Patton SmartNode 5480 Series User manual

SmartNode™ 5480 & 5490 Series
Enterprise Session Border Router, IAD
User Manual
Sales Office: [phone]
Technical Support: [phone]
E-mail: [e-mail]
WWW: www.patton.com
Part Number: 07MSN5480-90-UM, Rev. A
Revised: May 29, 2013
Important
This is a Class A device and is not intended for use in a residential environment.
If a copper module is used, it may void the CE Certification. This product is intended for Fiber SFP modules only.
Start Installation
For Quick

Patton Electronics Company, Inc.
7622 Rickenbacker Drive
Gaithersburg, MD 20879 USA
Tel: [phone]
Fax: [phone]
Support: [phone]
Web: www.patton.com
E-mail: [email protected]
Trademark Statement
The terms SmartNode and SmartWare are trademarks of Patton Electronics Company.
All other trademarks presented in this document are the property of their
respective owners.
Copyright © 2013, Patton Electronics Company. All rights reserved.
The information in this document is subject to change without notice. Patton Elec-
tronics assumes no liability for errors that may appear in this document.
Important Information
To use virtual private network (VPN) and/or AES/DES/3DES encryption capabilities
with the SmartNode 5480 and 5490 Series, you may need to purchase additional
licenses, hardware, software, network connection, and/or service. Contact sales@pat-
ton.com or [phone] for assistance.
Warranty Information
The software described in this document is furnished under a license and may be used
or copied only in accordance with the terms of such license. For information about the
license, see Appendix F, "End User License Agreement" on page 56 or go to
www.patton.com.
Patton Electronics warrants all SmartNode components to be free from defects, and
will—at our option—repair or replace the product should it fail within one year from
the first date of the shipment.
This warranty is limited to defects in workmanship or materials, and does not cover
customer damage, abuse or unauthorized modification. If the product fails to perform
as warranted, your sole recourse shall be repair or replacement as described above.
Under no condition shall Patton Electronics be liable for any damages incurred by the
use of this product. These damages include, but are not limited to, the following: lost
profits, lost savings and incidental or consequential damages arising from the use of or
inability to use this product. Patton Electronics specifically disclaims all other warran-
ties, expressed or implied, and the installation or use of this product shall be deemed
an acceptance of these terms by the user.

3
Summary Table of Contents
1General Information ......................................................................................................................................... 13
2Applications Overview ...................................................................................................................................... 22
3SmartNode Installation..................................................................................................................................... 24
4Initial Configuration......................................................................................................................................... 29
5Contacting Patton for Assistance....................................................................................................................... 34
ACompliance Information .................................................................................................................................. 37
BSpecifications ................................................................................................................................................... 41
CCabling ............................................................................................................................................................ 46
DPort Pin-outs .................................................................................................................................................... 49
ESmartNode 5480 and 5490 Series Factory Configuration ................................................................................ 53
FEnd User License Agreement ............................................................................................................................ 56

4
Table of Contents
Summary Table of Contents .............................................................................................................................. 3
Table of Contents .............................................................................................................................................. 4
List of Figures .................................................................................................................................................... 7
List of Tables ..................................................................................................................................................... 8
About This Guide .............................................................................................................................................. 9
Audience................................................................................................................................................................. 9
Structure................................................................................................................................................................. 9
Precautions ........................................................................................................................................................... 10
Safety when working with electricity ...............................................................................................................11
General observations .......................................................................................................................................12
Typographical Conventions Used in this Document ............................................................................................ 12
General conventions .......................................................................................................................................12
1General Information ......................................................................................................................................... 13
SmartNode 5480 and 5490 Series Overview..........................................................................................................14
SN5480 Series Model Codes ...........................................................................................................................15
SN5490 Series Model Codes ...........................................................................................................................15
CodesSmartNode 5480 and 5490 Series Rear Panels.............................................................................................16
SmartNode 5480 Rear Panel ...........................................................................................................................16
SmartNode 5490 Rear Panel ...........................................................................................................................17
SmartNode 5480 and 5490 Series Front Panels.....................................................................................................19
SmartNode 5480 Front Panel .........................................................................................................................19
SmartNode 5490 Front Panel .........................................................................................................................20
2Applications Overview ...................................................................................................................................... 22
Introduction..........................................................................................................................................................23
Typical Application ...............................................................................................................................................23
3SmartNode Installation..................................................................................................................................... 24
Planning the Installation........................................................................................................................................25
Site log ............................................................................................................................................................25
Network information ......................................................................................................................................25
Network Diagram ...........................................................................................................................................25
IP related information .....................................................................................................................................25
Software tools .................................................................................................................................................26
AC Power Mains .............................................................................................................................................26
Location and mounting requirements .............................................................................................................26
Installing the SmartNode.......................................................................................................................................26
Placing the SmartNode ...................................................................................................................................26
Installing cables ...............................................................................................................................................26
Connecting the 10/100/1000Base-T Ethernet LAN and WAN cables ......................................................27
Installation cable requirements for the DSL WAN cable (SN5490 only) ...................................................27

