PARUS SIPB Series User manual

September 2019 Version 2.2
User manual
Uninterruptible Power Supply
SIPB 1~3kVA

2
Class B EMC Statements
(High Voltage Models up to 3000 VA)
FCC Part 15
NOTE This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and the receiver.
●Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
●Consult the dealer or an experienced radio/TV technician for help.

3
All rights reserved. The information in this document is subject to change
without notice.
Publish statement
Thank you for purchasing this series UPS.
This series UPS is an intelligent, single phase, high frequency online UPS
designed by our R&D team who is with years of designing experiences on
UPS. With excellent electrical performance, perfect intelligent monitoring
and network functions, smart appearance, complying with EMC and safety
standards this UPS has become standard product which meets the world’s
advanced level.
Read this manual carefully before installation. This manual offers technical
support for equipment operator.
Parus electro LLC
115404, Russia, Moscow 6th Radialnaya str., 9
Tel.: [phone]
www.parus-electro.ru
[email protected]
Service support:
Tel.: [phone]
[email protected]

4
Special Symbols
The following are examples of symbols used on the UPS or accessories to
alert you to important.
Information:
RISK OF ELECTRIC SHOCK - Observe the warning associated with
the risk of electric shock symbol.
CAUTION, need your attention
This symbol indicates that you should not discard the UPS or the
UPS batteries in the trash. This product contains sealed, lead‐acid
batteries and must be disposed of properly. For more information,
contact your local recycling/reuse or hazardous waste center.
This symbol indicates that you should not discard waste electrical or
electronic equipment (WEEE) in the trash. For proper disposal,
contact your local recycling/reuse or hazardous waste center.

5
Table of Contents
1. Introduction ..................................................................................................................6
2. Safety Warnings ..........................................................................................................8
3. Installation...................................................................................................................10
Inspecting the Equipment.......................................................................................10
Unpacking the Cabinet.............................................................................................10
Checking the accessories.........................................................................................11
Rackmount Installation.............................................................................................11
Checking the Rail Kit Accessories（Options）.................................................12
4. Operation.....................................................................................................................28
Control Cover Functions ..........................................................................................28
Start up operation .............................................................................................46
Turn on the UPS in line mode........................................................................46
Turn on the UPS by DC without mains power .........................................46
Turn off operation..............................................................................................47
Turn off the UPS in line mode .......................................................................47
Turn off the UPS by DC without mains power.........................................47
UPS self-test/mute test operation................................................................47
Configuring Battery Settings..................................................................................47
5. Communication .........................................................................................................49
Installing Communication Options and Control Terminals .........................50
6. UPS Maintenance......................................................................................................57
UPS and Battery Care................................................................................................57
Storing the UPS and Batteries................................................................................57
Replacing Batteries ....................................................................................................58
Replacing Tower EBPs...............................................................................................58
Replacing RT UPS and EBPS ...................................................................................59
Testing New Batteries ...............................................................................................61
Recycling the Used Battery or UPS ......................................................................61
7. Specifications .............................................................................................................63
Model Specifications.................................................................................................63
8. Troubleshooting ........................................................................................................73

6
Introduction
This UPS protects your sensitive electronic equipment from most common
power problems, including power failures, power sags, power surges,
brownouts, line noise, high voltage spikes, frequency variations, switching
transients, and harmonic distortion.
Power outages might occur unexpectedly and power quality can be erratic.
These power problems have potential to corrupt critical data, destroy
unsaved work sessions, and damage hardware - causing hours of lost
productivity and expensive repairs.
With the UPS, you can safely eliminate the effects of power disturbances and
guard the integrity of your equipment. Providing outstanding performance
and reliability, the UPS's unique benefits include:
True online double-conversion technology with high power
density, utility frequency independence, and generator compatibility.
Output power factor up to 0.9.
Three segment charging mode to increase battery service life,
optimize recharge time.
Selectable High Efficiency mode of operation.
Cold start function to startup the UPS without utility.
Standard communication options: one RS-232 communication
port, one USB communication port, and relay output contacts or
SNMP card.
Power Shedding function may turn off uncritical load in battery
backup to make longer backup time for critical load.
Extended runtime with up to four Extended Battery Modules
(EBPs) per UPS.
Emergency shutdown control through the Remote Emergency
Power-off (EPO) port.
The content displayed on the interface is rich. The capacity of the
loads and the battery can be seen directly and the FLASH pictures
and fan rotating icon can be displayed while charging. Enhance, it is

