Panasonic TH-P42ST30R User manual

© Panasonic Corporation 2011.
Unauthorized copying and distribution is a violation
of law.
ORDER NO.PAVCTH1104033AE
Plasma Television
Model No. TH-P42ST30R
GPF14D-A Chassis
Please file and use this manual together with the service manual for Model No.
TH-P42ST30A, ORDER NO. PAVCTH1104013CE.

2
1 Different points
1.1. Mechanical Replacement Parts List
1.2. Electrical Replacement Parts List
Ref. No. Parts No. Parts name & Description Pcs Remarks
TH-P42ST30A TH-P42ST30R
4 K2CK3YY00041 K2CN3YY00011 AC CORD 1 PAVCTH
7 N2QAYB000583 N2QAYB000585 REMOTE CONTROL 1 PAVCTH
TBM4TC105 TBM4TC128 NAME PLATE 1 PAVCTH
30 TPC4TA04101 TPC4TA04204 CARTON BOX(WITH STAMP) 1 PAVCTH
31 TPD4TA0065 TPD4TA0067 TOP CUSHION 1 PAVCTH
32 TPD4TA0066 TPD4TA0068 BOTTOM CUSHION 1 PAVCTH
41 TQB4TC0056-1 TQB4TC0062 INSTRUCTION BOOK(ENGLISH) 1 PAVCTH
- - - - - TQB4TC0063 INSTRUCTION BOOK(ARABIC) 1 PAVCTH
- - - - - TQB4TC0064 INSTRUCTION BOOK(PERSIAN) 1 PAVCTH
61 TTU4TA0105 TTU4TA0128 REAR COVER 1 PAVCTH
TXFKL01MSUA - - - - - TIP-PREVENTION PARTS ASSY 0 PAVCTH
- - - - -N5ZZ00000216 3D EYEWEAR2PAVCTH
- - - - - K2KYYYY00151 CHARGE CABLE 2 (3D EYEWEAR)
- - - - - TPEH541 PROTECTION SHEET 2 (3D EYEWEAR)
- - - - - TQEF130 POLY BAG(3D EYEWEAR) 2 (3D EYEWEAR)
- - - - - TQEF132 POLY BAG(CHARGE CABLE) 2 (3D EYEWEAR)
- - - - - TQEF134 POLY BAG(EYEWEAR CASE) 2 (3D EYEWEAR)
Ref. No. Parts No. Parts name & Description Pcs Remarks
TH-P42ST30A TH-P42ST30R
PCB TZTNP01NCUA TZTNP01NSUR A-PRINT COMPLETE 1 (RTL)PAVCTH
IC8000 MN2WS0200LE MN2WS0200LD IC 1 PAVCTH
IC8900 TVRS216 TVRS218 IC 1 PAVCTH
IC8901 TVR***2A TVR*** IC 1 PAVCTH
IC8902 TVR***3A TVR*** IC 1 PAVCTH
