Patton electronics 1012ARC User manual

USER
MANUAL
MODEL 1012ARC
Asynchronous,
Two-Channel
Short Range Modem
Rack Card
SALES OFFICE
[phone]
TECHNICAL SUPPORT
[phone]
Part #07M1012ARC-C
Doc #040041UC
Revised 9/10/97
CERTIFIED
An ISO-9001
Certified Company
Dear Valued Customer,
Thank you for purchasing Patton Electronics products! We do
appreciate your business. I trust that you find this user manual helpful.
We manufacture one of the widest selections of data
communications products in the world including CSU/DSU's, network
termination units, powered and self-powered short range modems, fiber optic
modems, interface converters, baluns, electronic data switches, data-line surge
protectors, multiplexers, transceivers, hubs, print servers and much more. We
produce these products at our Gaithersburg, MD, USA, facility, and can
custom manufacture products for your unique needs.
We would like to hear from you. Please contact us in any of the
following ways to tell us how you like this product and how we can meet your
product needs today and in the future.
Web: http://www.patton.com
Sales E-mail: [email protected]
Support E-mail: [email protected]
Phone - Sales [phone]
Phone - Support [phone]
Fax: [phone]
Mail: Patton Electronics Company
7622 Rickenbacker Drive
Gaithersburg, MD 20879 USA
We are committed to a quality product at a quality price. Patton
Electronics is BABT and ISO 9001 certified. We meet and exceed the highest
standards in the industry (CE, UL, etc.).
It is our business to serve you. If you are not satisfied with any
aspect of this product or the service provided from Patton Electronics or its
distributors, please let us know.
Thank you.
Burton A.Patton
Vice President
P.S. Please tell us where you purchased this product:
_______________________________________________________________
_______________________________________________________________
_______________________________________________________________
_______________________________________________________________
_______________________________________________________________
_______________________________________________________________

1.0 WARRANTY INFORMATION
Patton Electronics warrants all Model 1012ARC components to
be free from defects, and will—at our option—repair or replace the
product should it fail within one year from the first date of shipment.
This warranty is limited to defects in workmanship or materials,
and does not cover customer damage, abuse or unauthorized
modification. If this product fails or does not perform as warranted,
your sole recourse shall be repair or replacement as described above.
Under no condition shall Patton Electronics be liable for any damages
incurred by the use of this product. These damages include, but are
not limited to, the following: lost profits, lost savings and incidental or
consequential damages arising from the use of or inability to use this
product. Patton Electronics specifically disclaims all other warranties,
expressed or implied, and the installation or use of this product shall be
deemed an acceptance of these terms by the user.
1.1 RADIO AND TV INTERFERENCE
The Model 1012ARC generates and uses radio frequency energy,
and if not installed and used properly—that is, in strict accordance with
the manufacturer’s instructions—may cause interference to radio and
television reception. The Model 1012ARC has been tested and found
to comply with the limits for a Class A computing device in accordance
with the specifications in Subpart J of Part 15 of FCC rules, which are
designed to provide reasonable protection from such interference in a
commercial installation. However, there is no guarantee that
interference will not occur in a particular installation. If the Model
1012ARC does cause interference to radio or television reception,
which can be determined by disconnecting the unit, the user is
encouraged to try to correct the interference by one or more of the
following measures: moving the computing equipment away from the
receiver, re-orienting the receiving antenna and/or plugging the
receiving equipment into a different AC outlet (such that the computing
equipment and receiver are on different branches). In the event the
user detects intermittent or continuous product malfunction due to
nearby high power transmitting radio frequency equipment, the user is
strongly advised to take the following steps: use only data cables with
an external outer shield bonded to a metal or metalized connector; and,
configure the rear card as shown in section 3.3 of this manual.
1.2 CE NOTICE
The CE symbol on your Patton Electronics equipment indicates
that it is in compliance with the Electromagnetic Compatibility (EMC)
directive and the Low Voltage Directive (LVD) of the Union European
(EU). A Certificate of Compliance is available by contacting Technical
Support. 1
1.3 SERVICE
All warranty and nonwarranty repairs must be returned freight
prepaid and insured to Patton Electronics. All returns must have a
Return Materials Authorization number on the outside of the shipping
container. This number may be obtained from Patton Electronics
Technical Support: [phone]; http://www.patton.com; or,
[email protected]. Notice: Packages received without an RMA
number will not be accepted.
Patton Electronics' technical staff is also available to answer any
questions that might arise concerning the installation or use of your
Model 1012ARC. Technical Service hours: 8AM to 5PM EST,
Monday through Friday.
2

