling the door ...... less than
2mW/cm 2.
1. Pour 275 ± 15cc (9ozss± 1/2oz) of 20°C ± 5°C (68° ± 9°F)
water in a beaker which is graduated to 600cc, and place in
the center of the oven.
2. Set the radiation monitor to 2450MHz and use it following
the manufacturer´s recommended test procedure to assure
correct results.
3. When measuring the leakage, always use the 2 inch (5cm)
spacer supplied with the probe.
4. Tap the start pad or set the timer and with the magnetron
oscillating, measure the leakage by holding the probe
perpendicular to the surface being measured.
3.2.1. Measurement with the outer panel
removed.
Whenever you replace the magnetron, measure for radiation
leakage before the outer panel is installed and after all
necessary components are replaced or adjusted. Special care
should be taken in measuring around the magnetron.
3.2.2. Measurements with a fully
assembled oven.
After all components, including outer panel are fully assembled,
measure for radiation leakage around the door periphery, the
door viewing window, the exhaust opening and air inlet
openings.
3.3. Record keeping and
notification after measurement
• • •
• After any adjustment or repair to a microwave oven, a
leakage reading must be taken. Record this leakage
reading on the repair ticket even if it is zero.
A copy of this repair ticket and the microwave leakage
reading should be kept by repair facility.
• • •
• Should the radiation leakage be more than 2 mW/cm2
(1mW/cm for Canada) after determining that all parts are in
good condition, functioning properly, and genuine
replacement parts as listed in this manual have been used,
immediately notify PASC, PSC or PCI.
3.4. At least once a year, have the
radiation monitor checked for
calibration by its
manufacturer.
3 PROCEDURE FOR MEASURING MICROWAVE ENERGY
LEAKAGE
8
NN-P994 NN-T994SF

4 EXPLODED VIEW AND PARTS LIST
4.1. EXPLODED VIEW
9
NN-P994 NN-T994SF

4.2. PARTS LIST
NOTE:
1. When ordering replacement part(s), please use part number(s) shown in this part list.
Do not use description of the part.
2. Important safety notice:
Components identified by mark have special characteristics important for safety.
When replacing any of these components, use only manufacture’s specified parts.
NOTE:
“A” parts are supplied by MOD (Japan)
“F” parts are supplied by SIMMC (China)
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
1F00064W70AP CAUTION LABEL 1P994 APH, T9*4SF APH
1F00069660AP CAUTION LABEL 1 H9*4 APH, S9*4 APH
1F00067600CP CAUTION LABEL 1 CPH
2F00076G30BAP NAME PLATE 1H964BF APH
2F00076G30HAP NAME PLATE 1H964WF APH
2F00076G60BAP NAME PLATE 1H944BF APH
2F00076G60HAP NAME PLATE 1H944WF APH
2F00076G80BAP NAME PLATE 1H944BFW APH
2F00076G80HAP NAME PLATE 1H944WFW APH
2F00076G40BAP NAME PLATE 1S954BF APH
2F00076G40HAP NAME PLATE 1S954WF APH
2F00076G70BAP NAME PLATE 1S944BF APH
2F00076G70HAP NAME PLATE 1S944WF APH
2F00076G90BAP NAME PLATE 1S944BFW APH
2F00076G90HAP NAME PLATE 1S944WFW APH
2F00076H20BAP NAME PLATE 1H924BF APH
2F00076H20HAP NAME PLATE 1H924WF APH
2F00076H40BAP NAME PLATE 1H914BF APH
2F00076H40HAP NAME PLATE 1H914WF APH
2F00076H00BAP NAME PLATE 1H934BF APH
2F00076H00HAP NAME PLATE 1H934WF APH
2F00076Q10BAP NAME PLATE 1H924BFW APH
2F00076Q10HAP NAME PLATE 1H924WFW APH
2F00076H30BAP NAME PLATE 1S924BF APH
2F00076H30HAP NAME PLATE 1S924WF APH
2F00076H50BAP NAME PLATE 1S914BF APH
2F00076H50HAP NAME PLATE 1S914WF APH
2F00076H10BAP NAME PLATE 1S934BF APH
2F00076H10HAP NAME PLATE 1S934WF APH
2F00076Q20BAP NAME PLATE 1S924BFW APH
2F00076Q20HAP NAME PLATE 1S924WFW APH
3F00334W00AP FUSE LABEL 1
4F10016G10AP BASE 1
5F10084T00AP RUBBER FOOT 4
6F110D5W00SAP CABINET BODY 1P994SF, T9*4SF APH
6F110D5W20BAP CABINET BODY 1P994BF, H9*4BF(W), S9*4BF(W)
6F110D5W20HAP CABINET BODY 1P994WF, H9*4WF(W), S9*4WF(W)
7F200A5W20AP OVEN 1 P994 APH/CPH, T9*4SF APH, H9*4 APH/CPH
7F200A5W30AP OVEN 1 S9*4 APH
8F20555K00AP COVER 1
9F21315Y00AP PULLY SHAFT 1
10 F2177-F80 WASHER 1
11 F290D9330AP ROLLER RING (U) 1
12 F3020-1200 DOOR HOOK 1
14 F3136-1200 HOOK LEVER A 1
15 F31374650AP HOOK LEVER B 1
16 F31384650AP HOOK LEVER C 1
17 F400A5Y00AP FAN MOTOR 1AC120V, SINGLE PHASE, 60Hz
18 F40084T00AP FAN BLADE 1
19 F40254W00AP AIR GUIDE A 1
21 F41445W00AP ORIFICE 1
22 F64508660AP SENSOR COVER B 1P994 APH/CPH, T9*4SF APH, H9*4 APH/CPH
24 F65434W00AP SENSOR COVER C 1P994 APH/CPH, T9*4SF APH, H9*4 APH/CPH
25 A607S4M00AP STEAM SENSOR 1P994 APH/CPH, T9*4SF APH, H9*4 APH/CPH
10
NN-P994 NN-T994SF

