ACCULINKr3150 CSU
Quick Reference
Document Number 3150-A2-GL11-80
May 2000
Product Documentation on the World Wide Web
We provide complete product documentation online. This lets you search the
documentation for specific topics and print only what you need, reducing the waste of
surplus printing. It also helps us maintain competitive prices for our products.
Complete documentation for this product is available at www.paradyne.com.
Select
Library → Technical Manuals → T1/E1 Digital Access Devices.
Select the following document:
3150-A2-GB24
ACCULINK CSU, Models 3150-A4 and 3151, Operator’s Guide
To request a paper copy of a Paradyne document:
HWithin the U.S.A., call 1-800-PARADYNE (1-800-727-2396)
HOutside the U.S.A., call 1-727-530-8623
Quick Start Procedure
Before installing the CSU, see the Important Safety Instructions beginning on
pageNO TAG.
The following procedure is offered for experienced CSU users who are familiar with the
3150 CSU installation process and have no special requirements for their application.
Refer to the
ACCULINK CSU Operator’s Guide for more information.
1. Attach the power cord to the rear of the CSU and the other end to a grounded
115 Vac power outlet.
2. Attach the DTE cable (DB15) and the 8-pin network cable to the DTE and
NETWORK connectors, respectively, located on the CSU rear panel. Then,
connect the other end of the DTE cable to the CPE. Connect the other end of the
network cable to the RJ48C jack provided by the telephone company. See
Appendix E,
Pin Assignments , in the Operator’s Guide for more information.
3. Power on the CSU to perform the power-on self-test. See
Power-On Self-Test in
Chapter 2,
Installation , of the Operator’s Guide for more information.
4. If you intend to use front panel emulation, connect the cable from the PC to the
COM port on the rear panel of the CSU.

2
NOTE:
To configure the CSU remotely, refer to the Acquiring/Releasing the User
Interface
section in Chapter 5, Security, in the Operator’s Guide .
5. If you intend to manage the 3150 CSU with SNMP over an Ethernet LAN, connect
the 10BaseT port to your LAN and assign an IP address to the port.
6. Verify that configuration options are appropriate for your network.
7. During the power-on self-test, the FAIL LED flashes, then all LEDs blink twice.
When the test is complete, verify that the CSU is functional by observing that the
OK, NETWORK SIG, and DTE SIG LEDs are lit.
Configuration Procedures
For detailed configuration procedures see Chapter 4, Configuration , and Appendix C,
Configuration Options , of the Operator’s Guide .
Displaying/Editing Configuration Options
To display/edit configuration options:
1. From the top-level menu screen (which you can access by pressing the key),
select Cnfig.
2. Select the configuration option set to be copied into the Edit area by using the
appropriate Function key (F1, F2, or F3). Use the scroll keys ( and ), if
necessary.
The Factory 1 configuration for ESF framing format and B8ZS line coding format is
the default configuration and is appropriate for most networks. For D4 framing
format and AMI line coding format, use the Factory 2 configuration. See Table 2.
3. Select Edit.
4. From the Edit screen, select the functional group you want to edit by pressing the
appropriate Function key. Use the scroll keys ( and ), if necessary.
Saving Edit Changes
To save edit changes:
1. From the Choose Funct screen (one level above the Edit screen, two levels below
the top-level menu screen), select Save.
2. Choose whether you want to save to the Active, Customer 1, or Customer 2 area.
Use the scroll keys ( and ), if necessary.

3