2.0 GENERAL INFORMATION
Thank you for your purchase of this Patton Electronics product.
This product has been thoroughly inspected and tested and is
warranted for One Year parts and labor. If any questions or problems
arise during installation or use of this product, please do not hesitate to
contact Patton Electronics Technical Support at [phone].
2.1 FEATURES
• Houses two short range modems
• Full or half duplex
• Asynchronous data rates to 38.4 Kbps
• Point-to-point or multipoint
• Automatic equalization and gain control
• Software and hardware handshaking
• Distances to 6 miles over two unconditioned twisted pair
• Transformer isolation
• Silicon Avalanche Diode surge protection
• Mounts in Patton’s rack chassis
• Made in USA
2.2 DESCRIPTION
The Patton Model 1012ARC is a miniature rack card designed to
house two asynchronous short range modems. Operating full or half
duplex at data rates to 38.4 Kbps, the Model 1012ARC supports point-
to-point or multidrop applications and offers automatic equalization and
gain control. The Model 1012ARC supports distances up to 6 miles
over two twisted pair. Built-in transformer isolation and surge
protection provide protection against ground potential differences and
AC/DC over-voltages, making the Model 1012ARC ideal for
connections between two buildings.
The Model 1012ARC is designed to mount in Patton’s Model
1000R16P rack chassis. This 16-card chassis has a switchable
120/240 volt power supply and uses mid-plane architecture: The front
card can be plugged into different rear cards. This means that the
1012ARC can have several interface options, and can be switched with
other Patton short haul cards. The rear card is available with an RJ-45
connection for each RS-232 channel and either RJ-11 or RJ-45
connections for twisted pair.
3
3.0 CONFIGURATION
The Model 1012ARC rack card is easy to set up since there are
only two configuration straps. Figure 1 (below) shows the location of
these straps on the Model 1012ARC PC board.
3.1 MOVING THE CONFIGURATION STRAPS
Figure 2 shows how to move the configuration straps. Note that the
Model 1012ARC only has two pegs, thus the straps can only be
“installed” or “removed”. The rear card uses three pegs, and can be on
either pegs 1 and 2, or pegs 2 and 3.
3.2 SETTING THE RTS/DCD STRAPS
Each RTS/DCD strap affects one of your modems. Their setting
determines how the respective transmitters (i.e., carrier) are activated.
When these straps are installed, the Model 1012ARC transmitter is
CONTROLLED CARRIER. When these straps are removed, the
transmitter is CONSTANT CARRIER. Each strap may be configured
separately.
4
Figure 1. Model 1012ARC, showing straps locations
RTS Channel A
RTS Channel B
Figure 2. Orientation of interface card straps
123 123 123

3.3 REAR CARD CONFIGURATION
After you have configured the Model 1012ARC, you will need to set
up your rear card. The Model 1012ARC has two interface card options:
the 1Q11 (which comes equipped with two RJ-11 ports and two RJ-45
ports) and the 1Q45 (which comes equipped with four RJ-45 ports).
Figure 3 illustrates these two different options.
Prior to installation, you should examine the rear card you have
selected and ensure that it is configured for your application. Each rear
card is configured by setting straps on the PC board. Section 3.4
describes the strap locations and settings for each card.
3.4 REAR CARD STRAP SETTINGS
Figure 4 shows the strap locations for the 1Q11 and the 1Q45 rear
cards. These straps determine various grounding characteristics for
the RS-232 and twisted pair lines.
5
The table below provides a summary of strap functions for both of
the rear cards. Following Figure 5 is a description of each strap and its
function.
JB2 & JB4: Line A Shield & Line B Shield
This strap pertains to the line interface. In the connected (closed)
position, the strap links RJ-11 pins 1 and 6 (RJ-45 pins 2 and 7) to
frame ground. These pins can be used as connections for the twisted
pair cable shield. In the open (disconnected) position, pins 1 and 6 (or
2 and 7) remain connected, but are “lifted” from frame ground.
JB2 Setting
Position 1&2 Line A Shield Connected
Position 2&3 No Shield (default)
JB4 Setting
Position 1&2 Line B Shield Connected
Position 2&3 No Shield (default)
JB5: SGND & FRGND
In the connected (closed) position, this strap links signal ground
and frame ground. In the open (disconnected) position, pin 1 is “lifted”
from frame ground.
JB5 Setting
Position 1&2 SGND and FRGND Connected
Position 2&3 SGND and FRGND Not Connected
(default)
6
Strap Position 1&2 Position 2&3
JB2 Line A Shield No Shield†
JB4 Line B Shield No Shield†
JB5 SGND & FRGND Open†
JB6 DTE A DSR†N/A
JB7 DTE B DSR†N/A
INTERFACE CARD STRAP SUMMARY TABLE #1
Summary of strap settings, †indicates factory default
Figure 3. Model 1012ARC rear interface card options
Figure 4. Strap locations for both rear cards
1
2
3
1
2
3
1
2
3
1
2
3
123
(Unit A)
JP2
JP4
JP5
JP6
JP7
(Unit B)
(Unit A)
(Unit B)
Converter
twisted pair
Terminal
}
}
1Q11 1Q45
RJ-45
RJ-45
RJ-45
RJ-45
RJ-11
RJ-11
RJ-45
RJ-45
Twisted Pair Line
Connection
Twisted Pair
Line Connection
RS-232
Connection
RS-232
Connection
}
}
}
}

