Panasonic VIERA TX-P42S10B Manual

Confidential
A
3BY 3D3ES
T
3H3IS 3N3PL 3SK 3U
A
3
AL 3CH 3DK 3F3I3L3NL 3RO 3SL
O
3FIN 3
B3CZ 3E3GB 3IRL 3LT 3P3S3TR 3Europe
Location
13/08/2009
Note: This modification applies to serial numbers prior to: **-9340001
Product Category:
Country Reported
Remedy /
Method:
Date
MQM022DG010909REV2Ref No:For Authorised Service Agents Only
The TV cannot power on, and the SOS LED blinks 5 or 7 times.
D
Note: Failure to use the correct IRIS and Activity codes may result in the claim being rejected
Activity Codes:
(UK Only)
Section Defect
IRIS Codes: 1
Repair
Subject:
Plasma TV / Plasma IDTV
The Sustain circuit reacted to an abnormal signal from the A-board when the set was
turned off, causing damage to several transistors.
Symptom /
Cause:
TECHNICAL INFORMATION
See list on page 3
Model(s) Affected:
SS PCB failure on G10 S10 and U10 series.
11F Area
W
Step 1: Replace transistors: Q16001, Q16002, Q16004, Q16021, Q16022, Q16023, Q16101, Q16102
Warranty Claims - Please use the following IRIS and Activity codes
1i3 DDC Code
R
N1
Condition
A
2
Symptom
Area
2.13. Remove the SD Card from the SD Card slot.
2.14. Turn the Plasma TV back on.
2.15. Repeat step 2.4.
2.16. Confirm the PDP Soft, PDP EEP, PDP FPGA, and PDP PDROM with the information in Fig. 4. (page 3)
AreaCode
Guarantee Status SourceRepair Type
Type Code
2.8. The Plasma TV will change to display the message in Fig. 2. (page 2)
onto the root directory of an SD Card. (See right)
2.3. Turn on the Plasma TV
2.12. Turn the Plasma TV off
2.9. Press the OK button on the remote control.
2.10. The Plasma TV will display the message in Fig. 3. (page 2)
2.11. Using the Cursor buttons on the remote control, select YES, then press the OK button to start the software
download - The plasma display will black out and the TV LED will change from green to red.
- Wait until the red LED turns off (about 9 minutes)
- Do NOT turn off the TV until the red LED turns off or the TV will be broken
2.7. Insert the SD card, with the files prepared in step 2.2, into the SD Card slot.
* See figure <SS-Board> for locations (See page 2.)
Step 2: Upgrade the set firmware. Obtain a copy of the "4in1-soft" firmware from your usual service source.
Upgrade Procedure
2.1. Copy the relevant zip file to a computer and unzip the file.
2.2. Copy the folders "PNL", "TEXT", and one file "SDIT.SDI"
2.4. Whilst holding down the Volume "-" button on the unit, press the RECALL button of the remote control 3 times.
with the information in Fig. 4. (page 3) If any of the version in the set are older, proceed to step 2.7.
2.5. The Plasma TV will display the information shown in Fig. 1. (page 2.)
Q16101, Q16102
ReferencesPart Number
2SK399500L Quantity 2
Order the following kit: TZS9EK088 (Kit Contents detailed below)
Q16001, Q16002, Q16004
Q16021, Q16022, Q16023B1JADP000004
2PG0060000RP 3 3
2.6. Compare the PDP Soft, PDP EEP, PDP FPGA, and PDP PDROM shown on the screen, Fig. 3.(page 2),
TZS9EK088
Service Kit
Panasonic 1 of 3 Document No: PUK-QST_TI
Rev: 9.00 DG310309

Confidential
MQM022DG010909REV2Ref No:For Authorised Service Agents Only
TECHNICAL INFORMATION
Fig. 2
Fig. 3
Fig. 1
Q16001Q16002
Q16004
Q16021
Q16022
Q16023
Q16102
Q16101
SS-board SUS Ｈｉ side IGBT Q16001，002，004
SUS Lo side IGBT Q16021，022，023
Ve MOS Q16101，102
ＳＳ１１
Panasonic 2 of 3 Document No: PUK-QST_TI
Rev: 9.00 DG310309

Confidential
MQM022DG010909REV2Ref No:For Authorised Service Agents Only
TECHNICAL INFORMATION
02.50 or
02.51
02.50 or
02.51
02.50 or
02.51
PDP SOFT FPGA PD3ROMModel Group
46 eco
panel models
50 eco
panel models
42 standard
panel models
42 eco
panel models
EEPROM
53.01
31.05
41.05
51.05
51.05
46 standard
panel models
50 standard
panel models 51.05
02.50 or
02.51
02.50 or
02.51
02.50 or
02.51 V012_42FHD_eco_4in1.zip
V012_46FHD_eco_4in1.zip
V012_50FHD_eco_4in1.zip53.0051.05
33.00
43.00
33.01
43.01
V021_46FHD_std_4in1.zip
V021_50FHD_std_4in1.zip
4in1 Soft
V021_42FHD_std_4in1.zip
51.01
51.05
51.05
51.05
31.01
41.01
46 eco
panel models 50 eco panel models
Model(s) Affected:
42 standard
panel models
TX-P42U10E
TX-PF42S10
TX-P42S10E
TX-P42S10ES
TX-P42S10L
TX-P42S11B
TX-PR42U11
TX-P42S11E
TX-P42U10B
42 eco
panel models
TX-PR42S10
TX-PR42S11
TX-PR42S12
TX-P42S10B TX-P46S10B
TX-P46S10E
TX-PF46S10
TX-PR46S10
TX-PR50U10
TX-P42G10B
TX-P42GW10
TX-P42G10E
TX-P42G10L
TX-P50S10B
TX-P50S10E
TX-P50S11B
TX-P50S11E
TX-PR42U10
TX-P50U10B
TX-P50U10E
TX-PF50S10
TX-PR50S10
TX-P42GA11
TX-P42GF12
46 standard
panel models
TX-P46G10B
TX-P46G10E
TX-P46G10L TX-P50GW10
TX-PF50G10
TX-PF42G10
TX-PR42G10
TX-P46GA11
TX-PF46G10
TX-PR46G10
TX-P46GQ11
TX-P42GN13
TX-P42GS11
50 standard
panel models
TX-P50G10B
TX-P50G10E
TX-P50G10L
TX-PR50G10
TX-P46GW10TX-P42GT14
Fig. 4
Panasonic 3 of 3 Document No: PUK-QST_TI
Rev: 9.00 DG310309