Ref. No. Part No. Part Name & Description Pcs/Set Remarks
26 F612E4W00AP INCANDESCENT LAMP (U) 1125V, 60Hz, 20W
27 J61424T00AP MICRO SWITCH 1(PRIMARY LATCH SWITCH) (V-15G-3C25)
28 J61414T00AP MICRO SWITCH 1(SECONDARY LATCH SWITCH) (D3V-16G-3C25)
29 F61455L00CP THERMAL CUTOUT 1105°C
30 F66264W00AP THERMAL CUTOUT
INSULATION BRACKET
1
31 J61784T00AP MICRO SWITCH 1(SHORT SWITCH) (D3V-1G-2C25)
32 A606Y6G00AP H.V.INVERTER (U) 1
33 F65856K10AP INVERTER BRACKET 1P994 APH, T9*4SF APH
33 F65856K50AP INVERTER BRACKET 1P994 CPH, H9*4 APH/CPH, S9*4 APH
34 2M261-M32F MAGNETRON 1 APH
34 2M261-M32G MAGNETRON 1 CPH
35 B62308250AP FUSE 1 18A
36 F62315G10XN FUSE HOLDER 1 APH
37 J692Y4T00CPR NOISE FILTER 1 CPH
38 F63265G60AP TURNTABLE MOTOR 1
39 F900C4T60CP AC CORD W/PLUG 1P994 APH/CPH, T9*4SF APH
39 F900C4T00AP AC CORD W/PLUG 1 H9*4 APH, S9*4 APH
39 F900C4W10CP AC CORD W/PLUG 1 CPH
40 F66626G10AP GROUNDING PLATE 1
41 XTWFA4+12T SCREW 4FOR MAGNETRON
42 F90804W00AP CANOE CLIP 1FOR COVER
43 XTTANE4T12A0 SCREW 5FOR CABINET BODY
44 XTTFA4+8BFZ SCREW 2FOR CABINET BODY SIDE (P994BF, H9*4BF(W), S9*4BF(W))
44 XTTFA4+8BCR SCREW 2FOR CABINET BODY SIDE
(P994SF/WF, T9*4SF, H9*4WF(W), S9*4WF(W))
45 XTWAFE4+8S SCREW 1FOR THERMAL CUTOUT
46 F02245Y00AP CAUTION LABEL 1P994SF APH/CPH, T9*4SF APH
47 F03346G60AP MENU LABEL 1H944BF/WF APH
47 F03346G80AP MENU LABEL 1H944BFW/WFW APH
47 F03346G40AP MENU LABEL 1S954BF/WF APH
47 F03346G70AP MENU LABEL 1S944BF/WF APH
47 F03346G90AP MENU LABEL 1S944BFW/WFW APH
47 F03346H20AP MENU LABEL 1H924BF/WF APH
47 F03346H40AP MENU LABEL 1H914BF/WF APH
47 F03346H00AP MENU LABEL 1H934BF/WF APH
47 F03346Q10AP MENU LABEL 1H924BFW/WFW APH
47 F03346H30AP MENU LABEL 1S924BF/WF APH
47 F03346H50AP MENU LABEL 1S914BF/WF APH
47 F03346H10AP MENU LABEL 1S934BF/WF APH
47 F03346Q20AP MENU LABEL 1S924BFW/WFW APH
50 F82575W00AP DOOR OPENING BRACKET 1P994 APH/CPH, T994SF APH, T984SF APH
50 F82574U00AP DOOR OPENING BRACKET 1T964SF APH, H9*4 APH/CPH, S9*4 APH
11
NN-P994 NN-T994SF