7
JB6 & JB7: DTE as DSR or RI
Because this rear card is designed to function with a variety of rack
cards, it comes equipped with two strap positions. However, when
used with the Model 1012ARC, this strap must be installed only in one
position. Place the jumper across pins 1&2 so that the terminal (DTE)
sees DSR as high when the DTE raises DTR. The other positions—
across pins 2&3, are for Ring Indicate as defined by EIA/TIA-561. The
RI function is irrelevant (and on the Model 1012ARC is also
disconnected) and can cause improper operation if the jumper is
installed incorrectly.
JB6 & JB7 Setting
Position 1&2 DSR (default)
Position 2&3 N/A
4.0 INSTALLATION
This section describes the functions of the Model 1000R16 rack
chassis, tells how to install front and rear Model 1012ARC cards and
provides diagrams for correctly wiring the interface connections.
4.1 THE MODEL 1000R16 RACK CHASSIS
The Model 1000R16 Rack Chassis (Figure 5) has sixteen short
range modem card slots, plus its own power supply. Measuring only
3.5” high, the Model 1000R16 occupies only 2U in a 19” rack. Sturdy
front handles allow the Model 1000R16 to be transported conveniently.
4.1.1 The Rack Power Supply
The power supply included in the Model 1000R16 rack uses the
same mid-plane architecture as the modem cards. The front card of
the power supply slides in from the front, and the rear card slides in
from the rear. They plug into one another in the middle of the rack.
The front card is then secured by thumb screws and the rear card by
conventional metal screws.
(continued)
8
Figure 5. Model 1000R16 Rack Chassis with power supply
WARNING! There are no user-serviceable parts in the
power supply section of the Model 1012ARC Series.
Voltage setting changes and fuse replacement should only
be performed by qualified service personnel. Contact
Patton Electronics Technical support at [phone] for
more information.

Switching the Power Supply On and Off
The power supply on/off switch is located on the front panel.
When plugged in and switched on, the power LED will glow. Since the
Model 1000R16 is “hot swappable”, you do not need to turn off the
power before removing rack cards. The power supply may be switched
off at any time without harming the installed cards.
NOTE: Please refer to the Model 1000RP Series User Manual AC
and DC Rack Mount Power Supplie s for fuse and power card
replacement information.
4.2 INSTALLING THE MODEL 1012ARC INTO THE CHASSIS
The Model 1012ARC is comprised of a front card and a rear card.
The two cards meet inside the rack chassis and plug into each other
via mating 50 pin card edge connectors. Use the following steps to
install each Model 1012ARC into the Model 1000R16 rack chassis:
1. Slide the rear card into the back of the chassis along the metal
rails.
2. Secure the rear card using the metal screws provided.
3. Slide the card into the front of the chassis. It should meet the rear
card when it is almost in the chassis.
4. Push the front card
gently into the card-edge receptacle of the
rear card. It should “click” into place.
5. Secure the front card using the thumb screws.
NOTE: Since the Model 1000R16 chassis allows “hot swapping” of
cards, it is
not necessary to turn the power off when you install or
remove a Model 1012ARC.
4.3 TERMINAL INTERFACE CONNECTION
The RS-232 ports are always the
lower ports on the interface card.
The 10-pin RJ-45 is pinned according Patton’s Modified Modular
Interface Standard (based on the EIA/TIA-561Standard). For specific
interface pin-outs, please refer to the diagrams in Appendix D.
The Model 1012ARC is wired as a DCE (Data Circuit-Terminating
Equipment). Therefore, it wants to connect to a DTE (Data Termination
Equipment). If your RS-232 output device is a DTE, you may need to
use a special cable (such as a DB-25 to modular cable). If your
RS-232 output device is DCE, call Technical Support at
[phone] for specific installation instructions.
9
4.4 TWISTED PAIR CONNECTION
The Model 1012ARC operates over two twisted pair. In
all
applications, the twisted pair wire must be 26 AWG or thicker,
unconditioned, dry metallic wire. Both shielded and unshielded wire
yield favorable results. Note: The Model 1012ARC can only
communicate in a closed data circuit with another Model 1012ARC.
Dial-up analog circuits, such as those used with a standard Hayes-type
modem, are not acceptable. For further information about acceptable
wire grades, please refer to the diagrams in Appendix B.
4.4.1 POINT-TO-POINT TWISTED PAIR CONNECTION
The 6-position RJ-11 and 8-position RJ-45 jack options for the
Model 1012ARC (always the upper jack on the rear interface card) are
pre-wired for a standard TELCO wiring environment. Connection of a
4-wire twisted pair circuit between two or more Model 1012ARCs
requires a crossover cable as shown in the following charts.
RJ-11
SIGNAL PIN# COLOR‡COLOR PIN# SIGNAL
GND†1 Blue‡.................White 6 GND†
RCV-◊2 Yellow...............Red 4 XMT-
XMT+ 3 Green...............Black 5 RCV+
XMT- 4 Red ..................Yellow 2 RCV-
RCV+ 5 Black ................Green 3 XMT+
GND†6 White................Blue 1 GND†
RJ-45
SIGNAL PIN# COLOR‡COLOR PIN# SIGNAL
GND†2 Orange.............Brown 7 GND†
RCV- 3 Black................Green 5 XMT-
XMT+ 4 Red..................Yellow 6 RCV+
XMT- 5 Green...............Black 3 RCV-
RCV+ 6 Yellow ..............Red 4 XMT+
GND†7 Brown ..............Orange 2 GND†
†Connection to ground is optional
‡Standard color codes—yours may be different
10

