PASCO OS-8514 User manual

Instruction Sheet
for the PASCO
Model OS-8514
LASER ADAPTER KIT
012-07094B
© 1999 PASCO scientific
Introduction
The PASCO OS-8514 Laser Adapter Kit adapts the
PASCO SE-9367 Mini Laser for use with all PASCO
optics systems.
INCLUDED
• (1) 648-07092 adapter bracket
• (2) 617-008 thumbscrews
• (2) 614-088 jam nuts
• (2) 615-010 fiber washers
Setup Procedure
1. Place jam nuts, flat side outward, into the
groove on the bottom of the Mini Laser.
2. Looking at the back of the laser, line up the
bracket’s holes with the nuts so the adapter bracket
comes up the left side of the laser.
3. Insert the thumbscrews with washers and finger
tighten.
ADAPTER BRACKET
GROOVE

Laser Adapter Kit 012-07094B
2
Limited Warranty
PASCO scientific warrants the product to be free
from defects in materials and workmanship for a
period of one year from the date of shipment to the
customer. PASCO will repair or replace, at its
option, any part of the product which is deemed to
be defective in material or workmanship. The
warranty does not cover damage to the product
caused by abuse or improper use. Determination of
whether a product failure is the result of a
manufacturing defect or improper use by the
customer shall be made solely by PASCO
scientific. Responsibility for the return of
equipment for warranty repair belongs to the
customer. Equipment must be properly packed to
prevent damage and shipped postage or freight
prepaid. (Damage caused by improper packing of
the equipment for return shipment will not be
covered by the warranty.) Shipping costs for
returning the equipment after repair will be paid by
PASCO scientific.