4.3. ESCUTCHEON BASE ASSEMBLY
4.3.1. NN-H9*4 APH/CPH, NN-S9*4 APH
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
E1 F603L6G30AP D.P.CIRCUIT 1H964BF/WF APH
E1 F603L6G60AP D.P.CIRCUIT 1H944BF/WF/BFW/WFW APH, H924BF/WF/BFW/WFW APH
E1 F603L6G30CP D.P.CIRCUIT 1H964BF/WF CPH
E1 F603L6G40AP D.P.CIRCUIT 1S954BF/WF APH
E1 F603L6G70AP D.P.CIRCUIT 1S944BF/WF/BFW/WFW APH, S924BF/WF/BFW/WFW APH
E1 F603L6H00AP D.P.CIRCUIT 1H934BF/WF APH, H914BF/WF APH
E1 F603L6H10AP D.P.CIRCUIT 1S934BF/WF APH, S914BF/WF APH
E3 F630Y6G30BAP MEMBRANE SWITCH (U) 1H964BF APH
E3 F630Y6G30HAP MEMBRANE SWITCH (U) 1H964WF APH
E3 F630Y6G60BAP MEMBRANE SWITCH (U) 1H944BF/BFW APH
E3 F630Y6G60HAP MEMBRANE SWITCH (U) 1H944WF/WFW APH
E3 F630Y6G30BCP MEMBRANE SWITCH (U) 1H964BF CPH
E3 F630Y6G30HCP MEMBRANE SWITCH (U) 1H964WF CPH
E3 F630Y6G40BAP MEMBRANE SWITCH (U) 1S954BF APH
E3 F630Y6G40HAP MEMBRANE SWITCH (U) 1S954WF APH
E3 F630Y6G70BAP MEMBRANE SWITCH (U) 1S944BF/BFW APH
E3 F630Y6G70HAP MEMBRANE SWITCH (U) 1S944WF/WFW APH
E3 F630Y6H20BAP MEMBRANE SWITCH (U) 1H924BF/BFW APH
E3 F630Y6H20HAP MEMBRANE SWITCH (U) 1H924WF/WFW APH
E3 F630Y6H00BAP MEMBRANE SWITCH (U) 1H934BF APH, H914BF APH
E3 F630Y6H00HAP MEMBRANE SWITCH (U) 1H934WF APH, H914WF APH
E3 F630Y6H30BAP MEMBRANE SWITCH (U) 1S924BF/BFW APH
E3 F630Y6H30HAP MEMBRANE SWITCH (U) 1S924WF/WFW APH
E3 F630Y6H10BAP MEMBRANE SWITCH (U) 1S934BF APH, S914BF APH
E3 F630Y6H10HAP MEMBRANE SWITCH (U) 1S934WF APH, S914WF APH
E4 F80346G40BAP ESCUTCHEON BASE 1H9*4BF(W) APH/CPH, S9*4BF(W) APH
E4 F80346G40HAP ESCUTCHEON BASE 1H9*4WF(W) APH/CPH, S9*4WF(W) APH
E5 F80726G40BAP DOOR OPENING BUTTON 1H9*4BF(W) APH/CPH, S9*4BF(W) APH
E5 F80726G40HAP DOOR OPENING BUTTON 1H9*4WF(W) APH/CPH, S9*4WF(W) APH
E6 F80375K00AP COOK BUTTON SPRING 1
E7 F82564M60AP DOOR OPENING LEVEL 1
E8 F00076G30BCP NAME PLATE 1H964BF CPH
E8 F00076G30HCP NAME PLATE 1H964WF CPH
12
NN-P994 NN-T994SF