4.4.2 MULTIPOINT TWISTED PAIR CONNECTION
The Model 1012ARC supports multipoint applications using a star
topology. Maximum distance between the units will vary based upon
the number of drops, data rate, wire gauge, etc. Call Patton Technical
Support for specific distance estimates. Figure 6 shows how to wire
the cables properly for a Model 1012ARC star topology. Note that the
ground connection is not needed.
11
5.0 OPERATION
Once you have configured each Model 1012ARC and connected
the cables, you are ready to operate the units. Section 5.0 describes
the LED status monitors and the power-up procedure.
5.1 LED STATUS MONITORS
The Model 1012ARC features thirteen front panel status LEDs that
indicate the condition of the modem and communication link. Figure 8
shows the relative front panel positions of the LEDs. Following Figure
8 is a description of each LED’s function.
• The “PWR” LED glows when power is being applied to the
modem card through its mid-plane chassis connection.
• The “TD” and “RD” indicators glow green to show a positive
voltage on the interface, and glow red to show negative voltage or
an idle data state.
• The “CD” indicators glow green to show a positive voltage on the
interface, and glow red to show negative voltage or an idle data
state.
12
HOST FIRST SLAVE SECOND SLAVE
XMT+ RCV+ RCV+
XMT- RCV- RCV-
RCV+ XMT+ XMT+
RCV- XMT- XMT-
Figure 6. Star wiring for Model 1012ARC host and slaves
1 - Blue
2 - Orange
3 - Black
4 - Red
5 - Green
6 - Yellow
7 - Brown
8 - Slate
1 - Blue
2 - Yellow
3 - Green
4 - Red
5 - Black
6 - White
Figure 7. AT&T standard modular color codes
Notice! Any modular twisted pair cable connected to the
Model 1012ARC must be shielded cable, and the outer shield
must be properly terminated to a shielded modular plug on both
ends of the cable.
Figure 8. The Model 1012ARC front panel, showing LED positions
Model 1012ARC
Power
TD
RD
CD
TD
RD
CD
Unit
A
Unit
B
Channel A
Channel B

