Park DF2000 DSP User manual

PROFESSIONAL
TWO CHANNEL
SWITCHING POWER AMPLIFIER
DF series with DSP
DF2000DSP
DF3200DSP
DF1400DSP
Owner’s Manual
R

ACCESSORIES
1. Power Cord 1pc.
2. Owner’s Manual 1pc.
3. Warranty 1pc.

CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS
RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
CAUTION! The amplifier runs on 230V AC voltage. Removing the cover will expose
you to a potentially dangerous voltage! Do not use the unit if the electrical power cord is
frayed or broken.
Power is supplied from 230V AC single-phase grounded 50/60 Hz source!
CAUTION! The amplifier can yield dangerous output voltage! Do not touch the non-
insulated cable parts, connected to the unit in operation!
CAUTION! The high sound pressure level of speaker systems generated by high
output power, delivered by the amplifier, may be hazardous to your hearing. Please,
take adequate safety precautions.
WARNING! The amplifier yields high output power. The manufacturer shall not be held
responsible for any damage to the speakers caused by excessive power from the unit.
WARNING SIGNS:
Important information!
Intended to warn the user about any important applicable information
contained in this Owner’s Manual.
Hazardous voltage inside!
Intended to warn the user about electric shock hazard due to high voltage
inside the product.

GENERAL
DFseries with DSP (DF1400DSP, DF2000DSP, DF3200DSP) are modern
amplifiers for professional entertainers, who require maximum performance and sound
quality on a limited budget. Amplifiers are designed for application in
PA systems with high requirements for precise tuning of the parameters, but without the
need for operative change.
Built-in DSP accurately handles the audio signal due to its functions of equalization,
filtering, delay and limiter. Processor has 2 inputs and 2 outputs and provides free signal
routing from any input to any output.
DSP enables users to choose between eight factory preset settings. Setting
presets (operation modes) is performed by DIP switch. Any of presets can be modified
using a computer connected via USB interface (software – SigmaStudio by Analog
Devices, Inc.).
ATTENTION! The DF1400DSP, DF2000DSP and DF3200DSP amplifiers have the
same design and functional features and differ only in the schematics elements, output
power and weight. Unless specified otherwise, the word «amplifier» hereinafter applies to
any of the above models..
To ensure the most advantageous and faultless operation of the amplifier, please,
read this Manual before use.
UNPACKING
The manufacturer’s quality control system provides for careful examination of each
product before it leaves the factory to ensure its flawless appearance. After unpacking,
please, check the unit for any physical damage. In case of damage, please, contact your
local dealer. Keep the shipping carton and all packing material, as you may require them
for reshipment of the unit.
2

DESIGN FEATURES
Physical Design
The amplifier is enclosed in a metal (steel) case of 88 mm (2U) height. The amplifier
is designed to be standard rack-mounted (RACK 19").
Power Supply Unit
Both channel of the amplifier share the same pulse power supply unit.
Power Factor Correction (in DF2000 DSP only)
The amplifier has power supply with Power Factor Correction, which significantly
reduces load to the mains and also reduces noise and distortion in the mains. What is
more important, the amplifier output power is no longer rigorously dependent on the mains
voltage. The amplifier provides full power at the mains voltage from 160V to 250V (with ~ ~
no need to use of external AC voltage stabilizer).
Cooling System
The amplifier features a forced cooling system which is common for both channels.
The amplifier and the power supply unit are cooled with a single fan blowing front to rear.
The cooling system provides for a double-step intensity-cooling rate switching. At a normal
temperature, the fan runs at a low speed, thus generating the least noise possible. When
the amplifier is set to deliver a high output power or when the ambient temperature is
higher than normal, the cooling system may switch the fan to the other (higher) cooling
rate.
Output Stage
The output stage of this digital power amplifier is designed according to Class D
technology to deliver high efficiency and least heat. The high switching rate ensures the
high sound quality comparable with the best analogue amplifiers.
Balanced Inputs
The use of balanced inputs provides for an essential reduction of the environment-
induced hum and noise interference with long input connecting cables.
Line Outputs
The line outputs have a post-DSP signal. The signal parameters are determined by
the selected preset setting. You can change the signal parameters using the USB
interface.
DSP
Built-in DSP accurately handles the audio signal due to its functions of equalization,
filtering, delay and limiter. Processor has 2 inputs and 4 outputs and provides free signal
routing from any input to any output.
DSP enables users to choose between eight factory preset settings. Preset
parameters are listed on the insert in the Owner’s Manual.
Any of presets can be modified, using a computer connected via USB interface
(software – SigmaStudio by Analog Devices, Inc.).
The installation package of the SigmaStudio ver.3.10 software (32-bit and 64-bit
program versions available) and user manual can be downloaded from the site
parkaudio.ua (Download section on the pages of the corresponding amplifiers).
3

