Panasonic TH-42PD60U, TH-42PD60X User manual

©2006 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
TH-42PD60U
GP9DU Chassis
Digital Progressive Wide Plasma Television
Specifications
Power Source AC 120 V, 50/60 Hz
Power Consumption
Maximum 345 W
Standby condition 0.2 W
Plasma Display panel
Drive method AC type
Aspect Ratio 16 : 9
Contrast Ratio (max) 10000 : 1
Visible screen size
(No. of pixels)
106 cmV
36.3 ” × 20.4 ” × 41.6 ” (920 mm × 518 mm × 1,056 mm)
408,960 (852 (W) × 480 (H)) [2,556 × 480 dots]
Sound
Speaker 4.8 ” × 2.4 ” (120 mm × 60 mm) × 2 pcs, 8W
Audio Output 20 W [10 W + 10 W] (10 % THD)
Channel Capability (Digital/Analog) VHF/UHF: 2 - 69, CATV: 1 - 135
Operating Conditions Temperature: 32 °F - 104 °F (0 °C - 40 °C)
Humidity: 20 % - 80 % RH (non-condensing)
Connection Terminals
INPUT 1-2 VIDEO: RCA PIN Type × 1 1.0 V [p-p] (75 W)
S-VIDEO: Mini DIN 4-pin Y: 1.0 V [p-p] (75 W) C: 0.286 V [p-p] (75 W)
AUDIO L-R: RCA PIN Type × 2 0.5 V [rms]
COMPONENT VIDEO
INPUT 1-2
Y: 1.0 V [p-p] (including synchronization)
PB,P
R:± 0.35 V [p-p]
AUDIO L-R: RCA PIN Type × 2 0.5 V [rms]
HDMI 1-2 TYPE A Connector
AUDIO L-R: RCA PIN Type × 2 0.5 V [rms]
Card slot (Service only) SD CARD slot × 1
ORDERNO.MTNC060265CE
B19 Canada: B07

1 Applicable signals 4
2 Safety Precautions 4
2.1. General Guidelines 4
3 Prevention of Electro Static Discharge (ESD) to
Electrostatically Sensitive (ES) Devices 5
4 About lead free solder (PbF) 6
5 Service Hint 7
6 Plasma panel replacement method 8
6.1. Remove the Back cover 8
6.2. Remove the tuner cover 8
6.3. Remove the P-Board 8
6.4. Remove the PA-Board 8
6.5. Remove the tuner unit 8
6.6. Remove the DT-Board 9
6.7. Remove the DG-Board 9
6.8. Remove the H-Board 10
6.9. Remove the HC-Board 10
6.10. Remove the D-Board 10
6.11. Remove the SU-Board 10
6.12. Remove the SD-Board 11
6.13. Remove the SC-Board 11
6.14. Remove the SS-Board 11
6.15. Remove the C1-Board 11
6.16. Remove the C2-Board 12
6.17. Remove the speaker L, R 12
6.18. Remove the S-Board 12
6.19. Remove the K-Board 13
6.20. Remove the stand brackets 13
6.21. Remove the Plasma panel section from the Front frame
(glass) 13
6.22. Replace the plasma panel (finished) 14
7 Location of Lead Wiring 15
7.1. Lead of Wiring (1) 15
7.2. Lead of Wiring (2) 16
7.3. Lead of Wiring (3) 17
7.4. Lead of Wiring (4) 18
7.5. Lead of Wiring (5) 19
7.6. Lead of Wiring (6) 20
8 Self-check Function 21
8.1. Check of the IIC bus lines 21
8.2. Power LED Blinking timing chart 23
8.3. No Power 24
8.4. No Picture 25
8.5. Local screen failure 26
9 Serviceman Mode 27
9.1. How to enter into Serviceman Mode 27
9.2. Contents of adjustment mode 27
9.3. Memory edit mode 28
9.4. Device data mode 29
10 Adjustment Procedure 30
10.1. Driver Set-up 30
10.2. Initialization Pulse Adjust 31
10.3. P.C.B. (Printed Circuit Board) exchange 31
10.4. Adjustment Volume Location 32
10.5. Test Point Location 32
11 Adjustment 33
11.1. White balance adjustment 33
11.2. Sub bright adjustment 35
11.3. ABL operation level adjustment 36
12 Hotel mode 37
13 Conductor Views 39
13.1. P-Board 39
AV PROG. OUT VIDEO: RCA PIN Type × 1 1.0 V [p-p] (75 W)
AUDIO L-R: RCA PIN Type × 2 0.5 V [rms]
DIGITAL AUDIO OUT PCM/Dolby Digital, Fiber Optic
FEATURES 3D Y/C FILTER
CLOSED CAPTION V-Chip
Dimensions (W × H × D)
Including pedestal 42.1 ” × 30.1 ” × 12.6 ” (1,068 mm × 764 mm × 320 mm)
TV Set only 42.1 ” × 27.6 ” × 3.8 ” (1,068 mm × 701 mm × 97 mm)
Weight
Including pedestal 68.4 lb. (31 kg)
TV Set only 64.0 lb. (29 kg)
Note:
Design and Specifications are subject change without notice.
Weight and Dimensions shown are approximate.
CONTENTS
Page Page
2
TH-42PD60U