5.2 POWER-UP
There is no power switch on the Model 1012ARC: Power is
automatically applied to the Model 1012ARC when its card-edge
connector makes contact with the chassis’ mid-plane socket, or when
the chassis’ power supply is turned on. The Model 1012ARC is a “hot
swappable” card—it will not be damaged by plugging it in or removing
it while the rack’s power supply is switched on.
When the local and remote Model 1012ARCs are both powered up and
are passing data normally , the following LED conditions will exist:
• PWR = solid green
• TD & RD = flashing
• CD = solid green
13
APPENDIX A
SPECIFICATIONS
Transmission Format: Asynchronous, half or full duplex
Transmission Line: Two unconditioned twisted pair 19 - 26 AWG
Transmit Level: -6 dBm
Operation: Point-to-point or multipoint
Interfaces: EIA RS-232, CCITT V.24
Data Rates: To 38.4 Kbps
Isolation: Minimum 1500 V RMS transformer coupled
Surge Protection: Silicon Avalanche Diodes
RTS/CTS Delay: 40mS
Connectors: RJ-45 on RS-232 side; RJ-11 or RJ-45 on line side
Power Supply: Rack-mount power supply is switchable between
120V and 240V AC; rack chassis supplies 10V AC to the Model
1012ARC, typical consumption is 700 mW
Internal Interface: Connection to the Model 1000R16 rack chassis
via 50 pin male card edge
Fuse: 400mA for 120V applications; 200mA for 240V applications
Temperature Range: 0-50°C (32-122°F)
Altitude: 0-15,000 feet
Humidity: Up to 95% non-condensing
Dimensions: 0.95”w x 3.1”h x 5.4”l
14

APPENDIX B
CABLE RECOMMENDATIONS
The Patton Model 1012ARC operates at frequencies of 20kHz or
less and has been performance tested by Patton technicians using
twisted-pair cable with the following characteristics:
Wire Gauge Capacitance Resistance
19 AWG 83nf/mi or 15.72 pf/ft. .0163 Ohms/ft.
22 AWG 83nf/mi or 15.72 pf/ft. .0326 Ohms/ft.
24 AWG 83nf/mi or 15.72 pf/ft. .05165 Ohms/ft.
Using or simulating cable with the above characteristics, the
following data rate/distance results were obtained by Patton during
bench tests:
Data Rate (Bps) Gauge (AWG) / Distance (Mi)
19 24 26
Up to 38,400 6.0 3.5 2.0
To gain optimum performance from the Model 1012ARC, please
keep the following guidelines in mind:
•
Always use twisted pair wire—this is not an option.
• Use twisted pair wire with a capacitance of 20pf/ft or less.
• Avoid twisted pair wire thinner than 26 AWG (i.e. avoid AWG
numbers higher AWG numbers than 26)
• Use of twisted pair with a resistance greater than the above
specifications may cause a reduction in maximum distance
obtainable. Functionality should not be affected.
• Many environmental factors can affect the maximum
distances obtainable at a particular site. Use the above
data rate/distance table as a general guideline only.
15
APPENDIX C
FACTORY REPLACEMENT PARTS
The Patton Model 1012ARC rack system features interchangeable
rear cards, power cords/fuses for international various operating
environments and other user-replaceable parts. Model numbers and
descriptions for these parts are listed below:
Patton Model # Description
1000RPEM..........................120/240V Rear Power Entry Module
1000RPSM-2.......................120/240V Front Power Supply Module
1000RPEM-DC ...................DC Rear Power Entry Module
1000RPSM-48A..................48V Front Power Supply Module
1000RPEM-V......................120/240V CE Compliant Rear Power
Entry Module
1000RPSM-V......................120/240V CE Compliant Front Power
Supply Module
0805US...............................American Power Cord
0805EUR.............................European Power Cord CEE 7
0805UK...............................United Kingdom Power Cord
0805AUS.............................Australia/New Zealand Power Cord
0805DEN.............................Denmark Power Cord
0805FR ...............................France/Belgium Power Cord
0805IN.................................India Power Cord
0805IS.................................Israel Power Cord
0805JAP..............................Japan Power Cord
0805SW ..............................Switzerland Power Cord
0516FPB1...........................Single Width Blank Front Panel
0516FPB4...........................4-Wide Blank Front Panel
0516RPB1...........................Single Width Blank Rear Panel
0516RPB4...........................4-Wide Blank Rear Panel
0821R4................................400 mA Fuse (5x20mm)
Littlefuse 239.400 or equivalent
0821R2................................200 mA Fuse (5x20mm)
Littlefuse 239.200 or equivalent
056S1..................................Set of 16 #4 pan head screws/washers
16

APPENDIX D
INTERFACE SETTINGS
PATTON MODULAR INTERFACE - 8/10 Wire RJ-45
Contact Number Circuit Description
1 N/A Not Used
2 125 DSR
3 109 Received Line Signal Indicator
4 108 / 2 DTE Ready
5 102 Signal Common
6 104 Received Data
7 103 Transmitted Data
8 106 Clear to Send
9 105 / 133 Request to Send / Ready for Receiving
10 N/A Not Used
Pins 2-9 conform to the EIA/TIA-561 eight position non-synchronous interface standard.
17
APPENDIX E
BLOCK DIAGRAM
Copyright ©
Patton Electronics Company
All Rights Reserved
18