Moreover, in the Download section you can find:
SigmaStudio User Manual – user guide on setting built-in amplifers with DSP by
SigmaStudio.
SigmaStudio Video Tutorial – video tutorial about setting amplifers with DSP by
SigmaStudio.
Limiter’s User Manual – recommendations on limiters setting in signal processing
tracts;
Project Templates – SigmaStudio project template for amplifiers with DSP;
DF-series Factory DSP Presets – DSP preset settings description.
Limiter’s Setting Calculations – simple calculator (Excel) to calculate the
parameters of the limiter.
DSP PRESET Switch
The amplifier modes (DSP presets) can be switched by the DIP switch, located on
the rear panel.
Input Level Attenuators
These allow setting the amplifier to the required sensitivity (each channel
individually) which is very helpful when several amplifiers are used to drive different types
of loudspeakers or are used within multi-speaker sound reinforcement systems. The
attenuators are located on the front panel.
Detachable Power Cord
This feature is provided for convenience of transportation and rack mounting.
4

FUNCTIONAL FEATURES
Overload and Short-Circuit Protection
Individual per each channel. This protective system becomes active in case of short-
circuited output or overload caused by reduced load impedance. It disables the output
signal of the respective channel for 0.5 second and then the amplifier gradually resumes
its delivery.
DC Output Protection
The amplifier’s schematics precludes transit of any clicks or noise during the power-
on/off transition process. The power source unit is responsible for preventing any DC
damage to loudspeakers. In the event of output DC voltage or any powerful LF
fluctuations, the power source unit goes off and all indicators, including the POWER LED,
go off too.
The amplifier can be restarted in 2 or 3 minutes by de-energizing and re-energizing
the amplifier with the POWER switch. If the DC is an occasional problem (which is unlikely)
the amplifier goes on and resumes its normal functioning. If, otherwise, the DC output
problem persists through the fault of the amplifier, then upon switching, the amplifier goes
on, the POWER amplifier goes on but in a short while the DC output protection system
disables the power supply source.
Thermal Protection
Independent for each channel. In this case upon reaching 85°C, the independent
protection system disables the respective channel of the amplifier. The CLIP LED goes on
and the SIGNAL LED of the affected channel goes off.
As soon as the amplifier cools down, the affected channels gradually regain their
amplification level up to the set value.
Soft Signal Start
During the power-on process, this feature ensures smooth gain from zero to the
maximum level to provide for a smooth rise of the sound level emitted from the loud-
speakers.
5

BLOCK DIAGRAM
INPUT CH 1
Power
amplifier
Ch 1 2+
2+
LEVEL
CH1, CH2,
BRIDGE
SPEAKER
OUTPUTS
CH2
DSP
Out 0
In 0
Out 2
Out 1
In 1
Out 3
DSP
PRESET
1
2
3
ON
DIP
Switch
Ch1 Ch2
CLIP
Ch2 LIMIT
Ch1 LIMIT
Ch2 CLIP
Ch1 CLIP
Ch 2
USB Port
USB
Interface
OUTPUT A
( )
POST DSP
INPUT CH 2
OUTPUT B
( )
POST DSP
1+
1+
6

7
FRONT PANEL
DF 1400
D IGI TAL PR OFE SS ION AL P OWE R AM PL IF IER
CH 2
T0
dB
LEVEL
CH 1
T0
dB
LEVEL
CLIP
SIGNAL
2
1 3
9
85
4 6 7
POWER LED.
LED goes off when the DC output protection system activated.
THERMAL – overheating alarm LED.
Brightness depends on the temperature of the heat sink (See: Thermal Protection).
POWER switch.
LEVEL – input (sensitivity) level attenuators for Channels 1 and 2, respectively.
CLIP – clip LEDs for Channels 1and 2, respectively.
They indicate:
– overload condition causing distortion;
– activation of DSP limiter;
– activation of thermal protection system which disables the respective channel
(the SIGNAL LED goes off). (See: Thermal Protection).
SIGNAL – LEDs, indicating output signal on Channels 1 and 2,respectively
5
6
4
8
7
9
1
2
3

