PatchMaster Lightning Capture User manual
User Manual
PatchMaster Lightning Capture is an extremely sensitive device to detect
lightning designed to help photographers take lightning photos during day or night. The
device has been designed based on microcontroller technology and has a response
(lag) time in microsecond level. This is more than enough to capture the lightning
events. Each unit is tested in various test environments after production to verify it is
ready to be shipped.
Features:
•Extremely sensitive optical sensor to detect lightning events
•Response (lag) time in microseconds level
•No need to manual adjustment self calibration based on light level
•Optical isolated output to fully protect the camera from any potential harms
•Hot shoe mount for mounting the device directly to your camera
•Power indicator LED
•Trigger indicator LED for simulating shutter output
•Powered by 9V alkaline battery
•Microcontroller-based design
Dimensions:
•Length : 3.93 in (100 mm)
•Width : 2.36 in (60 mm)
•Height : 1.38 in (35 mm)
Instructions:
1. Make sure the camera and the PatchMaster Lightning Capture are turned off.
2. Mount the trigger to the camera using the hot shoe mount.
3. Plug the release cable to the camera.
4. First turn on the PatchMaster Lightning Capture and then the camera.
5. Enjoy while the device is taking lightning photos for you.
Testing:
For sure, the best way for testing the PatchMaster Lightning Capture is
examining it during a real storm. However, you still have other options to test the
PatchMaster Lightning Capture until a real storm hits. A camera flash is the best device
which can simulate a real lightning for testing purposes. Mount your device per the
instructions given above, then fire the flash and verify PatchMaster Lightning Capture
triggers the camera as expected. Enjoy it!
LEDs and Buttons
1. Power LED: Device status
indicator LED. The LED lights
when the device is working
properly.
2. Trigger LED: Flash event
indicator LED. The LED blinks
when the lightning is detected.
3. ON/OFF Switch: The switch
is used to turn the device on/off.
Working Modes:
Daytime: When you turn the device on, if the device decides that it is daytime,
Power LED will blink for 2-3 times and then remain stable.
Night time: When you turn the device on, if the device decides that it is night
time, Power LED will NOT blink but remain stable.
Disclaimer:
•Lightning can be DANGEROUS. We are not liable for any damage or
personal injury associated with the use of the PatchMaster Lightning
Capture. The PatchMaster Lightning Capture is intended for use as a
camera shutter release device only and not any other purpose.
•The PatchMaster Lightning Capture is not waterproof. It should be
treated and handled with the care of a camera and should not be
dropped and/or exposed to extreme heat or moisture.
•All camera functions may not be available when using the
PatchMaster Lightning Capture.
Troubleshooting:
•If the Power LED does not light:
1. The switch may be OFF, make sure the switch is ON.
2. The battery may be empty, replace the battery.
•If the Trigger LED is blinking continuously:
1. The device may be in a strong static field, remove the device from
the static field.
2. Room lights may cause the device to false trigger, turn off the
room lights.
amera Settings
1. Set your camera on the tripod and make sure it is steady.
2. Put the camera to the Manual Focus mode.
3. If available, turn off the Image Stabilizer.
4. Set the camera focus to Infinity manually.
5. Turn the mode selection wheel to M (Full Manuel).
6. Set the aperture between 4.0 and 8.0.
7. Set exposure time value to maximum 1/10 (This duration can be adjusted per
the ambient light by the user.)