7
easy to know its operation status. When UPS fails, it can show the
fault code; therefore, the UPS can be repaired as soon as possible by
inquiring fault code table.
NOTICE: In the manual, RT is short for Rack-Tower conversion
Rack/Tower convertible LCD design. No matter what angle
required, only pressing the key slightly to reach your perspective
needs.
For RT model, it is equipped with hot swappable battery feature
needed for 19”rack solution.
RT models in a space-optimizing 2U size fits any standard 19”
rack.
Figure1 The Rackmount UPS front view
Figure2 The Rackmount EBP front view
Figure3 The Tower UPS and the EBP front view

8
1. Safety Warnings
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This manual contains important instructions that you should follow during
installation and maintenance of the UPS and batteries. Please read all
instructions before operating the equipment and save this manual for future
reference.
DANGER
The UPS contains LETHAL VOLTAGES. All repairs and
service should be performed by AUTHORIZED SERVICE
PERSONNEL ONLY. There are NO USER SERVICEABLE
PARTS inside the UPS.
WARNING
The UPS contains its own energy source (batteries). The
UPS output may carry live voltage even when the UPS is not
connected to an AC supply.
To reduce the risk of fire or electric shock, install the UPS
in a temperature and humidity controlled, indoor
environment, free of conductive contaminants. Ambient
temperature must not exceed 40°C (104°F). Do not operate
near water or excessive humidity (90% maximum).
To reduce the risk of fire, connect only to a circuit
provided with branch circuit overcurrent protection in
accordance with the National Electrical Code (NEC),
ANSI/NFPA 70.
Output overcurrent protection and disconnect switch
must be provided by others.
To comply with international standards and wiring
regulations, the sum of the leakage current of the UPS and
the total equipment connected to the output of the UPS
must not have an earth leakage current greater than 3.5

9
milliamperes.
If installing optional rackmount EBP(s), install the EBP(s)
directly below the UPS so that all wiring between the
cabinets is installed behind the front covers and is
inaccessible to users. The maximum number of EBP(s) per
UPS is four.
If the UPS requires any type of transportation, verify that
the UPS is unplugged and turned off and then disconnect
the UPS internal battery connector.
CAUTION
Batteries can present a risk of electrical shock or burn
from high short-circuit current. Observe proper precautions.
Servicing should be performed by qualified service
personnel knowledgeable of batteries and required
precautions. Keep unauthorized personnel away from
batteries.
Proper disposal of batteries is required. Refer to your
local codes for disposal requirements.
Never dispose of batteries in a fire. Batteries may explode
when exposed to flame.

10
2. Installation
This section explains:
Equipment inspection
Unpacking the cabinet
Checking the accessory kit
Cabinet installation
Wiring installation
Initial startup
Inspecting the Equipment
If any equipment received has been damaged during shipment, keep
the shipping cartons and packing materials for the carrier or place of
purchase and file a claim for shipping damage. If you discover
damage after acceptance, file a claim for concealed damage.
To file a claim for shipping damage or concealed damage: 1) File
with the carrier within 15 days of receipt of the equipment; 2) Send a
copy of the damage claim within 15 days to your service
representative.
NOTE Check the battery recharge date on the shipping carton
label. If the date has expired and the batteries were never
recharged, do not use the UPS. Contact your service
representative.
Unpacking the Cabinet
CAUTION
Unpacking the cabinet in a low-temperature
environment may cause condensation to occur in and on
the cabinet. Do not install the cabinet until the inside and
outside of the cabinet are absolutely dry (hazard of electric
shock).