REAR PANEL
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK
DO NOT EXPOSE THIS EQUIPMENTTO RAIN OR MOISTURE.
DO NOT REMOVE COVER.
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING
USB
DSP
PRESET
CH 2
CH 1CH 2
SPEAKER OUTPUTS
4 min
4 min
1
1
2
2
1
1
4 min
8 min
1
2
BRIDGE
(CH1-2)
MAINS IN
RISK OF ELECTRIC SHOCK
CAUTION
DO NOT OPEN
1
2
3
ON
PUSH PUSH
OUTPUT B
(POST DSP)
INPUT
CH 2INPUT
CH 1OUTPUT A
(POST DSP)
12
4
3
56789
Model
Power Requirements
Serial No
DSP PRESET – the amplifier modes DIP-switch.
SPEAKER OUTPUTS – SpeakON output connectors, used to link up to loud-
speakers.
The signals, applied to the output connectors, and their polarity are shown on the
rear panel of the amplifier.
MAINS IN – .power cord socket for 230V AC 50/60Hz grounded mains
OUTPUT A, OUTPUT B – line outputs the signal, processed by DSP . Used to send
engine, to another amplifier.
INPUT (CH1, CH2) – respective inputs (XLR female).
Used to connect input signal.
USB – port for connection to personal computer.
2 3
5
6 7
4
1
9
8
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK
DO NOT EXPOSE THIS EQUIPMENTTO RAIN OR MOISTURE.
DO NOT REMOVE COVER.
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING
USB
DSP
PRESET
CH 2
CH 1CH 2
SPEAKER OUTPUTS
4 min
4 min
1
1
2
2
1
1
4 min
MAINS IN
RISK OF ELECTRIC SHOCK
CAUTION
DO NOT OPEN
1
2
3
ON
PUSH PUSH
OUTPUT B
(POST DSP)
INPUT
CH 2INPUT
CH 1OUTPUT A
(POST DSP)
12
4
3
56789
Model
Power Requirements
Serial No
DF1400DSP, DF2000DSP
DF3200DSP
Park Audio II, Ltd Made i n Ukraine
Park Audio II, Ltd Made i n Ukraine
8

CABLE REQUIREMENTS
Input Cables
Make sure to use only shielded cables whether balanced or unbalanced. Shielding,
when properly grounded, protects a signal against external electrical interference.
As a rule, unbalanced lines over 3 meters long are not acceptable. Greater distances
require a balanced cable. Avoid placing input cables close to power cords or power
transformers.
Output Cables
The amplifier is capable of delivering high level output current; therefore, the wire
gauge used for speaker cables is particularly important. Inadequate wire gauge adds
significant resistance to the speaker’s own impedance, reducing the power, which is
actually delivered to the speaker. It will also result in a decreased damping factor and
possible fire hazard.
Since the power, applied to the loudspeaker, is of primary concern in system design,
we have included the table below to allow you determine the appropriate wire gauge for
your application.
Power Loss in a 10-meter Cable
The table shows the percentage of the power loss in a 10-meter copper multiple-core
cable. This table reflects the power loss as a percentage of the output power of the
amplifier applied to the load. Use this table to determine the power loss to the load at other
cable lengths. For example, if you plan to deliver 100 Watts to 8-Ohms load through 20-m
2
cable of 0.75-mm gauge, the power loss in the cable would be 5.8% x 2=11.6% of 100W
or 11.6W lost in the cable.
2
0.50mm
2
0.75mm
2
1.00mm
2
1.50mm
2
2.00mm
2
2.50mm
2
4.00mm
0.72 Ohms
0.49 Ohms
0.36 Ohms
0.24 Ohms
0.18 Ohms
0,15 Ohms
0.09 Ohms
15.4 %
10.9 %
8.3 %
5.7 %
4.3 %
3.6 %
2.3 %
8.3 %
5.8 %
4.3 %
2.9 %
2.2 %
1.8 %
1.1 %
Wire Gauge Cable
Resistance Cable Power Loss
4 Ohms Load 8 Ohms Load
9

