Panda XPANDAOFFICE User manual

Release 1.01
Office, man-portable, self assembly type EC1.1
assembly instructions
XPANDAOFFICE

Release 1.01
Office, man-portable, self assembly type EC1.1
1) Place the pack onto firm, level ground
2) Remove the four packing posts using a 19mm
spanner. (Fig. 2 & 3)
3) Remove the four bolts on the corners of the unit
using a 13mm spanner. (Fig. 4)
4) Remove the roof fascia cover on both sides
(Fig. 5 & 6)
5) Remove the roof connector
(4 x 13mm bolts)
(Fig. 7 & 8)
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Fig. 6
Fig. 7
Fig. 8

Release 1.01
Office, man-portable, self assembly type EC1.1
6) Remove the roof sections and the timber
packing. Remove the corner packing posts, take
all components out of the pack to leave you with a
clear chassis to work on. (Fig. 9, 10 & 11)
7) Fit one inner corner profile (Fig. 12) to the
chassis as shown using 19mm bolts &
washers.
Then fit one outer corner to the chassis as
shown using 19mm bolts & washers (Fig. 13)
Fig. 9
Fig. 10
Fig. 11
Fig. 12
Fig. 13
8) Remove the plastic film from all panels. (Fig. 14)
9) Starting with the short side, slot a narrow wall
panel into the corner post slot (cut side toward
post). Then two full panels (door, blank panels) as
required.
10) Fit another internal and external corner post.
11) Fit panels as before. Continue until all four walls
are fitted (Fig. 15, 16 & 17)
Fig. 14
Fig. 15
Fig. 16
Fig. 17
12) Fit the ceiling retention bars. (Fig. 18)
13) These fit on the top of the wall panels
and slot into the top of each corner post.
(Fig 19 & 20).
NOTE: If the pins do not line up with
the holes –the cabin is not level.
Fig. 18
Fig. 19
Fig. 20

Release 1.01
Office, man-portable, self assembly type EC1.1
14) Fit the ceiling panels. (Fig. 21)
15) These fit on the top of the retention bars
and slot together like the wall panels
Fig. 21
Fig. 24
16) Slide on the roof panels. Take care to
ensure the lip locates correctly where the
two halves connect.
(Fig. 24 & 25).
17) Fit the centre roof cap with 13mm bolts &
washers. (Fig. 26 & 27).
Fig. 25
Fig. 26
Fig. 27
Fig. 22
18) Fit the roof fascia to both long sides.
(Fig. 28).
19) Fit the bolts into the four corners. (Fig.29).
Congratulations –you have completed your office!
Fig. 29
18) Weather seal the inner roof (Optional - but recommended)
Use the supplied silver waterproofing tape to seal between all
joints on the roof. This forms a second line of defence for extreme
weather conditions, we recommend it is applied as
follows:
a) Between roof panels (Fig. 22)
b) All around the edge of the roof panels where they meet the ceiling
retention bar. Tip: Lap the tape over the ceiling panel and down over the
ceiling retention bar. This prevents capillary action in extreme weather
conditions.
c) Pay particular attention to the corners of the roof frame. (Fig. 23)
Fig. 23
Fig. 28

Release 1.01
Office, man-portable, self assembly type EC1.1
Lifting Kit (Optional)
The lifting kit simply bolts onto the side of
the XPandaOffice as shown.
To stack one on top of the other, simply
substitute the lifting eyes (Fig. 28) for the
supplied connection brackets (Fig. 29) as
shown to provide secure stacking.
Fig. 27
Fig. 28
Fig. 29
Fig. 30
Thank you for purchasing this unique building.
XPandaOffice can be linked together to form a modular building by using a simple linking
kit. Also available: windows guards, electric packs, forklift tunnels and replacement panels.
Contact your dealer for more information.