5
SmartNode 5480 & 5490 User Manual Table of Contents
Connecting the SmartNode’s DSL or Fiber port (SN5490 only) ...............................................................27
Connecting the power supply ....................................................................................................................28
Internal AC Power Supply ..................................................................................................................28
4Initial Configuration......................................................................................................................................... 29
Introduction..........................................................................................................................................................30
1. Connecting the SmartNode to your Laptop PC ................................................................................................30
2. Configuring the Desired IP Address ..................................................................................................................31
Factory-default IP settings ...............................................................................................................................31
Login ..............................................................................................................................................................31
Changing the WAN IP address .......................................................................................................................31
3. Connecting the SmartNode to the Network......................................................................................................32
4. Loading the Configuration (optional)................................................................................................................33
Additional Information .........................................................................................................................................33
5Contacting Patton for Assistance....................................................................................................................... 34
Introduction..........................................................................................................................................................35
Contact Information .............................................................................................................................................35
Patton support headquarters in the USA .........................................................................................................35
Alternate Patton support for Europe, Middle East, and Africa (EMEA) ..........................................................35
Warranty Service and Returned Merchandise Authorizations (RMAs)...................................................................35
Warranty coverage ..........................................................................................................................................35
Out-of-warranty service .............................................................................................................................36
Returns for credit ......................................................................................................................................36
Return for credit policy .............................................................................................................................36
RMA numbers ................................................................................................................................................36
Shipping instructions ................................................................................................................................36
ACompliance Information .................................................................................................................................. 37
Compliance ...........................................................................................................................................................38
EMC ...............................................................................................................................................................38
Safety ..............................................................................................................................................................38
PSTN Regulatory ............................................................................................................................................38
FCC Part 68 (ACTA) Statement ...........................................................................................................................39
Industry Canada Notice ........................................................................................................................................39
CE Declaration of Conformity ..............................................................................................................................40
Authorized European Representative .....................................................................................................................40
BSpecifications ................................................................................................................................................... 41
Data Connectivity .................................................................................................................................................42
Voice Processing (signaling dependent) .................................................................................................................42
Fax and Modem Support.......................................................................................................................................42
Voice Signaling......................................................................................................................................................42
IP Services .............................................................................................................................................................43
Management .........................................................................................................................................................43
System...................................................................................................................................................................43

6
SmartNode 5480 & 5490 User Manual Table of Contents
Physical .................................................................................................................................................................43
WAN Daughter Card (if applicable)......................................................................................................................44
Identification of the SmartNode Devices via SNMP..............................................................................................45
CCabling ............................................................................................................................................................ 46
Introduction..........................................................................................................................................................47
Console .................................................................................................................................................................47
Ethernet ................................................................................................................................................................48
DPort Pin-outs .................................................................................................................................................... 49
Introduction..........................................................................................................................................................50
Console Port..........................................................................................................................................................50
Ethernet ................................................................................................................................................................50
G.SHDSL Port......................................................................................................................................................51
EFM Port ..............................................................................................................................................................52
Fiber Port ..............................................................................................................................................................52
ESmartNode 5480 and 5490 Series Factory Configuration ................................................................................ 53
Introduction..........................................................................................................................................................54
FEnd User License Agreement ............................................................................................................................ 56
End User License Agreement .................................................................................................................................57
1. Definitions ..................................................................................................................................................57
2. Title ............................................................................................................................................................57
3. Term ...........................................................................................................................................................57
4. Grant of License ..........................................................................................................................................57
5. Warranty ....................................................................................................................................................57
6. Termination ................................................................................................................................................58
7. Other licenses .............................................................................................................................................58
8. SmartWare licenses .....................................................................................................................................58