10
INPUT AND OUTPUT CONNECTORS
Input Connectors
Use XLR (male) connectors to connect to the amplifier inputs and XLR (female)
connectors to line outputs.
See the wiring on the figures below.
Output Connectors
Use SpeakON NL2FC or NL4FC connectors to connect loudspeakers to the
amplifier individual channel outputs. For bridged connection or connection of two
channels via a single cable, use SpeakON NL4FC.
See the wiring on the figures below.
CAUTION! Never attempt to jumper or otherwise link up any pins of output
connectors.
21
3
2 1
3
-
1
1+
-
1
2+
1+
-
2
-
1
2+
1+
-
2
-
1
2+
1+
-
2
XLR (male) XLR (female)
Cold « – »
Shield (Ground)
Hot « + »
Cold « – »
Hot « + »
Shield (Ground)
NL2FC for individual channel mode
Output (+)
Output (–)
NL4FC or bridge mode
(only for Channel 1 connector)
Output (+)
Output (–)
NL4FC for individual channel mode
Output (+)
Output (–)
NL4FC for linking up two channels
with a single connector
(only for Channel 1 connector)
Channel 1
Output (+)
Channel 1
Output (–)
Channel 2
Output (–)
Channel 2
Output (+)

RACK-MOUNTING REQUIREMENTS
The amplifier is designed to fit a standard 19” rack. While mounting, make sure to
provide unhindered air access to the front and rear sides of the rack. Fan direction is from
front to back. It is not necessary to leave empty space above or below the amplifier.
For stationary use, it will be enough to fix securely only the front panel of the amplifier
to the rack. However, never attempt to transport the unit unless its rear end is properly
supported and/or securely fixed, as it may be fraught with danger of damage.
AC POWER REQUIREMENTS
The amplifier is supplied with a three-conductor grounded AC power cord, and
should be plugged into a standard 3-wire grounded electrical outlet, which supplies
230VAC 50/60Hz.
In the event of line voltage sag, the amplifier without PFC will continue to operate
normally, albeit with less power. The mains lower voltage limit for the amplifier to retain its
operability is ~160V.
The amplifier with PFC operates at the mains voltage range from ~160V to ~250V,
giving the full rated output power.
The amplifier is connected to the mains via cable, supplied with the amplifier. When
connecting to mains, make sure that no other devices with high power consumption are
connected to it, as the normal operation of several such devices may be impossible.
The actual AC current consumption depends on the audio signal level and the load
impedance. For system design purposes it must be noted, that for typical audio program
material the amplifiers, driving all channels at nominal impedance, just peaking at the
clipping level, have the following average power consumption:
– 2.4 A* for amplifier DF1400 DSP at 4 Ohm load;
– 1.2 A* for amplifier DF1400 DSP at 8 Ohm load;
– 3.4 A* for amplifier DF2000 DSP at 4 Ohm load;
– 1.7A* for amplifier DF2000 DSP at 8 Ohm load;
– 5.5A* for amplifier DF3200DSP at 4 Ohm load;
– 2.8A* for amplifier DF3200DSP at 8 Ohm load.
Note.
* At the mains voltage 230V AC. For the amplifiers DF2000DSP (with PFC) at low mains voltage
the current consumption increases.
In order to reduce the AC hum, please, plug all sound equipment, interconnected with
signal cables, into the same power mains outlet.
11

AMPLIFIER OPERATION MODES
The amplifier can operate in two or one-channel modes (respectively: each channel
independently, the two channels in a bridge mode). The amplifier has two input channels.
Signals routing for four channels is performed by the DSP engine.
DSP settings control, presets storing and the creation of the original signal
processing template is performed by personal computer with SigmaStudio editor,
installed to it.
Setting the high-pass filter and crossover filter parameters, EQ settings, desired
signal delay, as well as a number of other parameters can be performed by the DSP
engine, as described in SigmaStudio User Manual .
For the consumer’s convenience the amplifier has 8 presets, which provides a
number of the most frequently used switch configurations and settings. DSP presets
settings and block diagrams of the connections to the amplifier are in the Owner’s Manual.
Switching the amplifier DSP presets is performed by the DIP switch, located on the rear
panel of the amplifier.
12