4.3.2. NN-P994 APH/CPH, NN-T9*4 APH
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
E10 F603L6G00AP D.P.CIRCUIT (AU) 1 P994 APH
E10 F603L6G00CP D.P.CIRCUIT (AU) 1 P994 CPH
E10 F603L6G10AP D.P.CIRCUIT (AU) 1T994SF APH, T984SF APH
E10 F603L6Q00AP D.P.CIRCUIT (AU) 1T964SF APH
E11 F800L4M60BCP CONTROL PANEL (AU) 1T964SF APH
E12 F630Y6Q00SAP MEMBRANE SWITCH (U) 1T964SF APH
E13 F82565W00AP DOOR OPENING LEVEL 1P994 APH/CPH, T994SF APH, T984SF APH
E13 F82564M60AP DOOR OPENING LEVEL 1T964SF APH
E14 F81274M60CP BACK PANEL 1T964SF APH
E15 F00076G00SAP NAME PLATE 1P994SF APH
E15 F00076G00BAP NAME PLATE 1P994BF APH
E15 F00076G00HAP NAME PLATE 1P994WF APH
E15 F00076G00SCP NAME PLATE 1P994SF CPH
E15 F00076G00BCP NAME PLATE 1P994BF CPH
E15 F00076G00HCP NAME PLATE 1P994WF CPH
E15 F00076G10SAP NAME PLATE 1T994SF APH
E15 F00076G20SAP NAME PLATE 1T984SF APH
E15 F00076Q00SAP NAME PLATE 1T964SF APH
E16 F66164W20AP FLAT CABLE 1P994 APH/CPH, T994SF APH, T984SF APH
E17 F603Y5W00AP D.P.CIRCUIT (DU) 1P994 APH, T994SF APH, T984SF APH
E17 F603Y5W00CP D.P.CIRCUIT (DU) 1 P994 CPH
E18 F83376G10SAP MEMBRANE SHEET 1T994SF APH
E18 F83376G20SAP MEMBRANE SHEET 1T984SF APH
E19 F800L6G00SAP CONTROL PANEL (AU) 1P994SF APH
13
NN-P994 NN-T994SF