13.2. PA-Board 42
13.3. H-Board 44
13.4. HC, K and S-Board 46
13.5. DG-Board 47
13.6. DT-Board 49
13.7. D-Board 51
13.8. C1-Board 53
13.9. C2-Board 54
13.10. SC-Board 55
13.11. SU-Board 58
13.12. SD-Board 59
13.13. SS-Board 60
14 Schematic and Block Diagram 63
14.1. Schematic Diagram Note 63
14.2. Main Block Diagram 64
14.3. P-Board Block Diagram 65
14.4. P-Board (1 of 6) Schematic Diagram 66
14.5. P-Board (2 of 6) Schematic Diagram 67
14.6. P-Board (3 of 6) Schematic Diagram 68
14.7. P-Board (4 of 6) Schematic Diagram 69
14.8. P-Board (5 of 6) Schematic Diagram 70
14.9. P-Board (6 of 6) Schematic Diagram 71
14.10. PA-Board Block Diagram 72
14.11. PA-Board (1 of 2) Schematic Diagram 73
14.12. PA-Board (2 of 2) Schematic Diagram 74
14.13. H-Board Block Diagram 75
14.14. H-Board (1 of 3) Schematic Diagram 76
14.15. H-Board (2 of 3) Schematic Diagram 77
14.16. H-Board (3 of 3) Schematic Diagram 78
14.17. HC, K and S-Board Block Diagram 79
14.18. HC, K and S-Board Schematic Diagram 80
14.19. DG-Board (1 of 3) Block Diagram 81
14.20. DG-Board (2 of 3) Block Diagram 82
14.21. DG-Board (3 of 3) Block Diagram 83
14.22. DG-Board (1 of 8) Schematic Diagram 84
14.23. DG-Board (2 of 8) Schematic Diagram 85
14.24. DG-Board (3 of 8) Schematic Diagram 86
14.25. DG-Board (4 of 8) Schematic Diagram 87
14.26. DG-Board (5 of 8) Schematic Diagram 88
14.27. DG-Board (6 of 8) Schematic Diagram 89
14.28. DG-Board (7 of 8) Schematic Diagram 90
14.29. DG-Board (8 of 8) Schematic Diagram 91
14.30. DT-Board Block Diagram 92
14.31. DT-Board (1 of 6) Schematic Diagram 93
14.32. DT-Board (2 of 6) Schematic Diagram 94
14.33. DT-Board (3 of 6) Schematic Diagram 95
14.34. DT-Board (4 of 6) Schematic Diagram 96
14.35. DT-Board (5 of 6) Schematic Diagram 97
14.36. DT-Board (6 of 6) Schematic Diagram 98
14.37. D-Board Block Diagram 99
14.38. D-Board (1 of 6) Schematic Diagram 100
14.39. D-Board (2 of 6) Schematic Diagram 101
14.40. D-Board (3 of 6) Schematic Diagram 102
14.41. D-Board (4 of 6) Schematic Diagram 103
14.42. D-Board (5 of 6) Schematic Diagram 104
14.43. D-Board (6 of 6) Schematic Diagram 105
14.44. C1 and C2-Board Block Diagram 106
14.45. C1-Board (1 of 2) Schematic Diagram 107
14.46. C1-Board (2 of 2) Schematic Diagram 108
14.47. C2-Board (1 of 2) Schematic Diagram 109
14.48. C2-Board (2 of 2) Schematic Diagram 110
14.49. SC, SU and SD-Board Block Diagram 111
14.50. SC-Board (1 of 2) Schematic Diagram 112
14.51. SC-Board (2 of 2) Schematic Diagram 113
14.52. SU-Board Schematic Diagram 114
14.53. SD-Board Schematic Diagram 115
14.54. SS-Board Block Diagram 116
14.55. SS-Board Schematic Diagram 117
15 Parts Location & Mechanical Replacement Parts List 119
15.1. Parts Location 119
15.2. Packing Exploded Views 120
15.3. Mechanical Replacement Parts List 121
16 Electrical Replacement Parts List 122
16.1. Replacement Parts List Notes 122
16.2. Electrical Replacement Parts List 123
3
TH-42PD60U