SPECIFICATIONS
Number of input channels 2
Number of output channels 2 Speaker Out, 2 Line Out (Post DSP)
Number of operating modes 8
Output Power:
– DF1400DSP 2 x 700W/380W (4/8Ohm, ~230V)
1400W (bridge, 8Ohm, ~230V)
– DF2000DSP 2 x 1000W/500W (4/8Ohm, ~160-250V)
1900W (bridge, 8 Ohm, ~160-250V)
– DF3200DSP 2 x 1600W/1000W (channel, 4/8Ohm, ~230V)
Frequency Response 20Hz – 20kHz (±0.5dB, Pnom.)
Total Harmonic Distorsion 0.05% (20Hz – 20kHz)
Slew Rate 20/40V/µs (channel / bridge)
Damping Factor over 200 (200Hz, 8Ohm)
Channel Separation 60dB (1kHz)
Signal-to-Noise Ratio 95dB (unweighted)
Input Impedance 10kOhm (balanced)
Sensitivity 0.775V
Maximum Input Level 2.45 V (+10 dBu)
Power Requirements ~230V *, 50/60 Hz
Weight:
– DF1400DSP 6.2kg
– DF2000DSP 6.5kg
– DF3200DSP 7.7kg
Dimensions 482 (W) x 96 (H) x 362 (D) mm
Built-in DSP: Sampling rate – 48kHz.
DAC/ADC – 24-bit.
Internal processing – 56-bit.
2 inputs, 4 outputs.
Note.
* For the DF2000DSP amplifier at the mains voltage range ~160-250V.
OPERATING CONDITIONS
Ambient Temperature 5 ... 35°C
Atmosphefic Pressure 86.6 ... 106.7kPa (650 ... 800mmHG)
Relative Humidity less than 80%
13

445 max
482
466
76
88
96
38
324
362
DIMENSIONS
14

Attachment Preset 000 «Full Range»
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK
DO NOT EXPOSE THIS EQUIPMENTTO RAIN OR MOISTURE.
DO NOT REMOVE COVER.
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING
USB
DSP
PRESET
CH 2
CH 1CH 2
SPEAKER OUTPUTS
4 min
4 min
1
1
2
2
1
1
4 min
8 min
1
2
BRIDGE
(CH1-2)
MAINS IN
RISK OF ELECTRIC SHOCK
CAUTION
DO NOT OPEN
1
2
3
ON
PUSH PUSH
OUTPUT B
(POST DSP)
INPUT
CH 2INPUT
CH 1OUTPUT A
(POST DSP)
Model
Power Requirements
Serial No
FULL RANGE
Ch1 (L)Ch2 (R)
To Full Range Speakers
Speaker R Speaker L
-
1
1+
20 100 1k 10k
-15
-10
-5
0
5
dB
Hz
Ch1, Ch2, Output A, Output B
4 min
Function Full Range
Routing Input Ch1 (gain 0dB)
HPF Freq. 35Hz (BTW 24dB/oct)
Function Full Range
Routing Input Ch2 (gain 0dB)
HPF Freq. 35Hz (BTW 24dB/oct)
Function Full Range
Routing Input Ch1 (gain 0dB)
HPF Freq. 35Hz (BTW 24dB/oct)
Function Full Range
Routing Input Ch2 (gain 0dB)
HPF Freq. 35Hz (BTW 24dB/oct)
Ch1Ch2Output AOutput B Speaker OutputsLine Outputs
Input
( )
Ch1 L
Ouput A
Ouput B
Input
( )
Ch2 R
Speaker Outputs
Speaker L
Ch1
35Hz
35Hz
Speaker R
Ch2
35Hz
35Hz
4 min
4 min
To Input Signal Source
Park Audio II, Ltd M ade i n U kraine
15

Preset 001
«Bridge Full Range»*
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK
DO NOT EXPOSE THIS EQUIPMENTTO RAIN OR MOISTURE.
DO NOT REMOVE COVER.
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING
USB
DSP
PRESET
CH 2
CH 1CH 2
SPEAKER OUTPUTS
4 min
4 min
1
1
2
2
1
1
4 min
8 min
1
2
BRIDGE
(CH1-2)
MAINS IN
RISK OF ELECTRIC SHOCK
CAUTION
DO NOT OPEN
1
2
3
ON
PUSH PUSH
OUTPUT B
(POST DSP)
INPUT
CH 2INPUT
CH 1OUTPUT A
(POST DSP)
Model
Power Requirements
Serial No
BRIDGE
FULL RANGE
To Input Signal Source
To Full Range Speaker
2+
1+
8 min
Function Bridge Full Range
Routing Input Ch1 (gain 0dB)
HPF Freq. 35Hz (BTW 24dB/oct)
Function Full Range
Routing Input Ch1 (gain 0dB)
HPF Freq. 35Hz (BTW 24dB/oct)
Function Full Range
Routing Input Ch2 (gain 0dB)
HPF Freq. 35Hz (BTW 24dB/oct)
Ch1Ch2Output AOutput B Speaker OutputsLine Outputs
2
Ch
Input
Ouput B
Speaker Outputs
Ouput A 35Hz
35Hz
Ch2
Bridge
Ch1
35Hz
Input
Ch1
–
+ /
8 min
20 100 1k 10k
-15
-10
-5
0
5
dB
Hz
Bridge Ch1-2, Output A, Output B
Note.
* For amplifier DF3200DSP
preset 001 matches preset 000
(no BRIDGE mode in DF3200DSP).
Park Audio II, Ltd M ade i n U kraine
16