7
List of Figures
1 SmartNode 5480 (left) and SmartNode 5490 (right) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2 SN5480 rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3 SN5490 rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4 SmartNode 5480 Series front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5 SN5490 rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6 SN5480 typical application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
7 SN5490 typical application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
8 SN5480/5490 rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
9 SN5480/5490 Power LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
10 Connecting the SmartNode to your laptop PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
11 Connecting the SmartNode to the network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
12 Connecting a serial terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
13 Typical Ethernet straight-through cable diagram for 10/100Base-T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
14 Typical Ethernet straight-through cable diagram for 1000Base-T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
15 EIA-561 (RJ-45 8-pin) port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

8
List of Tables
1 General conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2 SmartNode 5480 Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3 SmartNode 5490 Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4 SN5480 rear panel ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5 SN 5490 rear panel ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6 SN5480 Front panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7 SN5490 Front panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
8 Sample site log entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
9 Factory default IP address and network mask configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
10 G.SHDSL Daughter Card Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
11 SmartNode Models and their Unique sysObjectID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
12 RJ45 socket 10/100Base-T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
13 RJ45 socket 1000Base-T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
14 RJ-45 connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
15 RJ-45 connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

9
About This Guide
This guide describes the SmartNode 5480 and 5490 Series hardware, installation and basic configuration. For
detailed software configuration information refer to the SmartWare Software Configuration Guide and the avail-
able Configuration Notes.
Audience
This guide is intended for the following users:
•Operators
•Installers
•Maintenance technicians
Structure
This guide contains the following chapters and appendices:
•Chapter 1 on page 13 provides information about SmartNode features and capabilities
•Chapter 2 on page 22 contains an overview describing SmartNode operation and applications
•Chapter 3 on page 24 provides hardware installation procedures
•Chapter 4 on page 29 provides quick-start procedures for configuring the SmartNode
•Chapter 5 on page 34 contains information on contacting Patton technical support for assistance
•Appendix A on page 37 contains compliance information for the SmartNode
•Appendix B on page 41 contains specifications for the SmartNodes
•Appendix C on page 46 provides cable recommendations
•Appendix D on page 49 describes the SmartNode’s ports and pin-outs
•Appendix E on page 53 lists the factory configuration settings for the SmartNode 5480 and 5490 Series
•Appendix F on page 56 provides license information that describes acceptable usage of the software pro-
vided with the SmartNode 5480 and 5490 Series
For best results, read the contents of this guide before you install the SmartNode.

10
SmartNode 5480 & 5490 User Manual
Precautions
Notes, cautions, and warnings, which have the following meanings, are used throughout this guide to help you
become aware of potential problems. Warnings are intended to prevent safety hazards that could result in per-
sonal injury. Cautions are intended to prevent situations that could result in property damage or
impaired functioning.
1ote A note presents additional information or interesting sidelights.
The alert symbol and IMPORTANT heading calls attention to
important information.
The alert symbol and CAUTION heading indicate a potential haz-
ard. Strictly follow the instructions to avoid property damage.
The shock hazard symbol and CAUTION heading indicate a
potential electric shock hazard. Strictly follow the instructions to
avoid property damage caused by electric shock.
The alert symbol and WARNING heading indicate a potential safety hazard.
Strictly follow the warning instructions to avoid personal injury.
The shock hazard symbol and WARNING heading indicate a potential electric
shock hazard. Strictly follow the warning instructions to avoid injury caused
by electric shock.
I
MPORTAN
T
CAUTIO
N
C
AUTIO
N
WARNIN
G
WARNIN
G

11
SmartNode 5480 & 5490 User Manual
Safety When Working with Electricity
•Do not open the device when the power cord is connected. For systems
without a power switch and without an external power adapter, line volt-
ages are present within the device when the power cord is connected.
•For devices with an external power adapter, the power adapter shall be a
listed Limited Power Source The mains outlet that is utilized to power the
device shall be within 10 feet (3 meters) of the device, shall be easily
accessible, and protected by a circuit breaker in compliance with local regu-
latory requirements.
•For AC powered devices, ensure that the power cable used meets all appli-
cable standards for the country in which it is to be installed.
•For AC powered devices which have 3 conductor power plugs (L1, L2 &
GND or Hot, Neutral & Safety/Protective Ground), the wall outlet (or
socket) must have an earth ground.
•For DC powered devices, ensure that the interconnecting cables are rated
for proper voltage, current, anticipated temperature, flammability, and
mechanical serviceability.
•WAN, LAN & PSTN ports (connections) may have hazardous voltages
present regardless of whether the device is powered ON or OFF. PSTN
relates to interfaces such as telephone lines, FXS, FXO, DSL, xDSL, T1, E1,
ISDN, Voice, etc. These are known as “hazardous network voltages” and
to avoid electric shock use caution when working near these ports. When
disconnecting cables for these ports, detach the far end connection first.
•Do not work on the device or connect or disconnect cables during periods of
lightning activity
This device is NOT intended nor approved for connection to the PSTN. It is
intended only for connection to customer premise equipment.
This device contains no user serviceable parts. This device can only be
repaired by qualified service personnel.
In accordance with the requirements of council directive 2002/
96/EC on Waste of Electrical and Electronic Equipment (WEEE),
ensure that at end-of-life you separate this product from other
waste and scrap and deliver to the WEEE collection system in
your country for recycling.
WARNIN
G
WARNIN
G
WARNIN
G

