Zcd CD player with MP3 playback
XXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXX XXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXX
Ultra-compact player for CDs and MP3 files on a USB flash drive
The new Parasound Zcd is an ultra-compact CD player with far more features than most full
sized players. The Zcd plays MP3s from a CD-R or a USB flash drive. Its analog volume control
enables you to combine the Zcd with our Zamp v.3 power amplifier for a truly high end compact
stereo system without the need for a separate preamp.
The Zcd includes a composite video output to view and select MP3 files. For installation
flexibility there are simultaneous fixed and variable level analog outputs as well as coax and
optical digital outputs. A 3.5mm analog line input jack makes it easy to integrate any portable
MP3 player or smartphone into your system even without a preamp.
The Zcd has a 12 volt trigger input which allows a preamp to turn the Zcd on and off
automatically. A 12 volt trigger output can trigger a power amp on. Full operation is possible
by the included remote control or 1-way RS-232 or rear panel IR input.
The combination of unique features and compact size makes the Zcd perfect for a wide variety
of applications. Like all the products in our Z custom line-up, the front panel is half a standard
rack width and can lock together with another Z custom product for use in a standard rack.
From high end desk top systems to custom AV solutions the Zcd can do it all.
TYPICAL APPLICATIONS
- Use with a Sonos® player for CD playback
- Use with a Zamp v.3 for a hi-performance system
- Compact size allows for use in small spaces
- Rack mount for unique custom AV solutions

Features:
- Plays MP3s from CD-R or USB flash drive
- Built in analog volume control for use without a preamp
- Composite video output to view MP3 file names
- Optical and Coaxial digital outputs
- Simultaneous fixed and variable analog outputs
- Rear panel 3.5mm input for portable MP3 player or smartphone
- Three turn on options (manual, 12V trigger, AC)
- 12 Volt trigger output for turning on power amp
- Remote control included (shown on right)
- Rear panel IR input and 1-way RS232 serial port
-Unique half-rack width chassis; 1 rack space high
- Shipping weight: 8 lbs., net weight: 5 lbs.
Specifications:
Frequency Response: 20 Hz - 20 kHz, +0/-1 dB
THD Distortion: < 0.02% at 20 Hz
S/N Ratio: > 98 dB, IHF A-weighted
Crosstalk: >75 dB at 20 kHz
Maximum Output Level: 2.0 Volts
Output Impedance: < 60 Ω
AC Power Requirement: 110-130 VAC, 60 Hz or 220-240 VAC, 50 Hz (15 Watts)
(Voltage must be set inside unit)
Dimensions (WxDxH): = 9.5” (242 mm) X 10” (254 mm) X 2” (51 mm)
Weight: Net: 5 lbs. (2.3 kg) / Shipping: 8 lbs. (3.6 kg)
Rack Mount Accessory (purchased separately):
• SBS –Side by Side mounting bracket for locking two Z custom units together
• Zblank – Blank panel extender for mounting one Z unit in a standard rack space
• Zrack – Half width desktop rack perfect for up to 5 Parasound Z components
Parasound Products, Inc., 2250 McKinnon Ave., San Francisco, CA 94124 / 415 397-7100
For more photos, features, specifications and product manuals, visit us at www.parasound.com