Preset 010
«Subwoofer + 2 Satellite (100Hz)»
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK
DO NOT EXPOSE THIS EQUIPMENTTO RAIN OR MOISTURE.
DO NOT REMOVE COVER.
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING
USB
DSP
PRESET
CH 2
CH 1CH 2
SPEAKER OUTPUTS
4 min
4 min
1
1
2
2
1
1
4 min
8 min
1
2
BRIDGE
(CH1-2)
MAINS IN
RISK OF ELECTRIC SHOCK
CAUTION
DO NOT OPEN
1
2
3
ON
PUSH PUSH
OUTPUT B
(POST DSP)
INPUT
CH 2INPUT
CH 1OUTPUT A
(POST DSP)
SUB + SAT
100Hz
To Input Signal Source
To Sat
-
1
1+
20 100 1k 10k
-15
-10
-5
0
5
dB
Hz
Output A, Output B
Ch2
Ch1
4 min
Function Subwoofer
Routing Input Ch1 (gain +3dB)
HPF Freq. 35Hz (BTW 24dB/oct)
LPF Freq. 100Hz (LR 24dB/oct)
Function Satellite
Routing Input Ch1 (gain 0dB)
HPF Freq. 100 Hz (LR 24dB/oct)
Function Full Range
Routing Input Ch1 (gain 0dB)
HPF Freq. 35Hz (BTW 24dB/oct)
Function Full Range
Routing Input Ch2 (gain 0dB)
HPF Freq. 35Hz (BTW 24dB/oct)
Ch1Ch2Output AOutput B Speaker OutputsLine Outputs
Input
Ch1
2
Ch
Input
Ouput B
Sub
Ch1
Speaker Outputs
100Hz
Ouput A 35Hz
35Hz
Ch2
Sat
100Hz
35Hz
4 min
4 min
To Sub
Park Audio II, Ltd M ade i n U kraine
Model
Power Requirements
Serial No
17

Preset 011
«Subwoofer + Satellite (125Hz)»
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK
DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.
DO NOT REMOVE COVER.
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING
USB
DSP
PRESET
CH 2
CH 1CH 2
SPEAKER OUTPUTS
4 min
4 min
1
1
2
2
1
1
4 min
8 min
1
2
BRIDGE
(CH1-2)
MAINS IN
RISK OF ELECTRIC SHOCK
CAUTION
DO NOT OPEN
1
2
3
ON
PUSH PUSH
OUTPUT B
(POST DSP)
INPUT
CH 2INPUT
CH 1OUTPUT A
(POST DSP)
SUB + SAT
125Hz
To Input Signal Source
-
1
1+
20 100 1k 10k
-15
-10
-5
0
5
dB
Hz
Output A, Output B
Ch2
Ch1
Function Subwoofer
Routing Input Ch1 (gain +3dB)
HPF Freq. 35Hz (BTW 24dB/oct.)
LPF Freq. 125Hz (LR 24dB/oct.)
Function Satellite
Routing Input Ch1 (gain 0dB)
HPF Freq. 125 Hz (LR 24dB/oct)
Function Full Range
Routing Input Ch1 (gain 0dB)
HPF Freq. 35Hz (BTW 24dB/oct)
Function Full Range
Routing Input Ch2 (gain 0dB)
HPF Freq. 35Hz (BTW 24dB/oct)
Ch1Ch2Output AOutput B Speaker OutputsLine Outputs
Input
Ch1
2
Ch
Input
Ouput B
Sub
Ch1
Speaker Outputs
125Hz
Ouput A 35Hz
35Hz
Ch2
Sat
125Hz
35Hz
4 min
4 min
4 min
To Sat To Sub
Model
Power Requirements
Serial No
Park Audio II, Ltd M ade i n U kraine
18
This manual suits for next models
2
Table of contents
