INSTALLATION INSTRUCTIONS
© Panduit Corp. 2001 Printed in U.S.A.
NETWORK CONNECTIVITY GROUP
10500 West 167th Street
Orland Park, Illinois 60467 Technical Support: 866-405-6654
Fax: [phone] E-mail: [e-mail]
Web site: www.panduit.com/ncg
WORLDWIDE SUBSIDIARIES AND SALES OFFICES
PN260
Page 1 of 1
Australian Furniture Adapter
PART NUMBER: CMAA1**-X
CMAA1
Module Installation
Module Removal
1. Orient module and Adapter as shown
above. 2. Align groove on module with notch on Adapter. Swing module downward. 3. Snap into place.
The Adapter can fit into a 25mm
or 1.00" square knock out in any
metal or plastic panel that is
1.5mm - 2mm (.06" - .08") thick.
The knock out could be located
in a furniture panel, raceway, or
desk as long as it meets the
previous criteria.
1. Press down on tab while pushing upward on the module. 2. Remove module from Adapter.