11
The cabinet is heavy (see page 65). Be careful to unpack
and move the cabinet.
Carefully to move and open the carton. Keep the
components packaged until ready to install.
To unpack the cabinet and accessories:
1. Open the outer carton and remove the accessories
packaged with the cabinet.
2. Carefully lift the cabinet out of the outer carton.
3. Discard or recycle the packaging in a responsible manner,
or store it for future use.
Place the cabinet in a protected area that has adequate
airflow and is free of humidity, flammable gas, and
corrosion.
Checking the accessories
It includes：
UPS user's guide
Software Suite CD
USB cable
Power cord (Input and output)
RS232 cable
If you ordered an optional Extended Battery Module (EBP), verify
that the following additional item is included with the EBP:
●EBP user's guide
NOTE Discard the EBP user's guide if you are installing the EBP
with a new UPS at the same time. Use the UPS user's guide to
install both the UPS and the EBP.
Rackmount Installation
The Rackmount cabinet comes with all of the hardware required for
installation in a standard EIA or JIS seismic Rackmount configuration
with square and round mounting holes. The rail assemblies adjust to

12
mount in 19”racks with a distance from front to rear around 70~76
cm (27 to 30 inches) deep.
Checking the Rail Kit Accessories (Options)
Verify that the following rail kit items are included for
each cabinet:
Left rail assembly:
- Left rail
- Rear rail
- (3) M5_8 pan-head screws
Right rail assembly:
- Right rail
- Rear rail
-(3) M5_8 pan-head screws
Rail hardware kit:
- (8) M5 butterfly nuts
- (2) rear stop brackets
- (8) M5 umbrella nuts
Mounting bracket kit:
- (2) mounting brackets
- (8) M4_8 flat-head screws
Tools Required
To assemble the components, the following tools may be needed:
cross-shaped screwdriver
5 and 6 mm wrench or socket
Rackmount Setup
CAUTION
 The cabinet is heavy. Removing the cabinet from
its carton requires a minimum of two people.
 If installing optional EBP(S), make sure to install the
EBP(S) directly below the UPS so that all wiring
between the cabinets is installed behind the front
covers and inaccessible to users.

13
NOTE Mounting rails are required for each individual
cabinet
To install the rail kit:
1. Assemble the left and right rails to the rear rails as shown in Figure4.Do
not tighten the screws.
Adjust each rail size for the depth of your rack.
Figure4 Securing the Rails
2. Select the proper size in the rack for positioning the UPS (see Figure 5).
The rail occupies four positions on the front and rear of the rack.
3. Tighten four M5 Umbrella Nuts in the side of rail assembly (see Figure
4).
4. Fix one rail assembly to the front of the rack with one M5×12 pan-head
screw and one M5 cage nut. Using two M5 cage nuts and two M5×12
pan-head screws, to fix the rail assembly to the rear of the rack.

14
Figure5 Fixing the Rails
5. Repeat Steps 3 and 4 for the other rail assembly.
6. Tighten the four butterfly nuts in the middle of each rail assembly.
7. If installing optional cabinets, repeat Step 1 through Step 6 for each rail
kit.
8. Place the UPS on a flat, stable surface with the front of the cabinet
facing to you.
9. Align the mounting brackets with the screw holes on each side of the
UPS and fix with the supplied M4×8 flat-head screws(see Figure 6)
Figure6 Installing the Mounting Brackets
10. If installing optional cabinets, repeat Step 8 and 9 for each cabinet.
Mounting Bracket
M4x8 Flat-Head
Screws (2 places)

15
11. Slide the UPS and any other optional cabinets into the rack.
12. Secure the front of the UPS to the rack using one M5×12 pan-head
screws and one M5 cage nuts on each side(see Figure 7).Install the
bottom screw on each side through the bottom hole of mounting
bracket and the bottom hole of the rail.
Repeat for any optional cabinets.
Figure7 Securing the Front of the Cabinet
13. Continue to the following section, “Rackmount Wiring Installation”
Rackmount Wiring Installation
This section explains:
Installing the UPS, including connecting the UPS internal batteries
Connecting any optional EBP(S)
Installing the UPS
NOTE Do not make unauthorized changes to the ups;
otherwise, damage may occur to your equipment and void
your warranty.
M5 Float
Nuts (2 places)
M5x12 Pan-Head Screws (2 places)