2.1.1. Leakage Current Cold Check
1. Unplug the AC cord and connect a jumper between the two
prongs on the plug.
2. Measure the resistance value, with an ohmmeter, between
the jumpered AC plug and each exposed metallic cabinet
part on the equipment such as screwheads, connectors,
control shafts, etc. When the exposed metallic part has a
return path to the chassis, the reading should be between
1MWand 5.2MW.
When the exposed metal does not have a return path to
the chassis, the reading must be .
Figure 1
2.1.2. Leakage Current Hot Check (See
Figure 1.)
1. Plug the AC cord directly into the AC outlet. Do not use an
isolation transformer for this check.
2. Connect a 1.5kW, 10 watts resistor, in parallel with a 0.15µF
capacitors, between each exposed metallic part on the set
and a good earth ground such as a water pipe, as shown in
Figure 1.
3. Use an AC voltmeter, with 1000 ohms/volt or more
sensitivity, to measure the potential across the resistor.
4. Check each exposed metallic part, and measure the
voltage at each point.
5. Reverse the AC plug in the AC outlet and repeat each of the
above measurements.
6. The potential at any point should not exceed 0.75 volts
RMS. A leakage current tester (Simpson Model 229 or
equivalent) may be used to make the hot checks, leakage
current must not exceed 1/2 milliamp. In case a
measurement is outside of the limits specified, there is a
possibility of a shock hazard, and the equipment should be
repaired and rechecked before it is returned to the
customer.
1 Applicable signals
2 Safety Precautions
2.1. General Guidelines
1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or
damaged by the short circuit.
2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly
installed.
3. After servicing, make the following leakage current checks to prevent the customer from being exposed to shock hazards.
4
TH-42PD60U

3 Prevention of Electro Static Discharge (ESD) to
Electrostatically Sensitive (ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called
Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and
semiconductor "chip" components. The following techniques should be used to help reduce the incidence of component damage
caused by electro static discharge (ESD).
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your
body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap,
which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as alminum
foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static (ESD protected)" can
generate electrical charge sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most
replacement ES devices are packaged with leads electrically shorted together by conductive foam, alminum foil or comparable
conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material
to the chassis or circuit assembly into which the device will be installed.
Caution
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise hamless motion such as the brushing
together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD) sufficient to
damage an ES device).
5
TH-42PD60U

4 About lead free solder (PbF)
Note: Lead is listed as (Pb) in the periodic table of elements.
In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder.
The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu).
That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.
This model uses Pb Free solder in it’s manufacture due to environmental conservation issues. For service and repair work, we’d
suggest the use of Pb free solder as well, although Pb solder may be used.
PCBs manufactured using lead free solder will have the PbF within a leaf Symbol stamped on the back of PCB.
Caution
· Pb free solder has a higher melting point than standard solder. Typically the melting point is 50 ~ 70 °F (30~40 °C) higher.
Please use a high temperature soldering iron and set it to 700 ± 20 °F (370 ± 10 °C).
· Pb free solder will tend to splash when heated too high (about 1100 °F or 600 °C).
If you must use Pb solder, please completely remove all of the Pb free solder on the pins or solder area before applying Pb
solder. If this is not practical, be sure to heat the Pb free solder until it melts, before applying Pb solder.
· After applying PbF solder to double layered boards, please check the component side for excess solder which may flow onto
the opposite side. (see figure below)
Suggested Pb free solder
There are several kinds of Pb free solder available for purchase. This product uses Sn+Ag+Cu (tin, silver, copper) solder.
However, Sn+Cu (tin, copper), Sn+Zn+Bi (tin, zinc, bismuth) solder can also be used.
6
TH-42PD60U