12
SmartNode 5480 & 5490 User Manual
General Observations
•Clean the case with a soft slightly moist anti-static cloth
•Place the unit on a flat surface and ensure free air circulation
•Avoid exposing the unit to direct sunlight and other heat sources
•Protect the unit from moisture, vapors, and corrosive liquids
Typographical Conventions Used in this Document
This section describes the typographical conventions and terms used in this guide.
General Conventions
The procedures described in this manual use the following text conventions:
Always follow ESD prevention procedures when removing and
replacing cards.
Wear an ESD-preventive wrist strap, ensuring that it makes good
skin contact. Connect the clip to an unpainted surface of the chas-
sis frame to safely channel unwanted ESD voltages to ground.
To properly guard against ESD damage and shocks, the wrist
strap and cord must operate effectively. If no wrist strap is avail-
able, ground yourself by touching the metal part of the chassis.
Table 1. General conventions
Convention Meaning
Garamond blue type Indicates a cross-reference hyperlink that points to a figure, graphic, table, or sec-
tion heading. Clicking on the hyperlink jumps you to the reference. When you
have finished reviewing the reference, click on the Go to Previous View
button in the Adobe® Acrobat® Reader toolbar to return to your starting point.
Futura bold type Commands and keywords are in boldface font.
Futura bold-italic type Parts of commands, which are related to elements already named by the user, are
in boldface italic font.
Italicized Futura type Variables for which you supply values are in italic font
Futura type Indicates the names of fields or windows.
Garamond bold type Indicates the names of command buttons that execute an action.
< > Angle brackets indicate function and keyboard keys, such as <SHIFT>, <CTRL>,
<C>, and so on.
[ ] Elements in square brackets are optional.
{a | b | c} Alternative but required keywords are grouped in braces ({ }) and are separated
by vertical bars ( | )
screen Terminal sessions and information the system displays are in screen font.
node The leading IP address or nodename of a SmartNode is substituted with node in
boldface italic font.
SN The leading SN on a command line represents the nodename of the SmartNode
#An hash sign at the beginning of a line indicates a comment line.
CAUTIO
N

13
Chapter 1 General Information
Chapter contents
SmartNode 5480 and 5490 Series Overview..........................................................................................................14
SN5480 Series Model Codes ...........................................................................................................................15
SN5490 Series Model Codes ...........................................................................................................................15
CodesSmartNode 5480 and 5490 Series Rear Panels.............................................................................................16
SmartNode 5480 Rear Panel ...........................................................................................................................16
SmartNode 5490 Rear Panel ...........................................................................................................................17
SmartNode 5480 and 5490 Series Front Panels.....................................................................................................19
SmartNode 5480 Front Panel .........................................................................................................................19
SmartNode 5490 Front Panel .........................................................................................................................20

