Patriot BT-1906 User manual

Bluetooth Speaker BT-1906
FEATURES:
1. Outdoor HiFi Wireless BT Speaker with double 4inch subwoofer.
2. Output power is strong, you can enjoy your music anywhere
3. BT 5.0 with lower power consumption and over 10m meters operating range.
4. Support USB and Micro-SD card and AUX and FM Radio, and TWS function.
5. Support wired microphone give you experience the singer's feeling.
6. Colorful LED lights looks more beautiful.
7. With handle, easy to take out, wherever beach, garden, party, outskirts etc.
SPECIFICATION:
Speaker Type
2 x 5.25inch
POWER WATTS/RMS Power
12W
HERTZ /Frequency Response
150Hz - 18KHz
Signal to Noise Ratio
≥80dB
Woofer
Full Range Frequency Speaker
Tweeter
BT Version
V5.0
InPut Specs
DC 5V, 1A
Output Voltage
3.7V
Battery
1200mAh*2
Illumination
LED Flashlight
Display
LED Display
Connections
BT/Micro SD/USB/FM/AUX/MIC
Unit Measures (mm)
185 x 185 x 460
Unit Weight (kgs)
2.02
Box Measures (mm)
194 x 194 x 480
Box Weight (kgs)
2.20
Master Box Measures (mm)
796 x 405 x 500
Master Box Weight (kgs)
19.6
Accessories
Remote Control, Charging Cable, Audio Cable
MANUAL
1. BT Mode:
a) BT Version: 5.0, with lower power consumption and over 10m meters operating range.
b) ON/OFF, after the power is turned on, the display “BLUE” flashes and the speaker emits a BT mode tone.
c) The “BLUE” character flashes into the pairing state, open the phone BT, search for the device name, click the device name to
confirm and then connect. After the connection is successful, “BLUE” is always on, and the speaker sends a pairing success
tone. The “BLUE” character is displayed during playback, and the “PAUS” character is displayed when paused.
2. TF/Micro SD Card Mode:
a) When the speaker is not plugged into the TF card device, it will boot into the BT mode. Inserting the TF card speaker will
automatically detect the TF card playback mode, displaying ‘PLAY’ and playback time. If the speaker has a TF card device, it
will enter the TF card mode directly after booting.
b) The display shows the playback time during playback, and “PAUS” character are displayed when paused.

3. U Disk Mode:
a) When the speaker is not plugged into the U disk, it will boot into the BT mode. Inserting the U disk, speaker will automatically
detect the USB playback mode, displaying ‘PLAY’ and playback time. If the speaker has a U disk, it will enter the TF card
mode directly after booting.
b) The display shows the playback time during playback, and “PAUS” character are displayed when paused.
4. FM Mode:
a) Press the button ‘MODE’, enter into FM mode. FM Frequency is 87.5Hz – 108.0MHz.
b) This speaker has a built-in radio antenna, needn’t an external antenna.
c) Press and hold the button ‘PLAY/PAUSE’ to automatically search the station, press the “PLAY/PAUSE’ button to pause.
5. AUX Mode:
a) Plug one end of the 3.5MM audio cable into the speaker AUX jack, the speaker will automatically detect the AUX mode, and
the other 3.5MM plug is connected to the phone or computer.
b) The “LINE” character is displayed in AUX mode. Press the “PLAY/PAUSE” button to pause.
6. MIC FUNCTION:
a) In the power-on mode, plug in the wired microphone, begin to work. (Note: turn on the button of wired microphone before
using.)
7. CHARGING:
a) Plug the USB cable into the speaker to connect to the 5V charger or computer to charge for inside Li-battery.
b) The item has a red light on the charging indicator. When charging, the indicator light is on. When it is full, the indicator light is
off.
8. Low-power protection:
When the speaker detects that the built-in battery voltage is lower than 3.3V, it will emit a low-power alarm sound. When the battery
voltage is lower than 3.1V, the speaker will automatically shut down.
9. Mode cycle: Press ‘MODE’ button to switch USB→TF→BT→FM→AUX.
(Note: USB, TF, AUX are only displayed when USB is plugged in.)
10. LED flashlight: Press and Hold ‘MODE’ button to turn on/off the LED flashlight.
11. TWS Function：Use your mobile phone connect one BT speaker successfully firstly, Under BT mode, double click Play/Pause
button of another BT speaker to enter into TWS pairing.
FCC Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure
condition without restriction.