5 Service Hint
Board Name Function Board Name Function
PPower Supply C1 Data Driver (Lower Right)
PA DC-DC Converter, Speaker out, Audio AMP C2 Data Driver (Lower Left)
HAV Terminal, AV Switch SC Scan Drive
DG Digital Signal Processor, Micom, HDMI Interface SU Scan out (Upper)
DT ATSC Interface SD Scan out (Lower)
DFormat Converter, Plasma AI, Sub-Field Processor SS Sustain Drive
HC Jig Connection KRemote receiver, Power LED, Key Switch
SPower Switch
7
TH-42PD60U

6.1. Remove the Back cover
1. See Service Hint (Section 5)
6.2. Remove the tuner cover
1. Remove the screws (×8 ,×5 ,×2 ).
2. Remove the tuner cover.
6.3. Remove the P-Board
Caution:
To remove P.C.B. wait 1 minute after power was off for
discharge from electrolysis capacitors.
1. Unlock the cable clampers to free the cable.
2. Disconnect the couplers (P2, P5, P9, P10, P11, P12, P23,
and P25).
3. Remove the screws (×7 ) and remove the P-Board.
6.4. Remove the PA-Board
1. Unlock the cable clampers to free the cable.
2. Disconnect the couplers (PA2, PA5, PA10 and PA40).
3. Disconnect the flexible cable (PA20).
4. Remove the screws (×4 ).
5. Remove the PA-Board.
6.5. Remove the tuner unit
1. Unlock the cable clampers to free the cable.
2. Disconnect the couplers (DG5, H53 and PA40).
3. Disconnect the flexible cables (DG3 and PA20).
4. Remove the screws (×4 ) remove the tuner unit.
6 Plasma panel replacement method
8
TH-42PD60U

6.6. Remove the DT-Board
1. Unlock the cable clampers to free the cable.
2. Disconnect the couplers (HC06).
3. Remove the screws (×5 ) remove the DT-Board unit.
(Be careful the coupler (DT12-DG22) when remove the DT-
Board unit.)
4. Disconnect the coupler (DT07)
5. Remove the screws (×2 ).
6. Remove the DT-Board metal cover and DT-Board.
6.7. Remove the DG-Board
1. Remove the DT-Board. (See section 6.6.)
2. Remove the screws (×8 ) and remove the DT-Board
metal frame.
3. Disconnect the coupler (DG2).
4. Disconnect the flexible cables (DG1, DG15 and DG20).
5. Remove the screw (×1 ) remove the DG-Board.
9
TH-42PD60U

6.8. Remove the H-Board
1. Unlock the cable clampers to free the cable.
2. Disconnect the couplers (H2 and H40).
3. Disconnect the flexible cable (H1).
4. Remove the screws (×6 ) and remove the H-Board.
6.9. Remove the HC-Board
1. Disconnect the couple (HC06).
2. Disconnect the flexible cable (HC15).
3. Remove the screws (×2 ) and remove the HC-Board.
6.10. Remove the D-Board
1. Remove the tuner unit. (See section 6.5.)
2. Disconnect the couplers (D5, D20 and D25).
3. Disconnect the flexible cables (D3, D31 and D32).
4. Remove the screws (×4 ) and remove the earth cable.
5. Remove the D-Board.
6.11. Remove the SU-Board
1. Remove the screws (×2 ).
2. Remove the flexible cables (SU1, SU2 and SU3) and
remove the bridge connector (SU45).
3. Slide the SU-Board to the left to disconnect from a coupler
(SC41-SU41) on the SC-Board and remove the SU-Board.
10
TH-42PD60U