Ref. No. Part No. Part Name & Description Pcs/Set Remarks
E19 F800L6G00BAP CONTROL PANEL (AU) 1P994BF APH
E19 F800L6G00HAP CONTROL PANEL (AU) 1P994WF APH
E19 F800L6G00SCP CONTROL PANEL (AU) 1P994SF CPH
E19 F800L6G00BCP CONTROL PANEL (AU) 1P994BF CPH
E19 F800L6G00HCP CONTROL PANEL (AU) 1P994WF CPH
E19 F800L5W00BAP CONTROL PANEL (AU) 1T994SF APH, T984SF APH
E20 F82986G00SAP BUTTON 1P994SF APH/CPH
E20 F82986G00BAP BUTTON 1P994BF APH/CPH
E20 F82986G00HAP BUTTON 1P994WF APH/CPH
E20 F82985W00AP BUTTON 1T994SF APH
E20 F82985W00BAP BUTTON 1T984SF APH
E21 F90095X00AP GROUNDING PANEL 1P994 APH/CPH, T994SF APH, T984SF APH
E22 F891P6G00SAP DOOR OPENING BUTTON 1P994SF APH/CPH
E22 F891P6G00BAP DOOR OPENING BUTTON 1P994BF APH/CPH
E22 F891P6G00HAP DOOR OPENING BUTTON 1P994WF APH/CPH
E22 F80724M60SCP DOOR OPENING BUTTON 1T9*4SF APH
E23 F80375K00AP COOK BUTTON SPRING 1P994 APH/CPH, T9*4SF APH
4.4. WIRING MATERIALS
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
W1 F030A6G30AP LEAD WIRE HARNESS 1 APH
W1 F030A6G30CP LEAD WIRE HARNESS 1 CPH
W2 F030E6G30AP H.V.LEAD WIRE 1 APH
W2 F030E6G30CP H.V.LEAD WIRE 1 CPH
14
NN-P994 NN-T994SF

4.5. PACKING AND ACCESSORIES
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
P1 F00036J00AP INSTRUCTION MANUAL 1P994SF/BF/WF APH, T9*4SF APH, H964BF/WF APH
P1 F00036J00CP INSTRUCTION MANUAL 1P994SF/BF/WF CPH, H964BF/WF CPH
P1 F00036J30AP INSTRUCTION MANUAL 1S954BF/WF APH
P1 F00036J50AP INSTRUCTION MANUAL 1H944BF/WF/BFW/WFW APH, H934BF/WF APH,
H924BF/WF/BFW/WFW APH, H914BF/WF APH
P1 F00036J60AP INSTRUCTION MANUAL 1S944BF/WF/BFW/WFW APH, S934BF/WF APH,
S924BF/WF/BFW/WFW APH, S914BF/WF APH
P2 F01026G00SAP PACKING CASE, PAPER 1P994SF APH
P2 F01026G00BAP PACKING CASE, PAPER 1P994BF APH
P2 F01026G00HAP PACKING CASE, PAPER 1P994WF APH
P2 F01026G00SCP PACKING CASE, PAPER 1P994SF CPH
P2 F01026G00BCP PACKING CASE, PAPER 1P994BF CPH
P2 F01026G00HCP PACKING CASE, PAPER 1P994WF CPH
P2 F01026G10SAP PACKING CASE, PAPER 1T994SF APH
P2 F01026G20SAP PACKING CASE, PAPER 1T984SF APH
P2 F01026Q00SAP PACKING CASE, PAPER 1T964SF APH
P2 F01026G30BAP PACKING CASE, PAPER 1H964BF APH
P2 F01026G30HAP PACKING CASE, PAPER 1H964WF APH
P2 F01026G60BAP PACKING CASE, PAPER 1H944BF APH
P2 F01026G60HAP PACKING CASE, PAPER 1H944WF APH
P2 F01026G80BAP PACKING CASE, PAPER 1H944BFW APH
P2 F01026G80HAP PACKING CASE, PAPER 1H944WFW APH
P2 F01026G30BCP PACKING CASE, PAPER 1H964BF CPH
P2 F01026G30HCP PACKING CASE, PAPER 1H964WF CPH
P2 F01026G40BAP PACKING CASE, PAPER 1S954BF APH
P2 F01026G40HAP PACKING CASE, PAPER 1S954WF APH
P2 F01026G70BAP PACKING CASE, PAPER 1S944BF APH
P2 F01026G70HAP PACKING CASE, PAPER 1S944WF APH
P2 F01026G90BAP PACKING CASE, PAPER 1S944BFW APH
P2 F01026G90HAP PACKING CASE, PAPER 1S944WFW APH
P2 F01026H20BAP PACKING CASE, PAPER 1H924BF APH
P2 F01026H20HAP PACKING CASE, PAPER 1H924WF APH
P2 F01026H40BAP PACKING CASE, PAPER 1H914BF APH
P2 F01026H40HAP PACKING CASE, PAPER 1H914WF APH
P2 F01026H00BAP PACKING CASE, PAPER 1H934BF APH
P2 F01026H00HAP PACKING CASE, PAPER 1H934WF APH
P2 F01026Q10BAP PACKING CASE, PAPER 1H924BFW APH
P2 F01026Q10HAP PACKING CASE, PAPER 1H924WFW APH
15
NN-P994 NN-T994SF