SmartNode 5480 and 5490 Series Overview 14
SmartNode 5480 & 5490 User Manual 1• General Information
SmartNode 5480 and 5490 Series Overview
The SmartNode 5480 and 5490 Series Enterprise Session Border Router enables Universal SIP Trunking and
provides a single Integrated Access Device with features like IP Routing, Redundancy, Security and a SIP regis-
trar for survivability. In addition, the SN5480/5490 enables Transcoding between two networks to most opti-
mally support the bandwidth requirements. It is an essential device to connect Enterprise IP telephony to cost-
effective SIP Trunking through the limited WAN access bandwidth. The SN5480/5490 connects to the Enter-
prise’s LAN to an Internet telephony service provider (ITSP), creating a single conduit for multimedia compo-
nents including voice, video and data.
Figure 1. SmartNode 5480 (left) and SmartNode 5490 (right)
The SmartNode 5480 and 5490 Series Enterprise Session Border Router performs the following major func-
tions:
•Enterprise Session Border Router with Transcoding: Enables up to 64 transcoding sessions between codecs
•Secure Enterprise: Enable VPN, NAT/NAPT, Access Control Lists with Downstream QoS to ensure the
most efficient use of your bandwidth
•IP Routing: RIP v1/v2, VRRP, policy based routing, loopback interface
•Universal Interface support for WAN: Support for G.SHDSL, PRI, EFM, Fiber and Gigabit Ethernet
interfaces for your WAN needs
•VPN Tunnels: Standard IPsec with AH and ESP ensures maximum protection when traversing unsecured
networks
•Configurable Security Profiles: Built-in IP address and IP port filtering, ACLs and DoS attack detection
creates a comprehensive security environment.

SmartNode 5480 and 5490 Series Overview 15
SmartNode 5480 & 5490 User Manual 1• General Information
SN5480 Series Model Codes
The SmartNode 5480 Series consists of several models. They differ in the number of transcoding sessions they
can support. All models come equipped with two 10/100/1000 Base-T Ethernet ports.
SN5490 Series Model Codes
The SmartNode 5490 Series consists of several models. They differ in the number of transcoding sessions they
can support and G.SHDSL, X.21, EFM or Fiber SFP options. All models come equipped with two
10/100/1000 Base-T Ethernet ports.
Table 2. SmartNode 5480 Models
Model Transcoding Sessions
SN5480/0P/EUI N/A
SN5480/16P/EUI 16
SN5480/32P/EUI 32
SN5480/64P/EUI 64
Table 3. SmartNode 5490 Models
Model Transcoding
Sessions
G.SHDSL
Port X.21 EFM 2 Pair
EFM 4
Pair Fiber SFP
SN5490/32P2GS/EUI 32 9----
SN5490/32PF/EUI 32 -- - 9
SN5490/32PD/EUI 32 -9---
SN5490/32P2G/EUI 32 -9- -
SN5490/32P4G/EUI 32 -- - 9-
SN5490/64P2GS/EUI 64 9----
SN5490/64P2G/EUI 64 --9- -
SN5490/64P4G/EUI 64 -- - 9-
SN5490/64PF/EUI 64 ----9

CodesSmartNode 5480 and 5490 Series Rear Panels 16
SmartNode 5480 & 5490 User Manual 1• General Information
CodesSmartNode 5480 and 5490 Series Rear Panels
SmartNode 5480 Rear Panel
The SmartNode 5480 Series rear panel ports are described in Table 4.
Figure 2. SN5480 rear panel
Table 4. SN5480 rear panel ports
Port Description
WAN ETH 0/0 Auto-MDX Gigabit-Ethernet port, RJ-45 (see Figure 2), connects the unit to an Ethernet
WAN device (for example, a cable modem, DSL modem, or fiber modem). Note:
Only full duplex modes are supported.
LAN ETH 0/1 Auto-MDX Gigabit-Ethernet port, RJ-45 (see Figure 2), connect the unit to an Ethernet
LAN (for example, a PC, printer, or wireless bridge). Note: Only full duplex modes
are supported.
Console Used for service and maintenance, the Console port (see Figure 2), an RS-232 RJ-45
connector, connects the product to a serial terminal such as a PC or ASCII terminal
(also called a dumb terminal).
12V DC, 1.0A Electricity supply socket. (See Figure 2.)
Reset The reset button (see Figure 2) has three functions:
•Restart the unit with the current startup configuration—Press (for less than 1 second)
and release the Reset button to restart the unit with the current startup configuration.
•Restart the unit with factory default configuration—Press the Reset button for
5 seconds until the Power LED (see Figure 4 on page 19) starts blinking to restart the
unit with factory default configuration.
•Restart the unit in bootloader mode (to be used only by trained SmartNode techni-
cians)—Starting with the unit powered off, press and hold the Reset button as you
apply power to the unit. Release the Reset button when the Power LED starts blink-
ing so the unit will enter bootloader mode.