6.12. Remove the SD-Board
1. Remove the screws (×2 ).
2. Remove the flexible cables (SD1, SD2 and SD3) and
remove the bridge connector (SD46).
3. Slide the SD-Board to the left to disconnect from a coupler
(SC42-SD42) on the SC-Board and remove the SD-Board.
6.13. Remove the SC-Board
1. Unlock the cable clampers to free the cable.
2. Disconnect the couplers (SC2, SC20 and SC23).
3. Remove the screws (×6 ) and remove the SC-Board.
6.14. Remove the SS-Board
1. Disconnect the couplers (SS11, SS12 and SS23).
2. Disconnect the flexible cables (SS41, SS42, SS43 and
SS44).
3. Remove the screws (×6 ) and remove the SS-Board.
6.15. Remove the C1-Board
1. Remove the tuner unit. (See section 6.5.)
2. Unlock the cable clampers to free the cable.
3. Remove the flexible cables holder fastening screws (×6
).
4. Disconnect the flexible cables (CB1, CB2 and CB3).
5. Disconnect the flexible cables (C11 and C12).
6. Remove the screws (×3 ) and remove the C1-Board.
11
TH-42PD60U

6.16. Remove the C2-Board
1. Remove the tuner unit. (See section 6.5.)
2. Unlock the cable clampers to free the cable.
3. Remove the flexible cables holder fastening screws (×8
).
4. Disconnect the flexible cables (CB4, CB5, CB6 and CB7).
5. Disconnect the flexible cables (C21 and C22).
6. Disconnect the coupler (C23).
7. Remove the screws (×4 ) and remove the C2-Board.
6.17. Remove the speaker L, R
1. Remove the screws (×4 each) and remove the speaker
L, R.
6.18. Remove the S-Board
1. Remove the screw (×2 ) and remove the S-Board unit.
2. Unlock the cable clampers to free the cable.
3. Disconnect the coupler (S2).
4. Remove the screws (×2 ) and remove the S-Board.
12
TH-42PD60U

6.19. Remove the K-Board
1. Unlock the cable clampers to free the cable.
2. Disconnect the couplers (H53 and S2). (See section 6.5
and 6.18)
3. Remove the screws (×3 ) and remove the K-Board.
6.20. Remove the stand brackets
1. Remove the plasma panel section from the servicing stand
and lay on a fiat surface such as a table (covered) with the
plasma panel surface facing downward.
2. Remove the stand brackets (left, right) fastening screws (×5
each) and remove the stand brackets (left, right).
6.21. Remove the Plasma panel
section from the Front frame
(glass)
1. Remove the front frame and the plasma panel fastening
screws (×8 ).
2. Remove the front frame and the stand brackets fastening
screws (×6 ).
3. For leaving the plasma panel from the front frame, pull the
bottom of the front frame forward, lift, and remove.
13
TH-42PD60U

6.22. Replace the plasma panel
(finished)
1. Place the new plasma panel (finished) on the flat surface of
the table (covered by a soft cloth), with the plasma panel
surface facing downward.
2. Attach the C1-Board and the C2-Board, connect the flexible
cables (×7) from the Plasma panel to the C1-Board and the
C2-Board, and fit the flexible cable holders.
3. Attach the Hooks (left, right) and fit the stand brackets (L,
R) to the new plasma panel.
4. Place the plasma panel section on the servicing stand.
5. Attach the front frame and each P.C.Board and so on, to
the new plasma panel.
* When fitting the front frame, be careful to allow any
debris, dust or handling residue to remain between the
front glass and plasma panel.
14
TH-42PD60U

7 Location of Lead Wiring
7.1. Lead of Wiring (1)
15
TH-42PD60U

7.2. Lead of Wiring (2)
16
TH-42PD60U

7.3. Lead of Wiring (3)
17
TH-42PD60U

7.4. Lead of Wiring (4)
18
TH-42PD60U

7.5. Lead of Wiring (5)
19
TH-42PD60U

7.6. Lead of Wiring (6)
20
TH-42PD60U