Ref. No. Part No. Part Name & Description Pcs/Set Remarks
P2 F01026H30BAP PACKING CASE, PAPER 1S924BF APH
P2 F01026H30HAP PACKING CASE, PAPER 1S924WF APH
P2 F01026H50BAP PACKING CASE, PAPER 1S914BF APH
P2 F01026H50HAP PACKING CASE, PAPER 1S914WF APH
P2 F01026H10BAP PACKING CASE, PAPER 1S934BF APH
P2 F01026H10HAP PACKING CASE, PAPER 1S934WF APH
P2 F01026Q20BAP PACKING CASE, PAPER 1S924BFW APH
P2 F01026Q20HAP PACKING CASE, PAPER 1S924WFW APH
P3 F01044W00AP UPPER FILLER 1P994 APH/CPH, T9*4SF APH
P3 F01045J00AP UPPER FILLER 1H9*4 APH/CPH, S9*4 APH/CPH
P4 F01054W00AP LOWER FILLER 1P994 APH/CPH, T9*4SF APH
P4 F01055J00AP LOWER FILLER 1H9*4 APH/CPH, S9*4 APH/CPH
P5 F01064W00AP P.E.BAG 1
P6 F01074U00AP DOOR SHEET 1
P7 F06014M00AP COOKING TRAY 1
P8 F01084M00AP TRAY PACKING 1
P9 F01924U00AP SHEET 1P994BF APH/CPH, H9*4BF(W) APH/CPH, S9*4BF(W) APH
P10 F00065G40AP CAUTION LABEL 1 APH
P11 F04456G00SCP OVERLAY 1P994SF CPH
P11 F04456G00BCP OVERLAY 1P994BF CPH
P11 F04456G00HCP OVERLAY 1P994WF CPH
P11 F04456G30BCP OVERLAY 1H964BF CPH
P11 F04456G30HCP OVERLAY 1H964WF CPH
4.6. DOOR ASSEMBLY
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
D1 F3018-1200 DOOR KEY A 1
D2 F302A6G00SAP DOOR A (U) 1 P994SF APH/CPH
D2 F302A6G00BAP DOOR A (U) 1 P994BF APH/CPH
D2 F302A6G00HAP DOOR A (U) 1 P994WF APH/CPH
D2 F302A5W00SAP DOOR A (U) 1 T9*4SF APH
D2 F30016G40BAP DOOR A 1 H9*4BF(W) APH/CPH, S9*4BF(W) APH
D2 F30016G40HAP DOOR A 1 H9*4WF(W) APH/CPH, S9*4WF(W) APH
D3 F302K4U00AP DOOR E (U) 1
D4 F30215G10XN DOOR KEY SPRING 1
D5 F30854U00AP DOOR C 1
D6 F31454U00AP DOOR SCREEN A 1
D7 F31466G00SAP DOOR SCREEN B 1P994 APH/CPH
D7 F31465W00SAP DOOR SCREEN B 1T9*4SF APH
D7 F31466G40BAP DOOR SCREEN B 1H9*4BF(W) APH/CPH, S9*4BF(W) APH
D7 F31466G40HAP DOOR SCREEN B 1H9*4WF(W) APH/CPH, S9*4WF(W) APH
D8 F02459660AP DHHS LABEL 1P994SF/BF/WF APH, T9*4SF APH
D8 F04114180CP DHHS LABEL 1 P994 CPH
16
NN-P994 NN-T994SF

5 DIGITAL PROGRAMMER CIRCUIT
5.1. NN-P994 APH/CPH
17
NN-P994 NN-T994SF

18
NN-P994 NN-T994SF

5.2. NN-T994SF APH, T984SF APH
19
NN-P994 NN-T994SF

20
NN-P994 NN-T994SF