CodesSmartNode 5480 and 5490 Series Rear Panels 17
SmartNode 5480 & 5490 User Manual 1• General Information
SmartNode 5490 Rear Panel
The SmartNode 5480 Series rear panel ports are described in Table 5.
Figure 3. SN5490 rear panel
Table 5. SN 5490 rear panel ports
Port Description
WAN ETH 0/0 Auto-MDX Gigabit-Ethernet port, RJ-45 (see Figure 2), connects the unit to an Ethernet
WAN device (for example, a cable modem, DSL modem, or fiber modem). Note:
Only full duplex modes are supported.
LAN ETH 0/1 Auto-MDX Gigabit-Ethernet port, RJ-45 (see Figure 2), connect the unit to an Ethernet
LAN (for example, a PC, printer, or wireless bridge). Note: Only full duplex modes
are supported.

CodesSmartNode 5480 and 5490 Series Rear Panels 18
SmartNode 5480 & 5490 User Manual 1• General Information
Expansion port
G.SHDSL, ADSL,
EFM, X.21 or SFP
The G.SHDSL, ADSL, EFM, X.21 or SFP LEDs are located on either side of the DSL
port. ACT (when lit or blinking) shows Activity, and LINK (when lit) shows that the
DSL port is connected.
1ote EFM Link Light is Different:
There are two colors in the Link light on the EFM Daughterboard. Red
and Green, the Green will be showing anytime ANY Link is up and traf-
fic can flow. The Red Link will then blink to signify specific pairs that are
training/not up. (Please note that if the device is configured to use less
than available pairs the non-provisioned link will not be reported as
down.
Link (Green)OFF: All pairs are DOWN, and traffic will not flow
Link (Green) ON: At least on pair is UP, and traffic will flow
Link (Red): This LED will blink with a rotating pattern to indicate ports
which are still DOWN.
1 BLINK - Pair 1
2 BLINKS - Pair 2
3 BLINKS - Pair 3
4 BLINKS - Pair 4
Console Used for service and maintenance, the Console port (see Figure 2), an RS-232 RJ-45
connector, connects the product to a serial terminal such as a PC or ASCII terminal
(also called a dumb terminal).
12V DC, 1.0A Electricity supply socket. (See Figure 2.)
Reset The reset button (see Figure 2) has three functions:
•Restart the unit with the current startup configuration—Press (for less than 1 second)
and release the Reset button to restart the unit with the current startup configuration.
•Restart the unit with factory default configuration—Press the Reset button for
5 seconds until the Power LED (see Figure 4 on page 19) starts blinking to restart the
unit with factory default configuration.
•Restart the unit in bootloader mode (to be used only by trained SmartNode techni-
cians)—Starting with the unit powered off, press and hold the Reset button as you
apply power to the unit. Release the Reset button when the Power LED starts blink-
ing so the unit will enter bootloader mode.
Table 5. SN 5490 rear panel ports
Port Description

SmartNode 5480 and 5490 Series Front Panels 19
SmartNode 5480 & 5490 User Manual 1• General Information
SmartNode 5480 and 5490 Series Front Panels
SmartNode 5480 Front Panel
Figure 4 shows SmartNode 5480 Series front panel LEDs, the LED definitions are listed in Table 6.
Figure 4. SmartNode 5480 Series front panel
Table 6. SN5480 Front panel LEDs
LED Description
1ote If an error occurs, all LEDs will flash once per second.
Power When lit, indicates power is applied.
Run When lit, the unit is in normal operation. Flashes once per second during
boot (startup).

SmartNode 5480 and 5490 Series Front Panels 20
SmartNode 5480 & 5490 User Manual 1• General Information
SmartNode 5490 Front Panel
Figure 5 shows SmartNode 5480 Series front panel LEDs, the LED definitions are listed in Table 7.
Figure 5. SN5490 rear panel
VoIP Link •On indicates the gateway is registered to an H.323 gatekeeper/SIP server, or, in
the case of direct routing, has at least one active VoIP connection.
•Off indicates the unit is not configured or registered, or has no active direct-
routed VoIP connection.
•Flashing green indicates that the unit is attempting to register or has failed
to register.
Ethernet Link •On when the Ethernet connection on the corresponding port has a
link indication.
Ethernet Speed
10/100
When the Ethernet Link LED is on, then:
•On when the Ethernet is connected to a 100Mb network.
•Off when the Ethernet is connected to a 10Mb network.
Ethernet Speed
1000
•On when the Ethernet is connected to a 1000Mb network.
Ethernet Activity •Flashes when data is received or transmitted at the corresponding Ethernet port.
Table 6. SN5480 Front panel LEDs
LED Description