16
NOTE Do not connect the ups power cord to utility until
after installation is completed.
To install the UPS:
1. Remove the front cover of each UPS
Press the cover side with LCD display, hold the other side and quickly extract
it, then extract the other side with display. (see Fig.8)
NOTE A ribbon cable connects the LCD control cover to the UPS. Do not pull
on the cable or disconnect it.
When remove the cover, Operate as the following right Figure shows instead
of the left one. (see Fig.8)
Figure8 Extract UPS front cover
CAUTION
A small amount of arcing may occur when connecting the internal batteries.
This is normal and will not harm personnel. Connect the cables quickly and
firmly
It is wrong that
extracting the front
cover from the handle
It is correct that
extracting the front
cover from the panel
First
Last
X
V

17
2. Connect the internal battery connector (see Figure9)
Connect red to red. Press the connector tightly together to ensure a proper
connection.
3. If you are installing EBPS, see the following section, “Connecting the
EBP(s),”before continuing with the UPS installation.
Figure9 Connecting the UPS Internal Batteries
4. Replace the UPS front cover.
To replace the cover, verify that the ribbon cable is protected and (if EBPS are
installed) the EBP cable is routed through the knockout on the bottom of the
cover.
Put the front cover hooks of side with display to the cover port, put another
side to the other two ports, then press it until the cover and the chassis are
combined tightly.

18
Figure10
5. If you are installing power management software, connect your computer
to one of the communication ports or optional connectivity card. For the
communication ports, use an appropriate cable.
6. If your rack has conductors for grounding or bonding of ungrounded
metal parts, connect the ground cable (not supplied) to the ground bonding
screw. See “Rear Covers”for the location of the ground bonding screw for
each model.
7. If an emergency power-off (disconnect) switch is required by local codes,
see “Remote Emergency Power-off”(REPO) to install the REPO switch
before powering on the UPS.
8. Continue to“UPS Initial Startup”.
Connecting the EBP(s)
To install the optional EBP(s) for a UPS:
1. Remove the front cover of each EBP and UPS (see Figure 11).
It is the same with the installation of the front cover. (Refer “To install the
UPS“)
EBM Cover Hooks
(4 places)
Top EBM cable knockout

19
Figure11 Removing the EBP Front Cover
2. On the bottom of the UPS front cover, remove the EBP cable knockout (see
Figure 12).
Figure12 Removing the UPS Cable Knockout
3. For the bottom (or only) EBP, remove the EBP cable knockout on the top of
the EBP front cover. See Figure 13 for the location of the top EBP cable
knockout.
4. If you are installing more than one EBP, for each additional EBP remove
the EBP cable knockout on the top and bottom of the EBP front cover. See
Figure 13 for the location of the EBP cable knockouts.
CAUTION
A small amount of arcing may occur when connecting an EBP to the UPS.
This is normal and will not harm personnel. Insert the EBP cable into the UPS
It is wrong that
extracting the front
cover from the handle
It is correct that
extracting the front
cover from the panel
First
Last
X
V

20
battery connector quickly and firmly.
5. Plug the EBP cable(s) into the battery connector(s) as shown in Figure 13.
Up to four EBPS may be connected to the UPS. Connect black to black,. Press
the connector tightly together to ensure a proper connection.
To connect a second EBP, unclip the EBP connector on the first EBP and pull
gently to extend the wiring to the EBP connector on the second EBP. Repeat
for any additional EBPS.
6. Verify that the EBP connections are tight and the adequate bend radius
and strain relief exist for each cable.
Figure13 Typical EBP Installation
7. Replace the EBP front cover.
To replace the cover, verify that the EBP cables are routed through the EBP
cover knockouts, cover connects with the cover hook near the left side of the
EBP cabinet. Repeat for each additional EBP.
It is the same with the installation of the front cover. (Refer”to UPS
installation”)
